Denver SCK-5400 Betriebsanleitung

Original Instruction

SCK-5400

www.facebook.com/denverelectronics

Before operating this electric kids scooter, parents/adult supervisors must read all the instructions for

safe assembly, operations and maintenance. User’s manual can guide you through the functions and

usage of the electric kids scooter. Before using this electric kids scooter, familiarize yourself with how to

operate, so that you can keep the electric kids scooter in the best condition possible.

The instruction manual must be retained since it contains important information.

Warning: This toy contains batteries that are non-replaceable.

Warning!

This appliance can be used by children aged from 8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of experience and knowledge if they have been given

supervision or instruction concerning use of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made

by children without supervision.

Chapter 1 Chapter 1 General information

We urge owners of this electric kids scooter model to charge and store it in a safe place. To increase

the safety and life of the batteries associated with this model it is important not to charge this model if

the temperature is below 5℃or above 45℃. In addition, the charger must be disconnected when the

battery is fully charged. Use only with the supplied charger XHK-922-25210 on the product.

The battery charger used with the electric toy shall be regularly examined for damage to the supply

cord, plug, enclosure or other parts, and in the event of damage, it shall not be used until the damage

has been repaired.

WARNING:

To avoid serious injury:

PARENTAL AND ADULT RESPONSIBILITY AND SUPERVISION ARE

NECESSARY.

Riding this electric kids scooter can be hazardous. Parents and supervising adults need to select the

riding products which are appropriate for their child’s age to avoid children are too immature or

inexperienced to endanger themselves.

Parents/supervising adults must assemble the product and make sure the product is working well

before they let the children use the product.

Parents/supervising adults must teach children how to safely ride this electric scooter. Always pay

attention to where the children are going.

Cleaning and maintenance shall not be made by children, only by parents or supervising adults. Please

make sure to cover the charging port with the rubber protection cap to avoid electrical problems.

Always disconnect the product from charger prior to wiping it down or cleaning it with a damp cloth.

Only clean the scooter with a damp cloth. Do not use running water or a pressured water-gun. Do not

clean with alcohol, gas, kerosene or other corrosive and volatile chemical solvents.

Do not immerse the product in water.

Store the product in a dry and cool place when not use it. Defectives caused by storing or using the

electric kids scooter in wet/humid places are not covered by the warranty.

Do not leave the device exposed to sunlight in a car.

1.1 The risk of driving

WARNING:

- This toy is unsuitable for children under 6 years due to its maximum speed.

Protective equipment should be worn. Not to be used in traffic.

- 50 kg max.

-Learn how to drive safely before you drive fast on the electric kids scooter.

-Do not make dangerous moves or one-handed rides while the scooter is running.

Keep your feet on the foot pedal.

-Falling, losing control, crashing, including violating the rules in the user’s manual can lead to injury.

-Speed and range may differ based on rider’s weight, terrain, temperature, and driving style.

-Make sure to wear helmet, protective clothing, kneepads and elbow pads before using the electric

kids scooter to avoid serious injury.

-Do not wear loose clothing or open laces that can be caught in the wheels.

-Make sure to read the manual carefully before using the electric kids scooter.

-Only for use in dry weather. Don’t ride in rain, snow or moist areas.

-When encountering rough or uneven road conditions, please slow down or get off the scooter.

-Do not try to directly pass steps exceeding3 cm. It may cause the scooter to subvert, causing the

rider to be injured or the scooter to be damaged.

-This electric kids scooter is for domestic use only. Direct parental/adult supervision is required at all

times. Only use the product in controlled environments free of potential traffic hazards and do not

use it on public streets.

-Do not use this product if the temperature is below -5℃.

-Do not use it in a sloping section over 5 degrees. For use over 5 degrees uphill, you need to assist

with your foot.

Please note:

The manufacturer accepts no liability for improper use of this product.

1.2 The preparation before operation

Before using, the battery should be fully charged. Please check Chapter 2.3.

1.3 The weight limitation of the operator

The reason of the weight limitation:

1. guarantee the safety of the operator

2. avoid overloading which can make motor defective.

Maximum load: 50kg.

Defective motor caused by overloading will not be covered by the warranty.

Chapter 2 Operating the Electric kids scooter

2.1

(A) Product installation instructions

2. Connect the vertical pipe to the bottom

plate and align it with the screw

1. Untwist in the direction of the arrow

1. Tighten the handle in the

direction of the arrow.

