Denver SCK-5300 MK2 Betriebsanleitung

Original Instruction

SCK-5300 MK2

www.facebook.com/denverelectronics

Before operating this electrickids scooter,parents/adult supervisorsmust read all the

instructions for safe assembly, operations and maintenance. User’s manual can guide you

through the functions and usageof the electric kidsscooter. Before usingthiselectric kids

scooter, familiarize yourself withhow to operate, so thatyou can keepthe electric kidsscooter

in the best condition possible.

Warning!

This appliance can be used by children aged from 8 years and above and personswith reduced

physical,sensory or mentalcapabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning useof theappliance in a safe wayandunderstand the

hazards involved.Children shall not play with the appliance. Cleaning and user maintenance shall

not be made by children without supervision.

Chapter 1 General information

We urge owners of this electric kids scooter model to charge and store it in a safe place.

To increase the safety and life of the batteries associated with this model it is important not

to charge this model if the temperature is below 5°C or above 45°C. In addition, the

charger must be disconnected when the battery is fully charged. Only use the supplied

charger (XHK-922B-25210).

We do not recommend kids under 6 years of age to ride this electric kids scooter.

WARNING:

To avoid serious injury:

PARENTAL AND ADULT RESPONSIBILITY AND SUPERVISION ARE

NECESSARY.

Riding this electric kids scooter can be hazardous. Parents and supervising adults need to

select the riding products which are appropriate for their child’s age to avoid children are

too immature or inexperienced to endanger themselves.

Parents/supervising adults must assemble the product and make sure the product is

working well before they let the children use the product.

Parents/supervising adults must teach children how to safely ride this electric scooter.

Always pay attention to where the children are going.

Cleaning and maintenance shall not be made by children, only by parents or supervising

adults. Please make sure to cover the charging input to avoid electrical problems. Always

disconnect the product from charger prior to wiping it down or cleaning it with a damp cloth.

Only clean the scooter with a damp cloth. Do not use running water or a pressured

water-gun. Do not clean with alcohol, gas, kerosene or other corrosive and volatile

chemical solvents.

Do not immerse the product in water.

Store the product in a dry and cool place when not use it. Defectives caused by storing

or using the electric kids scooter in wet/humid places are not covered by the warranty.

Do not leave the device exposed to sunlight in a car.

1.1 The risk of driving

WARNING:

-Learn how to drive safely before you drive fast on the electric kids scooter.

-Do not make dangerous moves or one-handed rides while the scooter is running.

Keep your feet on the foot pedal.

-Falling, losing control, crashing, including violating the rules in the user’s manual

can lead to injury.

-Speed and range may differ based on rider’s weight, terrain, temperature, and

driving style.

-Make sure to wear helmet, protective clothing, kneepads and elbow pads before

using the electric kids scooter to avoid serious injury.

-Do not wear loose clothing or open laces that can be caught in the wheels.

-Make sure to read the manual carefully before using the electric kids scooter.

-Only for use in dry weather. Don’t ride in rain, snow or moist areas.

-When encountering rough or uneven road conditions, please slow down or get off

the scooter.

-Do not try to directly pass steps exceeding3 cm. It may cause the scooter to

subvert, causing the rider to be injured or the scooter to be damaged.

-This electric kids scooter is for domestic use only. Direct parental/adult supervision

is required at all times. Only use the product in controlled environments free of

potential traffic hazards and do not use it on public streets.

-Do not use this product if the temperature is below -5°C.

-Do not use it in a sloping section over 5 degrees. For use over 5 degrees uphill, you

need to assist with your foot.

Please note:

The manufacturer accepts no liability for improper use of this product.

1.2 The preparation before operation

Before using, the battery should be fully charged. Please check Chapter 2.3.

1.3 The weight limitation of the operator

The reason of the weight limitation:

1. guarantee the safety of the operator

2. avoid overloading which can make motor defective.

Maximum load: 50kg.

Defective motor caused by overloading will not be covered by the warranty.

Chapter 2 Operating the Electric kids scooter

2.1 Folding procedure

Lift the folding handle up with one hand and lift the front fork tube with the other hand

and you hear a "click".

Press the folding lock firmly (the folding lock can adjust the tightness).

Use the screwdriver to lock the handle block.

Make sure that the buckle is released.

Press adjustment marble with one hand and adjust the telescopic rod to the proper

position with the other hand. Users must adjust the height of the product to the proper

position to ensure safe driving.

Tighten and lock the buckle.

2.2 Using the scooter

Start using the electric kids scooter.

1. Hold the handle with both hands and place one foot on the round power pedal and

keep it there.

2. Gently push forward with the other foot. When you reach 5-6 km/h then the motor will

make a BEEP and the engine starts.

3. Now the electric kids scooter drives itself and will maintain a speed of 4-6km/h

dependent on the surface.

