Cybex Pro+ Treadmill Service Manual
Service
Page 4-2
! WARNING: All maintenance activities shall be performed by qualified personnel.
Failure to do so could result in serious injury.
For any service related concerns, call Cybex
Customer Service at 888-462-9239 (for Cybex
customers living within the USA). For customers
living outside the USA, call 508-533-4300 or fax
508-533-5183.
NOTE: Read and understand each procedure
thoroughly before servicing. Unless
otherwise noted “right” and “left” denote
user orientation for all procedures.
Test Mode
To enter Test Mode press and hold down any key
on the display while turning the power switch to the
on (I) position. When all keys are released “PRO”
and the software revision “rx.x” are shown on the
display. To exit Test Mode press Stop.
Stuck Key List
If Test Mode occurs without holding any keys, a key may be stuck closed or Error 7 may have occurred.
You may need to replace the upper and/or lower display overlay. See Figure 1. If “KEY#” is displayed you
can determine which key is stuck closed by referring to the number list below.
Upper
Overlay
Lower
Overlay
Figure 1
1 Stop
2 Incline Down
3 Speed Down
4 Weight
5 Distance
7 Heart Rate
8 Manual Up
9 Incline
10 Speed Up
11 Quick Start
12 Center Up
13 9 Holes
14 Level
15 Mets
16 5K
17 Enter
18 Cardio
19 Center Down
20 Calories
21 HR Control
22 Time
23 Scan
24 Age
25 Min Mi/Km
26 Weight Loss
Cybex Pro+ Treadmill Service Manual
Service
Page 4-3
LED Functions
LEDs are used to indicate the status of many of the treadmill inputs. After entering Test Mode refer to the
following list to check that these LEDs are functioning properly:
Heart LED – Blinks on with every signal from the contact heart rate receiver.
Weight LED – Blinks on when CSAFE data is being received.
Level LED – Blinks on when CSAFE data is being transmitted.
Lower Left Window – The numbers indicate actual elevation. A '-' sign indicates the treadmill is below
0% grade. The decimal point before the numbers shows the activation of the 0% switch in the elevation
motor (on above 0%). If dashes are shown in the display, the treadmill is either above or below the 0%
switch, requiring it to be manually run through the switch to begin indicating actual elevation. The right
most decimal point indicates the status of the E-stop relay, on when the E-stop relay is on, off when it
is deactivated. NOTE: The right most decimal point may be difficult to see. Lean your head to the left
to see this.
Lower Right Window – The numbers indicate actual belt speed. The right most decimal point indicates
the pulses from the speed sensor on the motor.
Key Functions
While in Test Mode press the following keys for desired information:
Quick Start – Starts the belt at 1.0 mph (1.0 kph). Also will run calibration if held for 3 seconds.
Heart Rate Program key – Lights all of the LEDs for a short period of time.
Weight Loss key – Lights only the columns.
9 Holes key – Lights only the rows.
Incline – Run elevation motor up.
Incline – Run elevation motor down.
Speed + – Increase drive motor speed.
Speed - – Decrease drive motor speed.
Distance – Press once for odometer information (DST) to appear in the speed window.
Press again for hourmeter information (HRS) to appear in the speed window.
Press three times for number of starts information (USES) to appear in the speed window.
Press four times for brush wear mileage up to 100 miles since activated or “0” if it has not been
activated (BRSH).
Min Mi/Km – Displays and cycles through error log. Up to 10 errors can be stored.
Scan – Clears error log when pressed twice while in error log mode.
Mets – Value of motor load inA/D counts. The number range is relative to motor current and goes
from 0-225. (LOAD).
Calories – Displays motor pulse width (PWM) value.
Enter – Required to save setup values.
Cybex Pro+ Treadmill Service Manual
Service
Page 4-4
Error Codes
Error codes notify you of a problem condition and are displayed on the center of the console. These
codes can also help to indicate the part of the treadmill most likely to be causing the problem. Errors that
present a hazard to the user provide a measure of safety by causing a one second beep, stopping the
treadmill and locking out operation of the treadmill.
A log of errors can be viewed and cleared. Enter Test Mode and press the Pace (Min/km) key to display
the log. The most recent error is always first in the log. Press the Pace key again to cycle to the next the
error stored. Up to 10 errors can be stored. Press the Scan key twice to clear the error log. Press Stop to
exit Test Mode.
NOTE: A processor upset can cause a bAd#. See H then G.
Error Description
bAd0 Bad checksum. See H then G.
bAd2 Internal RAM error. See H then G.
bAd3 Watchdog timeout. See H then G.
Err1 Belt didn't start (or no speed sense). See I, E, D, B then A.
Err2 Underspeed (2 mph for 2 seconds without correction in process). See I, E, C then B.
Err3 Speed sense lost. See I, E, A, B and C.
Err5 No 0 switch sense within timed limits. This is declared when the timed
elevation reaches -2% without tripping the index. See F and A.
Err6 Overspeed (1 mph for 1 second or 2 mph for 0.2 seconds without
correction). See I, E.
Err7 EEPROM error (memory lost, loads new defaults, enters Test Mode). See G.
Err9 Brush wear too low. Indicator has been activated for over 100 miles. See D.
ErrE 0% always on (or switch disconnected or wired backwards). This means
that timed elevation has gone up 2% and the index is still sensed. See F.
Action
A Check lower board
B Check drive motor
C Check belt and deck
D Check motor brushes
E Check speed sensor
F Check elevation motor
G Replace display board
H Turn the treadmill to the off (O) position and back on (I)
I Perform speed calibration procedure
