CYP OR-42UHD Bedienungsanleitung

OR-42UHD

4x2 HDMI Matrix (4K)

OPERATION MANUAL

DISCLAIMERS

The information in this manual has been carefully checked and is

believed to be accurate. CYP (UK) Ltd assumes no responsibility for any

infringements of patents or other rights of third parties which may result

from its use.

CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be

contained in this document. CYP (UK) Ltd also makes no commitment to

update or to keep current the information contained in this document.

CYP (UK) Ltd reserves the right to make improvements to this document

and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer le, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express

written permission and consent from CYP (UK) Ltd.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts inside

the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if

it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sucient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE SUMMARY OF CHANGE

RDV1 03/09/12 Preliminary Release

RDV2 30/01/13 Add 4K x 2K HDMI cable spec.

RDV3 04/06/13 Separate 4H4H & 4H2H

RDV4 06/06/13 Remove Ethernet to Control

CONTENTS

1. Introduction...........................................6

2. Applications ...........................................6

3. Package Contents ..................................6

4. System Requirements ...........................6

5. Features..................................................6

6. Operation Controls and Functions .......7

6.1 Front Panel................................................... 7

6.2 Rear Panel..................................................... 8

6.3 Remote Control.......................................... 9

6.4 D-Sub 9 Pin Denitions ........................... 9

6.5 RS-232 Protocols......................................10

6.6 Web GUI Control ......................................11

7. Connection Diagram .......................... 13

8. Specications...................................... 14

9. Acronyms............................................. 15

1. INTRODUCTION

The 4 by 2 HDMI matrix with 4kx2k supported which allows HDMI signal

from any of its four sources to be routed to and displayed on any of its

two connected HDMI displays simultaneously. It supports 3D, 3Gbps

bandwidth, 16-bit Deep Colour, Hi-Def lossless audio and other features

dened by HDMI specications. The management of source/ sink

scenarios can be operated easily through on-panel buttons, IR remote

control, RS-232 or Web GUI controls.

2. APPLICATIONS

Showroom display control

Educational demo

Installation usage

Advertising display

3. PACKAGE CONTENTS

4x2 HDMI Matrix

Remote Control (CR-33)

Power Adaptor

Operational Manual

4. SYSTEM REQUIREMENTS

Input source equipment such as Blu-ray/DVD players with 3D/4kx2k

contents, output display HD TV/monitor with 3D/4kx2k functions and

HDMI high standard cables.

5. FEATURES

Support HDTV resolutions up to 4Kx2K

Supports 7.1CH of LPCM, Dolby TrueHD, and DTS-HD Master Audio

Supports Deep Colour up to 1080p 48-bit

Supports Internal/External EDID

Supports IR, RS-232 and Web GUI controls

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

POWER EDID A B 1234

1 2 3 4 5

1IR

IR receiver window accepts the remote control signal of this device.

2POWER & LED

Press this button to power the device on/o. The LED will illuminate

when the power is on.

3EDID & LED

Press this button to use the internal/STD or external/TV EDID. The

LED will illuminate when STD EDID is selected. STD EDID video up to

1080p@24/50/60 and audio up to LPCM 2CH at 192kHz & 24bit.

4OUTPUT A

Press this button to select input source for output A, the LED will

illuminate accordingly to the selection.

5OUTPUT B

Press this button to select input source for output B, the LED will

illuminate accordingly to the selection.

6.2 Rear Panel

1234 RS232 ETHERNET

SERVICE

DC 5V

POWER

INPUT OUTPUT

12 3 4 5 6

1INPUT 1~4

Connect input source equipments such as DVD/Blu-ray players with

HDMI cables.

2OUTPUT A/B

Connect to HDMI 3D TV/display or monitor for both audio and video

or moving/static graphic play.

3RS-232

Connect to a PC or laptop with D-Sub 9-pin male cable for the

transmission of RS-232 commands.

4CONTROL

Connect to an internet or network activate device. The yellow LED will

illuminate up on connection and the green LED will blink during data

transmission.

5SERVICE

Reserved for factory using only.

6POWER DC 5V

Connect the 5V DC power supply included in the package to an AC

wall outlet.

6.3 Remote Control

1POWER

Press this button to switch on

or set to standby mode of the

device.

2OUTPUT A 1~4

Press buttons 1~4 to selection

the nominated input for output

3OUTPUT B 1~4

Press buttons 1~4 to selection

the nominated input for output

6.4 D-Sub 9 Pin Denitions

OR-42UHD Remote Control

PIN Assignment PIN Assignment

1 NC 1 NC

2TX 2RX

3RX 3TX

4 NC 4 NC

5 GND 5 GND

6 NC 6 NC

7 NC 7 NC

8 NC 8 NC

9 NC 9 NC

Baud Rate: 19200bps

Data Bit: 8 bits

Parity: None

Flow Control: None

Stop Bit: 1

OUTPUT

POWER

CR-33

6.5 RS-232 Protocols

Command Description

A1~A4 Switch Output A to 1~4

B1~B4 Switch Output B to 1~4

AB...1~AB...4 Switch Output A B ... to 1~4 at the

same time

SETIP <IP> <SubNet> <GW> Setting IP. SubNet. GateWay

RSTIP IP conguration was reset to

factory default<DHCP>

IPCONFIG Display the current IP cong

P0 Power O

P1 Power On

I1~I4 Switch all the output to 1~4

ST Display the current matrix state

and F/W version

RS System Reset to A1, B1

EM Setting EDID MODE. 1-STD 2-TV

?Display all available commands

Note: All the RS-232 command will be not executed unless followed with a

carriage return and all command are case-insensitive.
