Digi XBee Wi-Fi Cloud Kit Bedienungsanleitung

XBee Wi-Fi Cloud Kit

Radio Frequency (RF) Modules

Getting Started Guide

Revision history—90002195

Revision Date Description

A November

2013

Initial release

B February

2014

Improved the quality of the images and corrected part number

discrepancies.

C May 2014 Updated the graphics of the loose components to match the loose

components and other accessories that are currently available with the kit.

D July 2014 Completed a major overhaul of the document including reformatting,

updating links and graphics, adding information for clarity.

E August

2016

Converted to the new MadCap Flare format with minor updates.

Trademarks and copyright

Digi, Digi International, and the Digi logo are trademarks or registered trademarks in the United

States and other countries worldwide. All other trademarks mentioned in this document are the

property of their respective owners.

Disclaimers

Information in this document is subject to change without notice and does not represent a

commitment on the part of Digi International. Digi provides this document “as is,” without warranty of

any kind, expressed or implied, including, but not limited to, the implied warranties of fitness or

merchantability for a particular purpose. Digi may make improvements and/or changes in this manual

or in the product(s) and/or the program(s) described in this manual at any time.

Warranty

To view product warranty information, go to the following website:

www.digi.com/howtobuy/terms

Send comments

Documentation feedback: To provide feedback on this document, send your comments to

techcomm@digi.com.

Customer support

Digi Technical Support: Digi offers multiple technical support plans and service packages to help our

customers get the most out of their Digi product. For information on Technical Support plans and

pricing, contact us at +1 952.912.3456 or visit us at www.digi.com/support.

XBee Wi-Fi Cloud Kit Getting Started Guide 2

Contents

Introduction to your XBee Wi-Fi Cloud Kit

XBee Wi-Fi development board components and descriptions

Set up your XBee Wi-Fi Cloud Kit

Configure your XBee Wi-Fi module using the Wi-Fi interface 10

Add your XBee Wi-Fi module to your Remote Manager account 10

Create a Remote Manager account 10

Add your XBee Wi-Fi module to Remote Manager 11

Configure widgets on your XBee Wi-Fi sample web application 12

How widgets work on the XBee Wi-Fi dashboard 12

Add widgets to your dashboard 13

Edit (and customize) widget settings 14

Remove widgets from your dashboard 15

Viewing widget source code 16

XBee Wi-Fi application exercise

Create a temperature sensor 19

Assemble the parts 19

Configure the radio 19

Wire up the circuit 20

View it 23

Use it 24

Do more with your XBee Wi-Fi Cloud Kit

Configure your XBee Wi-Fi module 26

Configure your XBee Wi-Fi module with Remote Manager 26

Configure your XBee Wi-Fi module with XCTU 28

Create XBee Wi-Fi applications 34

Learn more about XBee Wi-Fi

Connect your application to the cloud 36

Collaborate and share your story 36

Create your own applications 36

Additional services 36

XBee Wi-Fi Cloud Kit Getting Started Guide 3

XBee Wi-Fi Cloud Kit Getting Started Guide 4

Troubleshooting

XBee device fails to join wireless network 38

Check if the Associate LED is solid green 38

Check if the Associate LED is double-blinking green 38

Check if the Associate LED is lit 39

XBee device does not show up under listed devices 39

Potential cause 39

Resolution 39

XBee device is listed in the wireless networks but cannot connect 39

Potential cause 39

Resolution 39

XBee Wi-Fi dashboard does not work with the XBee device 40

Check if the XBee device is properly connected to your wireless network 40

Check if the changes made to the XBee Wi-Fi development board are reflected on the XBee

Wi-Fi dashboard 40

Check if certain functions within the XBee Wi-Fi sample web application are working as

expected 40

Introduction to your XBee Wi-Fi Cloud Kit

The XBee Wi-Fi Cloud Kit shows you how to set up your XBee Wi-Fi hardware and configure its sample

web application. You can see sensor data from your development board on the web, as well as send

data and commands from the web to your device. The components in this kit allow you to create

customized solutions for connected devices.

