D-Link DP 301U Bedienungsanleitung

Manual

Fast Ethernet Print Server

D-Link DP-301U

Contents

Package Contents ................................................................................ 3

Introduction ........................................................................................... 4

Setting up the DP-301U ...................................................................... 7

Getting Started ..................................................................................... 9

Using the Web Conﬁguration .............................................................. 10

TCP/IP Printing for Windows XP ........................................................ 25

TCP/IP Printing for Windows 2000 ..................................................... 33

TCP/IP Printing for Windows 98SE/ME .............................................. 42

Unix/Linux Printing ............................................................................. 53

Setting up AppleTalk or LPR Printing in MAC OSX ............................ 54

Setting up AppleTalk Printing in MAC OS9 ......................................... 59

Networking Basics .............................................................................. 62

Technical Speciﬁcations ..................................................................... 74

Contacting Technical Support ............................................................. 75

Warranty and Registration .................................................................. 76

Appendix: DP-301U Printer Compatibility List ................................... 79

Contents of Package:

D-Link DP-301U

Fast Ethernet Print Server

Manual and Warranty on CD

Printed Quick Installation Guide

Package Contents

If any of the above items are missing, please contact your reseller.

System Requirements:



A computer with an installed Ethernet adapter



Windows XP/2000/NT4/ME/98SE/95



Apple Mac OS with AppleTalk



Linux, Solaris, SCO Unix, AIX



NetWare 5.x (Native NDS)



Internet Explorer 6.0, or Netscape Navigator version 6.0 or above,

with JavaScript enabled



Printer must support required Operating System



Introduction

The D-Link DP-301U Print Server is an Ethernet/USB print server that connects

to your Ethernet/Fast Ethernet network anywhere you wish to locate printer

services. The DP-301U manages the ﬂow of print ﬁles from workstations or ﬁle

servers to connected printers, delivering print jobs to printers much faster than a

ﬁle server or a PC acting as a print server can. With one USB (v2.0) port, the DP-

301U can connect to almost any printer with a USB port.

The DP-301U includes easy-to-use software to install on most Windows-based

networks. Protocol support for TCP/IP, NetBEUI, and AppleTalk are provided to

ensure seamless connection to major networking Operating Systems.

The DP-301U has a built in Web-Based management feature that allows users to

easily conﬁgure and manage multiple print queues through TCP/IP. The DP-301U

also supports Telnet as an alternative method to conﬁgure the unit.

The DP-301U improves network printing services in the following ways:

 The DP-301U delegates print jobs to the connect USB printer. This provides

workload relief to your ﬁle servers, and allows the ﬁle servers’ full capacity

to be used for ﬁle access or other direct services to network users. On peer-

to-peer networks, workstations can print directly to the Print Server without

increasing the load of another workstation or server.

 The DP-301U’s USB port, version 2.0, can transmit to high-speed laser

printers much faster than a PC’s parallel printer port.

 Because the DP-301U is very portable and inexpensive compared to a PC-

based print server, and the Print Server connects to your ﬁle servers through

the network, printers can be deployed to locations of maximum

convenience to users.

External Features

Port Connectors

The DP-301U’s USB port is located on its rear panel. The USB can be conﬁgured

using the PS Admin program or the print server’s Telnet interface. (See the

PS Admin User’s Guide, available on the CD that came with the DP-301U, for

information about conﬁguring the print server’s ports.) The Print Server also

supports web conﬁguration permitting users to conﬁgure settings through the web

browser. The default IP Address is as follows:

 Default IP Address – 192.168.0.10

 Subnet Mask – 255.255.255.0

The DP-301U offers extraordinary ﬂexibility, operating with all major network

operating systems and protocols:

 TCP/IP

UNIX lpr/lpd (HP-UX, SunOS, Solaris, SCO, UnixWare, IBM AIX)

Windows NT/2000, Windows 95/98SE/ME, Windows XP

NetWare 5.x NDPS LPR Remote Printing

 NetBEUI

Windows NT/2000/XP, Windows 95/98SE/ME, Windows for Workgroups,

Microsoft LAN Manager, IBM LAN Server

 AppleTalk

MacOS EtherTalk

Windows-based setup and administration software, PS Admin, is supplied with

the Print Server, making conﬁguration and management quick and easy. The

Print Server also supports conﬁguration and management via the Telnet protocol

for networks without Windows-compatible machines.

Note:

The PC’s IP Address must be in the same subnet as the Print Server’s IP Address for

the two devices to communicate. (For example, if your Print Server’s IP Address is

192.168.0.10, with a subnet mask of 255.255.255.0, then your computer’s IP Address

should be 192.168.0.x, where x is a value between 1-254, excluding 10.)

