DMP Electronics XR500 SERIES Bedienungsanleitung

XR500 Series Update

March 2005

Version 108 Software

Effective March 2005, all XR500 Series panels are being manufactured with version 108 (3/1/05)

software. This version is an update from the 106 (1/4/05) software previously shipped and contains

new features.

New Features

Multi-Lingual Option

The XR500 Series panel now provides the option in System Options to view the Programming and User

menus in multiple languages.When more than one language is programmed, the installer or user is

prompted to choose the language to display.

PROG LANGUAGE

Programming Menu Language

Press the COMMAND key to select the programming language(s). Any changes

in PROG LANGUAGE do not take effect until the STOP routine completes.

PRI LANG: ENGLSH

The current primary programming language is displayed. The default language

is English. Press a Select key to change the primary programming language.

ENG SPN

Select the primary programming language.

ENG = English

SPN = Spanish

SEC LANG: NONE

The current secondary programming language is displayed. Selecting a

secondary language allows the installer to view programming in English or

Spanish. When the Programming Menu is accessed, the installer is prompted to

choose the programming display language. If SEC LANG: is set to NONE, the

option to choose a language does not display. To select a secondary language,

press the Select key below the language. Default is NONE.

NONE ENG SPN

Select the secondary programming language.

NONE = No secondary language options are displayed

ENG = English

SPN = Spanish

USER LANGUAGE

User Menu and Status List Language

Press the COMMAND key to select User language(s).

PRI LANG: ENGLSH

The current primary user language is displayed. The default language is

English.

Press a Select key to change the primary User language.

ENG SPN

Select the primary user language.

ENG = English

SPN = Spanish

Products

SEC LANG: NONE

The current secondary user language is displayed. Selecting a secondary user

language allows the user to view the User Menu and Status List text in English

or Spanish. When the User Menu is accessed, the user is prompted to choose

the display language. Status List text displays in the selected language until

another language is chosen. If SEC LANG: is set to NONE, the option to choose

a language does not display. To select a secondary language, press the Select

key below the language. Default is NONE.

For example, when Spanish is selected at a keypad, the User Menu and Status

List text display in Spanish at that keypad. When the user later accesses the

keypad, pressing the COMMAND key once displays the option for English or

Spanish. Pressing the COMMAND key again continues to display the Status List

text in Spanish. Later on, if English is selected at that keypad, the User Menu

and Status List text display in English at that keypad.

NONE ENG SPN

Select the secondary user language.

NONE = No secondary language options are displayed

ENG = English

SPN = Spanish

Arm First Option

The XR500 Series panel now provides the option in Area Information to program an area to

automatically arm when any other area is armed from a keypad.

ARM FIRST NO YES

Arm First Area

Select YES to enable this area to operate as an Arm First area. This area is

automatically armed when any non-Arm First area assigned to the same

keypad is armed but does not disarm when other areas become disarmed.

Assign areas to keypads using the Display Areas option in Device Setup

programming. You can have multiple Arm First areas in a system and divide

them among keypads if needed. If an Arm First area has faulted zones that

cannot be bypassed, arming stops and the areas are not armed. Correct the

problem with the Arm First area and then begin the arming process again.

Default value is NO.

Note: The Arm First automatic arming only occurs when arming from a

keypad. Arming from a zone, schedule, or remotely is not affected and Arm

First areas do not automatically arm.

User Codes

The XR500 Series panel now allows six-digits to be programmed for user codes. These six-digit user

codes can be used when manually entered at a keypad or entered from a card reader attached to a 734

Access Control Module. User Codes entered by the user from card readers attached to keypads and the

733 Access Control Module continue to accept a maximum five-digit codes only.

Closing Wait Output

The XR500 Series panel now provides a Closing Wait Output in Output Options just after the Sensor

Reset Output that turnson when a closing message is successfully sent to the receiver.

CLS WAIT OUT: 0

Closing Wait Output

Enter the output number to turn on for approximately four (4) seconds when

Closing Wait is programmed as YES and the panel successfully communicates

the closing message at arming. If the closing message does not communicate

successfully, this output does not turn on. Enter zero to disable this output.

Cancel Ambush Option

The XR500 Series panel now provides a Cancel Early Morning Ambush message (C) for a zone Alarm

Action in Zone Information programming. This zone action cancels a running Early Morning Ambush

timer.

A T L -

ALARM -Select A to send an alarm report to the receiver and activate the bell

output according to zone type. The zone name appears in the panel alarmed

zones and status lists.

TROUBLE -Select T to send a trouble report to the receiver. The zone name

appears in the panel alarmed zones and status lists.

Note: UL requirements prevent the Alarm (A) and Trouble (T) action for Fire

(FI), and Fire Verify (FV) zone types from being changed.

LOCAL -When you select L, an alarm report is NOT sent to the receiver. The

bell output activates and the zone name appears in the panel alarmed zones

and status lists.

-(Dash) -When you select a –(dash), reports are NOT sent to the receiver.

The bell output does not activate and there is no display in the panel alarmed

zones or status list. Only the relay output selected in the next section

operates.

D S C

CANCEL AMBUSH -Select C for the zone to cancel the Early Morning Ambush

timer and stop an Ambush message from being sent to the receiver. Faulting

the zone takes the place of a second user code being entered at the keypad

and is only available for non-fire type zones. Area assignment for the zone

does not affect this option. See Early Morning Ambush in Area Information

programming.

Products

New Feature Available for Purchase

Service User Authentication –Feature Key 105

The XR500 Series panel now offers the ability to authenticate service personnel with the SCS-1R

receiver before allowing access to panel programming or performing any user operations.

SVC USER AUTH

Service User Authentication

DISABLED

This feature offers the ability to authenticate service personnel before

allowing access to panel programming or performing any user operations.

When this feature is enabled and a valid Service User code is entered for

system operation or 6653 is entered for programming, the Service Code entry

option displays.

SVC CODE:

When the service person enters the Service Code, the panel authenticates the

code with the Service Code preprogrammed in the SCS-1R receiver, and access

to panel programming or the User Menu is granted. The Service Code can be

used for system operation for 30 minutes before authenticating again. If the

code entered is not validated, access to programming or the User Menu using

the Service User code is denied.

Note: The Service User code is user number zero (0) and can only be created

in the panel remotely.

Note: The SCS-1R receiver must have firmware version 902 or higher to

authenticate service personnel.

Purchasing Feature Upgrades

To purchase a feature upgrade, you may contact DMP Customer Service with the feature you would like

to enable and the panel serial number. The serial number(s) should be sent in writing via e-mail or fax.

A separate feature key is issued for each panel. The feature key only enables the requested feature on

the specified panel.

The panel serial number can be located in several different ways:

Printed on a label located on the right side of the XR500 PCB.

Using panel diagnostics. See the Appendix in the XR500 Series Programming Guide (LT-0679).

Using Remote Link (version 1.18 or higher)

—Initial panel connection screen displays panel serial number when you connect.

—New System Information screen displays all enabled panel features.

—The Panel>Feature Upgrade screen displays panel model, enabled panel

features, and panel serial number.

Ordering the New Software

XR500 Series software update version 108 (3/1/05)is available for download free of charge on the DMP

Dealer Direct Website at http://dmp.com/dealer.

Note: Remote Link Version 1.22 or higher is required to support the panel version 108 features. Remote

Link Version 1.22 is available for download free of charge on the DMP Dealer Direct Website at

http://dmp.com/dealer.
