Chef's Choice D202 Bedienungsanleitung

DIAMOND HONE® KNIFE SHARPENER

D202

READ THESE INSTRUCTIONS BEFORE USE.

IT IS ESSENTIAL THAT YOU FOLLOW THESE

INSTRUCTIONS TO ACHIEVE OPTIMUM RESULTS.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should

always be followed including the following:

1. Read all instructions. Every user should read this manual.

2. To protect against electrical hazards, do not immerse the

Chef’sChoice®sharpener in water or other liquid.

3. Make sure that only clean knife blades are inserted in Model D202.

4. Disconnect the appliance from its power source when not in use,

before cleaning, during service and when replacing parts.

5. Avoid contacting moving parts.

6. Do not operate any appliance with a damaged cord or plug or

after the appliance malfunctions, or is dropped or damaged in

any manner.

U.S. customers: You can return your sharpener to The Legacy

Companies’ factory for service where the cost of repair or

electrical or mechanical adjustment can be estimated. When the

electrical cord on this appliance is damaged, it must be replaced

by the Chef’sChoice®factory or other qualiﬁed service to avoid

the danger of electrical shock.

Outside U.S.: Please return your sharpener to your local

distributor where the cost of repair or electrical or mechanical

adjustment can be estimated. If the supply cord of this appliance

is damaged, it must be replaced by a repair facility appointed

by the manufacturer because special tools are required. Please

consult your Chef’sChoice®distributor.

7. CAUTION! This appliance may be ﬁtted with a polarized power

plug (one blade is wider than the other). To reduce the risk of

electric shock, this plug will ﬁt in a polarized outlet only one way.

If the plug does not ﬁt fully in the outlet, reverse the plug. If it still

does not ﬁt, contact a qualiﬁed electrician. Do not modify the

plug in anyway.

8. Carefully route the power supply cord to avoid damage from the

knife blades while sharpening.

English — 2

9. The use of attachments not recommended or sold by The

Legacy Companies may cause ﬁre, electric shock or injury.

10.The Chef’sChoice®sharpener is designed to sharpen American,

European, and Asian style knives as described in following

sections. Do not attempt to sharpen scissors, ax blades or any

blade that does not ﬁt freely in the slots.

11. Do not let the cord hang over edge of table or counter or touch

hot surfaces.

12.When in the “ON” position (Red ﬂash on switch is exposed when

“ON”), the Chef’sChoice®sharpener should always be on a stable

countertop or table.

13.WARNING: KNIVES PROPERLY SHARPENED ON YOUR

Chef’sChoice®SHARPENER WILL BE SHARPER THAN YOU

EXPECT. TO AVOID INJURY, USE AND HANDLE THEM WITH

EXTREME CARE. DO NOT CUT TOWARD ANY PART OF YOUR

FINGERS, HAND OR BODY. DO NOT RUN FINGER ALONG

EDGE. STORE IN A SAFE MANNER.

14.Do not use outdoors.

15. Appliance is not intended to be used or cleaned by children or

persons with reduced physical, sensory or mental capabilities or lack

of experience and knowledge of the hazards involved.

16. Do not use honing oils, water or any other lubricant with the

Chef’sChoice®sharpener Model D202.

17. For household use only.

18. This appliance is intended to be used in household and similar

applications such as: - sta kitchen areas in shops, oces, and

other working environments; - farm houses; - by clients in hotels,

motels, and other residential type environments; - bed and breakfast

type environments.

SAVE THESE INSTRUCTIONS.

English — 3

English — 4

DESCRIPTION OF THE

CHEF’SCHOICE DIAMOND HONE® KNIFE SHARPENER

The sharpener has two sharpening Stages, a ﬁrst sharpening Stage that is motor driven,

followed by a honing Stage that is entirely manual in operation. The sharpening Stage 1 is

motor driven, has two slots (the two slots on the left) to sharpen alternately the left and

right side of the blade’s edge. Always follow an alternating pattern of sharpening in right

and left slots when using Stage 1. This dual-slot stage quickly establishes a sharp edge

that is then honed and ﬁnished in the manual second stage which uses only a single slot

(far right slot) that hones both sides of the edge simultaneously.

USING THE DIAMOND HONE® SHARPENER

Note: Always clean your knife before sharpening! For your safety, keep your ﬁngers clear

of the blade edge at all times.

You will ﬁnd that the sharpener can create and maintain sharp and eective edge on

all your conventional ﬁne edge and serrated knives. The primary edge facets are each

formed in Stage 1 at a nominal 20 degrees on each side of the edge, which results in a

total primary edge of 40 degrees. Stage 2 creates a second bevel at a slightly larger angle

leaving a strong double beveled edge structure that will stay sharp longer. Always use the

sharpener with the stage numbers 1 and 2, facing you.

