D-Link Air DWL-660 Bedienungsanleitung

Before You Begin

You must have at least the following:

• A laptop computer with an available PCMCIA slot

• At least a 300 MHz processor and 32 MB of memory

• PCMCIA Controller properly installed and working in the laptop computer

• An 802.11b Access Point (for Infrastructure Mode) or another 802.11b

wireless adapter (for Ad-Hoc; Peer-to-Peer networking mode.)

Check Your Package Contents

These are the items included with your DWL-660 purchase:

If any of the above items are missing, please contact your reseller.

Insert the D-Link CD-ROM

Into Your Computer

Turn on the computer and

Insert the D- Link Air DWL-660 Driver

CD in the CD-ROM drive.

The step-by-step instructions that follow are shown in

Windows XP. The steps and screens are similar for

the other Windows operating systems.

specifications subject to change without notice. DWL-650+.05302002

Do NOT install

the DWL-660

PC Card into your

computer before

installing the driver

software on the

D-Link CD!

This product works with the following

operating system software: Windows XP,

Windows 2000, Windows Me, Windows

98se

DWL-660

D-Link Air™

Wireless PC Card Adapter

• DWL-660 Wireless PC Card Adapter

• CD-ROM (containing Drivers, Manual and Warranty)

Insert the D-Link

CD (continued)

The Install Screen will appear.

If the CD Autorun function on

your computer does not

automatically start, go to Start

> Run and type “D:\Setup.exe.”

If it does start, proceed to the

next screen.

Click Install Driver/PC Utility

Type “D:\Setup.exe.”

The letter “D”

represents the

letter of the CD-ROM

drive. Your CD-ROM

drive may be a

different drive letter.

Click OK

Click Next

Click Yes

Click Next

Insert the DWL-660 Wireless PC Card Adapter

Into the PCMCIA Slot in Your Laptop

A. Make sure to turn off the laptop computer.

B. Locate the PCMCIA slot on your laptop computer.

Shut down your laptop

Click Next

Click Finish

C. Gently insert the DWL-660 into the PCMCIA slot in your

laptop

computer.

Restart Your Laptop Computer

When you restart your computer this Found New Hardware Wizard

(Windows XP) screen will appear:

Select Install the

software

automatically

(Recommended)

Click Next

Make sure to select

the driver file that

corresponds with the

Operating System currently

installed on your laptop.

Click Next

For Windows Me and 98,

after your computer restarts,

this Systems Settings

Change screen may appear

For Windows XP:

this Hardware

Installation alert screen

may appear after the laptop

computer restarts.

Click Yes to finalize

the installation

Select Yes to finalize

the installation

D-Link Air DWL-660 Wireless Cardbus Adapter

Click Continue

Anyway to finalize

the installation

The D-Link driver software for this device is

undergoing Windows Logo testing. Microsoft

certification is pending.)

For Windows 2000, this Digital Signature

Not Found screen may appear after your

computer restarts.

Click Finish

Your Installation is Complete!

After you’ve continued in Windows XP (or after the computer restarts in

the other Windows operating systems), the D-Link Air DWL-660

Configuration Utility will automatically start and the utility icon will appear

in the bottom right hand corner of the desktop screen (systray). If this

icon appears GREEN, then you have successfully installed the DWL-

660, are connected to a wireless network and are ready to

communicate!

Using the Configuration Utility

The D-Link Air Client Manager window will appear.

Click on Actions, then

Add/Edit Configuration

Profile

Select the wireless network to which you

wish to connect from the list of Available

Networks.

Click Configure

Double-click the utility icon to

use the configuration utility.

Screen shot taken using

Windows XP. If you are using a

different Operating system your

screen may differ.

If the settings are correct for the Wireless

Network, Click OK

The Wireless Network will now appear

in the Preferred Networks.

Click OK.

The DWL-660 Client Manager

should now show the current

signal strength, channel, and

SSID of the associated

network.

APPENDIX

To connect to a network, make sure the proper

network settings are configured for DWL-660.

For Microsoft Windows XP:

Go to Start > right click on

My Network Places >

select Properties > Double-click on

the Network Connection associated

with the DWL-660.

Setup for wireless router or Access Point

using Static IP address.

Input a static IP address on the same network,

which will correspond with the Wireless Router or

Access Point.

Your Internet service provider provides

preferred DNS server information.

Click Properties

Select Obtain an IP address

automatically (if the Wireless Router or

Access Point has DHCP server enabled)

Click OK

Click Internet Protocol (TCP/IP)

Select Obtain DNS server

address automatically

Select Use the following IP address (if

the Wireless Router or Access Point does

not have DHCP server enabled

IP address: 192.168.0.51

Subnet mask: 255.255.255.0

Click OK

D-Link Air DWL-660 Wireless PC Card Adapter

For Windows 2000 users:

Go to Start > Settings > Network and Dial-up

Connections > Double-click on the Local Area

Connection associated with the DWL-660 >

select Properties

Setup for wireless router or Access Point

using DHCP server.

Setup for wireless router or Access Point

using Static IP address.

Input a static IP address on the same network,

which will correspond with the Wireless Router

or Access Point.

Your Internet service provider

provides preferred DNS server

information.

Select Obtain an IP address

automatically (if the Wireless Router or

Access Point has DHCP server enabled)

Click OK

Select Obtain DNS server

address automatically

IP address: 192.168.0.51

Subnet mask: 255.255.255.0

Click OK

Select Use the following IP address (if

the Wireless Router or Access Point does

not have DHCP server enabled)

Click Internet Protocol (TCP/IP)

Click Properties

D-Link Air DWL-660 Wireless PC Card Adapter
