Industrial Endoscope
DS350
01
Product manual
DEPSTECH® DS350 industrial endoscope was featured as a cost
efficient industrial endoscope with 4.3” digital screen, which was
invented to help car maintenance or pipeline repairing. We hope that
you can use this efficient tool to enable you to finish the job more
rapidly and help you discover the delights of miniature worlds.
※The Child can only operate this device with the guidance of adults,
please do not let them operate this device alone.
Battery
Please do not try to change the built-in battery yourself, it may raise
the risks of leading the battery overheat or get people harmed. For
better battery life spans, we would recommend you charge the device
every 3~6 months. (No matter uses it or not)
Operation and storage conditions
Please keep the tools out of fire source, especially keep it away from
temperature higher than 158℉(70℃) - or lower than -50℉(-10℃).
Be cautious the required working temperature should between
32~113℉(0~45℃). Please keep it in dry, clean area, free from oil,
water, or chemical liquid. Those measures will help the device
maintain longer lifes pans, also it will do great help to keep the
dangerous situation far away.
EN
02
Features
3
4
5
6
2
1
Hold this button for 2s to power on/off the endoscope.
Power Button
Menu Button
Click to enter the menu for more setttings.
“ ” Button
“ ” Button
“ ” Button
a: Time adjustment
b: In the menu mode, select the previous directory
c: Click to brighten the LED lightness
d: Press 2 seconds to change the lens
“ ” Button
a: Time adjustment
b: In the menu mode, select the next directory
c: Click to dim the LED lightness
d: Press 2 seconds to rotate the image 180°
Confirm choice/Long press to enter the album or exit the
album/Click to play or pause;
Hold this button to start video record, single press to
take a photo/end the video record.
1
6
3
45
2
When viewing photos, press to choose to delete the current
photo or delete all photos, and press again to return to the
album.
Photo/Video:
Take photos by pressing button, long press to start video
recording, single press to end video recording.
View Photos:
Long press in preview mode to enter the photo album, and
press / to view photos. Long press again to exit
the photo album.
Delete Photos:
Screen Rotation:
Long press the rotation button, and the image will rotate 180°.
Description of Product Functions:
03
8
7TF Card Slot
Support up to 32G TF card. (The TF card has been inserted into the machine,
please format it for the first time of usage)
Charging Status LED indicator
Red LED indicator flash: Charging status
Red LED indicator stay on: Charging finished
9Reset Button
Short click the reset button with the reset pin to shut down the device.
Micro-USB Charging Port
Charge the endoscope via Micro-USB cable.
10
710
9
8
5. System Reset: Enter the System Reset Interface, choose whether to
restore the factory settings, and then press to confirm;
6. Time Setting: Enter the time setting interface, press to select the
year, month, day, minute and second to be adjusted, press / to
adjust the time, and press to exit after setting;
4. TF Card Formatting: Enter the formatting interface, choose whether to
format, and then press to confirm;
3. Auto OFF Setting: Enter the Auto OFF setting interface, press /
to select the time, and then press to confirm;
2. Language Setting: Enter the language setting interface, press /
to select the language, and then press to confirm;
1. Resolution Setting: Enter the resolution interface, press / to
select the resolution, and then press to confirm;
Enter the MENU interface: Press to enter the menu interface,
press / to select options, and then press to enter the
option interface. Press again to exit.
Click the key to lower the brightness, and click the key to
increase the brightness.
Lens Switching (only applicable to double-lens products):
Long press the button to switch among main lens, side lens and
dual-lens.
04
Lens LED Brightness Adjustment:
Introduction to the Menu Interface:
7. Storage Space: Check the memory card capacity and the remaining
memory;
8. Software Version: Check the firmware version number of this product.
Copyphotoandvideofilestocomputer
The device does not support USB data cable to transfer data, you can
use a TF card reader to copy data directly.
05
Specifications
Model
Screen Spec
Camera Diameter
Best Focal Range
Video Spec
Photo Resolution
Battery Life
Waterproof
Cable Length
Charging Voltage
and Current
DS350 FHD DS350 Dual Camera
4.3” Super LCD Screen
0.216 in 0.31 in
1.18-3.15 in 1.18-3.15 in / 0.79-2.36 in
1080 P / 25 FPS
2 MP 2 x 2 MP
16.5 FT
3 H
IP67
DC 5V/2A
06
FAQ
Q1: The image quality wasn't that good as advertised?
A1: Please adjust the length between the camera and the object that
you’re observing into the focal range. The focal range should be
1.18”~3.15” for single camera version, and 1.18”~3.15”/0.79”~2.36”
in for dual camera version. Besides, it’s essential to adjust the
brightness of your endoscope for the best image quality. It will do a
great help if you wipe the lens of the camera regularly after used.
Q2: The endoscope was failing to turn on?
A2: It might due to low battery status, especially in cold area. To release
the low battery state you’ve to fully charge the endoscope. You can
charge the endoscope for 4~5 H and try to turn it on again.
Q3: The endoscope can not take a picture or record a video?
A3: First please make sure that the TF card has been inserted into the
machine or not. Then make sure that you’ve formatted the TF card
at the first use.
You can follow the steps below:
1. Short press menu
2. Short press “ ” button to remove the cursor down
3. Find and choose “Formate”, then choose “OK”.
