Before You Begin

It’s best to use a computer with an Ethernet adapter for configuring the DWL-6000AP.

The default IP address for the DWL-6000AP is 192.168.0.50 with a Subnet Mask of

255.255.255.0. You will need to assign your computer a Static IP address within the

same range as the DWL-6000AP’s IP address for the purpose of configuring the DWL-

6000AP. See the Appendix if you need assistance in assigning a Static IP address

for your network adapter.

Check Your Package Contents

These are the items included with your DWL-6000AP purchase:

If any of the above items are missing, please contact your reseller.

holders. Software and specifications subject to change without notice. DWL-6000AP.01232003

This product can be set up using any

current web browser, i.e., Internet

Explorer 5x, Netscape Navigator 4x.

DWL-6000AP

D-Link AirPro™ 2.4GHz/5GHZ

Wireless Access Point

• DWL-6000AP Wireless Access Point

• CD-ROM (containing Manual and

Warranty)

• Ethernet (CAT5 UTP/Straight Through)

Cable

• 5V DC, 2.5A Power Adapter

Using a powe

supply with a

different voltage rating

will damage and void

the warranty for this

product.

When connecting

the DWL-6000AP

Wireless Access Point to

an Ethernet Adapter in a

computer, use a Cross-

Over Ethernet cable.

Connecting The DWL-6000AP Multimode

Wireless Access Point To Your Network

A. First, connect the power adapter to the receptor at the back panel of

the DWL-6000AP and then plug the other end of the power adapter to

a wall outlet or power strip. The Power LED will turn ON to indicate

proper operation.

B. Using a Straight-Through Ethernet

cable, insert one end of the cable to the

Ethernet port on the back panel of the

DWL-6000AP and the other end of the

cable to an Ethernet Broadband

Router (i.e., D-Link DI-604) or Switch

(i.e., D-Link DSS-5+). Note: The

computer used to configure the DWL-6000AP must also be connected

to the same Ethernet router or switch.

C. Computers with 802.11b and 802.11a wireless adapters can connect

to the DWL-6000AP. The DWL-650+ AirPlus Wireless Cardbus

Adapter or the DWL-A650 AirPro and the

DWL-520+ AirPlus

Wireless PCI Adapter or the DWL-A520 AirPro will connect out

of the box

to the DWL-6000AP, using their default wireless settings.

B.LAN Port

For connecting to a

switch on a local network

with an Ethernet cable.

C.Antenna

Used to wirelessly

connect to

802.11b and

802.11a adapters.

Reset Button

Pressing this button

restores the DWL-

6000AP to its original

factor

default settin

A.Receptor for

Power Adapter

When you have completed the

steps in this Quick Installation

Guide, your connected network

should look similar to this:

Using The Setup Wizard

Open your Web

browser and type

“http://192.168.0.50”

into the URL address

box. Then press the Enter

or Return key.

Type “admin” for the

username and leave the

password field blank.

Click OK

The logon pop-up

screen will appear.

Using The Setup Wizard (continued)

Click Next

You will see the following

screens.

Once you have

logged in, the

Home screen

will appear.

Click Run Wizard

Click Next

Step 1 - Set up your new

password. You have the

option to establish a

password.

Step 2 - Wireless Setup for

your 802.11a Connection.

The default wireless settings are:

SSID = default

Channel = 36

You can change these settings

to match an existing wireless

network.

Click Next

Step 3 – Encryption for

802.11a Network

The DWL-6000AP is capable

of three levels of wireless

encryption - 64-bit, 128-bit,

and 152-bit. By default the

encryption is disabled. You

can change the encryption

settings for more secure

wireless communication.

Click Next

Step 4 - Wireless Setup for

your 802.11b Connection.

The default wireless settings are:

SSID = default

Channel = 6

You can change these settings

to match an existing wireless

network.

If you enable encryption on the DWL-6000AP make sure

to also enable encryption on all 802.11a wireless clients

or wireless connection will not be established

Your Setup is Complete!

Click Restart

Click Next

Step 5 – Encryption for

802.11b Network.

The DWL-6000AP is

capable of three levels of

wireless encryption - 64-

bit, 128-bit, and 256-bit.

By default the

encryption is disabled.

You can change the

encryption settings for

more secure wireless

communication.

If you enable encryption on the DWL-6000AP make sure

to also enable encryption on all 802.11b wireless clients

or wireless connection will not be established

You will be returned to the Home tab.

For additional settings or information, refer to the Advanced, Tools, or Status tabs on

the web-management interface; or to the manual located on the CD-ROM.

Click Close

Click Exit

For managing several DWL-6000s, please install the D-Link

AirPro Multiple AP Manager from the DWL-6000 CD-ROM.

For the latest version of the firmware or AP manager please

go to http://support.dlink.com

APPENDIX

To assign a Static IP address to the

Ethernet adapter, please do the

following steps. The examples below

are using a DFE-530TX+ in Microsoft

Windows XP, and Mac OS X.

Note: Screens in other Operating

Systems will look different.

For Microsoft Windows XP:

Go to Start > right click on

My Network Places >

select Properties > Double-click on

the Network Connection associated

with the Ethernet adapter (i.e.,

D-Link DFE-530TX+).

Click Internet Protocol (TCP/IP)

Click Properties

Select Use the following IP address

Enter the following:

IP address: 192.168.0.51

Subnet mask: 255.255.255.0

Click OK

Setting a Static IP address for

Apple Macintosh OS X:

Go to the Apple Menu

and Select System

Preferences.

Click on

Network

Select Built-in

Ethernet in the Show

pull-down menu

Select Manually in

the Configure pull-

down menu

Click on

Apply Now

Enter the IP address information,

the Subnet Mask and the

Router’s IP address.
