WARNING: Do not use the machine without reading this manual

OPERATION & MAINTENANCE

INSTRUCTIONS

GC0913

POWER WASHER

MODEL NO: JET 8000

PART NO: 7333500

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

INTRODUCTION

Thank you for purchasing this CLARKE Power Washer.

The machine has been designed to use hot or cold water to clean any

surfaces which can stand the force of the high pressure water jet and the

action of the detergents used.

The machine must only be used for the purpose for which it was designed.

Before attempting to use this product, please read this manual thoroughly and

follow the instructions carefully. In doing so you will ensure the safety of yourself

and that of others around you, and you can look forward to your purchase

giving you long and satisfactory service.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt which will be

required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or

tampered with in any way, or not used for the purpose for which it was

intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission.

This guarantee does not effect your statutory rights.

LIST OF CONTENTS

The following items should be supplied in the carton. If any parts are missing or

damaged, please see your Clarke dealer where you purchased the machine.

1 x Power Washer

1 x Gun Assembly

1 x Lance c/w fitted Pencil-Jet / Fan - High / Low Nozzle

1 x Hose Assembly on integral Hose-Reel

1 x Inlet Hose Adaptor

1 x Instruction Manual

1 x Accessory Adaptor

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

GENERAL SAFETY RULES

1. High pressure water jets can be dangerous if subject to misuse. They must

not be directed at animals or people.

2. NEVER allow children or untrained personnel to use this product.

3. NEVER operate the power washer with any covers removed.

4. NEVER attempt any electrical or mechanical repairs to this power washer.

Always refer to your Clarke dealer.

5. NEVER supply any liquid other than water to the water inlet.

6. Never use the detergent facility to introduce flammable liquids/solvents,

e.g. paint thinners, petrol, oil due to risk of explosion.

7. ALWAYS release any residual pressure in the machine by turning off the

water supply and operating the trigger, before disconnecting the hose.

8. ALWAYS keep the pressure washer itself dry and clear of water spray.

9. Never direct the spray jet at the pressure washer itself or any other

electrical equipment.

10. ALWAYS wear protective clothing, safety shoes and safety glasses. Loose

particles & other debris may be propelled at high speed by the water jet.

11. ALWAYS hold the spray gun firmly & expect the gun to ‘kick’ when starting.

12. ALWAYS disconnect from the water supply and ensure the machine is

completely drained when not in use. Store in a cool dry location.

13. Only use chemical cleaning agents (detergents), that are approved for

pressure washers. CLARKE Traffic Film Remover or CLARKE Wash and Wax

(available from your dealer), are recommended.

14. ALWAYS disconnect from the electrical power supply and remove the plug

from the socket before carrying out any maintenance.

15. ONLY use original spare parts from the Clarke service department.

16. High pressure hoses, fittings and couplings are important for the

safety of the machine. Use only hoses, fittings and couplings

recommended by the manufacturer.

17. NEVER use the pressure washer if the power cable or other

important parts of the power washer are damaged.

18.If an extension cable is used, the cable and plug must be of

watertight construction. Inadequate extension cables can be

dangerous.

WARNING: WATER AT HIGH PRESSURE CAN BE DANGEROUS AND CAN

CAUSE DAMAGE IF THE OPERATOR IS CARELESS. NEVER ALLOW ANYONE

TO OPERATE THIS MACHINE UNLESS THEY ARE FAMILIAR WITH THE SAFETY

PRECAUTIONS.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

SAFETY SYMBOLS

WARNING: Do not discharge the water

spray at persons or animals. Keep clear

of nozzle.

WARNING: Never direct spray toward

any electrical device or electrical

outlet.

Read Instructions before use.

Wear Eye Protection

Wear Gloves

Equipment covered by the European

WEE (Waste Electrical/Electronic)

Directive.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

ELECTRICAL CONNECTIONS

Before switching the product on, make sure that the voltage of your electricity supply is

the same as that indicated on the rating plate. This product is designed to operate on

230VAC 50Hz. Connecting it to any other power source may cause damage.

This product may be fitted with a non-rewireable plug. If it is necessary to change the

fuse in the plug, the fuse cover must be refitted. If the fuse cover becomes lost or

damaged, the plug must not be used until a suitable replacement is obtained.

If the plug has to be changed because it is not suitable for your socket, or due to

damage, it should be cut off and a replacement fitted, following the wiring instructions

shown below. The old plug must be disposed of safely, as insertion into a mains socket

could cause an electrical hazard.

