CYP AU-D9 Bedienungsanleitung
AU-D9
Universal Digital
/ Analog Audio
Converter
Operation Manual
AU-D9
Safety Precautions
Please read all instructions before attempting to unpack or install or
operate this equipment, and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
Always follow basic safety precautions to reduce the risk of
fire, electrical shock and injury to persons.
To prevent fire or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
Never spill liquid of any kind on or into this product.
Never push an object of any kind into this product through
module openings or empty slots, as you may damage parts.
Do not attach the power supply cabling to building surfaces.
Do not allow anything to rest on the power cabling or allow it to
be abused by persons walking on it.
To protect the equipment from overheating, do not block the
slots and openings in the module housing that provide
ventilation.
Revision History
Version No Date Summary of Change
V1 20090713 Preliminary Release
Table of Contents
1
1
1
1
1
2
2
3
4
4
4
5
5
6
1. Introduction…………………………………………………........……….
2. Applications……………………..…………………………................….
3. Package Contents…………………………......…………….............…
4. System Requirements......……………………..….…………........…….
5. Features…………………………………………….......……........………
6. Specications..………………………………………...........………...….
6.1 Input Audio Reference Level......................................................
6.2 Input Audio with Output Audio Comparison Chart.................
7. Operation Controls and Functions………………...……........…….…
7.1 Top Panel .................................................................................
7.2 Right Panel ………………………………………….........…….…
7.3 Left Panel .................................................................................
7.4 Back Panel ……………………………..………….........……...…
8. Connection and Installation …….…………………..........…..…..…...
1. Introduction
This comprehensive audio converter device allows users to make a wide use
with audio format and interfaces. With three different types of bidirectional
connectors of optical, Coaxial and L/R, this device can convert all three signals
into the desire format. Analog audio signal can be converts into digital output
and digital audio signal can be converts into analog output. Not only so, it
can be perform simultaneously without any signal loss. The audio converter is
compact and elegant, it is easy to set up and friendly use.
2. Applications
Analog audio signal convert into digital output
Digital audio signal convert into analog output
Simultaneously digital and analog audio output
Digital coaxial to Toslink and Toslink to coaxial conversion
3. Package Contents
Universal Digital / Analog Audio Converter
Power Adaptor
Operational Manual
4. System Requirements
Input audio source(s) equipments with connection cable(s) and output signal
with connection cables.
5. Features
Intergrated digital interpolator filter and Digital-to-Analog Converter (DAC)
Integrated Analog –to-Digital Converter (ADC)
Supports sampling frequencies from 16 to 100kHz
Provides elelctromagnetic-noise-free transmission
Easy to install and to operate
Compact size with elegant design
1
Input Ports Optical, Coaxial and L/R
Input Format Toslink, SPIDIF and LPCM 2CH
Sample Frequency 32kHz, 44.1kHz, 48kHz and 96kHz
Output Ports Coaxial, Optical and L/R
L/R Input Impedance 47KΩ
L/R Output Impedance 47KΩ
ESD Protection Human body model: ± 10kV (air-gap discharge)
± 6kV (contact discharge)
Power Supply 5V / 1A DC (US/EU standard, CE/FCC/UL certified)