Network Cable Connector

The Print Server’s rear panel features an RJ-45 connector for connection to

10Base-T Ethernet cabling or 100Base-TX Fast Ethernet cabling (which should

be Category 5 twisted-pair cable). The port supports the NWay protocol, allowing

the Print Server to automatically detect or negotiate the transmission speed of the

network.

DC Power Connector

The DC power input connector is located on the Print Server’s rear panel and is

labeled DC 5V.

LED Indicators

The front panel of the

Print Server features

ﬁve LED indicators:

Power

Rear Panel Connectors

USB

Power

LAN

USB

RJ-45

Reset

Power

Steady or ﬂashing green conﬁrms that the Print Server is powered

ON.

Link/Act

Steady or ﬂashing green conﬁrms that the Print Server has a good

connection to the Ethernet or Fast Ethernet network.

The indicator blinks off brieﬂy to indicate that the Print Server is

receiving or transmitting from the network.

USB

These three indicators are also used by the Print Server’s Power-ON Self Test

(POST) to indicate any hardware failures.

Setting up the DP-301U

Installing the Print Server

WARNING: Conﬁguration problems may result if the Print Server is powered up without

ﬁrst establishing its network connection. Follow this procedure to avoid complications at

the conﬁguration stage.



The LED indicator lights up to show that the Print Server is transferring

print data through the USB port.

Conﬁrm proper operation of each of the printers to be connected to the

DP-301U.

When you have conﬁrmed proper operation of each printer, switch its power

OFF.

Conﬁrm that your network is operating normally.

Connect the DP-301U RJ-45 Connector to the network, using an Ethernet

CAT5 cable.

While the printer is powered OFF, install the USB printer cable to connect the

printer’s USB port to the USB port of the Print Server.

Switch on each connected printer.

Plug the AC power adapter’s DC output plug into the DC 5V power socket on

the rear panel of the Print Server.

Plug the power adapter into a power outlet. This will supply power to the Print

Server, as it has no external power switch. The green Power LED on the Print

Server’s front panel should illuminate steadily, and the Print Server’s Self-Test

will proceed.

Front Panel LED Indicators

Immediately after power-up, all three of the green LEDs should illuminate steadily

for several seconds. Then the USB LED should ﬂash ON three times. Irregularity

of the LED during this LED test may mean there is a problem with the LED itself.

The actual component tests immediately follow the LED tests. A normal (no fault)

result is signaled by a ﬂashing of the USB LED, followed by a darkened LED.

If the Self-Test routine traps any component error, then following the LED tests

the Self-Test will halt and the LEDs will continuously signal the error according to

the following table. In the event of any such error signal, contact your dealer for

correction of the faulty unit.

When the DP-301U is powered ON, it also automatically performs a Self-Test

on each of its major components. The ﬁnal result of the Self-Test is signaled by

the state of the USB LED indicator following the Self-Test. Preliminary to the

actual component tests, the LED indicators are tested to conﬁrm their steady and

ﬂashing operation.

Power ON Self-Test

Every DP-301U has been factory-tested to operate properly.

USB LED Faulty Component

low speed ﬂashing Need to reload ﬁrmware

steady ON DRAM error

1 long 2 short

1 long 3 short

1 long 5 short

1 long 6 short

1 long 7 short

1 long 11short LAN I/O base error

LAN memory error

LAN Controller error

Flash Erase/Program error

Flash Protected

Timer INT error

1 long 18 short USB error

Getting Started

Below is a sample network using the DP-301U. The DP-301U has a built- in Web-

based management feature that allows users to easily conﬁgure and manage

multiple print queues through TCP/IP.

Warning!

Only a USB printer may be connected to the USB port of the DP-301U. Do not

connect any other USB devices to the USB port of the DP-301U; to do so, may

damage the unit and will void the warranty for this product.

For a list of printers that are compatible with the DP-301U, please see the Ap-

pendix in this manual. The compatibility list is not comprehensive. Even if it is

not included in the list, your printer may be compatible with the DP-301U.

When you entered the default IP address, the main screen of the Print Server’s

conﬁguration will appear (see below). In addition to the product information, you

can access and control the Print Server’s conﬁguration through four links on the top

of this main screen: Home, Conﬁguration, Tools, and Help.

Open your web browser and type http://192.168.0.10 in the address box, and

press <Enter>. This set of numbers is the default IP Address of your Print Server.

Please note that the PC’s IP Address must correspond with the Print Server’s

IP Address in the same segment for the two devices to communicate.

Using the Web Conﬁguration