3. Lock the screw with a screwdriver 4. Tighten the cap in the direction of

the arrow

2. Press the metal lock on the handle,

and then hold it while you pull up, or

push down until the handle reaches the

preferred height.

(

)

: Product expansion

demonstration

2.2 Using the scooter

Start using the electric kids scooter.

1. Hold the handle with both hands and place one foot on the round pedal switch and keep it there.

2. Gently push forward with the other foot. When you reach 3km/h then the motor will make a BEEP

and the engine starts.

3. Now the electric kids scooter drives itself and will maintain a speed of 3 -8km/h dependent on the

surface.

Tighten the cap after adjusting the height

Pedal switch

4. If you want to stop the motor again you just step off the pedal switch.

5. If you want to slow down then step lightly on the rear mechanical brake.

6. If you want to stop. Please use one foot to step on the rear mechanical brake. After hearing the

BEEP, then continue to step on the brake until the electric kids scooter stops.

7. If the scooter gives a continuous series of “beeps ,beeps ,beeps,beeps ,beeps”, the battery is low.

Please charge the scooter.

8. If the scooter gives a continuous series of “beeps ,beeps ,beeps”, means over speeding . Please

slow down otherwise scooter will be damaged.

9. Automatically turn off: The scooter will automatically turn off after 15 seconds of inactivity. If

you need to use it , please slide the motor again.

10. Lights: After the motor is started, the lights cycle from cyan to seven colors, then turn off, and

turn on again when the induction contact is pressed.

hen the scooter is started, press the switch by foot, then the buzzer will emit a”beep”. If it is

not started when press the switch, the buzzer will not sound. In this way can show that you

drive the scooter in right way.

Maintenance

To ensure you get the best possible performance and experience from your electric scooter, it is

important to do regular maintenance for important parts of the product.

Battery maintenance

Brake

Bearings, Screws, Brakes and Wheels

Storage and Cleaning

Your electric scooter will require some maintenance so please read and familiarize yourself with

this guide.

Battery maintenance

All batteries have a life cycle, and performance will decrease over time, however here are some advice

to maximize the life span of the battery.

Make sure that the battery is charged at regular intervals, even if you do not use the electric scooter for

a long time. This is to prevent damage to the battery, caused by low voltage over an extended period.

Avoid draining the battery completely. It is best to charge while there is still power on it. This will extend

battery life. If the battery is constantly depleted, it will damage the battery (damaged battery caused by

wrong handling are not covered by the warranty).

If riding the electric scooter in cold or very hot areas, the battery time can be lower than when riding in

temperatures from 15-25° Celsius. This is not a failure on the batteries, but normal behavior.

Please notice: Even a fully charged battery will run out of power if the electric scooter is not used for a

period. Expect a fully charged battery to keep power between 90 and 120 days in off mode, before it is

fully discharged. If only partially charged, this period is lower.

Please make sure the battery does not get above 50° Celsius, or below minus 10° Celsius for a longer

period. (e.g. don’t leave the electric scooter in a hot car in summer, do not put battery into fire etc.) Low

temperature (e.g. subzero temperature) can damage the battery cells.

Keep the Electric scooter away from open flame or other sources of heat to prevent the battery from

getting too hot. Also make sure not to leave the electric scooter at freezing temperatures. Both heat and

excessive cold can cause the battery to discharge.

Only use original charger or an official replacement, as different batteries may require specific charger,

and if using other chargers, this could cause damage to the product.

Do not overcharge and discharge the battery.

Please make sure to charge the battery before it is completely out of power, to avoid damaging the

battery cells. (damaged battery caused by wrong handling are not covered by the warranty)

It is forbidden to disassemble battery package. This is only to be handled by official service

repair centers and professionals.

Bearings, Screws, brakes and Wheels

Your electric scooter is made up of moving parts, which in time, will be susceptible to wear and tear.

Bearings and screws:

The electric scooter has sealed and dustproof bearings so that no lubrication is required. Check the

bearings for wear at regular intervals to avoid unsafe riding. Do not jump on and off and do not apply

excessive force otherwise to avoid damage to the bearings. This is not a sports electric scooter.

Make sure that all screws are properly tightened to avoid unsafe situations.

Please check the screws regularly and tighten if they seem loose.

Brakes:

Check the brake for wear at regular intervals to avoid unsafe riding. Do not apply excessive force to

avoid damage to the brake.

Wheels:

Check the wheels for wear at regular intervals to avoid unsafe riding.

Electric scooters come with different wheels but can in general be separated into tires with inflatable

inner tubes and solid wheels.