• The wire which is coloured Blue must be connected to the terminal which is

marked Nor coloured Black.

• The wire which is coloured Brown must be connected to the terminal which is

marked Lor coloured Red.

• The wire which is coloured Yellow and Green must be connected to the

terminal which is marked E ( ) or coloured Green.

WE STRONGLY RECOMMEND THAT THIS MACHINE IS CONNECTED TO THE MAINS SUPPLY VIA A

RESIDUAL CURRENT DEVICE (RCD)

If in any doubt, consult a qualified electrician. DO NOT attempt any repairs yourself.

WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS

THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS

SUPPLY.

WARNING! The wires in the power cable of this product are

coloured in accordance with the following code:

Blue = Neutral Brown = Live Yellow and Green = Earth

Plug must be BS1363/A approved.

Always fit a 13 Amp fuse.

Ensure that the outer sheath of the cable is firmly held by the clamp

Neutral

(Blue) Live

(Brown)

Earth

(Green and Yellow)

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

OVERVIEW

1 Spray Gun Assembly 6 Detergent Container

2 Telescopic Handle 7 Mains Water Inlet

3 High pressure Hose 8 On/OFF Switch

4PowerCable 9 Lance

5 Reel Handle

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

BEFORE USE

Unpack your power washer and check to ensure all the items listed on page 2

are present.

UNFOLDING THE HOSE REEL HANDLE

1. Open the reel handle from its

folded position before use.

2. Release the hose from the

retaining clip on the hose reel,

then pull the hose from the reel to

unwind whatever length is

required.

• Winding the handle clockwise

will reduce the length of the

hose.

• If the spray gun/lance assembly is not attached, the hose can be

secured in the retaining clip when the hose is re-wound.

USING THE CARRYING HANDLE

1. Press and hold the centre button

on the telescopic handle to

unlock it.

• This will enable the handle to

extend and retract.

ASSEMBLING THE LANCE

The lance must be fitted to the gun

assembly before use.

1. Assemble by screwing the end of

the lance into the gun assembly.

2. Tighten the locking nut using a 22

mm spanner.

3. Slide the plastic cap into position.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

CONNECTING THE GUN TO THE HOSE

Connect the gun to the hose by

screwing on the connector and

tightening with a 17 mm spanner.

CONNECTING THE MAINS WATER SUPPLY

NOTE: Always follow any regulations of

your local water supplier.

1. Screw the inlet adaptor to the

water inlet as shown.

2. Connect the mains water supply

hose to the inlet adaptor. A

standard garden hose is suitable.

• It is recommended to use a

reinforced hose with an inner

diameter of at least 10 mm

available from your CLARKE

dealer.

• Ensure the water connection is secure.

NOTE: The water source must provide

a minimum of 6.6 litres per minute

at not more than 40°C.

FILLING WITH DETERGENT

If you intend to use detergent:

1. Remove the detergent filler cap

located at the rear of the pressure

washer and fill with detergent.

• The detergent level should be

visible through the window in

the back of the machine. (max

capacity 500ml)

2. Replace cap before use.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

3. Only use detergents recommended for use with pressure washers, such as

CLARKE Traffic Film Remover which is a powerful ‘low foaming’ agent for

car cleaning, patio cleaning etc., or CLARKE Wash & Wax, both available

from your CLARKE dealer.

• The use of unsuitable cleaning agents may adversely affect the safety of

the machine. Before use, refer to correct operating temperatures on

page 17.

ACCESSORIES

A range of accessories are available from your Clarke dealer including:

Accessories with bayonet style couplings such as those shown can be fitted to

the hose by means of the adaptor supplied.

DESCRIPTION SIZE PART NUMBER

Car Wash & Wax Shampoo 5 Litre 3050815

Concentrated Traffic Film Remover 5 Litre 3050821

Concentrated Traffic Film Remover 25 Litre 3050820

Ready To Use Traffic Film Remover 5 Litre 3050818

Ready To Use Traffic Film Remover 25 Litre 3050819

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

OPERATION

GETTING STARTED

1. Ensure that the water supply is correctly connected and turned on.

2. Plug the power cable into the

mains supply.

3. Release the trigger lock.

• The pressure washer is now

ready for use.

