Burkert 3233 Bedienungsanleitung

3233-3234-3235

HAND-OPERATED DIAPHRAGM VALVES

Instruction Manual

Operating Instructions 0811/06_EU-ML_00440910

INTRODUCTION

ENGLISH

3233-3234-3235

Table of contents

INTRODUCTION.............................................................................................................................................2

1.1 GENERAL SAFETY INSTRUCTIONS.........................................................................................3

1.2 DESCRIPTION OF THE DIAPHRAGM VALVE.......................................................................3

INSTALLATION................................................................................................................................................4

2.1 RECOMMENDATIONS FOR INSTALLING THE VALVE.....................................................4

2.1.1 Before installation............................................................................................................................................. 4

2.1.2 During installation............................................................................................................................................. 4

2.1.3 Installation of the valve 3233 for self-draining ........................................................................4

2.1.4 Installation of a tank outlet valve 3235 .......................................................................................... 5

TECHNICAL DATA .........................................................................................................................................6

3.1 GENERAL SPECIFICATIONS ........................................................................................................6

3.2 MANUAL ACTUATOR SPECIFICATIONS.................................................................................6

3.3 DIAPHRAGM SPECIFICATIONS..................................................................................................6

3.4 VALVE BODY SPECIFICATIONS .................................................................................................7

MAINTENANCE...............................................................................................................................................8

4.1 MAINTENANCE AND STORING...................................................................................................8

4.1.1 Maintenance and order codes of the spare parts.................................................................. 8

4.1.2 Storing........................................................................................................................................................................ 8

4.2 DISMANTLING THE DIAPHRAGM VALVE ..............................................................................9

INTRODUCTION

ENGLISH

3233-3234-3235

1.1 GENERAL SAFETY INSTRUCTIONS

- Please verify that the product is complete and free from any damage.

- It is the customer’s responsibility to select an appropriate valve for the

application, ensure the unit is installed correctly and maintain the components.

- This product should only be installed and repaired by specialist staff using the

correct tools.

- Please observe the relevant safety regulations throughout the operation,

maintenance and repair of the product.

- If these instructions are ignored, no liability will be accepted and the guarantee

on the device and accessories will be invalid.

If the valve is used with dangerous fluids, insert the valve into the

process according to the legal security standards.

1.2 DESCRIPTION OF THE DIAPHRAGM VALVE

The diaphragm valve 3233, 3234 or 3235 has been designed to control the flow of fluids,

even charged or aggressive.

The compact design of this valve makes it possible to use it in processes where the space

requirement is very small.

This 2/2-way valve is made up of :

- a valve body

- a diaphragm that isolates the fluid from the atmosphere and the mechanical parts

of the top of the valve.

- an hand-operated actuator which makes it possible to control the valve opening.

- an optical position indicator indicating the valve status.

INSTALLATION

ENGLISH

3233-3234-3235

2.1 RECOMMENDATIONS FOR INSTALLING THE VALVE

• Insert the valve into the process according to the standard

industrial practices (preferably according to ASME or DIN 11850

standards).

• Only tighten the manual actuator by hand!

2.1.1 Before installation

- Carefully clean the pipes.

- Remove all the pressures and tensible forces exerted on the valve by the pipes.

2.1.2 During installation

- Ensure the pipes are aligned.

- If the valve body must be welded onto the pipes, dismantle the valve (see § 4.2)

to separate the actuator and the diaphragm from the body to prevent them from

any damage.

- Preferably improve the surface quality by grinding the weldings.

- Carefully clean the body before mounting back the actuator and the diaphragm

(see § 4.2).

2.1.3 Installation of the valve 3233 for self-draining

- Incline the valve of 15° to 30° (depending on the DN) with respect to the

horizontal (see figure below)

- Install the pipes with a 3 to 5% minimum gradient in the direction of flow.

During the assembling of the valve in self draining position, the leakage detection hole

must be at the lowest point.

Self-draining in a process system is ultimately the responsibility of the

system designer and/or end user.

