Crestron 4 Series Bedienungsanleitung

ZUM-HUB4

4-Series™ Control Processor for Zūm®

Lighting Control System

Product Manual

Crestron Electronics, Inc.

Original Instructions

The U.S. English version of this document is the original instructions.

All other languages are a translation of the original instructions.

Crestron product development software is licensed to Crestron dealers and Crestron Service Providers (CSPs) under a

limited nonexclusive, nontransferable Software Development Tools License Agreement. Crestron product operating

system software is licensed to Crestron dealers, CSPs, and end-users under a separate End-User License Agreement.

Both of these Agreements can be found on the Crestron website at www.crestron.com/legal/software_license_

agreement.

The product warranty can be found at www.crestron.com/warranty.

The specific patents that cover Crestron products are listed at www.crestron.com/legal/patents.

Certain Crestron products contain open source software. For specific information, visit www.crestron.com/opensource.

Crestron, the Crestron logo, 4-Series, Cresnet, XiO Cloud, Crestron Toolbox, SIMPL+, and Zūm are either trademarks or

registered trademarks of Crestron Electronics, Inc. in the United States and/or other countries. BACnet is either a

trademark or registered trademark of American Society of Heating, Refrigerating and Air-Conditioning Engineers, Inc. in

the United States and/or other countries. Bluetooth is either a trademark or registered trademark of Bluetooth SIG, Inc.

in the United states and/or other countries. Active Directory is either a trademark or registered trademark of Microsoft

Corporation in the United States and/or other countries. UL is either a trademark or registered trademark of UL LLC in

the United States and/or other countries. Other trademarks, registered trademarks, and trade names may be used in

this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any

proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or

photography.

Contents

Overview 1

Features 2

Zūm Net Wired Technology 2

Web-Based Management 2

Time Clock 2

BACnet™ Communications Protocol 3

Crestron XiO Cloud® Service Integration 3

Zūm Wireless Integration 3

Zūm System Integration with Other Crestron Control Systems 3

Physical Description 4

Specifications 6

Product Specifications 6

Dimension Drawings 9

Installation 10

Mount to a Rack 10

Place onto a Flat Surface 10

Make Connections 10

Configuration 13

Zūm App Configuration 13

Zūm App Main Screen 13

Calibrate Daylighting Settings 18

Log into the Web-Interface 22

Web Interface Overview 23

Category View, System View, and Settings View 24

Global Settings and Actions for the ZUM-HUB4 25

Navigation Toggle 26

Device Information and Status 26

Web Interface Configuration 26

Discover Rooms 27

Add a Room Category 28

Rename a Room Category 28

Turn Rooms On or Off 28

Set the Bluetooth PIN 30

Configure the Demand Response Mode and Level 33

Manage Rooms 37

Schedule Room Behavior 41

Manage Floors 49

Manage Devices 50

Product Manual — Doc. 9094B Contents • i

Manage Settings 54

Manage Users 58

Manage External Controls 60

Manage Commissioning 63

Review Device Information and Status 66

Reboot ZUM-HUB4 67

ii • Contents Product Manual — Doc. 9094B

iii • Contents Product Manual — Doc. 9094B

Product Manual — Doc. 9094B ZUM-HUB4 • 1

Overview

The Crestron® ZUM-HUB4 enables centralized management for Zūm® commercial lighting

systems of up to 1,000 rooms with an Ethernet switch (sold separately) across Zūm wired, Zūm

wireless, and external spaces. The device provides a web-based user interface for control. A

built-in time clock enables room lighting and occupancy and vacancy sensing automation. The

ZUM-HUB4 can also be integrated with other Crestron lighting systems and control systems.

The ZUM-HUB4 is featured in three kits.

lZUML-HUB4-GW: 4-Series™ Control Processor for Zūm® Lighting Control System with

Wireless Gateway and Power Supply

Contains:

oZUM-HUB4 and PW-2420RU power pack

oZUMNET-GATEWAY: Zūm® Net Wireless Gateway for Zūm Light Control System

oPW-2407WU: Wall Mount Power Pack, 24VDC, 0.75A, 2.1 mm, Universal

For use with the ZUMNET-GATEWAY

lZUML-HUB4-PAK: Zūm® Lighting Control Processor Panel, Basic

Contains:

oZUM-HUB4 and PW-2420RU power pack

oCEN-SW-POE-5: 5-Port PoE Switch

oGLEX-FT-24-HC: Feed-Through Enclosure, 24 Circuits, Hinged Cover

lZUML-HUB4-CN-PAK: Zūm® Lighting Control Processor Panel, Expanded

Contains:

oZUM-HUB4 and PW-2420RU power pack

oDIN-AP4: 4-Series™ DIN Rail Control System

oDIN-EN-6X18: Enclosure for DIN Rail Devices, 6 DIN Rails, 18 M Wide

oCEN-SW-POE-5 (x2): 5-Port PoE Switch

oDIN-HUB (x2): DIN Rail Cresnet Distribution Hub

oDIN-PWS60 (x2): DIN Rail 60 Watt Cresnet® Power Supply

For use with the DIN-HUB

•Features

•Physical Description

2 • ZUM-HUB4 Product Manual — Doc. 9094B

Features

lCentralized management for Zūm® commercial lighting systems

lProvides web-based user interface for easy configuration, control, scheduling, and

