DAELIM B-BONE Bedienungsanleitung
OM70-0812-01E
HEAD OFFICE(FACTORY)
#58, SUNG SAN-DONG, CHANG WON, KYUNGNAM, KOREA
TEL: (82-55) 239-7000 / FAX: (82-2) 467-9997
OWNER S MANUAL
WELCOME
Thank you for purchasing an Daelim vehicle. We hope you enjoy safe riding.
OPERATOR AND PASSENGER
This motorcycle is designed to carry the operator and one passenger.
Attempting to change the pre-set maximum speed may cause danger and will void the Daelim warranty.
ON-ROAD USE
This motorcycle is designed to be used only on the road.
READ THIS OWNER'S MANUAL CAREFULLY
Pay special attention to statements preceded by the following words:
Indicates a strong possibility of severe personal injury or death if instructions are not followed.
Indicates a possibility of personal injury or equipment damage if instructions are not followed.
Gives helpful information.
This manual is an important and integral part of your vehicle. keep it with your vehicle at all times, even though your vehicle is resold.
IMPORTANT NOTICE
WARNING
WARNING
CAUTION
NOTE
SPECIFICATION
OPERATION INSTRUCTION
SAFETY PRECAUTIONS
PRIOR TO STARTING VEHICLE
FOR SAFE DRIVING
OPERATION
CORRECT ATTIRE
MODIFICATION
ATTACHMENT
MUFFLER
PARTS LOCATION
METER READING AND USAGE
METER
WARNING AND INDICATOR LAMPS
MALFUNCTION INDICATOR LAMP
SWITCH OPERATION
MAIN SWITCH
START BUTTON
HEADLIGHT
PASSING SWITCH
WINKER SWITCH
HORN BUTTON
EQUIPMENT USAGE
STEERING STEM LOCK
SEAT LOCK
HOLE FOR A CHAINLOCK
CORRECT DRIVING OPERATION
STARTING THE ENGINE
AFTER STARTING ENGINE
PROPER DRIVING METHODS
STOPPING
SELF INSPECTIONS BEFORE OPERATION
INSPECTION OF CONCENED AREA
BRAKE INSPECTION
TIRE INSPECTION
FUEL CHECK
ENGINE OIL CHECK
LIGHTS AND WINKER INSPECTION
BULB REPLACEMENT METHOD
REAR VIEW MIRROR
FUEL LEAK INSPECTION
1
CONTENTS
3
4
4
5
5
6
7
7
8
8
9
12
12
12
12
13
13
13
14
14
15
15
16
16
16
16
17
17
19
20
21
23
23
24
24
26
27
27
28
28
28
MAINTENANCE
MAINTENANCE SCHEDULE
MAINTENANCE PRECAUTIONS
REPLENISHING FRONT / REAR BRAKE FLUID
BRAKE HOSE, PIPE LEAKAGE, DAMAGE, ASSEMBLY STATE
FRONT BRAKE PAD WEAR
CHANGING ENGINE OIL
TRANSMISSION OIL INSPECTION
TIRE PRESSURE INSPECTION
BATTERY INSPECTION
FUSE REPLACEMENT
AIR CLEANER ELEMENT INSPECTION
CABLE RUBBER PART
SPARK PLUG
HANDLING FOR POOR STARTING
SIDE STAND INSPECTION
CLEANING
GENERAL CLEANING
STORAGE GUIDE
FRAME AND ENGINE NUMBER
DRIVING METHOD
DRIVING POSITION
PRECAUTION WHEN DRIVING
STARTING
TURNING METHOD
PRINCIPLE OF TURN
EFFECT OF SPEED
3 POSITIONS OF TURNING
TURNING METHOD
PRECAUTION WHEN TURNING
BRAKING METHOD
BASIC PRINCIPLE OF BRAKE(FRICTION FORCE)
RESTRAINT OF BRAKING EFFECT (INERTIA)
BRAKING METHOD
COMPARISION OF BRAKING DISTANCE
IMPACT WHEN COLLISION
WIRING DIAGRAM (EURO2)
WIRING DIAGRAM (EURO3)
2
29
29
31
31
32
32
33
34
35
35
36
37
38
38
39
40
40
41
41
42
43
43
44
45
46
46
46
47
48
49
50
50
50
51
51
51
52
53
3
SPECIFICATION
LENGTH×WIDTH×HEIGHT(mm)
WHEEL BASE(mm)
GROUND CLEARANCE(mm)
SEAT HEIGHT(mm)
DRY WEIGHT(kgf)
PASSENGER
ENGINE TYPE
PISTON DISPLACEMENT(cc)
BORE AND STROKE(mm)
STARTING SYSTEM
TRANSMISSION TYPE
1,910×750×1,090
1,360
126
755
130
2
124.9
56.0×50.7
START MOTOR
CVT
IGNITION SYSTEM
BATTERY CAPACITY
ECU (C.D.I)
12V10AH(MF TYPE)
120/70-13
130/60-13
TELESCOPIC
UNIT SWING OIL DAMPER
HYDRAULIC DISK
HYDRAULIC DISK
CR8EH-9
15/30 (15)
ITEM DATA ITEM DATA
FR.
