XBee3™

RF Module

Hardware Reference Manual

Revision history—900001543

Revision Date Description

A October 2017 Initial release.

Trademarks and copyright

Digi, Digi International, and the Digi logo are trademarks or registered trademarks in the United

States and other countries worldwide. All other trademarks mentioned in this document are the

property of their respective owners.

Disclaimers

Information in this document is subject to change without notice and does not represent a

commitment on the part of Digi International. Digi provides this document “as is,” without warranty of

any kind, expressed or implied, including, but not limited to, the implied warranties of fitness or

merchantability for a particular purpose. Digi may make improvements and/or changes in this manual

or in the product(s) and/or the program(s) described in this manual at any time.

Warranty

To view product warranty information, go to the following website:

www.digi.com/howtobuy/terms

Send comments

Documentation feedback: To provide feedback on this document, send your comments to

techcomm@digi.com.

Customer support

Digi Technical Support: Digi offers multiple technical support plans and service packages to help our

customers get the most out of their Digi product. For information on Technical Support plans and

pricing, contact us at +1 952.912.3444 or visit us at www.digi.com/support.

XBee3™ RF Module Hardware Reference Manual 2

Contents

XBee3™ RF Module Hardware Reference Manual

General XBee3 specifications

General specifications 7

Regulatory conformity summary 7

Serial communication specifications 8

UART pin assignments 8

GPIO specifications 8

802.15.4-specific specifications

Performance specifications 10

Power requirements 10

Networking and security specifications 10

Communication interface specifications 10

Hardware

Mechanical drawings 12

XBee3 surface-mount (U.FL/RF Pad) 12

XBee3 surface-mount (embedded antenna) 13

XBee3 micro (U.FL/RF Pad) 14

XBee3 micro (chip antenna) 15

Pin signals for the XBee3 surface-mount module 15

Pin signals for the XBee3 micro module 18

Design notes 21

Power supply design 21

Board layout 21

Antenna performance 22

Recommended pin connections 22

Design notes for surface mount PCB antenna and micro footprint chip antenna devices 22

Design notes for RF pad devices 24

Regulatory information

United States (FCC) 28

OEM labeling requirements 28

FCC notices 28

XBee3™ RF Module Hardware Reference Manual 3

XBee3™ RF Module Hardware Reference Manual 4

FCC-approved antennas (2.4 GHz) 29

RF exposure 35

Europe (CE) 35

Maximum power and frequency specifications 36

OEM labeling requirements 36

Declarations of conformity 37

Antennas 37

IC (Industry Canada) 37

Labeling requirements 37

For XBee3: 37

RF Exposure 38

Manufacturing information

Recommended solder reflow cycle 40

Handling and storage 40

Recommended footprint 41

Flux and cleaning 44

Reworking 44

XBee3™ RF Module Hardware Reference Manual

This manual provides information for the XBee3 RF Module hardware. The XBee3 RF Module can be

either the micro or the surface-mount form factor.

For more information about the operation and programming functions of the device, see the XBee3®

Zigbee® User Guide.

XBee3™ RF Module Hardware Reference Manual 5

General XBee3 specifications

The following tables provide general specifications for the hardware.

General specifications 7

Regulatory conformity summary 7

Serial communication specifications 8

GPIO specifications 8

XBee3™ RF Module Hardware Reference Manual 6

General XBee3 specifications General specifications

XBee3™ RF Module Hardware Reference Manual 7

General specifications

The following table describes the general specifications for the devices.

Specification XBee3/XBee3-PRO Micro XBee3/XBee3-PRO surface-mount

Operating frequency

band

ISM 2.4 - 2.5 GHz

Form factor Micro Surface-mount

Dimensions Micro: 1.36 cm x 1.93 cm x 0.241 cm

(0.534 in x 0.760 in x 0.095 in)

Surface-mount: 2.199 x 3.4 x 0.368

cm (0.866 x 1.33 x 0.145 in)

Operatingtemperature -40 to 85 °C (industrial)

Antenna options RF pad, chip antenna, or U.FL

connector

RF pad, embedded antenna, or

U.FL connector

Regulatory conformity summary

This table describes the agency approvals for the devices.

Approval XBee3 XBee3-PRO

United States (FCC Part 15.247) FCC ID: MCQ-XBEE3 FCC ID: MCQ-XBEE3

Industry Canada (IC) IC: 1846A-XBEE3 IC: 1846A-XBEE3

FCC/IC Test Transmit Power Output range -6.8 to +19.9 dBm -6.8 to +19.9 dBm

Europe (CE) Yes

RoHS Compliant

General XBee3 specifications Serial communication specifications

XBee3™ RF Module Hardware Reference Manual 8

Serial communication specifications

The XBee3 RF Module supports Universal Asynchronous Receiver / Transmitter (UART).

UART pin assignments

Specifications Device pin number

UART pins XBee3 Micro XBee3 Surface-mount

DOUT/DIO13 3 3

DIN / CONFIG/DIO14 4 4

CTS / DIO7 24 25

RTS/ DIO6 27 29

GPIO specifications

XBee3 RF Modules have 15 General Purpose Input / Output (GPIO) ports available. The exact list

depends on the device configuration as some GPIO pads are used for purposes such as serial

communication.

GPIO electrical specification Value

Voltage - supply 2.1 - 3.6 V

Low switching threshold 0.3 x VCC

High switching threshold 0.7 x VCC

Input pull-up resistor value 40 kΩ(typical)

Input pull-down resistor value 40 kΩ(typical)

Output voltage for logic 0 0.2 x VCC (maximum)

Output voltage for logic 1 0.8 x VCC (minimum)

Output source/sink current 50 mA (maximum)

Total output current (for GPIO pads) 200 mA (maximum)

802.15.4-specific specifications

The following tables provide specifications specific to the XBee3 RF Module when using the 802.15.4

physical layer, for example: Zigbee, DigiMesh, and so forth.

Performance specifications 10

Power requirements 10

Networking and security specifications 10

Communication interface specifications 10

XBee3™ RF Module Hardware Reference Manual 9

802.15.4-specific specifications Performance specifications

XBee3™ RF Module Hardware Reference Manual 10

Performance specifications

The following table describes the performance specifications for the devices.

Specification XBee3 XBee3-PRO

Indoor/urban range Up to 60 m (200 ft) Up to 90 m (300 ft)

Outdoor RF line-of-sight range Up to 1200 m (4000 ft) Up to 3200 m (2 mi)

Transmit power output (maximum) 6.3 mW (+8 dBm) 79 mW (+19 dBm)

RF data rate 250,000 b/s

Receiver sensitivity -103 dBm

Power requirements

The following table describes the power requirements for the XBee3 RF Module.

Specification XBee3 XBee3-PRO

Adjustable power Yes

Supply voltage 2.1 - 3.6 V

Operating current (transmit) 40 mA @ +3.3 V, +8 dBm 135 mA @ +3.3 V, +19 dBm

Operating current (receive) 15 mA

Power-down current 1.7 µA @ 25° C

Networking and security specifications

The following table describes the networking and security specifications for the devices.

Specification XBee3/XBee3-PRO

Supported network topologies Point-to-point, point-to-multipoint, peer-to-peer, and DigiMesh

Number of channels 16 Direct sequence channels

Interface immunity Direct Sequence Spread Spectrum (DSSS)

Channels 11 to 26

Addressing options PAN ID and addresses, cluster IDs and endpoints (optional)

Communication interface specifications

The following table provides the device's communication interface specifications.

Interface options

UART 250 Kb/s maximum
