BUMBER PANBB305-020 Chicago Bedienungsanleitung

INSTRUCTIONS’ MANUAL

READ THIS MANUAL BEFORE USE

26/06/2019

PA N B B 3 0 5 -020 CHicago

Commercial Warranty

Bought on

www.bumber.fr)

Resellers’!websites!

2)years)

1)year)

from)date)of)delivery)

CUSTOMER SERVICE

)

From)Monday)to)Friday

+ 33 (0)9.74.59.42.65

contact@bumber.fr

BUMBER

22 rue de l’Industrie

ZI des Joncaux

64700 Hendaye

France

inventory

N°

A.!

M12!x!180mm!

B.!

M12!x!180mm

C.!

M12!x!180mm

EE.!

FF.!

M12!x!180mm!

D.!

M10!x!100mm!

E.!

M10!x!90mm

F.!

M8!x!110mm

M8!x!90mm

H.!

M8!x!45mm

I.!

M8!x!40mm

J.!

M8!x!20mm

K.!

M8!x!16mm

L.!

M.!

N.!

O.!

P.!

Q.!

R.!

S.!

T.!

U1.!

U2.!

V.!

W.!

X.!

Y.!

GG.!

HH.!

AA.!

BB.!

CC.!

DD.!

NOT!SUPPLIED!BUT!NECESSARY!

)

• Do!not!hang!on!the!hoop:!risk!of!serious!injury!or!death.!

• Secure!the!basket!before!use.!

• Minimum!height!of!use:!1,98!m!(6!'6'!')!to!the!panel.!

• For!domestic!use:!any!commercial!use!is!forbidden.!!

• Restrictions!of!use:!Not!recommended!for!pregnant!women,!people!with!heart!

problems,!children!under!14,!unattended!minors.!

• Assembly:!2!adults!

• Check!for!leaks!when!filling!the!base!

• DO! NOT! HANG! on! the! hoop! or! other! part! of! the! system,! including! the! panel,!

brackets!or!net.!

• Before!the!game,!remove!your!jewellery!(rings,!watches,!necklaces,!etc.).!These!

objects!can!be!hooked!in!the!net.!

• The!surface!under!the!net!must!be!empty,!smooth,!without!gravel!or!other!bulky!

and!sharp!objects.!!

• Check! the! system! before! each! use! (loose! screws,! excessive! wear! and! signs! of!

corrosion)!and!repair!before!use.!

• Check!the!stability!of!the!system!before!each!use.!

• Correct! and! complete! assembly,! use! and! supervision! are! essential! for! proper!

operation! and! for! reducing! the! risk! of! accident! or! injury.! Serious! injury! is! very!

likely!if!the!system!is!not!installed,!maintained!and!used!properly.!

• This!system!is!for!recreational!use!and!not!for!excessive!competition!games.!

• When!moving!the!system,!do!not!place!your!hands!on!moving!parts.!

• Do!not!let!children!move!or!adjust!the!system.!

• Do! not! use! the! system! in! extreme! weather! and! wind.! Protect! your! system! by!

protecting!it!from!falling!over.!

• In!general,!be!careful!when!moving!the!system!that!it!does!not!tip!over!if!placed!

on!uneven!or!sloping!surfaces,!do!not!sit!on!the!base!and!supervise!all!the!time.!

The) distributor,) the) seller,) the) importer) and) /) or) the) manufacturer) are) not)

responsible)for)the)misuse)of)the) product,)and) failure)of)these)instructions) by)its)

owner)voids)the)warranty.)

ENGLISH

USAGE TIPS

SAFETY INSTRUCTIONS

)

• Parcel)damaged)during)delivery)

If!your!product!has!a!problem!linked!to!the!transport!and!that!you!have!expressed!

some!reservations!about!the!state!of!your! product! and! not! just! the! packaging! and!

haven’t!signed!the!delivery!slip,!please!send!justifying!photos!and!product!invoice!to!

[email protected]!under!72!working!hours.!

However,!if! you!have!accepted! the!parcel! without! checking!the! product! inside!and!

without!expressing!reservations:!we!deny!all!responsibility!in!the!matter.!!

• Intact)packaging)but)the)product)has)a)problem)not)linked)to)the)transport)or)

missing)parts.))