15°-30°

INSTALLATION

ENGLISH

3233-3234-3235

2.1.4 Installation of a tank outlet valve 3235

Refer to ASME VIII Division I «Boiler and pressure Vessel code» standard for further

information on tanks and welding recommendations.

We recommend to weld the tank outlet valve before mounting the tank. Nevertheless,

welding valves on mounted tanks remains possible if need be.

- Ensure the tank outlet valve is not in conflict with any other equipment and the

mounting and dismounting of the actuator is always possible.

- Ensure the minimum distance between two weld seams is 3 times the thickness

of the tank wall.

We recommend to weld the valve to the center of the tank outlet to optimize the draining.

- The diameter of the whole in the tank wall must be the same as the diameter of the

flange.

The Bürkert valve has two welding bevels to ease the welding and valve positionning

operations. The welding bevel is about 3 mm long. If the tank thickness is more than

3 mm, position the valve as indicated in the figure below.

Grind the tank outlet wall by hand to prepare the welding operation.

Before welding, ensure the heat number corresponds to the one

indicated on the supplied manufacturer certificate 3.1.B.

- Insert the flange inside the whole so that the surfaces of the flange and the tank outlet

are tangent.

- Tack 4 weld points and check the positionning.

- Weld continuously the internal and external parts by supplying gaz and filler

material compatible with the 316L (DIN 1.4435) stainless steel the valve is made of.

- Cool down the weld seams then polish-grind and clean them according to the current

specifications.

These instructions will help you installing the tank outlet valves and make it possible to

avoid any change in shape and stress release within the tank.

These instructions do not override the country specific legal obligations about the

accreditation of welding operators and the carrying out of welding operations.

Part to be grinded

SPECIFICATIONS

ENGLISH

3233-3234-3235

3.1 GENERAL SPECIFICATIONS

The main advantages of the valve are the following:

- Heat number indicated on each valve to ensure the traceability of the material.

- Any mounting position.

- Any direction of flow.

- Perfect tightness due to diaphragm.

- Self-draining (valve 3233 only, see § 2.1).

- Small space requirement.

- Flow optimized design.

- Valve inside design optimized to reduce the turbulences to the minimum.

- Minimal charge loss.

- Internal mechanism adapted to the constraints of the food and drug industry.

- Steam sterilizable.

- Autoclavable.

3.2 MANUAL ACTUATOR SPECIFICATIONS

- Material: phenylene polysulphide (PPS), stainless steel or white epoxy coated cast

iron

- Handwheel diameter depending on the DN:

- Ambient temperature: +5 °C to +140 °C.

3.3 DIAPHRAGM SPECIFICATIONS

- Material:

• PTFE/EPDM

• elastomer (EPDM, FPM or CSM)

- Temperature of the medium:

DN 8 15 20 25 40 50 80 100

ø [mm] 35 80 80 80 114 114 225 275

Material Temperature [°C]

PTFE ./ EPDM

EPDM

CSM

-10 to +130

FPM -5 to +150

SPECIFICATIONS

ENGLISH

3233-3234-3235

3.4 VALVE BODY SPECIFICATIONS

- Material:

• Forged stainless steel (DIN 1.4435 BN2 / 316L according to ASME-BPE

1997).

• Cast stainless steel (316L).

• Rolled steel (316L).

- Types of connections:

• butt-weld ends which conform to ISO 4200, SMS 3008, DIN 11850,

BS 4825-1 and JIS standards

•Clamp ends which conform to BS 4825-3, ISO 2852, DIN 32676,

SMS 3017 standards

• dairy pipe unions which conform to DIN 11851 or SMS 1145 standards

• other connections on request.

- Nominal diameter (DN): DN8 to DN100

- Temperature of the conveyed medium: depends on the diaphragm material.

- Pressure class of the valve:

• Pmedium < 10 bar for DN8 to DN40

• Pmedium < 7 bar for DN50

• Pmedium < 5 bar for DN65 to DN100

MAINTENANCE

ENGLISH

3233-3234-3235

4.1 MAINTENANCE AND STORING

4.1.1 Maintenance and order codes of the spare parts

Regularly check if the diaphragm is not worn. Refer to the table below to have the order

code of the diaphragm corresponding to your valve (CSM diaphragms on request).