RR.
FR.
RR.
FR.
RR.
SPARK PLUG
FUSE(A)
TIRE SIZE
SUSPENSION
BRAKE
FUEL CAPACITY(ℓ)
RESERVE FUEL CAPACITY(ℓ)
7.1ℓ(6.8)
1.2ℓ
OIL-COOLED / AIR- COOLED
4CYCLE
“( )” MARKED CONTENSTS APPLY TO EURO 2 ONLY
This manual describes matters pertaining to correct operation,
safe operation and simple maintenance of the vehicle you
purchased.
To ensure more comfortable and safer operation, make sure to
read this manual carefully prior to operation.
●
The photographs and drawings shown in this manual may
differ from those of actual vehicles due to changes in vehicle
specifications and modifications made.
●
This vehicle is designed for 2 riders including the operator.
●
Careful driving and the wearing of proper attire and safety
equipment are the most important factors in the safe operation
of the scooter. Please obey traffic regulations and do not be
hurried and careless.
●
Many new vehicle owners operate their newly purchased
vehicles with great care and attention to safety factors.
However, after becoming accustomed to the operations are
often discarded, which can lead to accidents. Please don't let
this happen to you and always approach the operation of your
vehicle with the safety considerations needed.
When operating the vehicle, always keep in mind and obey
the notes of precaution printed on the“Safety Precaution
Label”attached to the vehicle.
4
OPERATION INSTRUCTION SAFETY PRECAUTIONS
●
Be sure to wear helmet at all time.
●
Be sure to put on gloves at all time.
●
Always respect speed limits where these are posted.
However, always adjust your speed to the visibility,
road and traffic conditions you are riding in.
●
Beware of muffler affer driving as it is still hot to be
burnt. Especially never children touch on it.
●
For safety, do not change, alteration or modification the
vehicle.
●
Regularly conduct specified maintenance inspections.
<Maintenance Inspection Points>
Brakes, Tires, Oil, Lights, Horn, Instruments
CAUTION
●
Do not use polluted gasoline.
Otherwise, it cause rust inside the fuel tank, and close
the supply of fuel to the injector, leading to an improper
engine starting or may cause serious damage to an
engine.
●
Do use genuine oil.
Then it will protect and extend vehicle life.
●
Warranty does not apply to the motorcycles used in
competitions or competitive trials. No motorcycle part
may be tampered with, altered, or replaced with parts
other than original Daelim spare parts during the
warranty periody.
●
As far as any defect caused by contaminated gasoline
or oil, the warranty will be automatically invalidated.
●
Do not operate this vehicle with more than 2 persons
●
This vehicle is designed to carry an operator and one
passenger.
●
Performing daily inspection.
●
Putting on protective gears. (helmet, glove, goggles, etc.)
●
Bring the driver’s licence.
●
Determinating the path to the desired destination.
●
Always hold the handlebars firmly with both hands whiling
driving.
●
The pillion passenger should always hold on to the suitable
grab handles at the sides of the seat with both hands.
otherwise, it cause severe injury or death.
●
Fasten the goods tighty before driving.
●
Exhaust gas contains harmful substance such as carbon
monoxide, Start engine in well-ve ilated places.
5
PRIOR TO STARTING VEHICLE FOR SAFE DRIVING
CAUTION
●
Do not keep engine idling in a closed or poorly ventilated
place for a long period of time.
6
OPERATION
●
Gasoline is extremely flammable. Avoid fire in the work
place, also paying particular attention to spark.
Furthermore the evaporated(gasified) gasoline is highly
explosive.
●
Make sure to stop engine and stay away from fire when
fueling.
●
Operators should naturally fix bodies to keep smooth driving.
●
Please check whether or not you are unnaturally strained and
strung up.
●
Driving pose has a great influence on safe operation.
Please always maintain the center of your body in the middle
of seat. Especially do not sit at the rear seat because it may
lessen the weight of front wheel and cause trembling steering
wheel.
