Blomberg LSP3579W Bedienungsanleitung

Refrigerator

Instruction of use

LSP3579W

Please read these instructions first before using your

appliance

Thank you for choosing a Beko appliance.

Please take some time to read this user manual before using your appliance,

to ensure you know how to safely operate the controls and functions.

Carefully follow all unpacking and installation instructions to ensure the

appliance is correctly connected and fitted prior to use.

Please write your product model and serial number on the last page of this

user manual, and store in a safe location close to the appliance for easy

future reference.

This user manual may also be applicable for several other models.

Differences between models will be listed.

If you have any questions or concerns, please call our contact centre or find

help and information online at www.beko.co.uk.

Explanation of symbols used throughout this User Manual

- The terminal in the plug is marked with the symbol.

-Important information or useful usage tips.

-Symbol for waste electrical and electronic equipment.

WARNING!

In order to ensure a normal operation of your refrigerating appliance, which uses

a completely environmentally friendly refrigerant the R600a (flammable only

under certain conditions) you must observe the following rules:

•

Do not hinder the free circulation of the air around the appliance.

Do not use mechanical devices in order to accelerate the defrosting,

others than the ones recommended by the manufacturer.

Do not destroy the refrigerating circuit.

Do not use electric appliances inside the food keeping compartment, other

than those that might have been recommended by the manufacturer.

CONTENTS

1 Your refrigerator 4

2 Warnings 5

Electrical requirements ....................... 6

Warning! This appliance must be

earthed .............................................. 6

Energy saving tips ............................. 7

Compliance with WEEE Directive and

Disposing of the Waste Product: ....... 7

Compliance with RoHS directive: .......7

Package information .......................... 7

3 Installation 8

Disposing of the packaging ............... 8

Disposing of your old refrigerator ....... 8

Placing and Installation ...................... 8

Installation instructions .......................9

Transportation instructions ...................8

Replacing the interior light bulb...........9

Reversing the door ..........................10

4 Before operating 11

Final Check .....................................11

5 Using your refrigerator 12

Setting the operating temperature .....12

Suggested arrangement of food in the

appliance .........................................13

Problem solving .............................. 15

6 Maintenance and

cleaning 14

7 Do’s and Don’ts 15

Defrosting ........................................ 12

Standard guarantee terms and

conditions......................................16

How to obtain service...................18

Built-in appliances guarantee

terms and conditions....................17

1 Your refrigerator

Congratulations on your choice of a Beko quality Appliance which has been

designed to give you service for many years.

1. Thermostat control and interior light

2. Movable shelves

3. Wine rack

4. Vegetable drawers

5. Defrost water collection channel - drain tube

6. Crisper cover

7. Front feet

8. Adjustable door shelves

9. Bottle shelf

Figures that take place in this instruction manual are schematic and may

not correspond exactly with your product. If the subject parts are not

included in the product you have purchased, then it is valid for other models.

2 Warnings

• Do not connect your appliance to the

electricity supply until all packing and

transit protectors have been

removed.

• If transported horizontally leave

to stand upright for at least 4

hours before switching on to allow

compressor oil to settle.

• If you are discarding an old

refrigerator with a lock or latch fitted

to the door, disable the lock/latch,

ensure that it is left in a safe condition

to prevent the entrapment of young

children.

• This fridge must only be used for its

intended purpose i.e. the storing and

cooling of edible foodstuff.

• Do not dispose of the appliance

on a fire. At Beko, the care and

protection of our environment is an

ongoing commitment. This appliance

which is among the latest range

introduced is particularly environment

friendly. Your appliance contains non

CFC / HFC natural substances in the

cooling system (called R600a) and in

the insulation (called cyclopentane)

which are potentially flammable if

exposed to fire. Therefore, take care

not to damage, the cooling circuit /

pipes of the appliance in

transportation and in use. In case of

damage do not expose the appliance

to fire or potential ignition source and

immediately ventilate the room where

the appliance is situated.