If your process uses muddy or abrasive fluids or fluids reaching high

temperatures, the diaphragm must be checked often.

4.1.2 Storing

If the valve is stored for a long time, unscrew the body screws to avoid permanent change

in shape of the diaphragm.

DN of body

Order codes for the diaphragms

EPDM diaphragm FPM diaphragm PTFE / EPDM diaphragm

8 642147 640597 643648

15 642140 640598 636336

20 642141 640599 643234

25 642142 640600 643235

40 643645 643653 643659

50 643646 643656 643660

80 650082 650083 650087

100 650084 650085 650088

MAINTENANCE

ENGLISH

3233-3234-3235

4.2 DISMANTLING THE DIAPHRAGM VALVE

Before dismantling or opening the valve, turn-off the medium and

depressurize the pipes.

Diaphragm

Valve body

Fixing

screws

Handwheel

Holes for

the fixing

screws

MAINTENANCE

ENGLISH

3233-3234-3235

- Open the valve until the optical indicator (yellow) is completely let out (till

blocking).

Only turn the handwheel by hand.

- Remove the protection caps from the nuts, if necessary.

- Unscrew the 4 fixing screws in an alternating pattern and remove the handwheel.

- Turn the handwheel a few times so that the diaphragm separates from the body.

- Remove the diaphragm:

• For DN15 and 20, remove the elastomer diaphragm.

• For DN > 20, unscrew the elastomer diaphragm.

• For a PTFE/EPDM diaphragm, turn a quarter turn to release the bayonet.

- Place back the new diaphragm so that the fixing holes are aligned with those of

the diaphragm (screw home if necessary).

- Open the handwheel again (turn until blocking).

- Place back the handwheel and the screws.

- Screw in an alternating pattern until the handwheel is in its proper place, without

tightening.

- Close the valve entirely then open it again completely so that the diaphragm

positions itself correctly.

- Tighten the screws in an alternating pattern to the torque rating (in Nm) specified

below:

For 3A approved products, please use only sterile food grade lubricant

complying with CFR 21 Part 178.3570.

DN Material of the diaphragm

Elastomer PTFE/EPDM

8 2 2,5

15 3,5 4

20 4 4,5

25 5 6

40 8 10

50 12 15

80 30 55

100 40 50

Andere Handbücher für 3233

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Burkert Steuereinheit Handbücher

Burkert

Burkert 0142 Bedienungsanleitung

Burkert

Burkert 3320 Bedienungsanleitung

Burkert

Burkert 6511 Bedienungsanleitung

Burkert

Burkert 3323 Bedienungsanleitung

Burkert

Burkert 6603 Bedienungsanleitung

Burkert

Burkert 6013 Bedienungsanleitung

Burkert

Burkert 2100 series Leitfaden

Burkert

Burkert 2012 Bedienungsanleitung

Burkert

Burkert 219639 Bedienungsanleitung

Burkert

Burkert 6128 Bedienungsanleitung

Burkert

Burkert 2030 Bedienungsanleitung

Burkert

Burkert 2301 Series Bedienungsanleitung

Burkert

Burkert 8640 Bedienungsanleitung

Burkert

Burkert AirLINE 8652 Series Bedienungsanleitung

Burkert

Burkert Robolux 2036 Bedienungsanleitung

Burkert

Burkert 8695 Bedienungsanleitung

Burkert

Burkert EPS 22 ATEX 1 136 X Bedienungsanleitung

Burkert

Burkert 2300 Series Bedienungsanleitung

Burkert

Burkert 5282 Bedienungsanleitung

Burkert

Burkert 8631 Bedienungsanleitung

Burkert

Burkert ACP016 Series Bedienungsanleitung

Burkert

Burkert 1094 Standard Bedienungsanleitung

Burkert

Burkert Magnetventil 6013 Bedienungsanleitung

Burkert

Burkert 6650 Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