monitoring

lTime clock for room lighting automation and sensing behavior

lDaisy-chain up to 20 Zūm Net load controllers (sold separately) via their built-in Zūm Net

ports for room-to-room communication

lUse with an Ethernet switch (sold separately) to support multiple Zūm Net daisy-chains

up to 1,000 rooms

lDaisy-chain up to 32 Zūm Link devices (sold separately) via their built-in Zūm Link ports for

in-room communication

lBACnet™ communication supports control for up to 9,000 BACnet objects

lDedicated Control Subnet

lGigabit Ethernet networking

lEnterprise-grade security

lEnables integration with other Crestron lighting systems, control systems, touch screens,

shading, HVAC, and more

lSingle-space rack-mountable

lUniversal 100–240V external power supply

Zūm Net Wired Technology

Zūm Net wired technology offers room-to-room communication. Control a room with one Zūm

Net device (ZUMNET-JBOX-DALI,ZUMNET-JBOX-16A-LV, sold separately), and daisy-chain up

to 20 Zūm Net devices with CBL-CAT5E-ZUMNET-P cable. For centralized management of a

Zūm Wired System, connect the chain directly to a ZUM-HUB4 or multiple chains to an Ethernet

switch (sold separately) to support up to 1,000 rooms.

Web-Based Management

The web browser user interface can manage, monitor, and schedule all of the available rooms on

the network. Use a laptop computer (not included) to configure devices to work with the

ZUM-HUB4. Active lighting scenes, daylight levels, occupancy detection, and scheduled time clock

events are displayed. Errors are shown to facilitate troubleshooting.

Time Clock

A built-in time clock enables automated lighting control based on the time of day. Assign a Room

Category (such as Office or Hallway) for consistent control and programming across multiple

rooms. The clock allows Day Pattern arrangement for each Room Category, with up to 24 Room

Product Manual — Doc. 9094B ZUM-HUB4 • 3

States scheduled over a 24 hour period. Different Day Patterns can be defined and assigned to

the calendar, which is pre-populated with typical day patterns and a selection of U.S. holidays.

BACnet™ Communications Protocol

Communicate with a Building Management System (BMS) to provide control of fire/life safety,

lighting, and other building automation systems. The ZUM-HUB4 supports up to 9,000 BACnet

objects.

Crestron XiO Cloud® Service Integration

Use Crestron XiO Cloud functionality for remote commissioning and monitoring of a Zūm Wired

system. Commissioning and monitoring can also be accomplished through custom programming.

Zūm Wireless Integration

Integration with existing Zūm Wireless installations is achieved with a ZUMNET-GATEWAY (not

supplied), which connects to the ZUM-HUB4 via Ethernet.

Zūm System Integration with Other Crestron

Control Systems

In addition to managing rooms equipped with Zūm lighting control, the ZUM-HUB4 enables

integration with other Crestron systems over an Ethernet connection. Two methods of

integration are available:

lExternal Rooms: A virtual room using legacy or conventional Crestron lighting control can

be added to the Zūm network to be monitored, controlled and scheduled.

lMirrored Rooms: An external Crestron system controls and monitors a room equipped

with a Zūm system. Mirrored rooms allow for room control with a Crestron touch screen or

handheld remote, as well as integration with shading, climate control, AV, and other

equipment.

4 • ZUM-HUB4 Product Manual — Doc. 9094B

Physical Description

Connectors and Card Slots

MEMORY (1) SD memory card slot;

Accepts one 32 GB SD or SDHC card to enable logging and for troubleshooting

purposes

USB (1) USB Type A connector, female;

USB 2.0 host port (not used)

LAN (1) 8-pin RJ-45 connector, female;

10Base-T/100Base-TX/1000Base-T Ethernet port;

Connects to the customer’s LAN

CONTROL SUBNET (1) 8-pin RJ-45 connector, female;

10Base-T/100Base-TX/1000Base-T Ethernet port;

Provides a dedicated local network for Zūm Net wireless gateways

NET (1) 4-pin 3.5 mm detachable terminal block;

Not used

24VDC 2.0A (1) 2.1 x 5.5 mm DC power connector;

24VDC power input;

PW-2420RU power pack included;

Passes through to NET port

G(1) 6-32 screw;

Chassis ground lug

COMPUTER (front) (1) USB Type B connector, female;

USB 2.0 device port for configuration via computer console (cable included)

Controls and Indicators

Product Manual — Doc. 9094B ZUM-HUB4 • 5

PWR (1) Green LED;

Indicates operating power supplied from the included power pack

NET (1) Amber LED;

Not used

MSG (1) Red LED;

Indicates that the ZUM-HUB4 has generated an error message

HW-R (1) Recessed pushbutton for hardware reset

SW-R (1) Recessed pushbutton for software reset

LAN (rear) (2) Bi-color green/amber LEDs;

Left LED indicates Ethernet link status and connection speed;

Right LED indicates Ethernet activity

CONTROL SUBNET

(rear) (2) Bi-color green/amber LEDs;

Left LED indicates Ethernet link status and connection speed;

Right LED indicates Ethernet activity