STAGE 1

To sharpen, place the sharpener on the table gripping it securely with your left hand. Push

on the power switch. Insert the knife blade, Figure 1, near its handle, into the far left slot

of Stage #1 and allow the left face of the blade to rest on the left face of the slot as you

pull the knife toward you. The knife edge should be in sustained moving contact with the

internal diamond coated disk. Only light downward force will be necessary as you pull the

blade toward you. Listen carefully to insure your knife maintains good contact with the

diamond disk. Take about 5 seconds to make each pull if you have a six inch (6”)

long blade. Increase the time of each pull for longer blades or decrease the time for

shorter blades.

Figure 1. Inserting the blade in the left slot of

the Stage 1. Alternate individual pulls in left and

right slots.

Burr

Figure 2. Develop a distinct burr along knife edge

before honing in Stage 2. Burr can be detected by

sliding ﬁnger across and away from the edge.

Caution! See text.

English — 5

Make one pull of the blade in the left slot as described above and then repeat the same

procedure in the adjacent (right) slot of Stage 1. As you pull the knife thru the right slot,

(see Figure 3), allow the right side of the knife to rest on the right face of the slot. If your

knife, before sharpening, is not very dull you will ﬁnd that only about 5 pairs of pulls,

alternating in the left and right slots of Stage 1, will be sucient to put a keen edge on the

blade. However, if the knife is initially very dull you may ﬁnd that 10 or more alternating

pairs of pulls in the left and right slots of Stage 1 will be needed the ﬁrst time as you

reshape and sharpen the old edge. In Stage 1 always pull the blade toward you. Never

push the blade away from you when using Stage 1. Before leaving Stage 1 it is important to

examine the knife edge to insure there is a small burr along one side of the edge.

Figure 2 illustrates how to check for the burr. Proceed as follows: If your last sharpening

pull was in the right slot there should be a small burr on the right side of the blade edge.

If the last pull was in the left slot there should be a small burr along the left side of the

edge. If there is no burr make another pair of pulls and again check for a burr. Repeat

making pairs of alternating right and left pulls until you create a small burr along the edge.

(Sometimes it is easier to create the burr if you pull the blade slower.) Make another single

pull and conﬁrm there is a burr along the edge after each pull. Only then are you are ready

to hone in Stage 2.

STAGE 2

Since Stage 2 is a manual honing stage you can turn o the power switch. If the knife is

fully sharpened in Stage 1 only 5-10 back and forth strokes will be needed in the single slot

of Stage 2 (the far right slot, see Figure 4) to hone a small second bevel along the edge

which will be exceedingly sharp and eective. It should cut paper smoothly allowing you

to make straight or curved cuts easily.

For optimum results in Stage 2 center the blade within the slot width and keep the

length of the blade aligned with the center line of the slot as you move the blade back

and forth in the slot without lifting. Apply only a light downward pressure, about 3-4

pounds, on the blade as you sharpen in Stage 2. For optimum results make smooth

consistent strokes while maintaining the light downward pressure to insure that the two

disks rotate as you move the blade back and forth. The ﬁnished edge will be very sharp

and burr free.

Figure 3. Inserting the blade in the right slot of

Stage 1. Alternate pulls in left and right slots.

Figure 4. Knife in Stage 2. Use back and forth

sharpening strokes with modest downward

pressure. See text.

English — 6

RESHARPENING THE KNIFE EDGE

To resharpen follow the procedure for Stage 2 described above, making ten to twenty

(10-20) complete back and forth stroke pairs while maintaining recommended downward

pressure. Listen to conﬁrm the sharpening disks are turning. Then test the edge for

sharpness. If necessary resharpen again but ﬁrst use Stage 1 followed by ﬁve to ten (5-10)

back and forth pairs of strokes in Stage 2. Generally you should be able to resharpen

several times using only Stage 2 before having to resharpen in Stage 1.

SERRATED BLADES

Serrated blades can be sharpened in Stage 2 (see Figure 5). Center the blade in the slot of

Stage 2 and make twenty-ﬁve (25) back and forth pairs of strokes. Examine the edge and

if necessary make another 25 full stroke pairs. Test the blade for sharpness. If the blade

to be sharpened is very dull, ﬁrst make two fast but full pairs of pulls — alternating right

and left slots in Stage 1 and then make twenty-ﬁve (25) paired strokes (back and forth)

in Stage 2. Because of its nature, a serrated knife will not ever appear as sharp or cut as

smoothly as a straight edged blade. Caution: Do not make many strokes in Stage 1, or you

will remove too much metal from the teeth of the serrated edge.