The XBee Wi-Fi sample web application integrates with Remote Manager to enable two-way

communication over the Internet, giving you remote control of your device wherever you are. This

application also allows you to customize your dashboard widgets so that you can create your own

connected device systems.

The following sections guide you through your kit setup for cloud-based access:

nXBee Wi-Fi development board components and descriptions

nSet up your XBee Wi-Fi Cloud Kit

nXBee Wi-Fi application exercise

nDo more with your XBee Wi-Fi Cloud Kit

nLearn more about XBee Wi-Fi

nTroubleshooting for XBee Wi-Fi Cloud Kit kit

XBee Wi-Fi Cloud Kit Getting Started Guide 5

XBee Wi-Fi development board components and

descriptions

The following table provides descriptions of the XBee Wi-Fi development board components.

XBee Wi-Fi Cloud Kit Getting Started Guide 6

XBee Wi-Fi development board components and descriptions

XBee Wi-Fi Cloud Kit Getting Started Guide 7

Development

board

components Description

1 Associate LED Indicates wireless connection status to local access point.

nSolid green: The XBee module is not connected to a local access

point.

nFlashing green: The XBee is connected to a local access point and

Remote Manager.

nTwo short double blinks: The XBee is connected to a local access

point, but not Remote Manager.

TCP/IP LED An output light connected to one of the GPIO pins that allows you to turn it on

or off using commands sent from Remote Manager.

User LED An output light that acts as a second User LED that allows you to turn it on or

off using commands sent from Remote Manager.

2 LED gauge The LED gauge indicates analog value ranging from 0-10 LEDs and is

controlled through the XBee Wi-Fi dashboard.

3 Vibration

motor

The vibration motor indicates change in status.

4 Buzzer The buzzer acts as an alarm to indicate trouble. It is loudest at 2 kHz, but

works at a range of frequencies. You can also control the frequency of the

buzzer through the dashboard using the buzzer frequency slider. Use the

buzzer toggle widget to turn the buzzer on or off.

5 Slide switch The XBee Wi-Fi dashboard indicates the state of the slide switch. The switch

stays either on or off.

6 Breadboard The rectangular plastic board that lets you easily insert electronic

components for testing purposes. This is useful for prototyping electronic

circuits.

7 Push button The state of the push button is displayed on the XBee Wi-Fi dashboard. The

button appears ON only when actively being pushed.

8 Potentiometer The potentiometer displays on the XBee Wi-Fi dashboard as a speedometer

gauge, progress bar, or graph. You can control the potentiometer by turning

the adjustable knob left or right.

9 Barrel jack Accepts 4.5V to 24V through the development board. You can also use the

barrel jack with the battery pack provided with the kit.

10 USB jack The USB jack has two purposes:

1. To power the development board up to 5V.

2. To provide serial port access to the XBee Wi-Fi for configuration or

sending and receiving data to and from Remote Manager.

XBee Wi-Fi development board components and descriptions

XBee Wi-Fi Cloud Kit Getting Started Guide 8

Development

board

components Description

11 XBee reset The XBee reset is connected to the XBee Wi-Fi reset pin. You can reconfigure

it via the USB port.

12 DIP switches These switches allow components on the XBee Wi-Fi development board to

disconnect from the XBee. If the switch is away from the XBee, the XBee pin

is connected to that built-in widget on the XBee Wi-Fi dashboard. If the switch

is towards the XBee, the XBee pin disconnects from that component.

Note When you are using loose components or doing advanced prototyping,

you may need to disconnect the built-in component from the XBee pin.

13 Prototyping

headers

The prototyping headers allow connection to all pins of the XBee Wi-Fi. Use

the prototyping headers to connect to your own circuits including those using

the loose components that came with your kit.

14 Commissioning

button

Press the commissioning button four times to reset the network parameters

and reactivate Soft AP mode.

Set up your XBee Wi-Fi Cloud Kit

The XBee Wi-Fi Cloud Kit includes access to a sample web application that makes it quick and easy to

work with your XBee device. The XBee Wi-Fi sample web application integrates with Remote Manager

to enable two-way communication over the Internet, giving you remote control of your device

wherever you are. This application also allows you to customize your dashboard widgets so that you

can create your own connected device systems.