4. If you want to stop the motor again you just step off the power pedal.

5. If you want to slow down then step lightly on the rear mechanical brake.

6. If you want to stop. Please use one foot to step on the rear mechanical brake. After

hearing the BEEP, then continueto step on the brake until the electrickids scooter

stops.

7. If the scooter gives a continuous series of “beeps”, the battery is low. Please charge

thescooter.

Maintenance

To ensure you get the best possible performance and experience from your electric scooter, it is important

to do regular maintenance for important parts of the product.

●Battery maintenance

●Bearings, Screws, Brakes and Wheels

●Storage and Cleaning

Your electric scooter will require some maintenance so please read and familiarize yourself with this

guide.

●Battery maintenance

All batteries have a life cycle, and performance will decrease over time, however here are some advice

to maximize the life span of the battery.

Make sure that the battery is charged at regular intervals, even if you do not use the electric scooter for a

long time. This is to prevent damage to the battery, caused by low voltage over an extended period.

Avoid draining the battery completely. It is best to charge while there is still power on it. This will extend

battery life. If the battery is constantly depleted, it will damage the battery (damaged battery caused by

wrong handling are not covered by the warranty).

If riding the electric scooter in cold or very hot areas, the battery time can be lower than when riding in

temperatures from 15‐25° Celsius. This is not a failure on the batteries, but normal behavior.

Please notice: Even a fully charged battery will run out of power if the electric scooter is not used for a

period. Expect a fully charged battery to keep power between 90 and 120 days in off mode, before it is fully

discharged. If only partially charged, this period is lower.

Please make sure the battery does not get above 50° Celsius, or below minus 10° Celsius for a longer period.

(e.g. don’t leave the electric scooter in a hot car in summer, do not put battery into fire etc.) Low

temperature (e.g. subzero temperature) can damage the battery cells.

Keep the Electric scooter away from open flame or other sources of heat to prevent the battery from

getting too hot. Also make sure not to leave the electric scooter at freezing temperatures. Both heat and

excessive cold can cause the battery to discharge.

Only use original charger or an official replacement, as different batteries may require specific charger, and

if using other chargers, this could cause damage to the product.

Do not overcharge and discharge the battery.

Please make sure to charge the battery before it is completely out of power, to avoid damaging the battery

cells. (damaged battery caused by wrong handling are not covered by the warranty)

It is forbidden to disassemble battery package. This is only to be handled by official service repair centers

and professionals.

●Bearings,Screws,brakesandWheels

Yourelectricscooterismadeupofmovingparts,whichintime,will be susceptible to wear and tear.

Bearingsandscrews:

Theelectricscooterhassealedanddustproofbearingssothatnolubricationisrequired.Checkthe

bearingsforwearatregularintervalstoavoidunsaferiding.Donotjumponandoffanddonotapply

excessive force otherwise to avoid damage to the bearings. This is not a sports electric scooter.

Makesurethatallscrewsareproperlytightenedtoavoidunsafesituations.

Pleasecheckthescrewsregularlyandtighteniftheyseemloose.

Brakes:

Checkthebrakeforwearatregularintervalstoavoidunsaferiding.Donotapply excessive force toavoid

damagetothebrake.

Wheels:

Checkthewheelsforwearatregularintervalstoavoidunsaferiding.

Electricscooterscomewithdifferentwheelsbutcaningeneralbeseparatedintotireswithinflatableinner

tubesandsolidwheels.

Forinflatabletires,pleasemakesuretokeeptherightpressure,ashardtireswilllastlonger.

Ifthewheelseemswobblyevenafterscrewsaretightened,thebearingsmightbe

worndownandneedreplacement

WARNING

●Please makesuretocheckthatthesteeringsystemiscorrectlyadjustedandthatall

connectioncomponentsarefirmlysecuredand not broken beforeriding,refertohandle

assemblyandsafetyinstruction.

●Pleasereadoperationguideandwarningsofcorrect techniquesforuseandbraking

●Alwayswearshoes.

●Wehighlyrecommendtoalwayswearhelmet/padsforyourownprotection.

●Self‐lockingnutsandotherself‐locking fixingsmaylosetheireffectiveness.

●All parts and materials of electric scooter cannot be changed, modifications of the scooter are

not allowed. If done, then warrantyisvoid.

●Storageandcleaning

IfyourElectricscootergetsdirty,pleasecleanitwithadampclothonly,youmaynotusepressured

water‐gun or running water,asthiscoulddamage vital parts.Itisalsopossibleto use a littletoothpasteif

the dirtisstuck.Remember to clean with dampclothafterthis.

Please make sure to keeptheelectricscooterturned off whilecleaningit,andmake sure to coverthe

charginginputtoavoid problems with theelectronics.

Makesuretodrythescooterwithatowel,shoulditbecomewet.