ASIAN BLADES

The sharpener which sharpens at a primary angle of 20 degrees, can sharpen double

faceted Asian blades such as the Santoku which is traditionally sharpened at 15º.

However, for optimum results with all Asian blades we recommend a 15º sharpener such

as the Chef’sChoice®Electric Models 15XV or 1520 as the preferred choice for all Asian

style blades.

Do not sharpen in the sharpener any single sided, single faceted Asian Kataba knives,

such as the traditional sashimi styled blade that is commonly used to prepare ultra thin

sashimi. Stage 2 sharpens simultaneously both sides of the cutting edge while the sashimi

knives are designed to be sharpened only on one side of the blade. The Chef’sChoice

electric sharpeners listed in the previous paragraph will correctly sharpen these single

sided knives.

Figure 5. Serrated knife in Stage 2.

English — 7

CERAMIC KNIVES

The sharpener is not recommended for ceramic knives.

SCISSORS

Do not attempt to use the sharpener to sharpen scissors. The Legacy Companies does

manufacture special sharpeners designed just for scissors.

BRANDS OF KNIVES

The sharpener will put an excellent edge on all conventional metal Euro/American and

Santoku style knives regardless of brands, including Henckels, Wüsthof, Sabatier, Lamson

and Goodnow, Global, Russell Harrington, Forshner, Chef’sChoice, Messermeisser, Mundial,

Cuisinart, Kitchen Aid, Shun and many, many more.

TEST FOR SHARPNESS

To test for sharpness and cutting ability of your ﬁne edge knives, hold a sheet of paper

vertically by its upper edge and carefully cut down through the sheet a small (but safe)

distance from your ﬁngers. A sharp edge (on a straight edge blade) will cut smoothly

without tearing the paper.

Alternatively try cutting a tomato. The knife should penetrate the skin of the tomato

and cut through it on the ﬁrst pull without applying signiﬁcant force to the knife.

MAINTENANCE

• The exterior of the sharpener can be cleaned with a damp soft cloth.

• Periodically shake out and dispose of the metal sharpening dust by inverting

the sharpener and lightly tapping it onto a newspaper, paper towel, or other

paper sheet.

• No oils or other lubricating liquids are necessary with this sharpener.

English — 8

Made in the U.S.A. with U.S. and globally sourced materials. chefschoice.com

This product may be covered by one or more EdgeCraft patents and/or patents pending as marked on the

product. Chef’sChoice®, EdgeCraft®, and Diamond Hone®and are registered trademarks of EdgeCraft

Corporation, Avondale, PA.

Conforms to UL Std. 982 Certiﬁed to CAN/CSA Std. E60335-1/4E

Certiﬁed to EN 60335-1, EN 60335-2-14

K21 E/F/S C208209

The Legacy Companies

149 Cleveland Drive, Paris, KY 40361 U.S.A.

VEUILLEZ LIRE CES INSTRUCTIONS AVANT

TOUTE UTILISATION. IL EST ESSENTIEL QUE VOUS

RESPECTIEZ CES INSTRUCTIONS POUR OBTENIR DES

RÉSULTATS OPTIMAUX.

AIGUISEUR DE COUTEAUX DIAMOND HONE®

D202

MESURES DE

PROTECTION IMPORTANTES

Lors de l’utilisation d’un appareil électroménager, il est impératif

de toujours respecter des précautions de base, notamment les

précautions suivantes :

1. Lire le mode d’emploi en entier. Chaque utilisateur doit lire

ce manuel.

2. Aﬁn d’éviter les accidents d’origine électrique, ne plongez pas

l’aiguiseur Chef’sChoice®dans l’eau ou dans tout autre liquide.

3. Assurez-vous de n’insérer que des lames de couteau propres

dans l’aiguiseur.

4. Débranchez l’appareil de sa source d’alimentation lorsqu’il n’est

pas utilisé, avant le nettoyage, pendant le service et lors du

remplacement de pièces.

5. Évitez de toucher les pièces mobiles.

6. N’utilisez aucun appareil dont le câble ou la prise est

endommagé, ou si l’appareil ne fonctionne pas correctement,

est tombé ou est endommagé.

Clients aux États-Unis :Vous pouvez renvoyer votre aiguiseur à

la société The Legacy Companies pour sa maintenance, qui

pourra estimer le coût d’une réparation ou d’un réglage

électrique ou mécanique. Si le câble électrique de l’appareil

est endommagé, il doit être remplacé par un distributeur

Chef’sChoice®ou tout autre service qualiﬁé aﬁn d’éviter tout

risque d’électrocution.

