Dirt Devil DDU01-E01-P01 Bedienungsanleitung

POWERLITE

SERIES

USER GUIDE

DDU01-E01-P01

Cyclonic Vacuum

WARNING

BASIC SAFETY PRECAUTIONS

• This vacuum cleaner is

intended for household use

only and NOT for commercial

or industrial use.

• Only use the vacuum cleaner

indoors on dry surfaces and

keep the area you’re cleaning

well lit.

• Keep ngers, hair and loose

clothing away from moving

parts and openings whilst

using the vacuum cleaner.

• This vacuum cleaner can be

used by children aged from 8

years and above and persons

with reduced physical, sensory

or mental capabilities or lack of

experience and knowledge if

they have been given

supervision or instruction

concerning use of the vacuum

cleaner in a safe way and

understand the hazards

involved. Children shall not

play with the vacuum cleaner.

Cleaning and user

maintenance shall not be made

by children without supervision.

• Only Dirt Devil recommended

tools should be used with the

vacuum cleaner, use of

non-branded Dirt Devil

accessories/tools will invalidate

your guarantee.

• Don’t use the vacuum cleaner

if it has been dropped,

damage or left outdoors.

• Don’t run over the power cord

or use vacuum cleaner if the

power cord or plug is

damaged. Please contact our

Customer Care Line on:

0330 026 2626 (Mon-Fri

9:00am-5:00pm).

• Don’t handle the plug or use

the vacuum cleaner with

wet hands.

• Don’t pull or carry the vacuum

cleaner by the power cord.

• Don’t use the power cord as a

handle, pull the power cord

around corners, sharp edges

or close a door over the

power cord.

• Don’t unplug the vacuum

cleaner by pulling on the

power cord.

• Don’t vacuum up any

ammable or combustible

materials (lighter uid, petrol,

kerosene etc) or use the

vacuum cleaner in an area with

explosive vapours or liquid.

• Don’t vacuum up hot coals,

cigarette butts, matches or

smoking hot burning items

DON'TS

WARNING

or use in an area where

there may be harmful uids

(chlorine, bleach, and ammonia

drain cleaner).

• Don’t attempt to remove

blockages with sharp objects

as this may cause damage

to the vacuum cleaner, remove

blockages only as instructed in

this guide.

• Don’t vacuum up hard or sharp

objects such as glass, nails,

screws or coins etc.

• Don’t use the vacuum cleaner

with incorrect voltage as this

may result in damage or injury

to the user. The correct voltage

is listed on the ratings label.

DON'TS CONTINUED...

• Turn off all controls on the

vacuum cleaner before

disconnecting or connecting

the plug from the mains socket.

• Always keep the power cord

away from the brushes during

use. After use always wrap the

power cord around the cord

clips provided.

• Always make sure both the

pre-motor/post-motor lters are

in place before use.

• Always make sure the brush

bar is switched off when using

the vacuum cleaning on stairs

or when using the hose and

accessories. Take extra when

positioning the vacuum cleaner

on the stairs.

• Always switch off the vacuum

cleaner before disconnecting

or connecting the hose and

accessories.

• Keep all openings clear and

free from debris as this may

affect the airow/suction.

• Always replace the fuse in the

plug with a British 13amp fuse.

Always protect the power

cable from heated surfaces

and open ames.

• Use only CE approved 13amp

extension cords, non-approved

extension cords may overheat.

Care should be taken to

arrange the extension cord as

it can be a trip hazard.

• Store the vacuum cleaner in a

cool, dry area. If the lters have

been cleaned as per user the

guide instructions ensure they

are thoroughly dry before

storing away.

PLEASE KEEP INSTRUCTIONS

FOR FURTHER USE.

DO'S

HI. WELCOME.

Congrats on purchasing your new POWERLITE

cyclonic vacuum. Inside, you’ll ﬁnd everything

you want to know from tools to how to.

So what are you waiting for? LET’S GO.™

Thank you for choosing a Dirt Devil product.

Please enter the complete model and serial

number in the spaces provided.

MODEL

SERIAL NUMBER

Serial number located on the machine’s

rating label

Hint: Attach your sales receipt to this owner’s

manual. Verification of date of purchase may

be required for warranty service of your

Dirt Devil product.

