DMP Electronics 7800 Series Installationsanleitung

INSTALLATION AND PROGRAMMING GUIDE

7800 Series Graphic

Touchscreen Keypad



 

 

























About the Keypad ...................................... 1

7872...................................................................................... 1

7873...................................................................................... 1

7873H................................................................................... 1

Keypad Features.........................................2

Programmable Carousel Menu ................................. 3

Enter Characters.........................................4

Number Pad ..................................................................... 4

Standard Keyboard ....................................................... 4

Install the keypad.......................................6

Remove the Cover......................................................... 6

Wire the Keypad............................................................. 7

Wire for Access Control .............................................. 9

Wire the Electronic Lock ............................................ 11

Wire the 333 Suppressor ............................................ 11

Mount the Keypad .................................... 13

TABLE OF CONTENTS

Program the Panel.................................... 15

Device Setup...................................................................15

Device Number ..................................................................15

Device Name.......................................................................15

Device Type.........................................................................16

Communication Type.......................................................16

Program the Keypad ................................ 17

Keypad Options.............................................................17

Current Keypad Address................................................17

Keypad Mode......................................................................18

Default Keypad Message................................................18

Arm Panic Keys..................................................................18

Activate Zone 2 Bypass ..................................................19

Activate Zone 3 Request to Exit..................................21

Arming/Disarming Wait Time ....................................22

Card Options .....................................................................23

Require Site Code............................................................ 27

Number of User Code Digits .......................................28

No Communication with Panel ...................................28

System Type...................................................................... 30

Dealer Logo....................................................................... 30

Dealer Info ......................................................................... 30

Carousel Z-Wave Items...................................................31

Shortcut Items....................................................................31

Select Language............................................................... 32

Additional Programming.........................33

Program a Credential .....................................................33

Update the Keypad .........................................................34

Test the keypad.........................................35

Keypad Diagnostics ....................................................35

Zone Test............................................................................. 35

Test the Credential Reader...........................................35

End User Training .................................... 36

Access the User Menu................................................36

Arm and Disarm the System....................................37

Use Access Control .....................................................38

Touchless Arming .......................................................38

Icon Reference ............................................................. 40

Change System Wi-Fi Password............................42

Clean the Keypad........................................................ 44

Keypad Bus Wiring Speciﬁcations........ 45

Public Card Formats ............................... 46

Readers and Credentials .........................47

Ordering Information.............................. 49

Keypads ...........................................................................49

Accessories.................................................................... 50

Compliance Speciﬁcations...................... 51

Certiﬁcations.............................................52

FCC Information .......................................53

Industry Canada Information................. 54

Digital Monitoring Products, Inc. | 7800 Series Installation and Programming Guide 1

ABOUT THE KEYPAD

7800 Series Graphic Touchscreen Keypads oer ﬂexible features and functionality. Each

keypad provides optional panic keys, an AC Power/Armed LED, an internal speaker, a

simple terminal connection to a 4-wire keypad bus, and optional backboxes for conduit or

wall-mount applications. Each model provides its own distinct functionality.

7872

Provides a built-in

proximity card reader

designed to read proximity

credentials.

Provides four fully-

programmable Class B,

Style A, supervised, power

limited protection zones

that can be programmed

for a variety of burglary

and access control

applications.

7873

Provides a built-in

proximity card reader

designed to read proximity

credentials.

Provides four fully-

programmable Class B,

Style A, supervised, power

limited protection zones

that can be programmed

for a variety of burglary

and access control

applications.

Provides a door strike relay

and allows Wiegand input

from external card readers.

7873H

Provides the same

functionality as the 7873

keypad.

Allows the keypad digits to

automatically randomize

on user code entry.

Features an integrated

privacy ﬁlter on the

keypad screen.

2 7800 Series Installation and Programming Guide | Digital Monitoring Products, Inc.

KEYPAD FEATURES

Figure 1: Keypad Features





  

























Armed/Power LEDs &

Proximity Reader

Dealer Logo Carousel Menu

Local

Weather

Interactive

Arming/

Disarming

Shield Press the

Navigation

Arrows or touch

and drag the

menu to scroll

microSD

Card Slot

Digital Monitoring Products, Inc. | 7800 Series Installation and Programming Guide 3

Figure 2: Keypad Options









 







Programmable Carousel Menu

The carousel menu allows the user to pick and choose what displays within the carousel

menu on the home screen. Press Options in the carousel menu. From here, adjust the

keypad screen brightness, keypad tone, and keypad volume. Press a box under Display

In Menu to select that option to display in the carousel menu. Press that box again to

deselect that option. See Figure 2.

A Brightness setting of 1 allows the keypad display to turn o automatically after a brief

period of inactivity. The Arm/Disarm LED remains lit. A Brightness setting of 0 allows both

the keypad display and LED to turn o automatically after a period of inactivity. To wake

the display, tap any part of the touchscreen surface.

4 7800 Series Installation and Programming Guide | Digital Monitoring Products, Inc.

ENTER CHARACTERS

Number Pad

1. Choose a character from Table 1.

2. Identify the Number the character

correlates with and press that

number on the number pad.

3. Identify the Select Area for the

character and press that select area

on the keypad. Press that select area

again for the lowercase letter. See

Figure 3.

4. When the desired character displays

on the keypad, return to Step 1 to

enter another character or press

CMD if ﬁnished.

Standard Keyboard

• Press ABC to enter uppercase

letters.

• Press abc to enter lowercase letters.

• Press !@# to enter special characters.

• Press 123 to enter numbers and to return to the number pad. See Figure 4.

NUMBER SELECT AREA

1 2 3 4

1 A B C ( [ {

2 D E F ) ] }

3 G H I ! ^ ~

4 J K L ? “ |

5 M N O / \ `

6 P Q R & $

7 S T U @ %

8 V W X , =

9 Y Z Space : _ ;

0 - + . ‘ * < # >

Table 1: Characters

Digital Monitoring Products, Inc. | 7800 Series Installation and Programming Guide 5

Select Areas



























   

  

 



Return

to Home

Screen

1 43

Figure 3: Number Pad

Figure 4: Standard Keyboard

1 2 3 4

5 6 7 8

9 0 CMD

ABC DEF GHI JKL

MNO PQR STU VWX



 

         

        

      

Number Pad

Uppercase/

Lowercase

Letters

Special

Characters

6 7800 Series Installation and Programming Guide | Digital Monitoring Products, Inc.

Remove the Cover

The keypad housing is made up of two parts:

the cover, which contains the circuit board and

components, and the base.

To separate the keypad cover from the base,

insert a slotted-tip screwdriver into one of the

slots on the bottom of the keypad and lift the

screwdriver upward. Repeat with the other slot.

Separate the cover from the base and set the

cover containing the keypad components aside.

See Figure 5.

INSTALL THE KEYPAD

Figure 5: Separate the

Keypad Housing

Cover

Base