Hors États-Unis : Veuillez retourner votre aiguiseur à votre

distributeur local qui pourra estimer le coût d’une réparation ou

d’un réglage électrique ou mécanique. Si le câble d’alimentation

de cet appareil est endommagé, il devra être remplacé par un

atelier agréé par le fabricant car l’utilisation d’outils spéciaux est

nécessaire. Veuillez contacter votre distributeur Chef’sChoice®.

7. ATTENTION ! Cet appareil peut être fourni avec une prise

électrique polarisée (l’une des ﬁches est plus large que l’autre).

Aﬁn de réduire le risque d’électrocution, cette prise ne pourra

être insérée dans une prise femelle que dans un seul sens. Si la

prise ne rentre pas complètement dans la prise femelle, essayez

de changer de sens. Si elle ne rentre toujours pas, veuillez

contacter un électricien qualiﬁé. Ne faites aucune modiﬁcation

sur la prise.

Français — 2

Inhaltsverzeichnis

Andere Chef's Choice Zubehör Handbücher

Chef's Choice

Chef's Choice Pronto Diamond Hone 463 Bedienungsanleitung

Chef's Choice

Chef's Choice 220 Bedienungsanleitung

Chef's Choice

Chef's Choice 476 Bedienungsanleitung

Chef's Choice

Chef's Choice 2100 Bedienungsanleitung

Chef's Choice

Chef's Choice Commercial Pronto Diamond Hone 465 Bedienungsanleitung

Chef's Choice

Chef's Choice Pronto Diamond Hone 463 Bedienungsanleitung

Chef's Choice

Chef's Choice EdgeCraft DC 220 Bedienungsanleitung

Chef's Choice

Chef's Choice Chef'sChoice Commercial Diamond Hone M2100 Bedienungsanleitung

Chef's Choice

Chef's Choice Hybrid AngleSelect Diamond Hone 290 Bedienungsanleitung

Chef's Choice

Chef's Choice DIAMOND HONE ULTRA Bedienungsanleitung

Chef's Choice

Chef's Choice Chef'sChoice 312 Bedienungsanleitung

Chef's Choice

Chef's Choice Diamond Hone 478 Bedienungsanleitung

Chef's Choice

Chef's Choice Diamond Hone 450 Bedienungsanleitung

Chef's Choice

Chef's Choice Angle Select 1520 Bedienungsanleitung

Chef's Choice

Chef's Choice Trizor XV Bedienungsanleitung

Chef's Choice

Chef's Choice EdgeCraft E120 Bedienungsanleitung

Chef's Choice

Chef's Choice Pronto Diamond Hone 463 Bedienungsanleitung

Chef's Choice

Chef's Choice EdgeSelect 120 Bedienungsanleitung

Chef's Choice

Chef's Choice Hybrid Diamond Hone 220 Bedienungsanleitung

Chef's Choice

Chef's Choice EdgeCraft DC 320 Bedienungsanleitung

Chef's Choice

Chef's Choice Pronto Diamond Hone 463 Bedienungsanleitung

Chef's Choice

Chef's Choice Angle Select 1520 Bedienungsanleitung

Chef's Choice

Chef's Choice Ceramic + Steel Diamond Hone 702 Bedienungsanleitung

Chef's Choice

Chef's Choice Diamond Hone 115 Bedienungsanleitung

Beliebte Zubehör Handbücher anderer Marken

Hillco

Hillco 2810 Bedienungsanleitung

Siemens

Siemens QSA2700D Bedienerhandbuch

Contours

Contours ZY024 Bedienungsanleitung

Saivod

Saivod VS621 Bedienungsanleitung

Virtuox

Virtuox VirtuCLEAN 2.0 Bedienungsanleitung

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Bedienungsanleitung

Z-Wave

Z-Wave HSD-200Z Bedienungsanleitung

turck

turck FMX-IM-2UPLI63FX Bedienungsanleitung

Decagon Devices

Decagon Devices 10HS Bedienungsanleitung

UPPAbaby

UPPAbaby Cup Holder Bedienungsanleitung

Elko

Elko SmartSensor Leakage Wireless Bedienungsanleitung

Grizzly

Grizzly H8371 Bedienungsanleitung

Panasonic

Panasonic HG-T Series Bedienungsanleitung

IFM Electronic

IFM Electronic Efector 250 Series Referenzhandbuch

DigiDesign

DigiDesign 888/24 I/O Bedienungsanleitung

PROZIS

PROZIS QUAY Bedienungsanleitung

patagonia

patagonia PSI Vest Bedienungsanleitung

SFC Energy

SFC Energy EFOY GO! Bedienungsanleitung
