CS-802D
Ultra High Resolution Scaler
Operation Manual
Operation Manual
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2012 by Cypress Technology.
All Rights Reserved.
Version VR1.0 January 2012
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 20/11/12 Preliminary Release
CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 1
6. Operation Controls and Functions....... 2
6.1 Front Panel ........................................2
6.2 Rear Panel.........................................4
7.OSD Menu and Function List.................. 5
8. Remote Control...................................... 6
8.1 RS-232 Protocols ...............................7
8.2 RS-232 Commands...........................8
9. Connection and Installation............... 10
10. Specications .................................... 11
10.1 PC, HDMI, DP Input Timing ..........12
10.2 Output Resolution ........................14
11. Acronyms ........................................... 15
1
1. INTRODUCTION
This Ultra Hight Resolution Scaler with Dual-Link DVI, Mini-DisplayPort
and PC/Component inputs to its HDMI output and the associated
audio signal processed synchronously. Accepting most of PC/Graphic
signal and scaling features can be handled easily through on-panel
buttons, IR remote control, or RS-232 protocol.
2. APPLICATIONS
• Scale Dual-Link DVI, Mini-DisplayPort and PC/Component inputs to
HDMI output
3. PACKAGE CONTENTS
• Ultra High Resolution Scaler
• VGA to 3RCA converter cable
• 5V/2.6A DC power adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
• Input Dual-Link DVI/Mini-DisplayPort/PC sources and output with
HDMI display.
5. FEATURES
• Supports Component input timing up to 1080p@50/60Hz, Dual-Link
DVI &Mini-DisplayPort up to 2560 x 1600@60HzRB and PC up to 1920
x 1200@60/75Hz
• Supports digital and analog audio bidirectional conversion,
extraction and insertion for the audio signals from individual
• inputs Supports component input when connected VGA to 3RCA
adaptor
2
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
XGA
720P
ENTER
MENU/
OPTICAL
OUT
IN
AUDIO HDMI OUT
DC 5V
POWER
OPTICAL AUDIO
1
6 7 8 9 10
2 3 4 5
1MENU/ENTER
Press this button to ENTER the OSD menu. Press again to conrm the
selection. Press it together with - button to switch output to720p or
with + button to swtich output to XGA instantly.
2-/IN
a. “-“: When in OSD page, sequentially press this button to move
down the OSD selection.
b. “IN”: Press this button to quick enter the input port selection.
3+/OUT
a. “+”: When in OSD page, sequentially press this button to move
up the OSD selection.
b. “OUT”: Press this button to quick enter the output resolution
selection.
4OPTICAL OUT
This slot is where you connect the amplier with OPTICAL cable
and from amplier to speaker.
3
5AUDIO L/R OUT
This slot is where you connect the speaker or amplier with audio
phone jack to the display.
6OPTICAL IN
This slot is where you connect the input OPTICAL audio source.
7AUDIO L/R IN
This slot is where you connect the L/R input audio source.
8HDMI OUT
This slot is where you connect the HDMI display with HDMI cable.
9IR sensor
10 DC 5V
Plug the 5V DC power supply into the unit and connect the
adaptor to AC wall outlet. Once the power supplyis connected
the power LED will illuminate
4
6.2 Rear Panel
RS232
SERVICEMDP
Dual-Link DVI PC/COMP
IN
1
2 3 4 5
1RS232
This slot is to connect with D-Sub 9pin cable from the PC/NB device
for RS-232 control.
2SERVICE
This slot is to connect with USB cable for manufacturers’ rmware
update only.
3Mini-DisplayPort IN
This slot is where you connect the MiniDisplayPort source output for
DisplayPort signal sending.
4Dual-Link DVI IN
This slot is are where you connect the Dual-Link DVI sources output
for Dual-Link DVI signal sending.
5PC/COMP IN
This slot is where you connect the PC/NB or DVD/Set-Top Box
source equipment with D-Sub 15-pin cable for PC source signal
input or with D-Sub 15-pin to 3 RCA adaptor for component signal
input.
5
7.OSD MENU AND FUNCTION LIST
Main Menu 2nd Layer
Input Video PC
COMP
DVI
MDP
Exit
Input Audio AUDIO
Optical
MDP
Mute
Exit
Output Resolution 720x480P
1280x720P
1920x1080P
640x480
800x600
1024x768
1280x1024
1600x1200
1920x1200RB
By Native
Exit
6
Main Menu 2nd Layer 3rd Layer
Misc. Setup EDID Mode Internal / External / Exit
Info. OSD Mode Off / On / Exit
About CS-802D FW Ver.
Factory Reset System Reset
Exit
Exit
8. REMOTE CONTROL
1Power
Press to select DV MDP/PC/
2VIDEO IN
Press to select DV MDP/PC/
Component input source.
3AUDIO IN
Press to select AUDIO/
OPTICAL/MDP input audio or
MUTE the system.
4EXIT
Press the EXIT the OSD
selection.
5MENU
Press this button to ENTER the
OSD menu.
6ENTER
Press to conrm the selection.
7INFO
To show input and output resolution information.
8OUTPUT
Press to show the output resolution table.
MDP
MENU
OUTPUTINFO
DVI
PC
AUDIO
MUTE
EXIT
NATIVE
MDP
COMP
OPTICAL
ENTER
CR-123
AUDIO IN
VIDEO IN
2
3
5
8
10
9
4
1
7
6
