Directive Systems & Engineering DSE3333LY Bedienungsanleitung

DSE3333LY Rev 3/21

Directive Systems & Engineering

2702 Rodgers Terrace

Haymarket, VA 20169-1628

www.directivesystems.com

703-754-3876

33cm Loop Yagi, Model DSE3333LY

SPECIFICATIONS

Frequency range: 890-910 MHz Gain: 18.5 dBi

Number of elements: 33 3 dB Beamwidth

Boom length: 144 inches (E plane): 20º

Boom diameter: 1 inch F/B ratio: >20 dB

Mast diameter: 2 inches max Maximum Power: 550 W average

Weight: (assembled) 5 pounds Stacking distance: 30 inches’ vertical

Connector: Type-N female 33 inches’ horizontal

Note: All hardware is Stainless Steel unless otherwise noted.

Anti-Seize Compound - Apply a small amount of the supplied Anti-Seize Compound to the aluminum joints and

to the threads of the U-Bolts to prevent galling.

BEFORE INSTALLING YOUR NEW ANTENNA, PLEASE BE SURE

TO READ THE ENCLOSED WARNING PAMPHLET.

ASSEMBLY INSTRUCTIONS

1) Unpack antenna and locate the two preassembled antenna sections and the hardware

package. The boom is broken between elements D16 and D17. Remove D16 from the boom

piece and slide boom pieces together to alignment marks. Replace D16 and retighten. The

booms are marked for your assembly.

2) Straighten any misaligned elements and tighten hardware if necessary. But do not

touch R1, DE or D1, as these have been factory set for minimum SWR.

3) Attach the boom to mast plate to the boom with the hardware provided. Install the U-

bolts so that the mast comes up directly under the boom.

P a g e | 2

DSE3333LY Rev 3/21

(Can be up or down) (Can be left or right)

4) Attach the feed line, and tape it to the bottom of the boom. The connector should be

sealed with electronic grade RTV or equivalent.

5) The antenna SWR has been adjusted at the factory for less than 1.5:1. Additional

tweaking can be accomplished by adjusting the distance between the driven element and R1

and D1, or by adjusting the shape of the driven element. NOTE: Do not attempt this

adjustment unless the proper equipment and qualified personnel are available.

6) If antennas are to be stacked, see "Instructions for Stacking Loop Yagis".

DO NOT, UNDER ANY CIRCUMSTANCES, APPLY ANY TYPE OF SEALANT OR COATING TO THE

DRIVEN ELEMENT, T-ARMS OR CONNECTOR ASSEMBLY, OTHER THAN KRYLON®

CLEAR COAT. ANY OTHER COATING WILL ADVERSELY AFFECT THE SWR AND VOID YOUR

WARRANTY.

Directive Systems Warranty Policy

All Directive Systems antennas are built with the finest materials available. We take great pride in

building a quality product that will give years of good service and performance. If there is a defect in materials

or workmanship within 90 days of purchase, Directive Systems will repair or replace the defective part, free of

charge, to the original purchaser. DO NOT RETURN ANYTHING WITHOUT PRIOR AUTHORIZATION

FROM DIRECTIVE SYSTEMS. Please contact us either by phone or email describing the problem and we

will work to resolve it.

If, after examining a new antenna you received, you are not satisfied, contact us immediately for return

authorization and refund. ANY ANTENNA THAT HAS BEEN MODIFIED WILL BE SUBJECT TO A

RESTOCKING CHARGE. IF AN ANTENNA IS SO MODIFIED AS TO MAKE IT UNUSABLE, DIRECTIVE

SYSTEMS RESERVES THE RIGHT TO REFUSE TO ACCEPT THE ANTENNA FOR RETURN.
