PIXMA iP6210D

SERVICE

MANUAL

Canon

shall be retained for reference purposes byAuthorized Service Facilities of Canon U.S.A. Its unauthorized use is prohibited.

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

(2/25)

1. PRODUCT LIST

1-1. Main Units

Product name Product code Sales territories Remarks

0012B001AA US

0012B002AA CA

0012B003AA LAM LVT

0012B004AA LAM HVT

0012B006AA EUM

0012B007AA EMB

0012B008AA ASA HVT

0012B009AA AU

0012B011AA GB

Canon Ink Jet Printer iP6210D

0012B014AA HK

1-2. Options

Product name Product code Sales territories Remarks

0689B001AA –

0689B006AA 001: JPN

002: USA/CAN/HK/MY/SPL

004: CN

005: EUR/AU

Blue Tooth Unit（BU-20）

006: KR

1-3. Consumables

Product name Product code Sales territories Remarks

Canon FINE Cartridge

CL-51 (Color) 0618B001AA~0618B005AA

CL-52 (Photo) 0619B001AA~0619B005AA

CL-41 (Color) 0617B001AA~0617B005AA

001: EUR

002: AMR

003: ASIA

005: AMR S

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

(3/25)

2. PRODUCT SPECIFICATIONS

2-1. Printer Main Unit Specifications

Paper feeding method ASF

Resolution 4,800 x 1,200 dpi (max.)

Printing speed Approx. 60 sec. (PP-101, 4 x 6, borderless printing, default print quality settings)

For reference:

Draft Standard

Black (J/E) 11 ppm 3 ppm

Color (J/E) 9 ppm 2.6 ppm

Printing direction Bi-directional / Uni-directional (automatically switched according to print data and print mod

Fast mode print duty 50% duty

Print width 203.2 mm (216 mm in borderless printing)

Interface - USB 2.0 Hi-Speed

- Direct print port (PictBridge, Bubble Jet Direct)

- Bluetooth 1.2 (optional, JPEG files only)

Supported ink cartridge Consumable

ASF stacking capacity

Paper weight Max. 10 mm (Approx. 100 pages of 75 g/m2)

64 to 105 g/m2

Plain paper 10 mm or less

High Resolution Paper 10 mm (Approx. 80 sheets) or less

Glossy Photo Paper A4, LTR, 5x7: 10 sheets or less

4x6: 20 sheets or less

Photo Paper Pro,

Photo Paper Plus Glossy,

Matte Photo Paper

A4, LTR, 5x7: 10 sheets or less

4x6, 4x8: 20 sheets or less

Photo Paper Plus Double Sided 1 sheet

Photo Paper Plus Semi-gloss A4, LTR: 10 sheets or less

4x6: 20 sheets or less

Transparency 30 sheets or less

Envelope 10 sheets or less

T-shirt Transfer 1 sheet

Photo Stickers 1 sheet

Borderless printing Up to A4, LTR

Detection function

Cover open Available

Presence of ink cartridge Available

Wrong installation of ink cartridge Available

Presence of memory card Available

Supported camera direct printing device Available

Carriage position Available

Presence of paper Available

Head-to-paper distance Available

Waste ink absorber full Available

Internal temperature Available

Remaining ink amount Available (Detected by dot counting)

Print head alignment Available (16 types) (Automatic alignment at default, possible to do manual alignment from

computer)

Acoustic noise level

Fine (Photo Paper Pro / Fine mode) Approx. 43 dB (Sound pressure level ISO9296)

HQ Approx. 44 dB

HS Approx. 53 dB

Environmental requirements

During operation Temperature: 5C to 35C (41F to 95F)

Humidity: 10% to 90%RH (no condensation)

Non-operation Temperature: 0C to 40C (32F to 104F)

Humidity: 5% to 95%RH (no condensation)

(2-1, Printer Main Unit Specifications cont’d)

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

(4/25)

Power supply

Input voltage / Frequency AC 100 to 240 V, 50/60Hz

During printing Approx. 11 W

Power consumption: Stand-by status Approx. 1 W

External dimensions - With the paper support extended: Approx. 435 (W) x 280 (D) x 259 (H) mm

- With the paper support retracted: Approx. 435 (W) x 253 (D) x 165 (H) mm

Weight Approx. 3.7 kg (excluding the ink cartridges)

Related standards

Electromagnetic radiance,

Electrical safety FCC, IC, CE Mark, Taiwan EMC, C-Tick, CCC (EMC), Korea MIC, Gost-R, DENAN, UL,

C-UL, CB Report, GS, FT, SASO, SPRING, Korea EK, IRAM (Argentine)

Note: Not Blue Angel compliant.