Dimensions(mm) 97(W) x 85(D) x 35(H)
Weight(g) 120
Chassis Material Plastic
Silkscreen Color Black
Operating Temperature 0ºC~40ºC / 32ºF~104ºF
Storage Temperature -20ºC~60ºC / -4ºF~140ºF
Power Consumption 1W
Relative Humidity 20~90% RH (non-condensing)
6.1 Input Audio Reference Level
Input L/R
Reference
Level/Freq
Output
Output
Reference
Level
Output
T.H.D+N
Signal to
Noise Ratio
L/R
2Vrms
1KHz
L/R 1Vrms±0.05 0.01%↓>90dB
COAX 0 dB~-0.35dB 0.01%↓>90dB
OPTICAL 0 dB~-0.35dB 0.01%↓>90dB
Input COAX
Reference
Level/Freq
Output
Output
Reference
Level
Output
T.H.D+N
Signal to
Noise Ratio
COAX
OdBFS
1KHz
L/R 1Vrms±0.05 0.01%↓>90dB
COAX 0 dB±0.05 0.01%↓>90dB
OPTICAL 0 dB±0.05 0.01%↓>90dB
6. Specications
2
Input Ports Optical, Coaxial and L/R
Input Format Toslink, SPIDIF and LPCM 2CH
Sample Frequency 32kHz, 44.1kHz, 48kHz and 96kHz
Output Ports Coaxial, Optical and L/R
L/R Input Impedance 47KΩ
L/R Output Impedance 47KΩ
ESD Protection Human body model: ± 10kV (air-gap discharge)
± 6kV (contact discharge)
Power Supply 5V / 1A DC (US/EU standard, CE/FCC/UL certified)
Dimensions(mm) 97(W) x 85(D) x 35(H)
Weight(g) 120
Chassis Material Plastic
Silkscreen Color Black
Operating Temperature 0ºC~40ºC / 32ºF~104ºF
Storage Temperature -20ºC~60ºC / -4ºF~140ºF
Power Consumption 1W
Relative Humidity 20~90% RH (non-condensing)
6.1 Input Audio Reference Level
Input OPTICAL
Reference
Level/Freq
Output
Output
Reference
Level
Output
T.H.D+N
Signal to
Noise Ratio
OPTICAL
OdBFS
1KHz
L/R 1Vrms±0.05 0.01%↓>90dB
COAX 0 dB±0.05 0.01%↓>90dB
OPTICAL 0 dB±0.05 0.01%↓>90dB
6.2 Input Audio with Output Audio Comparison Chart
Audio Input
Source Output Output
Format Remark
LPCM 2CH
stereo L/R,
coax or
optical
L/R Analog 2CH
COAX LPCM2CH(48KHz)
OPTICAL LPCM2CH(48KHz)
OPTICAL
LPCM 2CH/
AC3/DTS
L/R
No Support
(Support optical / coaxial
LPCM 2CH only)
Odd sound
may appear
COAX LPCM 2CH/AC3/DTS Bypass
OPTICAL LPCM 2CH/AC3/DTS Bypass
COAX
LPCM 2CH/
AC3/DTS
L/R
No Support
(Support optical / coaxial
LPCM 2CH only)
Odd sound
may appear
COAX LPCM 2CH/AC3/DTS Bypass
OPTICAL LPCM 2CH/AC3/DTS Bypass
3
① Power: Power LED indicator. When power on the device the LED is green,
when turn off the device the LED is red.
② Input Analog 2CH LED indicator. When selecting input L/R, blue LED will
illuminate.
③ Input COAX: Input Coax LED indicator. When selecting input COAX, blue
LED will illuminate.
④ Input OPTICAL: Input OPTICAL LED indicator. When selecting input
Optical, blue LED will illuminate.
7. Operation Controls and Functions
7.1 Top Panel
7.2 Right Panel
1 2 3 4
① OPTICAL: Connect from audio source equipment’s optical audio output
with optical cable.
② COAX: Connect from audio source equipment’s coaxial audio output
with coaxial cable.
③ L/R: Connect from audio source equipment’s L/R audio output with L/R
RCA jack cable.
1 2 3
POWER L/R COAX OPTICAL
4
7.3 Left Panel
① L/R: Connect to audio equipment’s L/R input such like TV or amplifier
with L/R RCA jack cable.
② COAX: Connect to audio equipment’s coaxial input such like TV or
amplifier with coaxial cable.
③ OPTICAL: Connect to audio display equipment’s optical input such like
TV or amplifier with optical cable.
2 31
7.4 Back Panel
1
① DC 5V Power Jack: Plug 5V 1A DC power supply into the unit and
connect the adaptor to AC wall outlet.
② INPUT SELECT: Use this switcher to select input from optical, coaxial or L/R.
③ Power Switch: Push to button the turn on or switch off the device.
2 3
5
8. Connection and Installation
TV
Optical
or
or
or
Amplifier
Blue Ray
DVD
Set-top-Box
L/R
Coaxial
Coaxial
Optical L/R
6
7
