CDA SC621 Bedienungsanleitung
www.cda.eu
SC621
Single Oven
Installation, use and maintenance
2
Contents:
3 Important information
5 Important safety notes
6 Before first use
7 Notes on usage
7 Oven controls and use
10 Setting the time/clock
10 Minute minder
11 Semi-automatic cooking
12 Automatic cooking
13 Care and maintenance
14 Changing the oven lamp
15 Reversing the door
16 Removing the inner door glass
17 Troubleshooting
19 Installation
20 Oven and furniture dimensions
21 Mains electrical connection
23 Energy eciency information
3
Important
This appliance must only be used for the purpose for which it is
intended, i.e. domestic cooking. Any other use could be dangerous
and may lead to premature failure of the appliance.
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
User information:
• Ovens become hot during and immediately after use.
• The oven door can become very hot during operation.
• After use, please ensure that the oven switches are in the
‘O’ position.
• Keep children away from the appliance when in use, and
immediately after use.
• Keep the oven door closed whilst grilling.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
4
EU Declarations of Conformity:
This oven has been designed, constructed and marketed in
compliance with safety requirements of EU Directive 2014/35/EU (LVD)
and requirements of EU Directive 2014/30/EU (EMC).
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
and Electromagnetic interference compatibility (EMC). Parts intended
to come into contact with food conform to 1935/2004/EC.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.
At the end of its working life, the product must not be disposed of as
urban waste. It must be taken to a special local authority dierentiated
waste collection centre or to a dealer providing this service.
At the end of its working life, the product must not be disposed of as
urban waste. It must be taken to a special local authority
dierentiated waste collection centre or to a dealer providing this
service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving
from inappropriate disposal and enables the constituent materials to
be recovered to obtain significant savings in energy and
resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin.
5
Important
• Read the user instructions carefully before using the oven
for the first time.
• Follow the instructions for first use of the oven.
• Clean the oven regularly.
• Remove spills as soon as they occur.
• Always use oven gloves when removing shelves and trays
from the ovens.
• Do not allow children near the oven when in use.
• Do not allow fat or oils to build up on the oven shelves,
grill pan or oven base.
• Do not place any cooking utensils or plates directly on the
oven base.
• Always grill with the oven door closed.
• Do not grill food containing fat without using the grill pan
grid.
• Do not cover the grill pan grid or the oven walls with
aluminium foil.
• Do not use the oven tray for roasting.
• Do not perform maintenance or cleaning of the oven
without first switching o the electricity supply. If the oven
has recently been used, allow to cool.
• Do not place hot enamel parts in water. Leave them to
cool first.
• Do not allow vinegar, coee, milk, saltwater, lemon or
tomato juice to remain in contact with enamel parts.
• Do not use abrasive cleaners or powders that will scratch
the surface of the enamel.
6
• Do not attempt to repair the internal workings of your
oven.
• Do not cover the oven floor with aluminium foil.
First use of the oven
First use
•The metal casing of this appliance has been coated with a
preservative to protect it during transport and storage. This should
be removed during installation by using a non-abrasive stainless
steel cleaner. Always follow the instructions given with the cleaner
being used.
• Before using the oven for the first time we recommend that you
clean the oven with soapy water, rinse carefully and then heat
on each of the below programmes at maximum temperature for
the specified time. A slightly unpleasant smell may be produced,
caused by grease remaining on the oven elements from the
production process.
15 minutes grill.
60 minutes fan oven.
60 minutes conventional oven.
7
Please note:
• This oven has been fitted with a cooling fan to achieve maximum
eciency and to maintain low surface temperatures. The cooling
fan will switch on automatically when the oven switches on. It is
normal for the cooling fan to run for an hour or more after use,
depending on the duration, temperature and type of cooking
programme used.
• The oven light remains on for every cooking function.
• Do not switch o the oven if you have set a programme for semi-
automatic or automatic cooking as this will cancel the programme.
Oven controls and use
Temperature knob
• To set the temperature, turn the temperature knob clockwise to the
required temperature.
• Once the oven has reached the required temperature, the
temperature indicator lamp on the control panel will switch o.
• The temperature indicator lamp will light up when the oven
elements are in operation.
Cooking function knob
To set the function, turn the cooking function knob to the required
function.
Each of the oven functions uses dierent elements within the oven to
oer you the best choice of cooking every time. These are
explained below:
Please note, the oven light will operate on all functions.
8
Defrost
Using the fan only this oven function circulates the air
around the oven cavity, speeding up the natural defrost
process (1kg takes approximately one hour, depending on
the type of food).
Fan Oven
Using the circular element and the fan with a temperature
between 50C and 250C, this cooking function blows
the air into and around the oven cavity. Temperatures are
achieved quicker, reducing or even removing the need
for preheating. Both cooking temperatures and cooking
times can be reduced for a more energy ecient cooking
programme.
Fanned Grill
This function uses the fan to circulate the heat from the
grill element around the food.
The temperature can be set between 50C and 250C.
Full Grill
This function radiates the heat from the grill element and
the top element.
This fully temperature variable grill is ideal for grilling a
full family meal. It can be set between 50C and 250C
maximum.
9
For each grill function please note:
• Always grill with the oven door closed.
• Put the grill pan as close to the grill as possible.
• Do not grill for more than 30 minutes at a time.
• Preheat the grill for up to five minutes with the oven
door closed.
Warming Oven
Using heat produced only by the bottom element, this
natural heat is perfect for dough proving and blind-baking.
Fan Assisted Oven
Using the circular element and the fan with a temperature
between 50C and 225C, this cooking function blows
the air into and around the oven cavity. Temperatures are
achieved quicker, reducing or even removing the need
for preheating. Both cooking temperatures and cooking
times can be reduced for a more energy ecient cooking
programme.
Conventional Oven
This function uses the upper and lower heating elements
with a temperature between 50C and 240C.
Natural convection creates a perfect cooking zone in the
centre of the oven, ideal for dark fruit cakes and pastries.
10
Programming the Oven
Please note:
•
manually.
Setting the clock
The clock is preset to 12:00, and will revert to this after a power failure.
When the current time indicator is flashing, touch or . When
the correct time is shown on the display, the clock will set after
approximately five seconds’ delay.
To change the clock once it has been set, touch repeatedly until the
current time indicator flashes, then touch or . When the correct
time is shown on the display, the clock will set after approximately five
seconds’ delay.
The minute minder
It can be set for up to 23 hours and 59 minutes.
fig. 1
5 6 7
1 Cooking time indicator
2 End of cooking time indicator
3 Minute minder indicator
4 Current time indicator
5 Decrease key
6 Mode key
7 Increase key
1
2
3
4