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

(5/25)

2-2. Direct Printing Specifications

Memory card drive

Supported memory card Compact Flash TYPE I/II, Microdrive, SmartMedia Card, Memory Stick,

MagicGate Memory Stick, SD Card, MultiMedia Card, xD-Picture Card*,

miniSD memory card*, Memory Stick Duo*, MagicGate Memory Stick Duo*

*: An adapter is necessary.

Storage function

Supported OS Windows ME / 98 / 2000 / XP, Mac OS X 10.2.1 or later

Settings Changeable via the operation panel

Function Read / Write

Card Direct Printing

Operation panel 2-line LCD, 11 buttons, 2 LEDs

File format JPEG (DCF, CIFF, Exif 2.21 or prior, JFIF), DPOF compliant

Print quality High, Fast

Image correction function Photo Optimizer PRO, VIVID, noise reduction, face brightener

Image adjustment function Brightness, contrast, hue

Image processing function Sepia, illustrated touch

Image retrieval function Available (date)

DPOF version Ver. 1.00 compliant

Print layout - Single-photo/multi-photo/all-photo printing:

1 photo per page (borderless/with borders, only with borders for plain

paper)

- DPOF printing:

1 photo per page (borderless/with borders)

6, 15, 24, 35, 80 photos per page

- Index printing:

6, 15, 24, 35, 80 photos per page

- Layout printing

2, 4, 8 photos per page (borderless/with borders)

- Sticker printing:

16 stickers

Resolution 1,200 x 1,200 dpi (max.)

Throughput Approx. 1 minutes 30 seconds, with the following conditions and settings:

- A photo from a 4 mega-pixel digital camera

- Process from pressing the printing start button to ejecting paper

Throughput Approx. 1 minutes 30 seconds, with the following conditions and settings:

- A photo from a 4 mega-pixel digital camera

- Process from pressing the printing start button to ejecting paper

Camera Direct Printing Support

Supported print paper See 2-3, Print Media Specifications.

Print layout - 1 photo per page (borderless/with borders)

- Index printing

Resolution 1,200 x 1,200 dpi (max.)

Throughput Approx. 69 seconds, with the following conditions and settings:

- A photo from a 5 mega-pixel digital camera

- PP-101 4” x 6”

- ExifPrint/Standard

- Process from pressing the printing start button to ejecting paper

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

(6/25)

Throughput Approx. 69 seconds, with the following conditions and settings:

- A photo from a 5 mega-pixel digital camera

- PP-101 4” x 6”

- ExifPrint/Standard

- Process from pressing the printing start button to ejecting paper

Print Beam printing (Direct Printing from a camera-equipped mobile phone via wireless communication) Support

Printable data Image (JPEG only, text printing not possible)

Supported print paper See 2-3, Print Media Specifications.

Supported layout 1, 2, 4, 8 images per page (borderless)

1, 2, 4, 5, 6, 7, 8, 9, 16 images per page (with borders)

(2-2, Direct Printing Specifications cont’d)

Printing via Bluetooth communication (optional)

Standard Bluetooth version 1.2

Output Bluetooth Power Class 2

Communication range Good for approx. 10 m in radius (depending on interference between the

communication devices, or radio wave conditions)

Frequency band 2.4 GHz

Communication speed Approx. 720 kbps

Supported profile BIP, OPP, SPP, HCRP

Supported OS for HCRP - Windows XP Service Pack 2 or later

- Windows XP Service Pack 1 or later: Microsoft "Support for Bluetooth

Wireless Devices" or Toshiba Bluetooth Stack for Windows Ver. 3.00.10 or

later has to be installed

- Mac OS X 10.3.3 or later

BU-20 specifications

External dimensions 18.5 (W) x 47.5 (D) x 8.7 (H) mm with a cap

Weight Approx. 7 g

Power supply voltage 4.4 to 5.25 V

Power consumption 500 mW (max.)

Operating temperature 5C to 35C (41F to 95F)

Operating humidity 10%RH to 90%RH (no condensation)

2-3. Product Life

Specified print volume or the years of use, whichever comes first.

- 3 years of use

- Print volume: 4,000 pages

- Black: 800 pages (A4, standard mode, 1,500 character pattern)

- Color: 600 pages (A4, 7.5% duty per color pattern)

600 pages (A4, photo, borderless printing)

1,800 pages (4 x 6, photo, borderless printing)

200 pages (Postcard, photo, borderless printing)

Note: The above print volume breakdown is estimated using average user consumption patterns of

printing 4,000 pages.