Please! send! justifying! photos! and! product! invoice! to! [email protected]! under! 72!

working!hours!and!don’t!sign!the!delivery!slip.!

Daily!maintenance!to!be!done!each!time!you!use!your!Basketball!Basket:!

• Clean!the!panel!with!a!soft,!damp!cloth.!!

• Check!that!all!screws!are!tight.!The!recommended!tool!for!checking!the!stability!

of!your!system!is!a!Phillips!screwdriver!to!tighten!or!change!the!screws.!

Make!sure!the!net!is!hooked!to!the!hoop!and!not!worn!or!punctured.!

ENGLISH

TRANSPORT

maintenance

)

1. Fill!the!base!with!water!or!sand!and!close!it!with!the!cap.!

2. Assemble!together!upper!pole!W.!and!middle!pole!X.!Insert!lower!pole!Y. ! i n t o ! m i d d l e !pole!X.!

Check!where!the!holes!are!located!so!that!you!can!insert!the!screws!afterwards.!

3. Install!triangle!bracket!Q.!on!middle!pole!X.!with!bolts!G1.,!G2.!and!G3.!

4. Once!the!pole’s!joint!is!polished!and!adapted!to!the!pole’s!base,!firmly!tap!the!base!of!the!

pole!several!times!on!a!piece!of!wood!or!cardboard.!

5. Put! the! 3! poles! W.,! X.! and! Y. ! together! with! bolts! E1.,! E2.! and! E3.!

Insert!simultaneously!wheel!shaft!V. ! into ! base!BB.,!then!into!wheels!M.!and!into!lower!pole!Y. !

Make!sure!that!Q.!is!facing!the!back.!

6. Attach!the!U1.!&!U2.!rods!on!lower!pole!Y.!and!on!base!BB.!With!bolts!D1.,!D2.!and!D3.!and!

bolts!J1.,!J2.!and!J3.!Watch!out!for!the!up!and!down!directions!of!the!rods.!

7. Assemble!ring!AA.,!panel!DD.!and!triangle!bracket!CC.!with!bolts!F1.,!F2.!and!F3.!and!bolts!I1.,!

I2.!and!I3.!

N.B!.:!The!2!small!L.!springs!are!attached!on!the!front!of!the!2!upper!AA!holes.!with!bolts!F1.,!

F2.!and!F3.!

8. Pull!the!2!sides!of!triangle!brackets!CC!and!fix!the!top!parts!behind!the!DD.!Panel!with!screw!

K1.!Then!fix!the!S.!&!T.!tubes!on!the!CC.!triangle!bracket!with!bolts!B1.,!B2.,!B3.,!B4.!and!B5.!

Note!that!B3.!must!be!installed!inside!CC.!

9. Install!T.!and!S.!on!W.!with!bolts!C1.,!C2.,!C3.!and!C4.!

10. Attach!the!top!part!of!external!tube!with!handle!HH.!On!the!end!of!the!longest!tube!T.! with!

bolts!A1.,!A2.,!A3.!and!A4.!Note!that!A2.!must!be!installed!between!T.!and!HH.!

11. Attach!the!end!of!the!internal!tube!GG.!on!Q.!with!bolts!H1.,!H2.!and!H3.!

12. Attach!EE.!and!FF.!on!the!shorter!tubes!S.!in!order!to!prepare!the!installation!of!big!springs!R.!

13. Attach!part!of!R.!on!the!hole!of!the!triangle!bracket!CC.!and!then!hang!the!other!end!of!R.!

with!EE.!and!FF.!

14. Install!the!P. !net!on!AA.!Ring!and!press!N.!on!W.!

)

+)HEIGHT)ADJUSTMENT)-)Raise)or)lower)the)HH)adjustment)handle.))

MOVING)THE)SYSTEM)-)Set)the)height)of)the)portable)basketball)net)to)the)lowest.)

While)holding)the)pole,)rock)the)entire)system)forward)until)the)wheels)touch)the)

ground.) Then) move) it) where) you) want.) Flip) the) system) vertically) and) check) its)

stability.)

ENGLISH

ASSEMBLY OF BASKETball stand

)

ASSEMBLY illustrations

)
