ClearCube Thin Client CD8831 Bedienungsanleitung

CD8831 Thin Client

ClearCube Technology, Inc.

www.clearcube.com

(866) 652-3500

1 of 5

Front

Overview

Package

Contents

•CD8831 thin client

•Power adapter and power cable

Continued on next page

Rear

Thin Client

Features

The pictures below show CD8831 thin client features.

Power Button

USB 2.0 Ports

Audio In

Audio Out

RJ45 LAN Port

USB 2.0 Ports

USB 3.0 Ports

DVI-I

DVI-D

DC Jack

CD8831 Thin Client

ClearCube Technology, Inc.

www.clearcube.com

(866) 652-3500

2 of 5

Network Infrastructure

Ethernet

Thin Client with

Monitors and

Peripherals

Chassis with

Blades

and VMs

Overview, Continued

Thin Client

Architecture

Overview

A thin client is a remote computing device that connects a user’s monitors, keyboard,

mouse, speakers, and other peripherals to remote PC blades (computers) and to

virtual desktops (VMs). As shown below, computing resources are typically located

in remote data centers.

Using a remote connection protocol, thin clients enable users to work on a blade or

VM as if it is a local PC. See the documentation for the remote protocol application

that you use for additional information.

CD8831 Thin Client

ClearCube Technology, Inc.

www.clearcube.com

(866) 652-3500

3 of 5

Thin Client Setup

Safety and

Precautions

•Always mount the thin client vertically.

•Do not install the thin client in areas where it can become wet or be

exposed to water.

•Only use the power cord shipped with the thinclient.

•Ensure there is four inches of space surrounding the thin client.

Inadequate ventilation can damage thedevice.

Setting up a

Thin Client

The steps below show how to set up a thin client.

Step

Action

Carefully unpack the thin client and components. Ensure that you

have the following items:

•Power cord and adapter (included)

•USB mouse

•USB keyboard

•DVI-D monitor, DVI-I monitor, or both

Place the thin client vertically as shown on page 1.

Connect a USB keyboard and mouse to the thin client.

Connect an Ethernet cable to the Ethernet port on the rear of the thin

client and to the Ethernet port on the remote compute device or

network device.

Optionally, connect any peripherals to the thin client. If you

purchased a thin client with an internal WLAN card, attach the

included antenna to the rear of thin client.

CD8831 Thin Client

ClearCube Technology, Inc.

www.clearcube.com

(866) 652-3500

4 of 5

NOTE: Change administrator password immediately after logging in. You can

specify a new password using the Configuration Wizard.

Thin Client Setup, Continued

Setting up a

Thin Client

(continued)

You can now use remote connection software to connect to a remote computing device.

BIOS Hotkey

To access the BIOS, press the ESC key when prompted as the ClearCube splash

screen appears.

User Accounts Depending on configuration, thin clients include a Windows operating systemor

ClearCube Cloud Desktop OS.

Windows:

The thin client boots to the Administrator user account. The default Administrator

password is admin. The default user password is user.

NOTE: Change administrator and user passwords immediately after loggingin.

Cloud Desktop OS:

The thin client boots to the user account and displays the Configuration Wizard the

first time you power on the thin client. The default password is admin (case-sensitive).

Step

Action

Connect the included power cord and AC adapter, and then plug the

adapter into the rear of the thin client. Continue by plugging the power

cord into an AC power outlet.

Power on the thin client by pressing the power button on the front of

the thin client.

CD8831 Thin Client

ClearCube Technology, Inc.

www.clearcube.com

(866) 652-3500

5 of 5

WEEE Disposal Guidelines

In the European Union, this electronic product falls under the European Directive (2002/96/EC) WEEE. When

it reaches the end of its useful life or is no longer wanted, dispose of it at an approved, designated recycling

or treatment facility. Check with your local authorities for proper disposal instructions. For assistance, contact

ClearCube at [email protected].

Resources and Support

Additional

Information

CD8831 User Guide shows how to configure, operate, and troubleshoot the

CD8831 Thin Client.

Cloud Desktop OS Quick Start Guide describes how to configure, use, and deploy

the Cloud Desktop operating system. All product documentation is available from

the ClearCube Support site (see address below).

Contacting

Support

Website: www.clearcube.com/support

Email: support@clearcube.com

Phone: (512) 652-3400

Toll-free: (866) 652-3400
