DRAX ELLIPTICAL Series Bedienungsanleitung
!Be sure to read the manual before using the product in order to use safely and correctly.
Please keep user manual at a place to be available easily.
ELLIPTICAL Series
User’s MANUAL
1. Getting Started ------------------------------------ 2
2. Installation ----------------------------------------- 3
- Precautions ------------------------------------------- 3
- Part Name -------------------------------------------- 3
- How to make installation --------------------------- 4
- How to check operation ----------------------------- 4
3. How to use ---------------------------------------- 5
- Display and Console Operation Panel ------------- 5
- Console Panel ---------------------------------- 6
4. Function of Program ---------------------------------- 7
- Main Screen ----------------------------------- 8
- Wi-Fi Setup ------------------------------------- 9
- Bluetooth Setup ----------------------------------10
- TV Setup -------------------------------------------10
- Mirroring Setup -----------------------------------11
5. Specification --------------------------------------------- 12
6. Part List ------------------------------------------------ 13
7. Limited Warranty ---------------------------------------- 13
CONTENTS
1
Safety Instructions
Please make sure to read the following precautions and information before operating the
Elliptical. Failure to adhere to the following will void warranty.
Caution
Warning
During a service/cleaning the Elliptical or for a period of non-operation, remove the power
plug from the electrical outlet.
Don’t dis-assemble the Cover ASSY except permitted person.
Never operate the Elliptical in case that abnormal noise or damages are detected. Please
Contact DRAX INC. Customer Support Center.
• The owner of Elliptical must inform all users of the safety instructions and the
methods how to use the Elliptical correctly.
• Always operate the Elliptical in accordance with the instructions.
• During installation, Elliptical is to be horizontally aligned with ground.
• The Elliptical must be installed in the environment where it is low humidity and low
dust area.
• Do not make operation until Elliptical is normally installed.(refer to “Installation”
instruction)
• Before operating the Elliptical, keep children or animals off Elliptical.
• The maximum weight supported by the Elliptical is 150kg.
• Do not use the Elliptical simultaneously more than 2 persons.
• The user is to wear appropriate clothes and shoes during using the Elliptical.
Avoid the Baggy clothes for safety.
• Do not bend, or place heavy objects on the power cord. Stepping on or allowing the
power cord to be crushed by a heavy object could result in electrical shock or fire.
• Do not remove the plug by pulling on the cord and do not handle the plug with wet
hands. This could result in electric shock or fire.
• Do not spill food or drink on the Elliptical.
• Regularly check the Elliptical to keep it in the normally operation.
Getting Started
1
2
①
⑤
⑦
⑥
⑧
⑨
⑩
④
②
③
⑪
①D i s p l a y
④T o u c h T y p e H e a r t r a t e
⑦C u p H o l d e r
⑩H a n d l e
②O p e r a t i o n P a n e l
⑤C o n s o l e C o l u m n
⑧F o o t
⑪O p e r a t i o n P a n e l
③USB & E a r p h o n e
⑥c o n s o l e
⑨P e d a l
(1) The Elliptical should be installed on a flat place and horizontally aligned. If the Elliptical is
placed on unstable pad or carpet, the belt may not be correctly arranged. In this case the Elliptical will
be overloaded and trouble can occur.
(2) Please be sure to use a standardized plug which should be earthed
Precautions
Part Name
Installation
2
3
Check the operation
(1) After plugging , check that the screen power is ON.
(2) Press the pedal on the Elliptical to see if it rotates normally. .
(3) If it rotates normally, press all the switches on the control panel to check whether it operates normally.
(4) If abnormal vibration or noise occurs on the product, please contact the DRAX Service Center.
(1) Separate the product from the packaging box.
(2) Lift the back of the product and move on the front wheel.
We need two adults to carry the product.
(3) Place the product where you want to install it.
※ Caution: The Elliptical must be installed in the environment where it is low humidity and low dust area.
(4) Adjust the foot for height adjustment to level the floor..
(5) Connect the power cord provided to verify normal operation before using it
※Caution: make sure that the power cord does not come into contact with the heated side and that the power
cable is installed to prevent being installed
How to make installation
4
①Main Screen
- It shows the data like as TV, internet and Screen-mirroring and etc.
②Exercise Display
- Show information of the user’s exercise conditions
- Exercise time/distance/speed/incline and user’s heartrate/consumed-calories
③USB : USB Port supported.
- By connecting USB Type storage device to USB port, you can enjoy video, music, photos in large screen.
④Earphone Jack : Earphone or headset supported.
⑤Program : You can make exercise according to program.
- There are various Buttons. They allows you to make a selection of TV, USB or Smart phone mirroring and etc.
Power : Power ON / OFF switch of "Main screen".
MENU : You can select T V, USB, video, etc. to connectwith the product.
Mirroring : Smart phone mirroring supported.
(regarding Mirroring-usage, refer to page 11 or your smart phone user’s manual)
OK : OK Button
CANCEL : Cancel Button
CH ∨∧: TV Channel Change-Button
VOL ＜＞: Volume Change-Button
②Exercise Display
⑤Program Button
③USB Port
⑥Control panel
①Main Screen
④Earphone Jack
③④
⑤
②
①
⑤
Display and Console Operation Panel
⑥
How to use
3
5
①
②
Control Panal
①START/STOP Button ②Level Adjust Button
①START/STOP Button
When you start exercise or finish exercise, push this button.
②Level Adjust Button
This button is used to adjust the intensity of exercise.
[∧: High intensity, ∨: Low intensity]
6
TV
You can switch to the TV screen and watch TV.
You can change the channel using 'CH +/-' on the screen remote control or 'CH ▲/ ▼' on
the control panel by touching the screen.
VIDEO
You can enjoy video and music by connecting the memory to the USB terminal below the
motion display window.
WORKOUT
You can exercise with the built-in target program.
You can exercise by choosing MANUAL, FATBURN, CARDIO, PROGRAM.
INTERNET
You can enjoy the web and watch Youtube by connecting Wi-Fi.
VTOUR
You can exercise while running in several virtual cities stored in equipment.
This machine’s system is android base included TV, video, and internet, etc.
4 Function of Program
●Main Screen
7
MIRRORING
You can connect your smartphone and enjoy your smartphone on the big screen.
GO
A quick start button to get you started right away.
Language
You can change your language. When the power is turned off and on, the default language is
changed.
SETUP
You can make settings for the equipment functions.
CAUTION
If the SETUP setting is wrong, the equipment may not operate normally.
8
1. Press SETUP at the bottom right of the screen.
2. Press 'Admin Setup', then 'WiFi Setup'.
- Password : 1100
3. Turn on Wi-Fi, find the AP you want to connect to, select it, and enter your access password.
4. When you see the message that you are connected, press the Cancel button at the bottom right.
●Wi–Fi Setup
9
