ENGLISH

Intended use

Your Black & Decker vacuum cleaner has

been designed to vacuum dry substances.

This product is intended for household

use only.

Safety instructions

 Warning! When using mains-powered

appliances, basic safety precautions,

including the following, should always

be followed to reduce the risk of ﬁre,

electric shock, personal injury and

material damage.

 Read all of this manual carefully

before using the appliance.

 The intended use is described in this

manual. The use of any accessory or

attachment or the performance of

any operation with this appliance

other than those recommended in

this instruction manual may present a

risk of personal injury.

 Retain this manual for future reference.

Using your appliance

 Make sure that the appliance is

switched off before connecting to or

disconnecting from the power supply.

 Always take care when using the

appliance.

 Do not use the appliance outdoors.

 Never pull the power supply cord to

disconnect the plug from the socket.

Keep the power supply cord away

from heat, oil and sharp edges.

 If the power supply cord is damaged

during use, disconnect the appliance

from the power supply immediately.

Do not touch the power supply cord

before disconnecting from the power

supply.

 Disconnect the appliance from the

power supply when not in use, before

ﬁtting or removing parts and before

cleaning.

Safety of others

 Do not allow children or any person

unfamiliar with these instructions to

use the appliance.

 Do not allow children or animals to

come near the work area or to touch

the appliance or power supply cord.

Close supervision is necessary when

the appliance is used near children.

 This appliance is not intended for use

by persons (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience

and knowledge, unless they have

been given supervision or instruction

concerning use of the appliance by a

person responsible for their safety.

After use

 Switch off and remove the plug from

the socket before leaving the

appliance unattended and before

changing, cleaning or inspecting any

parts of the appliance.

 When not in use, the appliance

should be stored in a dry place.

Children should not have access to

stored appliances.

Inspection and repairs

 Before use, check the appliance for

damaged or defective parts. Check

for breakage of parts, damage to

switches and any other conditions

that may affect its operation.

 Do not use the appliance if any part

is damaged or defective.

 Have any damaged or defective parts

repaired or replaced by an authorised

repair agent.

 Before use, check the power supply

cord for signs of damage, ageing and

wear.

 Do not use the appliance if the power

supply cord or mains plug is

damaged or defective.

 If the power supply cord or mains

plug is damaged or defective it must

be repaired by an authorised repair

agent in order to avoid a hazard.

Do not cut the power supply cord and

do not attempt to repair it yourself.

 Never attempt to remove or replace

any parts other than those speciﬁed

in this manual.

ENGLISH

Electrical safety

# This tool is double insulated;

therefore no earth wire is

required. Always check that the

power supply corresponds to

the voltage on the rating plate.

 If the supply cord is damaged, it must

be replaced by the manufacturer or

an authorised Black & Decker Service

Centre in order to avoid a hazard.

Additional safety instructions for

vacuum cleaners

 Before use, always make sure that

the ﬁlters are correctly seated. Do not

use the appliance without all ﬁlters in

place.

 Do not carry the appliance at the

container handle.

 Do not use the appliance to pick up

liquids.

 Do not use the appliance to pick up

any materials that could catch ﬁre.

 Do not use the appliance near water.

Do not immerse the appliance in water.

 Keep the motor draught away from

your eyes and face.

 Keep children and animals at a safe

distance when using this appliance.

 Always work from bottom up when

using the appliance on stairs, and

keep the appliance at least a stair

below your working position.

 Always be aware of the position of

the power cord and hose while using

the appliance.

 Do not use the appliance without the

suction head or another suitable

accessory mounted to the tube.

 After use, fully rewind the power cord

and store the appliance in a tidy

manner.

 Keep your hair, clothing and gloves

away from moving parts.

 Do not use damaged accessories.

 Use only Black & Decker accessories.

Features

This appliance includes some or all of the

following features:

1. On/off switch

2. Cord rewind button

3. Speed control selector

4. Handle

5. Hose

6. Airﬂow control switch

7. Extension tube

8. Suction head

9. Dust container

10. Wheels

11. Bin full indicator

In addition, this appliance is supplied with

some or all of the following accessories

(ﬁg. A):

12. Crevice tool / Brush tool

13. Upholstery brush

14. Parquet ﬂoor head (VB2010P)

Assembly

Connecting the hose (ﬁg. B)

 Insert the hose connector (15) into

the inlet (16) of the appliance.

 Push the hose until the release

buttons (17) click into place.

 To disconnect the hose, press the

release buttons and pull out the hose.