2.3Chargingthescooter

Thischaptermainlydiscussesthechargingmethods,batterymaintenance,safetyissues

andbatteryspecifications.Forsafetyofyourselfandothers,andextendingthebattery’s

lifeandimprovingbatteryperformance,pleasemakesuretofollowthefollowing

operations.Iftheproductisnotusedforalongperiodoftime,besuretochargeitoncea

monthtoprotectthebatterylife.Chargershouldonlybeoperatedbyanadult.Itisnota

toy.

Note:Ifthebatteryisdamagedduetowater,collisionandotherabnormalusage,it

isnotcovered bythewarranty.

Lowbattery

Iftheelectrickidsscootergivesacontinuousseriesof“beeps”,thebatteryislow.

Pleasestopridingandchargeimmediatelyafterthescooteremitsa lowbattery

warningtonetoavoiddamagetothebatteryoraffectyouruse.

Charging the battery

1. Only use the supplied and dedicated charger (XHK-922B-25210).

2. Open the charging rubber cover on the pedal and insert the charger output

connector into the charging hole.

Please notice: Do not use alcohol, gas, kerosene or other corrosive and volatile chemical solvents. This can

damage both theappearance and the internal structure ofthe electricscooter.

Please store your Electric scooter in a dry and cool environment when not in use. Avoid leaving it outdoors,

as itis not made for storing in wet areas. Nor is it good to expose to hightemperatures caused by directsun

for a long time.

3. Plug the charger input power into the power socket.

4. The charger indicator is red, indicating that it is charging. When the charger

indicator turns green, the battery is fully charged and after approximately 30 mins

the adapter will stop charging.

5. When the charging is finished, unplug the battery charger from the mains power

supply and from the electric kids scooter and close the charging rubber cover

again.

6. The electric kids scooter is ready for use.

WARNING:

Do not charge the battery or use the product in the following cases.

-Giving out some odor or excessive heat.

-Leakage of any substance.

WARNING:

-Do not ride the electric kids scooter when charging!

-It is prohibited to disassemble the battery.

Inhaltsverzeichnis

Sprachen:

Andere Denver Roller Handbücher

Denver

Denver SEL-10800 Bedienungsanleitung

Denver

Denver SEL-10350 ODIN Bedienungsanleitung

Denver

Denver SCO-65210 Betriebsanleitung

Denver

Denver SEL-65110 MK2 Bedienungsanleitung

Denver

Denver SEL-10820F Betriebsanleitung

Denver

Denver SEL-85360F Betriebsanleitung

Denver

Denver SCK-5400 Betriebsanleitung

Denver

Denver DSC-5000 Bedienungsanleitung

Denver

Denver SEL-65230 Reparaturanleitung

Denver

Denver DBO-6501 Betriebsanleitung

Denver

Denver SEL-10350 ODIN Bedienungsanleitung

Denver

Denver SEL-10860DONARPRO Betriebsanleitung

Denver

Denver DBO-6500 Bedienungsanleitung

Denver

Denver SEL-85355 Bedienungsanleitung

Denver

Denver SEL-80135 Betriebsanleitung

Denver

Denver SEL-85350F MK2 Bedienungsanleitung

Denver

Denver SEL-85350F Bedienungsanleitung

Denver

Denver DBO-8000 Betriebsanleitung

Denver

Denver SEL-10510 Bedienungsanleitung

Denver

Denver DSC-5000 Bedienungsanleitung

Denver

Denver SEL-10820 Betriebsanleitung

Denver

Denver SEL-80130F Bedienungsanleitung

Denver

Denver SEL-10510F Bedienungsanleitung

Denver

Denver SCO-80125 Bedienungsanleitung

Beliebte Roller Handbücher anderer Marken

TEKTRO

TEKTRO CHEETAH Bedienungsanleitung

Douglas

Douglas Vespa Sprint Installationsanleitung

PLAYTIVE

PLAYTIVE AS-2448 Bedienungsanleitung

Ebinger

Ebinger DONKEY XL Bedienungsanleitung

Flyer

Flyer Mountain Benutzerhandbuch

BackCountry eBikes

BackCountry eBikes Storm Bedienungsanleitung

equipmed

equipmed FreeRoam II Bedienungsanleitung

Yoto

Yoto Lion Bedienungsanleitung

WESTHILL BIKES

WESTHILL BIKES LINK Bedienungsanleitung

BAnff

BAnff eProdigy series Bedienungsanleitung

Winther

Winther 475 Bedienungsanleitung

Jetson

Jetson JBZL17 Bedienungsanleitung

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Bedienungsanleitung

Carrera

Carrera impel Bedienungsanleitung

Afikim

Afikim Superlight SL-3 Bedienungsanleitung

CareCo

CareCo ZOOM Bedienungsanleitung

Douglas

Douglas Vespa G.S. Bedienungsanleitung

Gazelle

Gazelle with BOSCH System Bedienungsanleitung
