Commell LP-150 Bedienungsanleitung

LP-150

ARM Pico-ITX Motherboard

User’s Manual

Edition 1.2

2018/05/21

LP-150 User’s Manual

-1-

The information in this document is subject to change without prior notice to make

improvements to the products.

This document contains proprietary information and protected by copyright. No part of this

document may be reproduced, copied, or translated in any form or any means without prior

written permission of the manufacturer.

All trademarks and/or registered trademarks contains in this document are property of their

respective owners. Disclaimer

The company shall not be liable for any incidental or consequential damages resulting from

the performance or use of this product.

The company does not issue a warranty of any kind, express or implied, including without

limitation implied warranties of merchantability or fitness for a particular purpose.

The company has the right to revise the manual or include changes in the specifications of

the product described within it at any time without notice and without obligation to notify any

person of such revision or changes.

Trademark

All trademarks are the property of their respective holders.

Any questions please visit our website at TUhttp://www.commell.com.twUT

LP-150 User’s Manual

-2-

Packing List:

Please check the package content before you starting using the board.

Optional:

1 x LP-150 Motherboard

1 xDC Input Power Cable

(OALDC-B / 1040513)

1 x Audio cable

(OALPJ-HDUNB / 1040123)

1 x Dual COM cable

(OALES-BKU2NB / 1040090)

LP-150 User’s Manual

-3-

Index

Chapter 1 <Introduction> .............................................. 4

1.1 <Product Overview> .............................................................................................4

1.2 <Product Specification>........................................................................................5

1.3 <Block Diagram>...................................................................................................6

Chapter 2 <Hardware setup> ........................................ 7

2.1 <Connector Location and Reference> ..................................................................7

2.1.1 <Internal connectors list> ........................................................................8

2.1.2 <External connectors list> ........................................................................8

2.2 <I/O Interface> .....................................................................................................9

2.2.1 <Audio Interface>.....................................................................................9

2.2.2 <Debug Interface>..................................................................................10

2.2.3 <RTC Interface> ......................................................................................10

2.2.5 <Expend GPIO Interface> .......................................................................11

2.2.6 <UART Interface> ...................................................................................12

2.2.7 <RS-232 Interface>.................................................................................13

2.2.8 <Push Button>........................................................................................14

2.2.9 <CVBS Interface>....................................................................................14

2.2.10 <Touch Panel Interface>.......................................................................15

2.2.11 <FPC Touch Interface> Shared with J27 ...............................................15

2.2.12 <LVDS Interface> ..................................................................................16

2.2.13 <FPC LCD Inverter Interface> Shared with J35 .....................................17

2.2.14 <LCD Inverter Interface> ......................................................................18

2.2.15 <Power supply>....................................................................................19

Contact information..................................................... 20

LP-150 User’s Manual

-4-

Chapter 1 <Introduction>

1.1 <Product Overview>

LP-150 is a Pico motherboard that based on Rockchip RK3128 high performance

Quad-core application processor to implement most useful features and functionalities of

this integrated processor. This motherboard is designed to be a development board for

customers to implement and verify their applications for RK3128 features.

The RK3128 Quad-core Cortex-A7 is integrates with separately Neon and FPU coprocessor,

also shared 256KB L2 Cache. Mali400 MP2 GPU is embedded to support smoothly

high-resolution (1080p) display and mainstream game.

Lots of high-performance interface to get very flexible solution, such as multi-pipe display

with HDMI1.4, TV Encoder. Crypto hardware is integrated for support security BOOT. 32bits

DDR3/LPDDR2 provides high memory bandwidths for high-performance.

The device enables OEMs and ODMs to quickly bring to market devices featuring robust

operating systems support, rich user interfaces, and high processing performance life

through the maximum flexibility of a fully integrated mixed processor solution.

The Cortex-A7 processor builds on the energy-efficient 8-stage pipeline of the Cortex-A5

processor. It also benefits from an integrated L2 cache designed for low-power, with lower

transaction latencies and improved OS support for cache maintenance. On top of this there

is improved branch prediction and an improved memory system performance, with 64-bit

load-store path, 128-bit AMBA4 AXI buses and increased TLB size (256 entry, up from 128

entry for Cortex-A9 and Cortex-A5), increasing performance for large workloads such as

web browsing.