4. Press the start switch (‘I’).

5. Pull the trigger.

NOTE: When the trigger is pulled the

pressure of water will cause

the lance/gun assembly to

kick back suddenly.

6. When using the power washer for

the first time, let it run for a few

moments so that any air bubbles

or other impurities are discharged.

7. Release the trigger to stop the water flow.

• This pressure washer is fitted with an auto stop system to protect the

motor during use.

• When the trigger is released, the motor will stop. When the trigger is

squeezed the motor will start up again.

WARNING: FAILURE TO TURN ON THE WATER FULLY COULD CAUSE

DAMAGE TO THE POWER WASHER INTERNAL COMPONENTS.

WARNING: DO NOT USE THE POWER WASHER IF THE SUPPLY CABLE OR

IMPORTANT PARTS OF THE MACHINE ARE DAMAGED, E.G. SAFETY

DEVICES, HIGH PRESSURE HOSES, TRIGGER

WARNING: WE RECOMMEND THAT THIS MACHINE IS CONNECTED TO THE

MAINS SUPPLY VIA A RESIDUAL CURRENT DEVICE (RCD)

Inhaltsverzeichnis

Andere Clarke Hochdruckreiniger Handbücher

Clarke

Clarke JETSTAR 1900 Installations- und Betriebshandbuch

Clarke

Clarke Tiger 2600B Bedienungsanleitung

Clarke

Clarke TIGER 2600A Bedienungsanleitung

Clarke

Clarke JETSTAR 1750 Bedienungsanleitung

Clarke

Clarke JET 8000B Bedienungsanleitung

Clarke

Clarke Power Wash EHD130 Installations- und Betriebshandbuch

Clarke

Clarke PLS100FH Handbuch

Clarke

Clarke Power Wash ELS145 Installations- und Betriebshandbuch

Clarke

Clarke PLS130AH Installations- und Betriebshandbuch

Clarke

Clarke KING 200 Bedienungsanleitung

Clarke

Clarke JETSTAR 1800 Installations- und Betriebshandbuch

Clarke

Clarke JetKing 2000 Installations- und Betriebshandbuch

Clarke

Clarke Power Wash KING 135 Installations- und Betriebshandbuch

Clarke

Clarke ELS140 Installations- und Betriebshandbuch

Clarke

Clarke PLS130AH Installations- und Betriebshandbuch

Clarke

Clarke Power Wash PLS265A Bedienungsanleitung

Clarke

Clarke Power Wash EHD130 Installations- und Betriebshandbuch

Clarke

Clarke JETSTAR 1600 Installations- und Betriebshandbuch

Clarke

Clarke PLS195B Bedienungsanleitung

Clarke

Clarke CWG2 Installations- und Betriebshandbuch

Clarke

Clarke PLS195 Bedienungsanleitung

Clarke

Clarke PLV100LB Installations- und Betriebshandbuch

Clarke

Clarke PLV100LT Installations- und Betriebshandbuch

Clarke

Clarke JETSTAR 1700 Installations- und Betriebshandbuch

Beliebte Hochdruckreiniger Handbücher anderer Marken

Shark

Shark RG-232637 Bedienungsanleitung

Shakti Technology

Shakti Technology S3 Bedienungsanleitung

Kärcher

Kärcher K 4 Pure Bedienungsanleitung

Porter-Cable

Porter-Cable D25806-025-2 Bedienungsanleitung

REM POWER

REM POWER HDEm 662 Bedienungsanleitung

Landa

Landa HS-3000 Bedienungsanleitung

Craftsman

Craftsman 580.752270 Bedienungsanleitung

HIKOKI

HIKOKI AW 100 Bedienungsanleitung

Delco

Delco DC 1302 Bedienungsanleitung

Kärcher

Kärcher K 3 Full Control Bedienungsanleitung

BIEMMEDUE

BIEMMEDUE 120/10 - 170/13 Bedienungsanleitung

ARKSEN

ARKSEN 014-HG-14141-HR Bedienungsanleitung

Black & Decker

Black & Decker PW1700SPX Bedienungsanleitung

Kärcher

Kärcher 595 - SPARE Leitfaden

Kranzle

Kranzle B 10 200 Bedienungsanleitung

Stihl

Stihl RE 90 Bedienungsanleitung

Husky

Husky HU80911 Bedienungsanleitung

PowR-Quip

PowR-Quip PQ-2600 Bedienungsanleitung