●
When wanting to turn, slightly lean to body toward the
direction of the turn. It is unsafe if the body is not moved in
union with the vehicle.
●
Curvy roads and poor, unpaved roads constantly change in
surface quality. Driving on these roads can be unsafe if
certain safety precautions are not followed.
●
In order to safely drive through these driving conditions,
anticipate coming road conditions, slow down to at least half
the normal speed, and relax your shoulders and wrists while
securely holding the handles.
7
●
Be sure to wear helmet and gloves at all time for seafty.
●
Wear shirts or jackets with tight in the wheel driving.
Otherwise it can be caught in the wheel to cause serious
damage by overturn of vehicle.
●
Many automobile/motorcycle accidents happen because the
automobile driver does not “Look” the motorcyclist.
- Wear bright or reflective clothing.
- Don’t ride in another motorist’s “blind spot”.
●
Be sure to wear dress to catch an eye to avoid any crash from
behind.
●
Modification of vehicle structure of function deteriorates
manipulatability or causes exhaust noise to become louder
shortening the vehicle life. These modifications are not only
prohibited by law but also are the acts harmful to other people.
Modifications are not covered by warranty.
CORRECT ATTIRE
Be sure to wear helmet at all time and
the helmet chin strap securely
fastened.
Always put on gloves.
Choose fitting and
low-heeled shoes.
WARNING
●
Be sure you and a fellow passenger always wear a helmet,
eye protection and other protective apparel when you ride.
●
Not wearing a helmet increases the chance of serious
injury or death in a crash.
Wear shirts or
jackets with tight.
MODIFICATION
8
●
Except designated attachment by DAELIM MOTOR CO.,
LTD., don't attach any extra lighting device, because it may
cause an early discharging of battery.
●
Carefully inspect the accessory to make sure it does not
obscure any lights, reduce ground clearance and banking
angle, or limit suspension travel, steering travel or control
operation.
●
Do not add electrical equipment that will exceed the
motorcycle’s electrical system capacity. A blown fuse could
cause a dangerous loss of lights or engine power.
●
Pay particular attention to fellow passenger so that he/she can
prevent getting burnt by the hot muffler during travel.
WARNING
●
Improper accessories or modifications can cause a
crash in which you can be seriously hurt or killed.
●
Follow all instructions in this manual regarding
accessories and modification.
ATTACHMENT MUFFLER
CAUTION
●
Beware of muffler after driving as it is still hot to be
burnt. Especially never children touch on it. And pay
attention to park where pedestrian zoon.
●
If haystack or vinyl is stuck to the muffler, it might be
fired.
Andere Handbücher für B-BONE
1
Inhaltsverzeichnis
Andere DAELIM Roller Handbücher
DAELIM
DAELIM S2-125 Bedienungsanleitung
DAELIM
DAELIM S4 50cc Bedienungsanleitung
DAELIM
DAELIM E-FIVE Bedienungsanleitung
DAELIM
DAELIM S2 125 Bedienungsanleitung
DAELIM
DAELIM DELFINO Bedienungsanleitung
DAELIM
DAELIM CORDI - Bedienungsanleitung
DAELIM
DAELIM BONITA - CATALOG Bedienungsanleitung
DAELIM
DAELIM LIBERTY Bedienungsanleitung
DAELIM
DAELIM S-FIVE - Bedienungsanleitung
DAELIM
DAELIM NS 125 DLX Bedienungsanleitung
DAELIM
DAELIM BESBI - Bedienungsanleitung
DAELIM
DAELIM A-FOUR - Bedienungsanleitung
DAELIM
DAELIM NS125DLX Bedienungsanleitung
DAELIM
DAELIM S-FIVE - Bedienungsanleitung
DAELIM
DAELIM S1 125 - SERVICE Bedienungsanleitung
DAELIM
DAELIM HISTORY Bedienungsanleitung
DAELIM
DAELIM S-FIVE - Bedienungsanleitung
DAELIM
DAELIM S2 125 Bedienungsanleitung
DAELIM
DAELIM S2 250 - Bedienungsanleitung
DAELIM
DAELIM BESDI 125 - SERVICE Bedienungsanleitung
Beliebte Roller Handbücher anderer Marken
First Choice Mobility
First Choice Mobility Roma Medical Corella S741 Bedienungsanleitung
Carrera
Carrera impel Bedienungsanleitung
Afikim
Afikim Superlight SL-3 Bedienungsanleitung
CareCo
CareCo ZOOM Bedienungsanleitung
Douglas
Douglas Vespa G.S. Bedienungsanleitung
Gazelle
Gazelle with BOSCH System Bedienungsanleitung
