Blu Stream SC11HD-V2 Bedienungsanleitung

HDMI Output L/R Out Upgrade

Coaxial

Out

Link

Mode

3 2 1

DC 5V

L/R In HDMI Input EDID

Power

Link

3 2 1

SC11HD-V2

User Manual

SC11HD-V2 USER MANUAL

02 www.blustream.co.uk

Introduction 3

Features 3

Panel Descriptions 4

EDID Management 5

Mode Management 5

Application Diagram 6

Specifications 7

Package Contents 7

Maintenance 7

Contents

Surge protection device

recommended

This product contains sensitive

electrical components that may be

damaged by electrical spikes, surges,

electric shock, lightning strikes, etc. Use

of surge protection systems is highly

recommended in order to protect and

extend the life of your equipment.

Safety And

Performance Notice

Do not substitute or use any other

power supply other than the enclosed

unit, or a Blustream approved

replacement.

Do not disassemble either the

Transmitter or Receiver units for

any reason. Doing so will void the

manufacturer’s warranty.

Thank you for purchasing

this product.

For optimum performance and safety,

please read these instructions carefully

before connecting, operating or

adjusting this product. Please keep this

manual for future reference.

SC11HD-V2 USER MANUAL

contact support@blustream.co.uk / support@blustream.com.au

Our Blustream SC11HD-V2 is a HDMI 4K scaler, designed for installations with multiple

displays that support dierent maximum video resolutions. The SC11HD-V2 is ideal for

installations with muliple output resolution requirements.

The SC11HD-V2 supports down-scaling of 4K video to 1080P and supports HDCP 2.2 with

advanced EDID management. It also features either de-embedding or embedding audio

within the HDMI signal path.

Introduction

FEATURES:

• HDMI 4K video scaler

• Supports 4K UHD video input (3840 x 2160 @30Hz 4:4:4 with HDR) 3840 x 2160 @ 50/60Hz 4:2:0)

• HDMI output will downscale 4K@24/25/30Hz 4:4:4 to 1080P@24/25/30Hz, and 4K@24/25/30/50/60Hz 4:2:0 to 1080P@ 24/25/30 /50/60Hz

• Supports 10-bit HDR10

• Can be configured to work as either a HDMI audio de-embedder or audio embedder

• HDMI audio de-embedded to both analogue L/R audio and coaxial digital outputs concurrently (2CH PCM only)

• Embed analogue L/R 2CH audio input onto HDMI output

• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission

• Advanced EDID management

• HDCP 2.2 support

• CECandARCpassthrough

SC11HD-V2 USER MANUAL

04 www.blustream.co.uk

HDMI Output L/R Out Upgrade

Coaxial

Out

Link

Mode

3 2 1

DC 5V

L/R In HDMI Input EDID

Power

Link

3 2 1

Rear Panel

7 8

Front Panel

1 2

Connections:

1MODE dip-switches - adjust the MODE setting for HDMI output - see page 5 for further details

2HDMI output - connect to a HDMI display / end point

3HDMI LED indicator - lit when there is an active HDMI connection to a display / end point

4Le/Right Analogue Audio Output 3.5mm stereo jack - Extract audio from HDMI input source

NOTE: Source audio must be PCM 2 channel.

5Coaxial Digital Output - used when audio is de-embedded from HDMI

6Micro USB port - used for firmware upgrade only

Connections:

7Power connection – use supplied 5V 1A DC adaptor

8Le/Right Analogue Audio Input

9HDMI input - connecto to source device

qHDMI LED indicator - lit when there is an active HDMI connection from source device

wEDID dip-switches - adjust the EDID setting for source input - see page 5 for further details

