Dell PowerVault MD1000 Montageanleitung

Latest Update

April 2010

Dell™ PowerVault™ MD1000 Systems

Support Matrix

Table of Contents

Supported RAID Controllers .......................................................................................... 3

PERC 5/E Adapter ..................................................................................................... 3

PERC 6/E Adapter ..................................................................................................... 4

Supported Servers ..................................................................................................... 4

Supported Operating Systems ....................................................................................... 5

Supported Management Software ................................................................................... 5

Supported Hard Drives ................................................................................................ 5

Supported Hardware Configurations ............................................................................... 8

Dell™ PowerVault™ MD1000 Systems Support

Matrix

This document provides information on supported software and hardware for Dell PowerVault MD1000

Systems.

The PowerVault MD1000 supported software and hardware are directly tied to the RAID controller to which it is

attached. If a PERC 5/E or PERC 6/E is supported in a server, then the PowerVault MD1000 is supported on

that server.

NOTE: For the latest driver and firmware releases, see the Downloads section at

support.dell.com.

Supported RAID Controllers

PERC 5/E Adapter

Table 1 PERC 5/E Minimum Revision Requirements for PowerVault MD1000 Systems (SAS/SATA)

Component

Minimum

Revision

Notes

Firmware 5.2.1-0066 Firmware

Microsoft®Windows®2003 Server and

Windows Server 2008

2.14.0.32 Driver

Microsoft Windows Server®2003 x64 2.14.0.64 Driver

Red Hat®Enterprise Linux®

version 3 (x86)

00.00.03.16-1 Driver

Red Hat Enterprise Linux

version 4 (x86 and x86-64)

00.00.03.16-1 Driver

Red Hat Enterprise Linux

version 5 (x86 and x86-64)

00.00.03.16-1 Driver

SUSE®Linux Enterprise

Server 9 (x86-64)

00.00.03.16-1 Driver

SUSE Linux Enterprise Server 10 (x86-64) 00.00.03.16-1 Driver

NOTE: The MD1000 is not supported on SAS 5/E.

NOTE: The MD1000 is not supported as a boot device.

NOTE: Refer to Supported OS section below for additional support added after initial release.

PERC 6/E Adapter

Table 2.

PERC 6/E Minimum Revision Requirements for PowerVault MD1000 Systems (SAS/SATA)

Component

Minimum

Revision

Notes

Firmware 6.0.1-0080 Firmware

Microsoft®Windows®2003 Server and

Windows Server 2008

2.14.0.32 Driver

Microsoft Windows Server®2003 x64 2.14.0.64 Driver

Red Hat®Enterprise Linux®

version 3 (x86)

00.00.03.16-1 Driver

Red Hat Enterprise Linux

version 4 (x86 and x86-64)

00.00.03.16-1 Driver

Red Hat Enterprise Linux

version 5 (x86 and x86-64)

00.00.03.16-1 Driver

SUSE®Linux Enterprise

Server 9 (x86-64)

00.00.03.16-1 Driver

SUSE Linux Enterprise Server 10 (x86-64) 00.00.03.16-1 Driver

NOTE: The MD1000 is not supported on SAS 5/E.

NOTE: The MD1000 is not supported as a boot device.

NOTE: Refer to Supported OS section below for additional support added after initial release.

Supported Servers

To see a current list of supported servers reference www.dell.com/perc.

If a PERC 5/E or PERC 6/E is supported in a server then the PowerVault MD1000 is supported on that server.

NOTE: For the latest BIOS information, see the specific server website on

support.dell.com.

Supported Operating Systems

If a PERC 5/E or PERC 6/E is supported in a server then the PowerVault MD1000 is supported on that server.

To determine the latest supported operating system perform the following two steps:

1) Reference www.dell.com/perc to verify controller support within a platform.

2) Using the info from step one, reference www.dell.com/ossupport to see the latest supported

Operating Systems for that platform.

Supported Management Software

Table 3.

Minimum Supported Management Software for PowerVault

MD1000 Systems

Software Minimum OMSA Revision Notes

Dell OpenManage™ 5.3

The minimum supported OMSA version for MD1000 is 5.3. Refer to your server’s specific documentation for

minimum supported OMSA level.

Supported Hard Drives

Table 4. below contains the latest supported Hard Drives at the time of this document publication.

