CareCo Airlite Bedienungsanleitung

Airlite

Owner’s Manual

CareCo (UK) Ltd

Hubert Road

Brentwood

Essex

CM14 4JE

Thank you for purchasing your AIRLITE Scooter. We are delighted you have chosen

CareCo (UK) Ltd for your mobility needs

Standard Packing List:

1 Owner’s Manual

1 Battery Pack

1 Seat

1 Key

Battery Charger

Seat Post Nut and Bolt or Detent Pin

DISCLAIMER

We ask that you read this manual completely before operating your new AIRLITE scooter.

CareCo (UK) Ltd is not, and cannot be held responsible for, any damage or injury incurred due to improper or

unsafe use of the CareCo AIRLITE scooter.

CareCo (UK) Ltd specifically disclaims responsibility for any bodily injury or property damage that may occur

during any use that does not comply with applicable laws.

Congratulations on the purchase of your new AIRLITE scooter. The AIRLITE combines cutting edge

technology with attractive design which is highly functional in today’s world. We at CareCo (UK) Ltd know

that you have chosen a scooter that will give you years of dependable operation and will also enhance the

quality of your life by providing you with the mobility to experience an active daily lifestyle.

Even though your new AIRLITE is both user-friendly and designed for maximum manoeuvrability in the

tightest spaces, we ask that you please read, understand and follow all of the instructions and suggestions in

this manual before you operate your scooter for the first time. The safe use of your new scooter is very

important to us.

If you feel that you do not understand the instructions and suggestions presented in this Owner’s Manual, or

if, for any reason, you do not feel capable of performing the activities necessary to assemble, disassemble,

operate, or maintain your AIRLITE scooter, please contact CareCo Customer Services on 0845 611 8022.

CareCo (UK) Ltd cannot be held responsible for personal injury or property damage resulting from the unsafe

or the improper use of any of our broad range of health and personal mobility products. Also, CareCo (UK)

Ltd cannot be held responsible for personal injury or property damage resulting from attempts to follow

instructions, suggestions, and guidelines presented in this Owner’s Manual.

Our Research and Development Department, our Quality Control Department, and our Engineering

Department have used the latest product specifications and the latest product design information to

manufacture your AIRLITE scooter. CareCo (UK) Ltd reserves the right to implement changes into our

product lines when those changes become desirable or necessary. If changes are implemented into our

product line, there may be minor differences between the product you purchased and the illustrations and

instructions in this Owner’s Manual.

We at CareCo (UK) Ltd would appreciate hearing about the dependability of your AIRLITE and about the

convenience of mobility it has provided for you. We would also appreciate hearing about the service you

received from our Company.

CareCo (UK) Ltd. Customer Services Phone: 0845 611 8022

Hubert Road Fax: 01277 204245

Brentwood

Essex

CM14 4JE

www.careco.co.uk

For more information about our products and services, or to send us your comments, please visit our website

at www.careco.co.uk or email: cs@careco.co.uk

PREFACE AND INTRODUCTION ……..…………………………….

SAFETY NOTICE………………………………………...……………….

2.1 Before Driving

2.2 While Driving

2.3 Labelling

PARTS INTRODUCTION

3.1 Parts Description

OPERATION………………………………………………………………..

4.1 Control Panel

4.2 How to Operate your Scooter

4.3 Disassembling & Assembling

BATTERY CHARGING AND CARE………….............................................

5.1 Charging the Battery

5.2 Battery

INSPECTION AND MAINTENANCE……………………………..….

6.1 Inspection

6.2 Regular Checking Record

6.3 Battery, Fuse and Tyres

6.4 Storage

6.5 Manually Moving the Scooter

TROUBLE SHOOTING AND SPECIFICATION……………………

WARRANTY……………………………………………………………….

TABLE OF CONTENTS

1. PREFACE AND INTRODUCTION

Please carefully read this owner’s manual before using the vehicle. Improper use of the vehicle

could result in accident and injury.

This owner’s manual includes operation instructions for every aspect of the vehicle.

The symbols used in this manual are explained below:

Warning

Improper usage could result in serious injury or death

Attention

Improper usage could lead to injury and/or damage to your scooter.

Suggestion

Follow these instructions to keep your vehicle in a good operating

order.

This manual includes a copy of repair and maintenance record chart and warranty

information. Please keep it in a safe place or in the scooter.

If someone else uses the scooter, please make sure that you provide them with the

instruction manual for their information.

We reserve the right to make design modifications. As designs change, some illustrations

and pictures in the manual may not correspond to the vehicle that you purchased.

The scooter has been designed and manufactured to provide a comfortable and secure, yet

affordable, solution for some mobility requirements.

2. SAFETY NOTICE

2.1 Before Driving

The user should become familiar with the usage and operation of this vehicle before driving.

Please follow the recommendations in this safety notice.

■The same traffic rules apply to the use of this vehicle as apply to pedestrians

For your safety, please follow the rules that apply to pedestrians.

Ride on the pavement, single carriage roads, or pedestrian areas only. Never ride on

motorways or dual carriageways.

Please do not drive your scooter after consuming alcohol or when tired.

Please be careful when driving your scooter in low light. It has not been designed for use

at night.