2-4. Ink Cartridge Specifications

Ink cartridge

Type Ink-tank-integrated print head

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

(7/25)

Print head Color: 192 nozzles in 3 vertical lines

Photo: 192 nozzles in 2 vertical lines

Ink droplet: Col 5 pl / 2 pl, Photo 5 pl / 2 pl,

Ink color Col: Y/M/C (super dye-based), Photo: PBK/PM/PC (super dye-based)

Weight CL-51(Col) approx. 56 g, CL-52(Photo) approx. 56 g

CL-41(Col) approx. 51 g

Supply method As a consumable

<Supported ink cartridges by models>Ink cartridge

High capacity Standard

Model CL-51 (Color) CL-52 (Photo) CL-41 (Color)

IP6210

D Standard package Standard package Usable as an

option

Units: pages

CL-52 CL-51

1,500 character pattern

plain paper / standard mode 450

ISO JIS-SCID No. 5

plain paper / standard mode 710 330

Digital camera 24 images

PP-101 4x6 110 180

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

(8/25)

3. ERROR DISPLAY

Errors are displayed by the LEDs, and ink low warnings are displayed by the Status Monitor.

3-1. Operator Call Error (Alarm LED Blinking in Orange)

LED display

Alarm

LED

blinking

(Service

mode)

Error

(Error code) Corrective action Remarks

There is no paper. 2 times No paper

(ASF)[1000] Set paper in ASF, and press

the OK button.

The paper is jammed. 3 times Paper jam[1300] Remove the jammed paper,

and press the OK button.

Ink has run out.

Replace the ink

cartridge and close the

cover.

U041

- No ink[1600] Replace the ink cartridge(s),

or press the OK button. When selecting to

press the OK

button, ink may run

out during printing.

The following ink

cartridge cannot be

recognized.

U051 / U059

5 times The ink cartridges

are not

installed[1401],

or a non-supported

ink cartridge is

installed[1485].

Check if supported ink tank(s)

is installed, and re-install

them properly, and then close

the front cover.

Some ink cartridges

are not installed in

place.

U075 / U076

7 times Ink cartridge’s

position is wrong.

[1487 / 1486]

Install the ink cartridge(s) in

the correct position.

The following ink

cartridge cannot be

recognized.

U052

15 times Ink cartridge is not

installed.[1682] Re-install the ink cartridge(s)

properly and close the front

cover.

Or, turn off/on the printer

with the ink cartridges

installed.

The following ink

cartridge cannot be

recognized.

U053

4 times Ink cartridge is not

installed properly. Re-install the ink cartridge(s)

properly and close the front

cover.

The waste ink

absorber is almost full. - Waste ink absorber

full[1700],

or platen waste ink

absorber full[1710].

Pressing the OK button will

clean the error, and enable to

print.

<Replace Ink absorber kit

(QY5-0148-000)>

<Replace Platen waste ink

absorber QC1-6014-000)>

Waste ink absorber

full warning

(service call error)

may appear.

Incompatible device

detected. - The connected

digital camera /

video camera is not

supported for

Camera Direct

Printing.

Disconnect the cable from a

the digital camera/video

camera, and press the Reset

button, and then re-connect

the cable.

The following ink may

have run out.

U161

An ink cartridge that

was once empty is

installed.

U162

- Ink remaining is

unknown.

[1685/1686]

Install an new ink cartridge, or

press the OK button.

* When an cartridge that was

once used (excluding the

cartridge used just before) is

installed, this error occurs.

(See 8-2. Major Functions (4)

Remaining ink level detection

function.)

When the error is

resolved by

pressing the OK

button, the function

for detecting the

remaining ink level

will be released.

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

(9/25)

3-2. Service Call Error (Cyclic Blinking in Orange (Alarm LED) and Green (Power LED))

Cycles of blinking

in orange and

green Error Corrective Action

2 times Carriage error [5100] Replace the printer as it has failed.

3 times Paper feed error [6000] Replace the printer as it has failed.

4 times Purge unit error [5C00] Replace the printer as it has failed.

5 times ASF(cam) sensor error [5700] Replace the printer as it has failed.

6 times Internal temperature rise error [5400] Replace the printer as it has failed.

7 times Waste ink absorber full or platen waste ink

absorber full [5B00] Replace the printer as it has failed.

8 times Ink cartridge temperature rise error [5200] Replace the printer as it has failed.

9 times EEPROM error [6800] Replace the printer as it has failed.

13 times Paper feed position error [6B00] Replace the printer as it has failed.

15 times USB Host VBUD overcurrent error [9000] Replace the printer as it has failed.

17 times Abnormal motor driver error [6Ｄ00] Replace the printer as it has failed.

20 times Other hardware error [6500] Replace the printer as it has failed.

Continuous

alternate blinking ROM error Replace the printer as it has failed.

Alarm LED

(orange) lit ROM error Replace the printer as it has failed.

3-3. Ink Low Warning (Ink low warnings are displayed by the Status Monitor only when the remaining ink

level detection is enabled, and no Status Monitor display when disabled.)

Note: The Status Monitor display in the table below is for Windows.

