Crossover M
Building instructions
www.creative-products.nl
Crossover M
Building instructions
www.creative-products.nl
While building, the structure has to be lifted multiple times so that the assembly can easily be done on oor
level. The structure is designed for two lifting methods:
1. Lifting from below (for example with a traverse lift) by using the subframe. Requirements lifting device:
• minimum lifting height: 4,2 meter
• minimum save working load: 225kg
2. Lifting from above (for example with a crane) by using lifting slings (2 meter, 1000 KG) and the hooks of the
X-connectors
LIFTING
Note: this lifting methode
requires more height for building
!
Tension cable
2x per X-connector
CS-0245
Use the 2 inner eyes
of the X-connectors
!
Mount the rst end of the 8 tension cables
STEP 4