9 11

3 4 5 6

HDMI Output L/R Out Upgrade

Coaxial

Out

Link

Mode

3 2 1

DC 5V

L/R In HDMI Input EDID

Power

Link

3 2 1

SC11HD-V2 USER MANUAL

contact support@blustream.co.uk / support@blustream.com.au

3 2 1 0 EDID Type

Combination of DIP positions

0 0 0 0 Copy EDID from output

0 0 0 1 1080p 2.0ch

0 0 1 0 1080p 5.1ch

0 0 1 1 1080p 7.1ch

0 1 0 0 1080i 2.0ch

0 1 0 1 1080i 5.1ch

0 1 1 0 1080i 7.1ch

0 1 1 1 4K60Hz 4:2:0 2.0CH

1 0 0 0 4K60Hz 4:2:0 5.1CH,

1 0 0 1 4K60Hz 4:2:0 7.1CH

1 0 1 0 4K30Hz 4:4:4 2.0CH

1 0 1 1 4K30Hz 4:4:4 5.1CH

1 1 0 0 4K30Hz 4:4:4 7.1CH

1 1 0 1 DVI 1280x1024

1 1 1 0 DVI 1920x1080

1 1 1 1 DVI 1920x1200

EDID Management

EDID (Extended Display Identification Data) is a data

structure that is used between a display and a source.

This data is used by the source to find out what audio

and video resolutions are supported by the display then

from this information the source will determine what

the best resolution is to output.

While the objective of EDID is to make connecting

a digital display to a source a simple plug and play

procedure issues do arise when multiple displays or

video matrix switching is introduced because of the

increased number of variables.

The SC11HD-V2 will act as an ‘end point’ in the HDMI

signal path. Using the EDID dip-switches pre-determins

the video resolution and audio format of the source

regardless of the video output resolution that the

SC11HD-V2 scales to.

To change the EDID settings move the EDID dip-

switches as required on the front panel of the unit.

Please see adjacent table for settings.

Note: You must power-cycle the SC11HD-V2 aer

changes have been made in order for the EDID settings

to update.

3210Mode Settings

Combination of DIP positions

1x x 0 Always convert 4K formats to 1080P

0x x 0 Auto convert 4K formats to 1080P when the device detects the display cannot support 4K

x1x 0 HDCP follows the source device

x0x 0 HDCP follows the display device

x x 10 Audio embed mode - embeds the analogue le/right audio onto the HDMI signal

x x 00 Audio bypass mode - allows HDMI audio to pass through

xxx1Mode control by serial USB

xxx0Mode control by DIP switch

Note: You must power-cycle the SC11HD-V2 aer changes have been made in order for the Mode settings to update.

The SC11HD-V2 cannot up-scale to 4K video formats.

Mode Management

SC11HD-V2 USER MANUAL

06 www.blustream.co.uk

Example Schematic

SC11HD-V2

HDMI

Coaxial Digital Cable

Speaker Cable

Analogue Audio Cable

4K SOURCE

Non 4K Display

Down-scaled

video output

HDMI Output L/R Out Upgrade

Coaxial

Out

Link

Mode

3 2 1

DC 5V

L/R In HDMI Input EDID

Power

Link

3 2 1

SC11HD-V2 USER MANUAL

contact support@blustream.co.uk / support@blustream.com.au

Specifications

Audio Input Connectors: 1x Analogue Le/Right audio (3.5mm stereo jack)

Audio Output Connectors: 1x RCA (SPDIF) & 1x Analogue Le/Right audio (3.5mm stereo jack)

Video Input Connectors: 1x HDMI Type A, 19-pin, female

Video Output Connectors: 1x HDMI Type A, 19-pin, female

EDID: 4-PIN DIP Switch

MODE: 4-PIN DIP Switch

Product upgrade: 1x Female Micro USB

Dimensions including connections (W x H x D): 83mm x 15mm x 83mm

Shipping Weight: 0.5kg

Operating Temperature: 32°F to 104°F (0°C to 40°C)

Storage Temperature: - 4°F to 140°F (- 20°C to 60°C)

Power Supply: 5V/1A DC

Package Contents:

• 1x SC11HD-V2

• 1x 5V/1A DC power supply

• 1x Mounting kit

• 1x Quick Reference Guide

Maintenance

Clean this unit with a so, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit.

www.blustream.co.uk

www.blustream.com.au
