BW Technologies GasAlertMicroClip Series Bedienungsanleitung
User Manual
GasAlertMicroClip
1, 2, 3, and 4 Gas Detectors
H2S, CO, O2, Combustibles
Limited Warranty & Limitation of Liability
BW Technologies LP (BW) warrants this product to be free from defects in material and workmanship under normal use and service for a period of two years,
beginning on the date of shipment to the buyer. This warranty extends only to the sale of new and unused products to the original buyer. BW’s warranty
obligation is limited, at BW’s option, to refund of the purchase price, repair, or replacement of a defective product that is returned to a BW authorized service
center within the warranty period. In no event shall BW’s liability hereunder exceed the purchase price actually paid by the buyer for the Product.
This warranty does not include:
a) fuses, disposable batteries or the routine replacement of parts due to the normal wear and tear of the product arising from use;
b) any product which in BW’s opinion, has been misused, altered, neglected or damaged by accident or abnormal conditions of operation, handling or use;
c) any damage or defects attributable to repair of the product by any person other than an authorized dealer, or the installation of unapproved parts on the
product; or
The obligations set forth in this warranty are conditional on:
a) proper storage, installation, calibration, use, maintenance and compliance with the product manual instructions and any other applicable
recommendations of BW;
b) the buyer promptly notifying BW of any defect and, if required, promptly making the product available for correction. No goods shall be returned to BW
until receipt by the buyer of shipping instructions from BW; and
c) the right of BW to require that the buyer provide proof of purchase such as the original invoice, bill of sale or packing slip to establish that the product is
within the warranty period.
THE BUYER AGREES THAT THIS WARRANTY IS THE BUYER’S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. BW SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES, INCLUDING LOSS
OF DATA, WHETHER ARISING FROM BREACH OF WARRANTY OR BASED ON CONTRACT, TORT OR RELIANCE OR ANY OTHER THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or exclusion or limitation of incidental or consequential damages, the
limitations and exclusions of this warranty may not apply to every buyer. If any provision of this warranty is held invalid or unenforceable by a court of competent
jurisdiction, such holding will not affect the validity or enforceability of any other provision.
BW Technologies by Honeywell BW Technologies by Honeywell BW Technologies by Honeywell
Corporate Headquarters America Europe
2840 – 2nd Ave. SE 3279 West Pioneer Parkway 5 Canada Close
Calgary, AB Arlington, TX Banbury, Oxfordshire
Canada T2A 7X9 USA 76013 UK OX16 2RT
Table of Contents
Title Page
Introduction............................................................................................................................................1
Contacting BW Technologies by Honeywell.........................................................................................2
Safety Information - Read First.............................................................................................................2
Getting Started......................................................................................................................................6
Activating the Detector........................................................................................................................10
Self-Test......................................................................................................................................10
Self-Test Pass.............................................................................................................................15
Self-Test Fail ...............................................................................................................................15
Battery Test .................................................................................................................................15
Backlight......................................................................................................................................16
Deactivating the Detector....................................................................................................................16
Options................................................................................................................................................16
Detector Identification..................................................................................................................17
Sensor Options............................................................................................................................17
User Options Menu .....................................................................................................................20
Language Menu...........................................................................................................................21
Alarms.................................................................................................................................................22
Computed Gas Exposures..........................................................................................................24
Viewing Gas Exposures..............................................................................................................25
Gas Alarm Setpoints ...................................................................................................................26
Resetting Gas Alarm Setpoints...................................................................................................26
Stopping a Gas Alarm.................................................................................................................27
Sensor Alarm...............................................................................................................................27
i
GasAlertMicroClip
User Manual
ii
Title Page
Low Battery Alarm .......................................................................................................................27
Automatic Shutdown Alarm.........................................................................................................27
Calibration...........................................................................................................................................28
Guidelines....................................................................................................................................28