• We suggest you contact your local

authority for disposal information and

facilities available.

• See 'Installation instructions' on page

9 for information on suitable location.

• To obtain the best possible

performance and trouble free

operation from your appliance it is

very important to carefully read these

instructions.

• On delivery, check to make sure that

the product is not damaged and that

all the parts and accessories are in

perfect condition.

• Ensure that the plug remains readily

accessible. Do not use multiple

adapter or extension cable.

• Failure to observe these instructions

may invalidate your right to free

service during the guarantee period.

• Keep ventilation openings, in the

appliance enclosure or in the built-in

structure, clear of obstruction.

• Do not use mechanical devices

or other means to accelerate the

defrosting process, other than those

recommended by the manufacturer.

• Do not damage the refrigerant circuit.

• Do not use electrical appliances

inside the food storage

compartments of the appliance,

unless they are of the type

recommended by the manufacturer.

• We suggest you keep these

instructions in a safe place for easy

reference.

• This appliance can be used by

children aged from 8 years and

above and persons with reduced

physical, sensory or mental

capabilities or lack of experience and

knowledge if they have been given

supervision or instruction concerning

use of the appliance in a safe way

and understand the hazards

involved. Children shall not play with

the appliance. Cleaning and user

maintenance shall not be made by

children without supervision.

• Children should be supervised to

ensure that they do not play with the

appliance.

Important! Fitting A Different Plug

As the colours of the wires in the mains

lead of this appliance may not

correspond with the coloured markings

identifying the terminals in your plug

proceed as follows: (see diagram).

1. Connect the green-yellow or green

(Earth) wire to the terminal in the plug

marked ‘E’ or with the symbol or

coloured green and yellow or green.

2. Connect the blue (Neutral) wire to

the terminal in the plug marked ‘N’ or

coloured black.

3. Connect the brown (Live) wire to the

terminal in the plug marked ‘L’ or

coloured red.

With alternative plugs a 13 A fuse must

be fitted either in the plug or adaptor

or in the main fuse box. If in doubt

contact a qualified electrician.

Electrical requirements

Before you insert the plug into the wall

socket make sure that the voltage and

the frequency shown on the rating

plate inside the appliance corresponds

to your electricity supply.

Rating label is on the left hand side of

fridge inner liner.

We recommend that this appliance be

connected to the mains supply via a

suitable switched and fused socket.

The appliance must be positioned so

that the plug is accessible.

WARNING: When positioning the

appliance ensure the supply cord is

not trapped or damaged.

Should the mains lead of the appliance

become damaged or should it need

replacing at any time, it must be

replaced by a special purpose made

mains lead which can only be obtained

from a Beko authorised service agent.

Warning! This appliance

must be earthed

If the fitted moulded plug is not

suitable for your socket, then the plug

should be cut off and an appropriate

plug fitted. Destroy the old plug which

is cut off as a plug with bared cord

could cause a shock hazard if inserted

into a socket elsewhere in the house.

The moulded plug on this appliance

incorporates a 13 A fuse. Should

the fuse need to be replaced an

ASTABEAB approved BS 1362 fuse of

the same rating must be used. Do not

forget to refit the fuse cover. In the

event of losing the fuse cover the plug

must not be used until a replacement

fuse cover has been fitted.

Colour of the replacement fuse cover

must be the same colour as that

visible on the pin face of the plug.

Fuse covers are available from any

good electrical store.

FITTED WITH

BS 1362 13A FUSE ALWAYS

FIT BS 1362 REPLACEMENT

CARTRIDGE FUSE

GREEN &

YELLOW

GREEN

BLUE

BLACK

BROWN

RED

22 mm.

6 mm.

6mm.

6 mm. 32mm.

12 mm.

FUSE

CORD GRIP

Energy saving tips

1. Ensure your appliance is installed in a

well ventilated area.