In a 28nm process, the Cortex-A7 can run at 1.2-1.6GHz, has an area of 0.45mm2 (with

Floating-Point Unit, NEON and a 32KB L1 cache) and requires less than 100mW of total

power in typical conditions. This lowest performance profile makes it an ideal standalone

processor for a range of mobile devices, and means the Cortex-A7 can ultimately deliver

similar performance to the Cortex-A9 processor at much higher levels of power efficiency.

LP-150 User’s Manual

-5-

1.2 <Product Specification>

System

Processor

Rockchip RK3128 Quad-core Cortex-A7

Speed

[email protected] GHz

Memory

512MB DDR3

Real Time Clock

Integrated RTC onboard

GPU

Mali400 MP2 GPU is embedded

Display

HDMI

Integrated HDMI 1.4 output up to 1080P

Display

Default 1024x600 LVDS LCD panel

Display Interface

Default Capacitive 1024x600 touch screen

Software

Compatible with Android 4.4.4

I/O

Flash Support

1 x 8GB onboard eMMC, 1 x Micro SD card slot

Audio

Rk3128 Built-in Stereo Audio CODEC

LAN

RTL8211E Ethernet Transceiver

Internal I/O

1 x Pin header for RS232 x 2, 1 x Pin header for UART x 3

1 x LVDS panel connector, 1 x LVDS inverter connector,

1 x Pin header for expand GPIO, 1 x RTC battery

1 x Audio pin header for line-out and MIC-in

1 x system reset, power LED

External I/O

1 x Micro SD card slot, 1 x HDMI port, 1 x USB Host 2.0 ports

1 x USB OTG 2.0 port, 1 x RJ-45 LAN port, 1 x CVBS Input

1 x 5V DC-in power

Mechanical & Environmental

Power Requirement

DC INPUT 5V

Size & Thickness

100mm x 72mm (L x W)

Temperature

Operating within 0°C~70°C (32°F~158°F)

Storage within -20°C~80°C (-4°F~176°F)

Relative Humidity

10%~90%, non-condensing

LP-150 User’s Manual

-6-

1.3 <Block Diagram>

CPU

Apollo Lake

SoC

HDMI

LVDS

TP+INV

USB HOST

USB OTG

Micro SD

WIFI

ETHERNET

LVDS

AP6181

RTL8211E

POWER

HOST

OTG

RTC Battery

CVBS IN

COM x2

(RS232)

UART x3

ADV7180

WK2204

SP3223

CIF

UABT0

UART0

UART1

AUDIO

EX GPIO

SN7325

I2C0

Main board

LP-150 User’s Manual

-7-

Chapter 2 <Hardware setup>

2.1 <Connector Location and Reference>

(J40) AUDIO

(J21) 5V_IN

(J27) TOUCH

(J35) LVDS

(J28) Debug

(J38) UART

(J36) RS232

(J24) RTC Header

(SW3) RESET

(SW5) PWR_KEY

(J2) OTG

(J10) LCD

(J32) TOUCH

(J26) INV

(U16) RTC-Holder

Top View

Bottom View

(J41) EX_GPIO

(J22) AV IN

LP-150 User’s Manual

-8-

2.1.1 <Internal connectors list>

Connector

Function

J21

2-pin power input Terminal Block (5V Only)

J22

2-pin AV IN pin header

J27

6-pin Touch panel connector

J35

20 x 2-pin LVDS connector

J40

5 x 2-pin AUDIO pin header

J38

9 x 2-pin UART pin header

J41

10 x 2-pin External IO pin header

J36

10 x 2-pin RS-232 pin header

SW5

Power button

SW3

Reset button

J24

2-pin RTC battery pin header

J28

2-pin DEBUG pin header

U16

RTC Battery holder

J10

40-pin FPC LCD panel connector

J32

6-pin FPC Touch panel connector

J26

5-pin LCD inverter connector

2.1.2 <External connectors list>

Connector

Function

J30

RJ45 LAN connector

Micro SD connector

HDMI connector

USB

USB Host 2.0 connector

J6202

WiFi SMAAntenna connector

USB OTG 2.0 connector

(J30) LAN

(J3) Micro SD

(J4) HDMI

(USB)

USB2.0

WIFI ANT

(J6202)

Rear I/O

LP-150 User’s Manual

-9-

2.2 <I/O Interface>

2.2.1 <Audio Interface>

J40: Front panel audio 10-pin header (Pitch 1.27mm x 2.54mm)

Signal

MIC_IN-

GND

MIC_IN+

HP_OUTR

HP_OUTL

J40 (AUDIO)