Diagnostics Protection.................................................................................................................29
Applying Gas to the Sensors.......................................................................................................29
Calibration Procedure..................................................................................................................30
Datalogs ..............................................................................................................................................34
Event Logs ..........................................................................................................................................34
Downloading Datalogs and Event Logs......................................................................................34
Maintenance........................................................................................................................................34
Charging the Detector .................................................................................................................35
Replacing a Sensor or Sensor Filter ...........................................................................................36
Troubleshooting...................................................................................................................................39
Replacement Parts and Accessories..................................................................................................42
Specifications......................................................................................................................................43
General Datalogger Specifications..............................................................................................45
List of Tables
Table Title Page
1. Gases Monitored ...................................................................................................................1
2. International Symbols............................................................................................................5
3. GasAlertMicroClip Detector...................................................................................................7
4. Display Elements...................................................................................................................8
5. Pushbutton.............................................................................................................................9
6. Alarms..................................................................................................................................22
7. Computed Gas Exposures ..................................................................................................24
8. Gas Alarm Setpoints............................................................................................................26
9. Sample Factory Alarm Setpoints.........................................................................................26
10. Applying Gas to the Sensors...............................................................................................29
11. Replacing a Sensor or Sensor Filter ...................................................................................37
12. Troubleshooting Tips...........................................................................................................39
13. Replacement Parts and Accessories ..................................................................................42
iii
GasAlertMicroClip
User Manual
iv
List of Figures
Figure Title Page
1. GasAlertMicroClip Detector...................................................................................................7
2. Display Elements...................................................................................................................8
3. Applying Gas to the Sensors...............................................................................................29
4. Connecting the Charging Adapter.......................................................................................35
5. Replacing a Sensor or Sensor Filter ...................................................................................36
6. Replacing the Rear Shell.....................................................................................................38
v
GasAlertMicroClip
User Manual
vi
CAUTION: FOR SAFETY REASONS, THIS EQUIPMENT
MUST BE OPERATED AND SERVICED BY QUALIFIED
PERSONNEL ONLY. READ AND UNDERSTAND
INSTRUCTION MANUAL COMPLETELY BEFORE
OPERATING OR SERVICING.
GasAlertMicroClip Multi-Gas Detector with User
Downloadable Datalogger and Event Log
Standard instrument is equipped with integral concussion-
proof boot, internal vibrator alarm, and provides full-time
continuous datalogging while the instrument is operating.
Data is saved to memory and can be downloaded by the
user via an IR device to a PC. Data is imported into standard
office software (Microsoft® Excel, Access, etc.). Wraparound
memory ensures the most recent data is always saved.
GasAlertMicroClip
Introduction
aWarning
To ensure your personal safety, read “Safety
Information” before you use the detector.
The GasAlertMicroClip gas detector (“the detector”) warns of
hazardous gas at levels above user-selectable alarm
setpoints.
The detector is a personal safety device. It is your
responsibility to respond properly to the alarm.
Table 1 lists the gases monitored.
Table 1. Gases Monitored
Gas Detected Unit of Measure
Hydrogen sulfide (H2S) parts per million (ppm)
Carbon monoxide (CO) parts per million (ppm)
Oxygen (O2) percent by volume (%)
Combustible gases (LEL)
Field selectable for: a) percent of lower
explosive limit (% LEL)
b) percent by volume
methane 0-5.0% v/v
1
GasAlertMicroClip
User Manual
Contacting BW Technologies by
Honeywell
To contact BW Technologies by Honeywell, call:
USA: 1-888-749-8878
Canada: 1-800-663-4164
Europe: +44 (0) 1295 700300
Other countries: +1-403-248-9226
Address correspondence to:
BW Technologies by Honeywell
Corporate office
2840 – 2 Avenue S.E.
Calgary, AB T2A 7X9
CANADA
Visit BW Technologies by Honeywell’s web site at:
www.gasmonitors.com
ISO 9001
Safety Information - Read First
Use the detector only as specified in this manual, otherwise
the protection provided by the detector may be impaired.
International symbols used on the detector and in this
manual are explained in Table 2.
Read the Cautions on the following pages before using the
detector.
ec Note
This instrument contains a lithium polymer
battery. Do not mix with the solid waste stream.
Spent batteries should be disposed of by a
qualified recycler or hazardous materials
handler.