2. Ensure the time between buying

chilled/frozen food and placing them

in your appliance is kept at minimum,

particularly in summer. We

recommend you use a cool bag or a

special carrier bag to carry perishable

food.

3. Do not leave the door of your

appliance open longer than

necessary and ensure they are closed

properly after each opening.

4. Defrost frozen food in the fridge, so

that frozen food acts as an ice pack

to assist cooling in the fridge.

Compliance with WEEE

Directive and Disposing of

the Waste Product:

This product complies with EU WEEE

Directive (2012/19/EU). This

product bears a

classification symbol for

waste electrical and

electronic equipment

(WEEE). This product has

been manufactured with

high quality parts and materials which

can be reused and are suitable for

recycling. Do not dispose of the waste

product with normal domestic and other

wastes at the end of its service life.

Take it to the collection center for the

recycling of electrical and electronic

equipment. Please consult your local

authorities to learn about these

collection centers.

Compliance with RoHS

directive:

The product you have purchased

complies with EU RoHS Directive

(2011/65/EU). It does not contain

harmful and prohibited materials

specified in the Directive.

Package information

Packaging materials of the product

are manufactured from recyclable

materials in accordance with our

National Environment Regulations. Do

not dispose of the packaging materials

together with the domestic or other

wastes. Take them to the packaging

material collection points designated

by the local authorities.

3 Installation

Disposing of the packaging

The packing materials may be

dangerous for children. Keep the

packing materials out of the reach

of children or dispose of them by

classifying them in accordance

with the waste instructions. Do not

dispose of them along with the normal

household waste.

The packing of your refrigerator is

produced from recyclable materials.

Disposing of your old

refrigerator

Dispose of your old refrigerator without

giving any harm to the environment.

• You may consult your authorised

dealer or waste collection center of your

municipality about the disposal of

your refrigerator.

Before disposing of your refrigerator, cut

off the electric plug and, if there are

any locks on the door, make them

inoperable in order to protect children

against any danger.

Placing and Installation

Install your refrigerator to a place that

allows ease of use.

Keep your refrigerator away from heat

sources, humid places and direct

sunlight.

There must be appropriate air

ventilation around your refrigerator in

order to achieve an efficient operation.

Place your refrigerator on an even

floor surface to prevent jolts.

Do not keep your refrigerator in

ambient temperatures under 10°C.

WARNING: Do not locate extension

sockets or charging transformers/

power supplies or Lithium-Iron battery

operated products adjacent to the

compressor as they could overheat.

Transportation instructions

1. The appliance should be transported

only in a vertical upright position. The

packing as supplied must be intact during

transportation.

2. If during the course of transport, the

appliance has to be transported

horizontally, it must only be laid on its right

hand side when standing in the front of

the appliance. After bringing

it to upright position, it must not be

operated for at least 4 hours to allow the

system to settle.

Failure to comply with the above

instructions could result in damage

occurring to the appliance. The

manufacturer will not be held responsible

if these instructions are disregarded.

4. The appliance must be protected

against rain, moisture and other

atmospheric influences.

When positioning your appliance take

care not to damage your flooring, pipes,

wall coverings etc. Do not move the

appliance by pulling by the door or handle.

6. Empty any water in the drain

tray before moving. See section

‘Defrosting’ and ‘Maintenance and

cleaning’ for further information.

7. Make sure that the defrost water pipe

at the back of the product is fixed to the

plastic evaporating pan on the top of the

compressor, to avoid defrost water

spillage on the floor.

IMPORTANT: Care must be taken while

cleaning / carrying the appliance to avoid

touching the bottom of the condenser

metal wires at the back of the appliance

as you might injure your fingers and

hands.

Do not attempt to sit or stand on top of

your appliance as it is not designed for

such use. You could injure yourself or

damage the appliance.

If the ambient temperature is below

0°C, the food in the fridge will freeze. So,

we recommend you don’t use the

appliance in such low ambient conditions.