Be extremely cautious when driving your scooter on a busy street or in shopping malls.

■Practice operating your vehicle

Before using the scooter familiarise yourself with its operation. Practice in a wide and open

area like a park. In order to avoid accidents with your scooter whilst driving, please take care

when accelerating, stopping, turning, reversing and driving up and down ramps.

Please turn the speed dial to low speed position for your initial practice.

Be sure someone accompanies you for safety when driving your scooter for the first time.

Only use higher speed settings when you are confident that you can easily operate and

control your scooter.

■The AIRLITE is only to be used by one person at a time

Do not carry passengers on your scooter (including children)

■Do not use this vehicle to carry or haul goods

For the maximum weight that can be carried, please refer to ‘MAX USER WEIGHT’ in ‘7.

SPECIFICATION’

Maximum load weight for the basket is 3 kg.

2.2 While Driving

■Please carry out regular inspections on your scooter. Refer to ‘6. INSPECTION &

MAINTENANCE’.

■Do not alight from the vehicle whilst it is moving

Such action may cause you to lose balance and risk injury from falling.

Ensure that your clothes do not tangle in the wheels.

■Do not use your vehicle under any of the following conditions:-

On roads with heavy traffic or roads that are muddy, gravelly, uneven, narrow, snowed

over, icy or on canal towpaths not guarded by a fence or hedge.

Do not drive at night or when it is raining, snowing, misty, or windy.

Do not drive your vehicle in an ‘S’pattern or make erratic turns.

Do not take the scooter onto escalators.

UNDER NO CIRCUMSTANCES SHOULD THE SCOOTER BE USED AS A SEAT IN A MOTOR

VEHICLE (e.g. CARS, BUSES, TRAINS, ETC).

■Mobile Phones and other electrical equipment

Do not use a mobile phone or other wireless communication device while driving.

Always switch off the scooter and remove the ignition key before using a mobile phone.

Do not charge a mobile phone or any other electrical device from your scooter’s battery.

■Automatic Power Shut Down

In order to avoid accidentally draining the battery, your scooter is equipped with an

automatic power shut down facility. If the scooter is switched on, after remaining

undisturbed for a period of ten minutes, it will automatically turn off. Should this occur,

simply switch your scooter off and back on and it will be ready to use once again.

■Ramps, inclines and descents

Do not drive onto steep ramps greater than the specified gradient. Refer to the section

entitled ‘CLIMBING ANGLE’in ‘7. SPECIFICATION’.

Always use a low speed setting when ascending or descending a slope.

Do not drive on uneven ground.

Do not make sudden turns when driving on gravel roads or ramps.

Always lean forward when climbing uphill.

■Starting and Driving

1. Make sure the seat is installed properly.

2. Make sure the tiller has been secured.

3. Fold down the armrests so you can rest your arms.

4. Turn the power switch to ‘ON’. If necessary, turn on the headlights.

5. Check battery indicator to see whether there is enough power for your journey. If you

have any

doubt about the remaining power, recharge the battery before departure.

6. Set the speed dial to a safe and comfortable speed.

7. Check the forward/reverse speed lever works correctly.

8. Make sure the electromagnetic brake works correctly.

9. Make sure it is safe around you before you set off.

WARNING!

Do not set in the freewheel mode when driving on a slope.

Always re-engage the anti-freewheel device before use. Failure to do so may result in injury.

To protect your safety, the power will automatically cut off and the electromagnetic brake

system will activate while you are driving down a steep slope. This will limit the speed to a

safe level. Turn the power on again to re-start your scooter.

Maximum User Weight Limit

Refer to section entitled ‘MAX. USER WEIGHT’in ‘7. SPECIFICATION’. Overloading past the

weight limit may lead to damage of your scooter or cause it to malfunction and endanger

your safety. The warranty does not cover this type of damage.

Attention

1. Do not push both RH & LH sides of the speed control lever simultaneously. This could

cause a lack of control of your scooter.

2. Do not turn the power switch to ‘OFF’while driving as this will lead to an emergency

stop and possible risk of accident or injury.

3. Do not set to the highest speeds while driving indoors.

4. Do not adjust the speed dial while driving; a sudden change in speed may cause danger

to you and others, and may damage to your scooter.

5. Do not place magnetic devices near the area of the operation handle as this could affect

the safe operation of your scooter.

6. Do be careful while driving in heavy traffic or crowded areas.

7. While reversing the vehicle, beware of people or objects behind you.

▓Stopping

1.Release the speed control lever completely. The vehicle will naturally brake and stop.

2.Turn the power switch to ‘OFF’. Then remove the key.

2.3 LABELLING

Carefully read all labels on the scooter before driving it. Do not remove these labels for future

reference.

1. CE LABEL …………………………………………………………

2. WARNING EMI LABEL…………………………………………

3. FREEWHEEL LABEL…………………………………….………..

3. PARTS INTRODUCTION

Parts Description

1. Power switch 2. Charger Socket Cover 3. Basket Bracket

4. Tiller Adjustment Knob 5. Wheel lock knob 6. Seat Remove knob

7. Circuit Breaker 8. Freewheel Lever 9. Anti-tip Wheel

10. Connecting device (remove cover)
