D-Link DWL-3200A Bedienungsanleitung

DWL-3200AP

802.11b/g Access Point

Command Line Interface Reference Manual

First Edition (January 2006)

RECYCLABLE

Table of Contents

Using the CLI .......................................................................................................................................................................................................................................................1

CLI Commands.....................................................................................................................................................................................................................................................7

First-Time Configuration Examples .................................................................................................................................................................................................................19

802.11 a/g Dual Band Access Point Command Line Interface Manual

SING THE

CLI

The DWL-3200AP can be accessed by Telnet. Using Microsoft Windows Operation system as example, open the Command Prompt on the computer that will be used for configuring and

managing the AP and enter telnet and IP address of DWL-3200AP in the first line. Using the default IP address as example, enter telnet 192.168.0.50 to cause the following screen to open:

Press Enter in the screen above. The following screen opens:

802.11 a/g Dual Band Access Point Command Line Interface Manual

Type “admin” for the D-Link Access Point login username in the screen above and press Enter. The following screen opens:

Press Enter as there is no initial password.

The following screen opens to indicates you have successfully logged into the DWL-3200AP.

Commands are entered at the command prompt, D-Link Access Point wlan1 – >

802.11 a/g Dual Band Access Point Command Line Interface Manual

There are a number of helpful features included in the CLI. Entering the “?” command and then pressing Enter will display a list of all of the top-level commands. The same information can

also be displayed by entering “help”.

Press Enter to see a list of all the available commands. Alternatively, you may enter “help” and the press Enter.

802.11 a/g Dual Band Access Point Command Line Interface Manual

When you enter a command without all of its required parameters, the CLI will prompt you with a list of possible completions. For example, if “tftp” was entered, the following screen

opens:

This screen displays all the possible command completions for “tftp”

When you enter a command without a variable or value that needs to be specified, the CLI will prompt you with further information about what is needed to complete the command. For

example, if “snmp authtrap” was entered, the following screen opens:

The missing value for the “snmp authtrap”command, “enable/disable,” is displayed in the screen above.

802.11 a/g Dual Band Access Point Command Line Interface Manual

OMMAND

YNTAX

The following symbols are used to describe how command entries are made and values and arguments are specified in this manual. The online help contained in the CLI and available

through the console interface uses the same syntax.

Note: All commands are case-sensitive. Be sure to disable Caps Lock or

any other unwanted function that changes text case.

Purpose Encloses a variable or value that must be specified.

Syntax set login <username>

Description In the above syntax example, you must specify the username.

Do not type the angle brackets.

Example Command set login accounting

[square brackets]

Purpose Encloses a required value or set of required arguments. One

value or argument can be specified.

Syntax get multi-authentication [index]

Description In the above syntax example, you must specify an index to be

created. Do not type the square brackets.

Example Command get multi-authentication 2

802.11 a/g Dual Band Access Point Command Line Interface Manual

: colon

Purpose Separates two or more mutually exclusive items in a list, one of

which must be entered.

Syntax set antenna <1:2:best>

Description In the above syntax example, you must specify either 1,2 or

best. Do not type the colon.

Example Command set antenna best

802.11 a/g Dual Band Access Point Command Line Interface Manual

CLI

OMMANDS

The following is a complete list of the Command Line Interface (CLI) commands along with their respective arguments.

Access Point CLI command

Function Syntax

Config Commands:

config wlan Select WLAN Adapter to configure. Only WLAN 1 is available for

configuration. This command is not necessary. config wlan [0:1]

Delete Commands:

del acl Delete specified Access Control List entry del acl [1-16]

del wdsacl Delete specified WDS ACL entry: 1-8 del wdsacl [1-8]

del key Delete specified Encryption key del key [1-4]

DHCP Server Help Command:

dhcps help Display DHCP Server Command Help dhcps help

dhcps state get DHCP Server state dhcps state

dhcps state <on|off> set to on or off DHCP Server dhcps state [on|off]

dhcps dynamic info get current settings dhcps dynamic info

dhcps dynamic ip set start ip dhcps dynamic ip <x.x.x.x>

dhcps dynamic mask set netmask dhcps dynamic mask <x.x.x.x>

dhcps dynamic gw set gateway dhcps dynamic gw <x.x.x.x.>

dhcps dynamic dns set dns dhcps dynamic dns <x.x.x.x>

dhcps dynamic wins set wins dhcps dynamic wins <x.x.x.x>

dhcps dynamic range set range dhcps dynamic range [0-255]

dhcps dynamic lease set lease time (sec.) dhcps dynamic lease [60-31536000]

dhcps dynamic domain set domain name dhcps dynamic domain <string..>

dhcps dynamic state set state dhcps dynamic state [on:off]

dhcps dynamic map get mapping list dhcps dynamic map

dhcps static info get setting from <0-255> to <0-255> dhcps static info [0-255] [0-255]

dhcps static ip set static <id> pool start ip dhcps static <id> ip <x.x.x.x>

dhcps static mask set static <id> pool netmask dhcps static <id> mask <x.x.x.x>

dhcps static gw set static <id> pool gateway dhcps static <id> gw <x.x.x.x.>

802.11 a/g Dual Band Access Point Command Line Interface Manual

dhcps static dns set static <id> pool dns dhcps static <id> dns <x.x.x.x>

dhcps static wins set static <id> pool wins dhcps static <id> wins <x.x.x.x>

dhcps static domain set static <id> pool domain name dhcps static <id> domain <string..>

dhcps static mac set static <id> pool mac dhcps static <id> mac <xx:xx:xx:xx:xx:xx>

dhcps static state set static <id> pool state dhcps static <id> state [on:off]

dhcps static map get static <id> pool mapping list dhcps static map

Find Commands:

find bss Perform Site Survey, Wireless service will be disrupted find bss

find channel Channel sPanning to select the Preferred Channel find channel

find all Perform Site Survey including Super G and Turbo, Wireless service will

be disrupted find all

find rogue Find rogue AP find rogue

GET Commands:

get 11gonly Display 11g Only Mode operational state of enabled or disabled get 11gonly

get acl Display Access Control Setting of Enabled or disabled get acl

get wdsacl Display WDS Access Control List get wdsacl

get wdsap Display WDS Access Point List get wdsap

get aging Display Aging Interval in seconds get aging

get antenna Display Antenna Diversity of 1, 2, or best get antenna

get association Display Association Table get association

get authentication Display Authentication Type get authentication

get autochannelselect Display state of Auto Channel Selection feature (enabled, disabled) get autochannelselect

get apmode Display current AP Mode get apmode

get beaconinterval Display Beacon Interval get beaconinterval

get channel Display Radio Frequency (MHz) and Channel Designation # get channel

get availablechannel Display available Radio channels get availablechannel

get cipher Display Encryption cipher get cipher

get config Display Current AP Configuration Settings get config

get countrycode Display Country Code setting get countrycode

get cpuloadlimit Get CPU load limit get cpuloadlimit

get cpuloadperoid Get CPU load peroid get cpuloadperoid

get dhcpc Display DHCP Clinet State of enabled or disabled get dhcpc

get diap Display DIAP State get diap

get dtim Display Delivery Traffic Indication Message Beacon Rate get dtim

get encryption Display (WEP) configuration state: enabled or disabled get encryption

get eth2wlan Display Eth2Wlan Broadcast packet filter state get eth2wlan