SERIAL NUMBER

(Label located on bottom of vacuum)

Model

DDU01-E01

Wattage

1000W

6113641413011111

TABLE OF

CONTENTS

Safety information 3

Contents 5

Machine overview 6

Quick start 7

Hard ﬂoor cleaning 12

Using your machine 12

Maintenance 13

Troubleshooting 18

Other information 19

Limited guarantee 19

VACUUM DESCRIPTION

1. Handle

2. Stretch Hose

3. Dusting Brush

4. Dirt Bin Release Button

5. Shroud and Separator

6. Dirt Bin

7. Filters

8. System Check Indicator

9. Crevice Tool (Attached to

handle and stored in cleaner)

10. Hose Holder

11. Quick Release Cord Hook

12. Power Cord

13. Wheels

14. On/Off Pedal

15. Brushbar Control Button

16. Hard Floor Adaptor

Remove all parts from carton and

identify each item shown. Make

sure all parts are located before

disposing of packaging.

A. Handle

B. Crevice Tool

(Attached to handle)

C. Main Body

D. Dirt Bin

E. Dusting Brush

F. Hard Floor Adaptor

G. TurboTool (certain models only)

WHAT'S IN THE BOX

1. Insert handle into

body of cleaner. Push

down until handle locks

into place.

2. Position hose over

hose holder (A) and into

hose tube (B).

3. To remove handle,

remove hose and press

handle/wand release

button (C) to remove.

IMPORTANT: Hose must be connected as shown for all operations.

ATTACH HANDLE

Place bottom of

dirt bin into

vacuum body first.

Pivot Bin into

vacuum. Dirt Bin

is secure when

you hear a click.

STORE TOOLS

1. Snap dusting

brush (D) into

storage area on

side of cleaner.

3. TurboTool is

included in certain

models and will

be a separate

addition. Attach

TurboTool to hose

end for use.

DO NOT ATTACH

TURBOTOOL TO

HANDLE.

2. Crevice tool is

permanently

attached to end

of handle/wand

and inserted into

cleaner body for

storage.

ATTACH

DIRT BIN

CAUTION

Not to be used for grooming a pet.

Pull back handle

to tilt back. Press

on the front of

nozzle if needed.

Move the handle

and adjust it to the

desired position

for operating the

cleaner, and

lowering handle to

clean under

furniture.

FLOOR/

CARPET

CLEANING

Use the carry

handle to move

the cleaner from

room to room.

CARRY

HANDLE

For optimal

cleaning

performance on

hard floors,

brushbar should

be turned off. The

vacuum is shipped

with the brushbar

in the ON position.

To turn brushbar

OFF for Suction

Only Mode, step

on pedal (A).

SUCTION

ONLY MODE

This vacuum cleaner is fitted with a

constantly rotating brushbar. To avoid

damage to your flooring, make sure

the brushbar is turned off when using

the hose, accessories and when using

on stairs.

CAUTION: Turn brushbar off

before disconnecting and connecting hose

to hose tube (A). To use hose, lift hose end

as shown.

CLEANING TOOLS

HANDLE

RELEASE

Remove the hose from hose caddy.

Connect tools to end of hose or use

hose alone.

To use handle wand, first remove hose

from hose holder then remove handle

from main body by pressing the handle

release button. Attach hose to top

of handle.

To use brush tool remove from machine

and place over crevice tool.

To use Turbo Tool attach to hose end.

A. Dusting brush may be used for

carved furniture, table tops, books,

lamps, lighting fixtures, venetian

blinds, baseboards, shutters,

and registers.

B. Crevice tool (permanently fixed to

the bottom of the handle/wand) may

be used in tight spaces, corners and

along edges in such places as dresser

drawers, upholstered furniture, stairs

and baseboards.

C. The handle/wand is used to give

extra length to your hose. Can also be

used with dusting brush. Dusting

brush can only be used when inserted

into the crevice tool.

D. TurboTool is designed to help you

remove pet hair from your home

easily. Can only be used with hose.

SELECT PROPER TOOL Tools may vary per model)

ATTACH WAND AND TOOLS