NOTE: If no minimum firmware level is displayed, then the drive has shipped with the required minimum firmware level for support

Table 4.

Supported Hard Drives for PowerVault MD1000 Systems

Drive description Model Number Minimum Firmware

Level

Maxtor SAS 73 GB 10K RPM ATLAS10K5_073SAS BP05

Maxtor SAS 146 GB 10K RPM ATLAS10K5_147SAS BP05

Maxtor SAS 300 GB 10K RPM ATLAS10K5_300SAS BP05

Maxtor SAS 36 GB 15K RPM ATLAS15K2_036SAS BP05

Maxtor SAS 73 GB 15K RPM ATLAS15K2_073SAS BP05

Maxtor SAS 146 GB 15K RPM ATLAS15K2_147SAS BP05

Fujitsu (AL9LX) SAS 36 GB 15K RPM MAX3036RC D206

Fujitsu (AL9LX) SAS 73 GB 15K RPM MAX3073RC D206

Fujitsu (AL9LX) SAS 146 GB 15K RPM MAX303147RC D206

Fujitsu (AL10LX) SAS 73 GB 15K RPM MBA3073RC

Fujitsu (AL10LX) SAS 146 GB 15K RPM MBA3147RC

Fujitsu (AL10LX) SAS 300 GB 15K RPM MBA3300RC

Hitachi (Ultrastar 15K147) SAS 36 GB 15K RPM HUS151436VLS300 A280

Hitachi (Ultrastar 15K147) SAS 73 GB 15K RPM HUS151473VLS300 A280

Hitachi (Ultrastar 15K147) SAS 146 GB 15K RPM HUS151414VLS300 A280

Hitachi (Ultrastar 15K300) SAS 73 GB 15K RPM HUS153073VLS300

Hitachi (Ultrastar 15K300) SAS 146 GB 15K RPM HUS153014VLS300

Hitachi (Ultrastar 15K300) SAS 300 GB 15K RPM HUS153030VLS300

Hitachi (Ultrastar 15K450) SAS 300 GB 15K RPM HUS154530VLS300

Hitachi (Ultrastar 15K450) SAS 450 GB 15K RPM HUS154545VLS300

Hitachi SAS 300GB 15K RPM HUS156030VLS600

Hitachi SAS 450GB 15K RPM HUS156045VLS600

Hitachi SAS 600GB 15K RPM HUS156060VLS600

Seagate (15K.4) SAS 36 GB 15K RPM ST336754SS S410

Seagate (15K.4) SAS 73 GB 15K RPM ST373454SS S410

Seagate (15K.4) SAS 146 GB 15K RPM ST3146854SS S410

Seagate (15K.5) SAS 73 GB 15K RPM ST373455SS

Seagate (15K.5) SAS 146 GB 15K RPM ST3146855SS

Seagate (15K.5) SAS 300 GB 15K RPM ST3300655SS

Seagate (15K.6) SAS 146GB 15K RPM ST3146356SS

Seagate (15K.6) SAS 300GB 15K RPM ST3300656SS

Seagate (15K.6) SAS 450GB 15K RPM ST3450856SS

Seagate (Cheetah 15K.7) SAS 300GB 15K RPM ST3300657SS

Seagate (Cheetah 15K.7) SAS 450GB 15K RPM ST3450857SS

Seagate (Cheetah 15K.7) SAS 600GB 15K RPM ST3600057SS

Seagate (T10) SAS 73 GB 10K Performance ST373355SS

Seagate (T10) SAS 146 GB 10K Performance ST3146755SS

Seagate (T10) SAS 300 GB 10K Performance ST3300555SS

Seagate (TNS) SAS 400 GB 10K RPM ST3400755SS

Seagate (Cheetah NS 10K.2) SAS 600GB 10K RPM ST3600002SS

Hitachi (Ultrastar A7K1000) SATA 500 GB 7.2K RPM HUA721050KLA330 A74A

Hitachi (Ultrastar A7K1000) SATA 750 GB 7.2K RPM HUA721075KLA330 A74A

Hitachi (Ultrastar A7K1000) SATA 1 TB 7.2K RPM HUA721010KLA330 A74A

Hitachi (Ultrastar A7K2000) SATA 2TB 7.2K RPM HUA722020ALA330

Hitachi (Deskstar 7K500) SATA 500 GB 7.2K RPM HDS725050KLA360

Seagate (Barracuda ES.1) SATA 250 GB 7.2K RPM ST3250620NS 3.BKE

Seagate (Barracuda ES.1) SATA 500 GB 7.2K RPM ST3500630NS 3.BKE

Seagate (Barracuda ES.1) SATA 750 GB 7.2K RPM ST3750640NS 3.BKE

Seagate (Barracuda ES.2) SAS 500 GB 7.2K RPM ST3500620SS