2. Do not place the appliance near

cookers, radiators or in direct sunlight

as this will cause your appliance to

work harder. If installed next to a

source of heat or freezer, maintain the

following minimum side clearances:

From Cookers 50 mm (2”)

From Radiators 300 mm (12”)

From Freezers

25 mm (1”)

5.A special receptacle is supplied to

store the mains plug during transit. The

receptacle is fixed at the back of the

cabinet, on the side of the compressor

(see diagram). Gently remove the plug

from the receptacle. Never pull the mains

cord, you may damage the appliance. In

the case of transportation, ensure you

locate the plug in the receptacle provided

to avoid transit damage.

“IMPORTANT: Make sure that mains

cable is not caught under the appliance

during and after carrying / moving the

appliance, to avoid the mains cable

becoming cut or damaged.”

Do not allow children to play with the

appliance or tamper with the controls.

Beko declines to accept any liability

should the instructions not be followed.

Replacing the interior light bulb

To change the Bulb/LED used for

illumination of your refrigerator, call your

Authorised Service. The lamp(s) used in

this appliance is not suitable for

household room illumination. The

intended purpose of this lamp is to

assist the user to place foodstuffs in the

refrigerator in a safe and comfortable

way. The lamps used in this appliance

have to withstand extreme physical

conditions such as temperatures below

-20°C (only chest and upright freezer).

Installation instructions

1. The space in the room where the

appliance is installed must not be

smaller than 10 cubic metres.

(The picture is drawn up as a

representation and it is not identical with

your product).

3. Refer to "Maintenance and cleaning"

section to prepare your appliance for use.

Attach 2 plastic wedges as illustrated

below. Plastic wedges are intended to

keep the distance which will ensure the

air circulation between your refrigerator

and the wall.

6.The appliance should be located on

a smooth surface. The two front feet

can be adjusted as required. To

ensure that, your appliance is standing

upright adjust the two front feet by

turning clockwise or anti-clockwise,

until the product is in firm contact with

the floor. Correct adjustment of feet

avoids excessive vibration and noise.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Blomberg Kühlschrank Handbücher

Blomberg

Blomberg TSM 1551 Bedienungsanleitung

Blomberg

Blomberg DNE 9650T Bedienungsanleitung

Blomberg

Blomberg BRFB 1450 Bedienungsanleitung

Blomberg

Blomberg DNE 9650 Bedienungsanleitung

Blomberg

Blomberg KFD4952XD Bedienungsanleitung

Blomberg

Blomberg KQD 1250 Bedienungsanleitung

Blomberg

Blomberg DNM 9650 T Bedienungsanleitung

Blomberg

Blomberg SST3455I Bedienungsanleitung

Blomberg

Blomberg SSM 1550 i Bedienungsanleitung

Blomberg

Blomberg SSM 4460 XN Bedienungsanleitung

Blomberg

Blomberg KQD 1253 XN-KQD1254XN Bedienungsanleitung

Blomberg

Blomberg BRFB 1150 Bedienungsanleitung

Blomberg

Blomberg KND 9860 XA++ Bedienungsanleitung

Blomberg

Blomberg BRFB1052FFBI2 Bedienungsanleitung

Blomberg

Blomberg KSM 1510 Bedienungsanleitung

Blomberg

Blomberg BRFB1800SS Bedienungsanleitung

Blomberg

Blomberg SSM 9450 Bedienungsanleitung

Blomberg

Blomberg KSM 9640 A Series Bedienungsanleitung

Blomberg

Blomberg FNE 1530 Bedienungsanleitung

Blomberg

Blomberg BRFB 1450 SS Bedienungsanleitung

Blomberg

Blomberg TSM 1541 i A+ Bedienungsanleitung

Blomberg

Blomberg SSM 9450 X A+ Bedienungsanleitung

Blomberg

Blomberg KQD114VPX Bedienungsanleitung

Blomberg

Blomberg SOE 96733 Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