Configure your XBee Wi-Fi module using the Wi-Fi interface 10

Add your XBee Wi-Fi module to your Remote Manager account 10

Configure widgets on your XBee Wi-Fi sample web application 12

XBee Wi-Fi Cloud Kit Getting Started Guide 9

Set up your XBee Wi-Fi Cloud Kit Configure your XBee Wi-Fi module using the Wi-Fi interface

XBee Wi-Fi Cloud Kit Getting Started Guide 10

Configure your XBee Wi-Fi module using the Wi-Fi interface

By now you should have already verified the contents of your XBee Wi-Fi Cloud Kit, connected the

hardware, and configured your XBee to connect to a local Wi-Fi access point.

1. If you have not yet configured your XBee to connect to a local Wi-Fi access point, follow the

instructions in the Quick Start Guide that came in your kit, or find the XBee Wi-Fi Cloud Kit

Quick Start Guide online at Digi.com.

2. If your module is not able to connect to your Wi-Fi access point, it returns to Soft AP

configuration mode, and you are required to repeat the configuration steps. Keep in mind that

your SSIDand password are case sensitive.

3. If you are still having trouble connecting your XBee Wi-Fi to a local access point, see

Troubleshooting.

Add your XBee Wi-Fi module to your Remote Manager account

The XBee Wi-Fi Cloud Kit includes access to a sample web application that makes it quick and easy to

work with your XBee device. The XBee Wi-Fi sample web application integrates with Remote Manager

to enable two-way communication over the Internet, giving you remote control of your device

wherever you are. This application also allows you to customize your dashboard widgets so that you

can create your own connected device systems.

You must have a Remote Manager account to use the features of the XBee Wi-Fi sample web

application.

nIf you do not yet have a Remote Manager account, go to Create a Remote Manager account.

nIf you already have an account, go to Add your XBee Wi-Fi module to Remote Manager.

Create a Remote Manager account

Remote Manager enables you to set up and manage dynamic device networks. Your free developer

account lets you explore Remote Manager's application development and device management tools,

with a limited number of devices and transactions. With this developer account you discover how

Remote Manager's suite of device management and application development tools can help you

realize your machine-to-machine (M2M) solution. When you are ready to expand your Remote Manager

access, complete the following steps.

To create your free Remote Manager account:

Inhaltsverzeichnis

Andere Digi Steuereinheit Handbücher

Digi

Digi Digi XBee SX Bedienungsanleitung

Digi

Digi XBee SX 868 Bedienungsanleitung

Digi

Digi ConnectCore Wi-9P 9215 Anwendungshandbuch

Digi

Digi XBee DigiMesh 2.4 Bedienungsanleitung

Digi

Digi RabbitCore RCM4000 Bedienungsanleitung

Digi

Digi XBee 3 Kurzanleitung

Digi

Digi XBee ZigBee S2C Bedienungsanleitung

Digi

Digi ConnectCore 6 Plus Kurzanleitung

Digi

Digi ConnectCore 8X Kurzanleitung

Digi

Digi Digi Connect EM DC-EM02T-JT Anwendungshandbuch

Digi

Digi Digi Conntect ME Anwendungshandbuch

Digi

Digi ConnectCore 8X Kurzanleitung

Digi

Digi XBee 3 ZigBee Bedienungsanleitung

Digi

Digi XBee Bedienungsanleitung

Digi

Digi XBee3 802.15.4 Bedienungsanleitung

Digi

Digi Connect Series Benutzerhandbuch

Digi

Digi XBee3 DigiMesh 2.4 Bedienungsanleitung

Digi

Digi XBee 868LP Bedienungsanleitung

Digi

Digi ConnectCore 9P 9215 Anwendungshandbuch

Digi

Digi XBee3 802.15.4 Bedienungsanleitung

Digi

Digi ConnectCore 7U Anwendungshandbuch

Digi

Digi XLR PRO Bedienungsanleitung

Digi

Digi XBee Bedienungsanleitung

Digi

Digi Connect ME 9210 Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