Connecting the tube (ﬁg. C)

 Push the hose nozzle (18) into the

tube (7).

 To remove the tube, pull the hose out

of the tube.

Mounting the suction head (ﬁg. D)

The suction head (8) allows for

vacuuming on carpet and hard surfaces

(e.g. laminate and tiles).

 Push the tube (7) into the head (8).

 To remove the head, pull the tube out

of the head.

VB2010P - Mounting the parquet

ﬂoor head (ﬁg. D)

The parquet ﬂoor head (14) allows for

vacuuming on wooden and polished

surfaces.

 Push the tube (7) into the head (14).

 To remove the head, pull the tube out

of the head.

ENGLISH

Mounting accessories (ﬁg. D)

The crevice tool (12) allows for

vacuuming in narrow and hard-to-reach

places. The brush tool (12) allows for

vacuuming on furniture, blinds, curtains,

windows and stairs. The upholstery brush

(13) allows for vacuuming furniture.

The accessories can be mounted on both

the hose (5) and the tube (7).

 Push the accessory onto the hose

nozzle (18) or the tube (7).

 To remove an accessory, pull the

accessory from the hose nozzle or

the tube.

Selecting the crevice tool or

brush tool (ﬁg. E)

 To use the crevice tool, move the

brush part (19) against the direction

of the arrow.

 To use the brush tool, move the

brush part (19) in the direction of the

arrow.

Use

Unwinding and rewinding the

power cord

The cord rewind button (2) can be

operated by hand or foot.

 Pull a sufﬁcient length of cord from

the back of the appliance.

 After use, press the cord rewind

button to retract the cord into the unit.

Manually guide the cord to ensure it

does not swing back. Ensure the plug

is correctly located.

Adjusting the tube length (ﬁg. F)

The extension tube (7) can be adjusted

as follows:

 Push the knob (20) and slide the tube

to the desired length.

 Release the knob.

Adjusting the suction head (ﬁg. D)

 For vacuuming on carpets, switch the

brush actuator (21) into the up

position.

 For vacuuming on laminates, tiles,

etc., switch the brush actuator into

the down position.

Switching on and off

The on/off switch (1) can be operated by

hand or foot.

 To switch the appliance on, press the

on/off switch (1).

 To switch the appliance off, press the

on/off switch again.

Setting the suction force

The speed control selector (3) allows for

a precise setting of the suction force.

For vacuuming on a hard surface

(e.g. ﬂoors), choose a high speed setting.

For vacuuming on soft surfaces

(e.g. upholstery), choose a low speed

setting.

 Slide the speed control selector to

the desired setting.

Adjusting the airﬂow (ﬁg. G)

Move the airﬂow control switch (6) to

adjust the airﬂow as desired.

Vacuuming

 When operating the appliance, make

sure that the hose is not trapped,

twisted or blocked.

 In case of overheating, a cut-out will

operate and the appliance will

automatically stop.

 If the appliance stops operating,

unplug the appliance and allow it to

cool for 2-3 hours before continuing.

Ensure the ﬁlters are cleaned and the

unit is blockage free before switching

back on.

Hints for optimum use

 When vacuuming stairs, always start

at the bottom and work your way up.

Position the appliance on the ﬂoor

and do the stairs until halfway. Then

carry the appliance to a stable

position which is at least one stair

below your working position, and do

the top half of the stairs.

Carrying the appliance

During use the appliance can be carried

using the handle (4).

ENGLISH

Temporarily parking the suction

head (ﬁg. H)

 Use the park position (22) for a

temporary parking of the suction head.

Storing the appliance (ﬁg. I)

Warning! When storing the appliance,

switch the appliance off and unplug it.

 Make sure that the cord is fully

rewound.

 Place the appliance in an upright

position.

 Park the tube in the park position (23).

 Store the appliance in a dry location.

Maintenance

Your Black & Decker appliance has been

designed to operate over a long period of

time with a minimum of maintenance.

Continuous satisfactory operation

depends upon proper appliance care and

regular cleaning.

Warning! Before performing any

maintenance or cleaning on the

appliance, unplug the appliance.

 Regularly clean the ventilation slots

in your appliance using a soft brush

or dry cloth.

 Regularly clean the motor housing

using a damp cloth. Do not use any

abrasive or solvent-based cleaner.

Emptying the dust container

(ﬁg. J & K)

The dust container (9) must be emptied

when the maximum mark is reached or

the bin full indicator (11) changes from

green to red.

 Remove the hose.

 Press the release button (24).

 Hold the dust container at the handle

(25). Slide the container (9) out of the

appliance.