If the wheel seems wobbly even after screws are tightened, the bearings might be worn down and need

replacement

WARNING

Please make sure to check that the steering system is correctly adjusted and that all connection

components are firmly secured and not broken before riding, refer to handle assembly and safety

instruction.

Please read operation guide and warnings of correct techniques for use and braking

Always wear shoes.

We highly recommend to always wear helmet/pads for your own protection.

Self‐locking nuts and other self‐locking fixings may lose their effectiveness.

All parts and materials of electric scooter cannot be changed, modifications of the scooter are not

allowed. If done, then warranty is void.

Storage and cleaning

If your Electric scooter gets dirty, please clean it with a damp cloth only, you may not use pressured

water‐gun or running water, as this could damage vital parts. It is also possible to use a little

toothpaste if the dirt is stuck. Remember to clean with damp cloth after this.

Please make sure to keep the electric scooter turned off while cleaning it, and make sure to cover the

charging port with the rubber protection cap to avoid problems with the electronics.

Make sure to dry the scooter with a towel, should it become wet.

Please notice: Do not use alcohol, gas, kerosene or other corrosive and volatile chemical solvents.

This can damage both the appearance and the internal structure of the electric scooter.

Please store your Electric scooter in a dry and cool environment when not in use. Avoid leaving it

outdoors, as it is not made for storing in wet areas. Nor is it good to expose to high temperatures

caused by direct sun for a long time.

2.3 Charging the scooter

This chapter mainly discusses the charging methods, battery maintenance, safety issues and battery

specifications. For safety of yourself and others, and extending the battery’s life and improving battery

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Denver Roller Handbücher

Denver

Denver SEL-10810FD Bedienungsanleitung

Denver

Denver SCO-80130LIME Bedienungsanleitung

Denver

Denver DSC-5000MK2 Betriebsanleitung

Denver

Denver SEL-90100 Betriebsanleitung

Denver

Denver SEL-80130 MK2 Bedienungsanleitung

Denver

Denver SEL-10350 ODIN Bedienungsanleitung

Denver

Denver SEL-10510F Bedienungsanleitung

Denver

Denver SEL-10510 Bedienungsanleitung

Denver

Denver DBO-6520 Bedienungsanleitung

Denver

Denver SCO-80125 Bedienungsanleitung

Denver

Denver DBO-6501 Betriebsanleitung

Denver

Denver SEL-80140F Betriebsanleitung

Denver

Denver SCK-5300 MK2 Betriebsanleitung

Denver

Denver SEL-10370F Betriebsanleitung

Denver

Denver SEL-80130F Bedienungsanleitung

Denver

Denver SEL-65110 MK2 Bedienungsanleitung

Denver

Denver DSC-5000 Bedienungsanleitung

Denver

Denver SCO-80110 Bedienungsanleitung

Denver

Denver SEL-80140 Bedienungsanleitung

Denver

Denver SEL-80150 Betriebsanleitung

Denver

Denver SEL-10820F Betriebsanleitung

Denver

Denver SEL-85350F MK2 Bedienungsanleitung

Denver

Denver SEL-10800 Bedienungsanleitung

Denver

Denver SEL-65230 Reparaturanleitung

Beliebte Roller Handbücher anderer Marken

TEKTRO

TEKTRO CHEETAH Bedienungsanleitung

Douglas

Douglas Vespa Sprint Installationsanleitung

PLAYTIVE

PLAYTIVE AS-2448 Bedienungsanleitung

Ebinger

Ebinger DONKEY XL Bedienungsanleitung

Flyer

Flyer Mountain Benutzerhandbuch

BackCountry eBikes

BackCountry eBikes Storm Bedienungsanleitung

equipmed

equipmed FreeRoam II Bedienungsanleitung

Yoto

Yoto Lion Bedienungsanleitung

WESTHILL BIKES

WESTHILL BIKES LINK Bedienungsanleitung

BAnff

BAnff eProdigy series Bedienungsanleitung

Winther

Winther 475 Bedienungsanleitung

Jetson

Jetson JBZL17 Bedienungsanleitung

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Bedienungsanleitung

Carrera

Carrera impel Bedienungsanleitung

Afikim

Afikim Superlight SL-3 Bedienungsanleitung

CareCo

CareCo ZOOM Bedienungsanleitung

Douglas

Douglas Vespa G.S. Bedienungsanleitung

Gazelle

Gazelle with BOSCH System Bedienungsanleitung