Seagate (Barracuda ES.2) SAS 750 GB 7.2K RPM ST3750630SS

Seagate (Barracuda ES.2) SAS 1 TB 7.2K RPM ST31000640SS

Seagate (Barracuda ES.2) SATA 500 GB 7.2K RPM ST3500320NS

Seagate (Barracuda ES.2) SATA 750 GB 7.2K RPM ST3750330NS

Seagate (Barracuda ES.2) SATA 1 TB 7.2K RPM ST31000340NS

Seagate (Constellation ES) SAS 500GB 7.2K RPM ST3500414SS

Seagate (Constellation ES) SAS 1TB 7.2K RPM ST31000424SS

Seagate (Constellation ES) SAS 2TB 7.2K RPM ST32000444SS

Seagate (Constellation ES) SATA 500GB 7.2K RPM ST3500514NS

Seagate (Constellation ES) SATA 1TB 7.2K RPM ST31000524NS

Seagate (Constellation ES) SATA 2TB 7.2K RPM ST32000544NS

Western Digital (WD2500JS) SATA 250 GB 7.2K RPM WD2500JS-75NCB3 2E04

Western Digital (WD2500YS) SATA 250 GB 7.2K RPM WD2500YS-18SHB2 6C05

Western Digital (RE) SATA 500GB 7.2K RPM WD5000YS-18MPB1 2E0A

Western Digital (RE1) SATA 500 GB 7.2K RPM WD500YS-18MPB12

Western Digital (RE2) SATA 500 GB 7.2K RPM WD5001ABYS-18YNA0

Western Digital (GP250RE2) SATA 1 TB 5.4K RPM WD1000FYPS-18ZKB0

Western Digital (XL320RE) SATA 500 GB 7.2K RPM WD5002ABYS-18B1B0

Western Digital (XL333RE) SATA 750GB 7.2K RPM WD7502ABYS-18A6B0

Western Digital (XL333RE) SATA 1TB 7.2K RPM WD1002FBYS-18A6B0

Western Digital (EP500M) SATA 2TB 5.4K RPM WD2002FYPS-18U1B0

Supported Hardware Configurations

NOTE: The following MD1000 hardware configurations are supported only on Dell-qualified hardware.

There is a limit of two RAID controllers (PERC 5/E and/or PERC 6/E) per PowerEdge server. There is a limit of

three MD1000 enclosures per controller port. Therefore, the maximum number of supported enclosures is 12.

-[(2 controllers) x (2 ports) x (3 enclosures)] = 12 enclosures

Supported Hardware Configuration shows typical hardware configurations for the PowerVault MD1000

enclosure.

Max Configuration on a Single PERC 5/E or PERC 6/E Controller (both ports connected) shows the maximum

configuration in a single PERC 5/E or PERC 6/E controller (three enclosures per port in unified mode) with

both ports connected.

Figure 1. Supported Hardware Configuration

Figure 2. Max Configuration on a Single PERC 5/E or PERC 6/E Controller (both ports connected)

The PERC 6/E adapter can detect and use redundant paths to drives contained in an MD1000 enclosure. With

redundant paths, if one path fails, another path can be used to communicate between the controller and the

hard drive.

NOTE: Redundant Path connectivity is not supported on PERC 5/E

Host controllerHost controller

Split Mode

Single-host configuration

Host controller

Two-host configuration

Host controller

Unified Mode

Unified Mode single-HBA host server

Figure 3. Redundant Path with 1 Enclosure

Supported Configuration/Setup Unsupported Configuration/Setup

Figure 4. Redundant Path with 2 Enclosures

Supported Configuration/Setup Unsupported Configuration/Setup

Figure 5. Redundant Path with 3 Enclosures

Supported Configuration/Setup Unsupported Configuration/Setup