 Hold the container over a waste bin.

 Press the release button (26) to open

the container (ﬁg. K). Empty the dust

container as necessary.

 Close the base (27) by moving it

upward until the lock locates in the

latch.

 Re-insert the container into the

appliance until it locks into place.

Cleaning (ﬁg. J - N)

Warning! Before cleaning and

maintenance, switch the appliance off

and unplug it.

 From time to time wipe the appliance

with a damp cloth. Do not use any

abrasive or solvent-based cleaner.

Do not immerse the appliance in water.

The appliance is ﬁtted with 5 ﬁlters.

Four of these are accessible to the user

and are replaceable. The ﬁfth ﬁlter is

internal to protect the motor. The four

ﬁlters are: pre-ﬁlter cover, main ﬁlter, bin

ﬁlter and exhaust ﬁlter.

Cleaning the dust container ﬁlter

(ﬁg. J - M)

The dust container ﬁlter prevents dust

and dirt from entering the motor housing.

The ﬁlter is re-usable. There are two

levels of ﬁltration: pre-ﬁlter and main

ﬁlter. To maintain efﬁcient suction

performance, the ﬁlter should be cleaned

every week, or whenever suction

performance is noticeably reduced. The

appliance is ﬁtted with a bypass valve.

When the ﬁlter is clogged, the operation

of the valve is audible. This is normal and

does not indicate a problem. Switch off

the appliance and remove the plug from

the socket before cleaning the ﬁlters.

 Remove the container (9) from the

appliance (ﬁg. J).

 Empty the container (ﬁg. K).

 Remove the cartridge (28) from the

container by turning it clockwise (ﬁg. L).

 Remove the pre-ﬁlter cover (29) from

the main ﬁlter (30).

 Shake off excess dust by tapping the

ﬁlter into a dustbin.

Warning! Do not brush or use

compressed air to clean the ﬁlter.

 Depending on its condition, rinse the

outside of the ﬁlter with water.

Allow the ﬁlter to dry for 24 hours

before re-inserting it.

Warning! Do not wash the inside of the

ﬁlter.

ENGLISH

 Take out the ﬁlter (31) located right

below the grid and brush off any

loose dust before re-inserting it.

 Slide the pre-ﬁlter cover back over

the main ﬁlter.

 Place the cartridge back in the

container by turning it

counterclockwise.

 Close the container.

 Re-insert the dust container into the

appliance.

Cleaning the exhaust ﬁlter (ﬁg. N)

The exhaust ﬁlter gives a further ﬁltration

level. The ﬁlter is re-usable and should

be cleaned regularly.

 Remove the lid (32).

 Take the exhaust ﬁlter (33) out.

 Brush any loose dust off the ﬁlter.

 Re-insert the ﬁlter.

 Close the lid.

Replacing the ﬁlters (ﬁg. J - N)

The container ﬁlter should be replaced

every 6 to 9 months and whenever worn

or damaged. When replacing the dust

container ﬁlter, the pre-ﬁlter, main motor

ﬁlter and the exhaust ﬁlters have to be

replaced as well. Replacement ﬁlter sets

(all 4 ﬁlters - VBF60-OX) are available

from your Black & Decker dealer.

Replacing the pre-ﬁlter and main

container ﬁlter (ﬁg. J - M)

 Proceed as described above to

replace the ﬁlters.

Replacing the exhaust ﬁlter (ﬁg. N)

 Proceed as described above to

replace the ﬁlter.

Mains plug replacement

(U.K. & Ireland only)

If a new mains plug needs to be ﬁtted:

 Safely dispose of the old plug.

 Connect the brown lead to the live

terminal in the new plug.

 Connect the blue lead to the neutral

terminal.

Warning! No connection is to be made to

the earth terminal. Follow the ﬁtting

instructions supplied with good quality

plugs. Recommended fuse: 13 A.

Protecting the environment

Z Separate collection. This

product must not be disposed

of with normal household

waste.

Should you ﬁnd one day that your

Black & Decker product needs

replacement, or if it is of no further use to

you, do not dispose of it with household

waste. Make this product available for

separate collection.

z Separate collection of used

products and packaging allows

materials to be recycled and

used again. Re-use of recycled

materials helps prevent

environmental pollution and

reduces the demand for raw

materials.

Local regulations may provide for

separate collection of electrical products

from the household, at municipal waste

sites or by the retailer when you

purchase a new product.

Black & Decker provides a facility for the

collection and recycling of Black & Decker

products once they have reached the

end of their working life. To take

advantage of this service please return

your product to any authorised repair

agent who will collect them on our behalf.

You can check the location of your

nearest authorised repair agent by

contacting your local Black & Decker

ofﬁce at the address indicated in this

manual. Alternatively, a list of authorised

Black & Decker repair agents and full

details of our after-sales service and

contacts are available on the Internet at:

www.2helpU.com

ENGLISH

Technical data

VB2000 VB2010P

Voltage V 230 230

Power input W 2,000 2,000

Cable length m 5 5

Container size l 2.5 2.5

Weight kg 6.0 6.2

EC declaration of conformity

VB2000 TYPE1/VB2010P TYPE1

Black & Decker declares that these

products conform to:

89/336/EEC, 73/23/EEC, EN 55014,

EN 61000, EN 60335

Level of sound pressure, measured

according to EN 60704-1: 71 dB(A)

The undersigned is responsible for

compilation of the technical ﬁle and

makes this declaration on behalf

of Black & Decker.

_Kevin Hewitt

Director of Consumer Engineering

Spennymoor, County Durham DL16 6JG,

United Kingdom

30-4-2009

Guarantee

Black & Decker is conﬁdent of the quality

of its products and offers an outstanding

guarantee. This guarantee statement is

in addition to and in no way prejudices

your statutory rights. The guarantee is

valid within the territories of the Member

States of the European Union and the

European Free Trade Area.

If a Black & Decker product becomes

defective due to faulty materials,

workmanship or lack of conformity, within

24 months from the date of purchase,

Black & Decker guarantees to replace

defective parts, repair products subjected

to fair wear and tear or replace such

products to ensure minimum

inconvenience to the customer unless:

 The product has been used for trade,

professional or hire purposes;

 The product has been subjected to

misuse or neglect;

 The product has sustained damage

through foreign objects, substances

or accidents;

 Repairs have been attempted by

persons other than authorised repair

agents or Black & Decker service staff.

To claim on the guarantee, you will need

to submit proof of purchase to the seller

or an authorised repair agent. You can

check the location of your nearest

authorised repair agent by contacting

your local Black & Decker ofﬁce at the

address indicated in this manual.

Alternatively, a list of authorised

Black & Decker repair agents and full

details of our after-sales service and

contacts are available on the Internet at:

www.2helpU.com

Please visit our website

www.blackanddecker.co.uk to register

your new Black & Decker product and to

be kept up to date on new products and

special offers. Further information on the

Black & Decker brand and our range of

products is available at

www.blackanddecker.co.uk

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Black & Decker Staubsauger Handbücher

Black & Decker

Black & Decker CV1205 Bedienungsanleitung

Black & Decker

Black & Decker BDH2400FH Bedienungsanleitung

Black & Decker

Black & Decker HHVK515BP Bedienungsanleitung

Black & Decker

Black & Decker SteamBuster 612736-00 Bedienungsanleitung

Black & Decker

Black & Decker 5145522-00 Bedienungsanleitung

Black & Decker

Black & Decker BDDV31 Bedienungsanleitung

Black & Decker

Black & Decker FLEX HFVAB320JC Bedienungsanleitung

Black & Decker

Black & Decker AV1500LA Bedienungsanleitung

Black & Decker

Black & Decker Dustbuster V1999 Bedienungsanleitung

Black & Decker

Black & Decker HFEJ415JWMF Bedienungsanleitung

Black & Decker

Black & Decker HNVC215BW Bedienungsanleitung

Black & Decker

Black & Decker NVD220BP Bedienungsanleitung

Black & Decker

Black & Decker Powerful Solutions Dustbuster Flexi PD1200 Bedienungsanleitung

Black & Decker

Black & Decker Dustbuster Bedienungsanleitung

Black & Decker

Black & Decker BDWDS20 Bedienungsanleitung

Black & Decker

Black & Decker BDH1800PL Bedienungsanleitung

Black & Decker

Black & Decker PV1200AV Bedienungsanleitung

Black & Decker

Black & Decker BDH1220AV-CA Bedienungsanleitung

Black & Decker

Black & Decker bdh1200fvav Bedienungsanleitung

Black & Decker

Black & Decker Dustbuster AV1210 Bedienungsanleitung

Black & Decker

Black & Decker SVA420B Bedienungsanleitung

Black & Decker

Black & Decker PD1820L Bedienungsanleitung

Black & Decker

Black & Decker HNV115B series Bedienungsanleitung

Black & Decker

Black & Decker EPD1200AVA Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