Warning Display by Status Monitor

Ink low warning 1 (approx. 70% of ink remaining)

Ink low warning 2 (approx. 40% of ink remaining)

Ink low warning 3 (low remaining ink)

Ink low warning 4 (no ink remaining)

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

(10/25)

4. REPAIR

4.1 Notes on Service Part Replacement (and Disassembling/Reassembling) in Asia

Service part Notes on replacement Adjustment/settings Operation check

Logic board ass’y

(QM2-2841) - Detach the logic board

ass’y about one

minute after removing

the power cord to

prevent the logic board

ass’y from being

damaged. (to

discharge the

accumulated electricity

in the capacitor)

- If a waste ink amount

is more than 7%,

replacement of the ink

absorber is necessary.

After replacement:

1. Initialize the

EEPROM.

2. Reset the waste ink

counter.

3. Set the destination in

the EEPROM.

See 4.2 SERVICE

MODE.

4. Perform the print

head alignment in

the user mode.

- EEPROM print

- Service test print

- Printing via an

USB connection

- Camera Direct

Operation panel unit

(QM2-3327) After replacement:

1. Check the buttons /

the LCD

See 4.2 SERVICE

MODE.

Absorber kit

(QY5-0418)

Platen ink absorber

(QC1-6014)

After replacement:

1. Reset the waste ink

counter.

See 4.2 SERVICE

MODE.

- Service test print

4.2 SERVICE MODE

Item Timing Objective Remarks

Service test print

- Model name

- Rom version

- USB serial number

- Waste ink amount

At printer operation

checking or parts

replacement

Operation checking See Service mode

operation procedures.

Load A4, LTR, or more

large sized paper.

Print sample: See

APPENDIX 1: SHIPMENT

INSPECTION PATTERN 1.

EEPROM reset At Logic board replacement Reset except for the

followings.

- USB serial number

- Destination setting

- Waste ink counter

See Service mode

operation procedures.

Waste ink counter reset At waste ink absorber

replacement Waste ink counter reset See the waste ink counter

reset procedures.

(For Asia only)

Destination setting At Logic board replacement Destination setting See Service mode

operation procedures &

Destination setting

procedures.

(For Asia only)

Button / LCD checking At Operation panel

operation checking

(such as Operation panel

unit replacement)

Button / LCD operation

checking See Button / LCD checking

operation procedures.

(For Asia only)

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

Andere Handbücher für iP6210D - PIXMA Color Inkjet Printer

Inhaltsverzeichnis

Andere Canon Drucker Handbücher

Canon

Canon PIXMA MG4160 Bedienungsanleitung

Canon

Canon imageRUNNER 2545i Montage- und Bedienungsanleitung

Canon

Canon iR1018 Bedienungsanleitung

Canon

Canon imageRUNNER ADVANCE DX 6870i Bedienungsanleitung

Canon

Canon imagePROGRAF iPF815 Bedienungsanleitung

Canon

Canon imagePASS-N1 Bedienungsanleitung

Canon

Canon PIXMA MP640 Bedienungsanleitung

Canon

Canon IX-R7000 Bedienungsanleitung

Canon

Canon 820D - S Color Inkjet Printer Benutzerhandbuch

Canon

Canon Pixma iP110 series Bedienungsanleitung

Canon

Canon PIXMA E300 series Bedienungsanleitung

Canon

Canon PIXMA TS3310 Bedienungsanleitung

Canon

Canon SELPHY ES30 Bedienungsanleitung

Canon

Canon Color imageCLASS LBP633Cdw Bedienungsanleitung

Canon

Canon 2238B002 Bedienungsanleitung

Canon

Canon imagePRESS C8000VP Bedienungsanleitung

Canon

Canon imageFORMULA DR-G2140 Bedienungsanleitung

Canon

Canon imageRUNNER ADVANCE DX C7700 Series Bedienungsanleitung

Canon

Canon PowerShot S330 Digital ELPH Handbuch

Canon

Canon iP1800 - PIXMA Color Inkjet Printer Handbuch

Canon

Canon pixma mg3620 Installations- und Benutzerhandbuch

Canon

Canon imageCLASS LBP622Cdw Bedienungsanleitung

Canon

Canon PIXMA TS5365 Bedienungsanleitung

Canon

Canon iP3000 - PIXMA Photo Printer Handbuch

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

IRA3D

IRA3D POETRY4 Bedienungsanleitung

Ricoh

Ricoh Aficio AP400 Bedienungsanleitung

BIXOLON

BIXOLON SRP-352plusV Bedienungsanleitung

Epson

Epson Stylus Photo PX700W Montageanleitung

Ricoh

Ricoh SP204SF Bedienungsanleitung

Star Micronics

Star Micronics futurePRNT TSP100 Bedienungsanleitung

Epson

Epson TM-TM88V-i Gebrauchs- und Pflegehandbuch

Canon iP6210D - PIXMA Color Inkjet Printer Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken
