Cypher Micro Cooler
Installation Guide v1.0
MOUNTING THE BASEPLATE
FILLING THE KETTLE
• Determine the best location to mount your system inside the car. If possible, keep your system away
from any heat sources to ensure maxium cooling eciency. Ensure there is a sucient gap between the
back of the unit so that the air can circulate freely.
Note: The Cypher Micro Cooler should be mounted in a horizontal state with a maximum tilt angle of 30°.
• Place the systems base platewhere you have decided to install it and use a sharpie to mark the holes
for installation into the vehicle.
• Drill out the holes so that you can install the rivnuts to the vehicle. Once the rivnuts are installed, you
can attach the base plate to the vehicle. Be sure to install the provided rubber isolators between the base
plate and the installed rivnuts to keep airow underneath the unit.
• With the base plate now installed, insert the system into the plate and secure with the 2 ball pin
connectors.
The Cypher Micro Cooler comes with an external kettle for the uid. The drivers shirt and kettle must be
lled with uid before the system is powered on.
• Unscrew the lid of the kettle and pour in your uid to just over 2/3’s of the kettles volume.
• If you are using Propylene Glycol solution, the volume of concentration should not exceed 25%. If other
antifreeze solution is used, its viscosity at 40°F / 25°C should not exceed 2.2mPa·s.
Note: Puried water is also suitable uid for the system if Chillout Systems Coolant Formula is not available.
• When turning on the Cypher for the rst time you will need to allow the internal pump cycle the uid
through the uid lines. Before connecting to your shirt allow the system to cycle through and discharge
the air in the tubing. This may take a few minutes.
When installing a NACA duct and plenum, consider using ChillOut Systems 4 inch ducting and plenums. With
nearly twice the airow as 3 inch ducting, this is the most ecient way to keep your system cool. In some cases 3
inch ducting may be the only option. In this case, the system must be paired with a in-line 3 inch blower that is
rated to 275 cfm..
• Place the NACA Duct where you have decided to install it and use a sharpie to trace an outline to the
vehicle. Once the outline has been traced onto your window, a rotary cutting tool can be used to cut out
the outline. We recommend using M4 nuts and bolts to secure the naca duct to a lexan window.
INSTALLING THE WIRING
• Connect the wiring harness to the system and run it to your electrical source. This can be directly to
the battery with an inline fuse or to a 40amp relay if you are using a switch for the install.
• Once you gure out the length of wire required you can trim the excess and connect it accordingly.
(Our wiring harness uses 8 AWG wire)
• Connect the remote wire to the system if you have purchased a remote. We recommend putting the
remote somewhere that sun won’t directly glare onto it (This can make it hard to read while driving).
