Datalogic Magellan 3300HSi Bedienungsanleitung

MagellanTM 3300HSi

Omni-Directional Imaging Scanner

Quick Reference Guide

Datalogic ADC, Inc.

959 Terry Street

Eugene, OR 97402

USA

Telephone: (541) 683-5700

Fax: (541) 345-7140

procedures described therein may be reproduced or transmitted in any form or by any means

without prior written permission of Datalogic ADC, Inc. or its subsidiaries or affiliates ("Datalogic"

or “Datalogic ADC”). Owners of Datalogic products are hereby granted a non-exclusive, revocable

license to reproduce and transmit this documentation for the purchaser's own internal business

purposes. Purchaser shall not remove or alter any proprietary notices, including copyright notices,

contained in this documentation and shall ensure that all notices appear on any reproductions of

the documentation.

Should future revisions of this manual be published, you can acquire printed versions by contact-

ing your Datalogic representative. Electronic versions may either be downloadable from the Data-

logic website (www.datalogic.com) or provided on appropriate media. If you visit our website and

would like to make comments or suggestions about this or other Datalogic publications, please let

us know via the "Contact Datalogic" page.

Disclaimer

Datalogic has taken reasonable measures to provide information in this manual that is complete

and accurate, however, Datalogic reserves the right to change any specification at any time with-

out prior notice.

Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries,

including the U.S.A. and the E.U. All other brand and product names may be trademarks of their

respective owners.

Magellan is a registered trademark of Datalogic ADC, Inc. in many countries, including the U.S.A.

and the E.U.

Patents

See www.patents.datalogic.com for patent list.

See the Regulatory Addendum included with your product

for additional regulatory, safety and legal information.

i MagellanTM 3300HSi

Table of Contents

Quick Reference ................................................................... 1

Labeling and Nomenclature ............................................... 1

Installation............................................................................ 2

How to Scan.......................................................................... 3

Cleaning ................................................................................ 4

Troubleshooting ................................................................... 5

Productivity Index Reporting™ Option ............................... 5

Scanner Push Button ................................................... 6

LED and Beeper Indicators ................................................. 8

Error Codes ......................................................................... 10

Going Green ........................................................................ 11

Bar Code Mask ................................................................... 12

Programming ..................................................................... 13

ii MagellanTM 3300HSi

NOTES

Quick Reference Guide 1

Quick Reference

Use this guide to quickly complete your installation and begin

using your scanner. For more details, including programming

information, reference the Product Reference Guide (PRG), which

is available for viewing and download from the Datalogic website

listed on the back cover of this manual.

Labeling and Nomenclature

Figure 1. Labeling and Nomenclature

1. Top Cover 2. Speaker Port

3. Cover Removal Indentation 4. Push Button

5. Label 6. Lift Handles

7. LED Indicator 8. Cable Cover

9. SD Card Slot

2Magellan

TM 3300HSi

Installation

Connect the scanner to the host (terminal) using the interface (I/

F) cable as shown in Figure 2. A cable from an older existing

installation can be re-used if it uses Power Off the Terminal

(POT), unless it is a USB POT cable. If external power is used/

needed, plug the AC Adapter into the AC wall outlet, then connect

it to the I/F cable as shown in ‘b’ and ‘c’ of the illustration.

Scan some known-good bar code samples to verify correct oper-

ation. The scanner should beep and/or flash its good read LED1

and send the bar code data to the host or terminal. If not, use the

Troubleshooting section of this guide to identify any problems.

Remove the Top

Cover and use the lift

handles provided

(see Figure 1) when-

ever lowering or lift-

ing the scanner from

the counter.

Scanner installation

is complete.

Figure 2.

Connections

1. Be aware that beeper and LED behavior may have previously been config-

ured as “disabled” by another user.

or...

Power Off

the Terminal

(POT)

Terminal (PC)

To Terminal (PC)

Keyboard Wedge, RS-232 and USB Cables

Other Non-POT Cables

via short adapter cable

Keyboard

Wedge

Quick Reference Guide 3

How to Scan

The scanner is mounted flush with the counter to allow items to

be slid or pushed over its top in the direction of the arrow as

shown in Figure 3. Face the bar code toward the scanner or direc-

tion of scan to optimize the scan rate.

Figure 3. Scanning Items

1. Product 2. Bar Code

3. LED Indicator 4. Slide or push items in the direction of the

arrow

4Magellan

TM 3300HSi

Cleaning

Exterior surfaces and scan windows exposed to spills, smudges or debris

accumulation require periodic cleaning to assure best performance

during scanning. Use a clean, lint-free cloth or paper towel dampened

with a nonabrasive, mild, water-based window cleaner to wipe away

stains, smudges, fingerprints, spills, etc. from the scan window and exte-

rior surfaces.

CAUTION

DO NOT use abrasive cleaning agents or

abrasive pads to clean this product.

Harsh chemicals, disinfectants, and

cleansers can cause damage which will

adversely affect scanning performance.

CAUTION

DO NOT spray

cleaners directly

on the scanner!

Quick Reference Guide 5

Troubleshooting

Use this table to resolve common problems.

Productivity Index Reporting™ Option

Your scanner may be equipped with the optional Productivity

Index Reporting™feature. This feature allows for data collection

on the readability index of bar codes scanned by the scanner.

This data may be transmitted to the POS Terminal where it may

be easily sorted for action by the MIS department to improve bar

code quality at the front end.

For additional information on how to enable Productivity Index

Reporting in your scanner, please refer to the Product Reference

Guide (PRG)

PROBLEM SOLUTION

Scanner does not power-on Exchange the power supply with a known

good power supply and retest operation.

No communication with the host

Consult your technical support personnel

or refer to your host system manual to

verify the proper interface type, cable and

connection port(s) for the scanner. Verify

the interface cable is securely attached to

the host and the scanner.

The scanner will not read bar codes at

all, or reads poorly

Make sure the window is clean. Check

that the bar codes are of sufficient quality

to be recognized by the scanner. Wrin-

kled, smudged, or torn labels can cause

the scanner to not read at all. Scan

known-good labels of an active symbol-

ogyato check the scanner's read opera-

tion.

a. Reading of the various bar code symbologies can be independently

enabled or disabled in the scanner.

If the scanner still does not function properly, consult the Product Reference Guide

(PRG) or contact your local supplier or Datalogic Customer Support Services.

6Magellan

TM 3300HSi

Scanner Push Button

The Scanner Push Button also performs multiple functions

depending upon the duration of time it is pressed:

NOTE

Volume changes made using the Volume/Tone

Push Button are lost when the scanner is pow-

ered-down and are reset to the configured set-

ting. If you wish to permanently change the

volume, use the special programming labels in

the Product Reference Guide.

Table 1. Scanner Push Button Functions

PRESS

DURATION FUNCTION COMMENT

Momentary

(when scanner is

asleep)

Wakes scanner from

Sleep Mode

Alternatively, the scanner can

be awakened by:

- Moving an object through the

scan zone.

- Scanning with an attached

auxiliary scanner.

Momentary

(when scanner is

awake)

Increments volume

Press the push button momen-

tarily to increase speaker vol-

ume. When the loudest volume

is reached, a repeated press of

the push button cycles volume

back to the lowest setting, then

volume increases on subse-

quent press(es). Four volume

levels are available.

Hold, then

release when the

beeper sounds

Increments tone

Press the push button for

approximately 2 seconds, then

release. Each time this is done,

the beeper will sound at one of

three tones. Stop when the

desired tone (high, medium or

low) is sounded.
