Checkpoint TE250X Bedienungsanleitung

CHECK POINT

TE100X/TE250X/ TE1000X/TE2000X

THREAT EMULATION PRIVATE CLOUD

APPLIANCES

Quick Start Guide

POWER UP YOUR CHECK POINT

TE100X/TE250X/TE1000X/TE2000X APPLIANCE

CONNECT YOUR PC FOR

INITIAL SETUP

• Connect the power cable to the power port on the TE100X/TE250X/TE1000X/

TE2000X appliance rear panel and plug it into a power outlet.

• Turn the power on.

• Initial setup must be done from a PC connected to the appliance’s MGMT

interface via the included Ethernet cable. After completing the initial

connection, the First Time Conﬁguration Wizard will guide you through the

process of conﬁguring the appliance.

• Before continuing, make sure your PC is conﬁgured correctly.

FOR WINDOWS 7 AND WINDOWS VISTA

OPERATING SYSTEMS

FOR WINDOWS XP OPERATING SYSTEMS

• Click

> Control Panel > Network and Internet

> Network and Sharing Center

> Manage network connections.

• Right-click Local Area Connection,

and then click Properties. If you are

prompted for an administrator password

or confirmation, type the password or

provide confirmation.

• Click the Networking tab.

Under This connection uses the following

items, click Internet Protocol Version 4

(TCP/IPv4), and then click Properties.

• In the IP address field, enter 192.168.1.2.

• In the Subnet mask field, enter 255.255.255.0.

• Leave the Default gateway and DNS settings fields empty.

• Click OK and close the dialog boxes.

Figure 1

Internet Protocol (TCP/IP) Properties

Figure 2

Internet Protocol (TCP/IP) Properties

• Click

> Settings > Control Panel

> Network Connections.

• Double-click Local Area Connection.

• In the General tab, click Properties.

• In the IP address field, enter 192.168.1.2.

• In the Subnet mask field, enter

255.255.255.0.

• Leave the Default gateway and DNS

settings fields empty.

• Click OK and close the dialog boxes.

CONFIGURE YOUR TE100X/TE250X/TE1000X/

TE2000X APPLIANCE

Figure 3

TE100X/TE250X/TE1000X/TE2000X Appliance

Figure 4: First Time Configuration

Wizard – Welcome Page

Figure 5: First Time Configuration

Wizard – Summary Page

• Launch the Web browser and type

https://192.168.1.1 in the address

bar.

Note – A certificate error will be

shown upon login. This is due to the

fact that default certificate is self-

signed. Select the option that allows

you to continue to the website.

Click Continue to this Web site.

• Log in with the default system

administrator login name/

password,

admin/admin, and click Login.

For additional information regarding setting up your appliance, refer to the

Check Point TE100X/TE250X or TE1000X/ TE2000X Appliances Getting

Started Guide.

Note – Popups must always be allowed on https://<appliance_ip_address>.

• After logging in for the first time and changing the default login name and

password, the First Time Configuration Wizard will begin automatically.

• The wizard will guide you through the connection setup process.

Fill in the parameters as required and click Finish.

REGISTRATION AND TECHNICAL SUPPORT

Appliance Registration

TE100X/TE250X/TE1000X/TE2000X appliances require a license to be installed

prior to operation.

To license and register your appliance, please visit:

http://register.checkpoint.com/cpapp

If you are evaluating TE100X/TE250X/TE1000X/TE2000X appliances, you will

have access to a 15-day evaluation license key.

Appliance User Center

For further information about the TE100X/TE250X/TE1000X/TE2000X

appliances, see:

https://usercenter.checkpoint.com/usercenter/login/cpapp.

For technical assistance, contact Check Point 24 hours a day,

seven days a week at:

+1 972-444-6600 (Americas)

+972 3-611-5100 (International)

P/N: 706475

WWW.CHECKPOINT.COM

Check Point, the Check Point logo and Smart-1 are trademarks or registered trademarks of

Check Point Software Technologies Ltd. or its affiliates. All other product names mentioned herein

are trademarks or registered trademarks of their respective owners. The products described in

this document are protected by U.S. Patent No. 5,606,668, 5,835,726, 6,496,935, 6,873,988, and

6,850,943 and may be protected by other U.S. Patents, foreign patents, or pending applications.

CHECK POINT

TE100X/TE250X/TE1000X/ TE2000X

THREAT EMULATION PRIVATE CLOUD

APPLIANCES

Quick Start Guide
