SERVICE MANUAL

Dynatron®150plus

CAUTION: Federal law restricts this device to sale by or on the order of a physician,

chiropractor, physical therapist, or dentist licensed by the law of the state in which

said person practices to use or order the use of the device.

IMPORTANT: Before treating a patient with the Dynatron 150plus, read the

Contraindications, Warnings, and Precautions in this manual, and observe them

whenever treating a patient with this device.

INDICATIONS FOR ULTRASOUND USE:

Ultrasound therapy is intended to generate deep heat within body tissues for the

treatment of selected medical conditions such as relief of pain, muscle spasms, and

joint contractures, but not for the treatment of malignancies. (21 CFR 890.5300)

Dynatron 150plus Service Manual

Revised June 2004

Dynatronics Corporation

7030 Park Centre Drive

Salt Lake City, UT 84121

(800) 874-6251 - (801) 568-7000

Rev. 06-04_01

Dynatron®150plus

Table of Contents

iii

Table of Contents

Page

Introduction to the Dynatron 150plus..........................................................................................1

About Ultrasound.......................................................................................................................1

Installation and Features...............................................................................................................3

Unpacking..................................................................................................................................3

Standard Accessories .................................................................................................................3

Dynatron 150plus Physical Features..........................................................................................4

Soundheads ................................................................................................................................6

Treatment Instructions..................................................................................................................7

Soundhead Warming..................................................................................................................7

Turn Soundhead Warming OFF / ON........................................................................................8

Treatment Setup.........................................................................................................................8

Modify a Treatment in Progress ................................................................................................9

Patient Coupling ......................................................................................................................10

Ultrasound Coupling Bar Graph..............................................................................................10

Head Temperature Bar Graph..................................................................................................11

Head Temperature Hot.............................................................................................................12

No Soundhead..........................................................................................................................12

Display Watts or Watts/cm2....................................................................................................13

Restore Factory Defaults .........................................................................................................13

Battery Operation........................................................................................................................15

Battery Requirements ..............................................................................................................16

Battery Life..............................................................................................................................16

Ultrasound With Electrical Stim Input .....................................................................................17

Ultrasound General Information ...............................................................................................19

and Usage Cautions......................................................................................................................19

Selecting the Appropriate Soundhead......................................................................................19

Penetration of Ultrasound Waves ............................................................................................20

Types of Delivery ....................................................................................................................21

Treatment Time........................................................................................................................22

Treatment Intensity..................................................................................................................22

Frequency of Treatment...........................................................................................................22

Dynatron®150plus

Continuous Verses Pulsed Ultrasound.....................................................................................23

Duty Cycle ...............................................................................................................................23

Patient Susceptibility ...............................................................................................................23

Potential for Burns or Periosteal Pain......................................................................................23

Output Power ...........................................................................................................................24

Coupling...................................................................................................................................24

Usage Cautions - Combination Treatments.............................................................................25

Contraindications, Warnings, Precautions ...............................................................................27

Contraindications.....................................................................................................................27

Precautions...............................................................................................................................28

Warnings..................................................................................................................................28

Usage Cautions - Combination Treatments.............................................................................28

Safety Features of the Dynatron 150plus.................................................................................28

Technical Specifications ..............................................................................................................29

Environmental Conditions .......................................................................................................29

Dynatron 150plus Care and Cleaning Instructions..................................................................30

Suggested Maintenance Schedule............................................................................................30

Routine Calibration Inspections...............................................................................................31

Authorized Service Center.......................................................................................................31

Definition of Symbols..............................................................................................................32

Equipment Classification.........................................................................................................32

Disposal of Equipment and Accessories..................................................................................32

Ultrasound Regulation ................................................................................................................33

Beam Profile .................................................................................................................................35

Enter Soundhead Parameters.....................................................................................................37

New Smart Heads ....................................................................................................................37

Using Older Model Soundheads..............................................................................................37

Calibration Procedure.................................................................................................................41

Problem Solving ...........................................................................................................................45

Soundhead Temperature Too Hot............................................................................................45

Cooling the Soundhead............................................................................................................45

Whirlpool Treatments..............................................................................................................45

Soundhead Temperature Too Cold..........................................................................................46

Error Message in the Display...................................................................................................46

Sending a Unit in for Repair.......................................................................................................49

Dynatron®150plus

Table of Contents

Return Authorization ...............................................................................................................49

Why the Information is Necessary...........................................................................................49

Packaging and Shipping of Replacement Parts .......................................................................50

Medical Device Reporting Requirements..................................................................................51

Schematics and QC Check Lists.................................................................................................51

Dynatron®150plus

Introduction

Introduction to the Dynatron 150plus

Your new Dynatron 150plus gives you a wide range of treatment capabilities, yet it is

compact, convenient and simple to use with its user-friendly touch panel for easy

treatment setup. Here are some highlights of your Dynatron 150plus:

• Patented Multi-Frequency Ultrasound. With the Dynatron 150plus you can

select three different frequencies without changing the soundhead. The

2 cm2, 5 cm2, and 10 cm2soundheads each operate at 1, 2, and 3 MHz.

• Customizable Duty Cycle. Select from 10, 20, 50 percent, and Continuous

duty cycle options.

• Head Warming. When the device is ON but idle, the soundhead is warmed

automatically. Head warming may be turned OFF, if it is not desired.

• Coupling Sensing. If coupling becomes inadequate during a treatment, the

displays flash and an audible beep is sounded to notify the user that coupling

should be corrected. If your device is version 1.04 or above, a bar graph will

appear.

• Modify Treatments In Progress. You can modify treatment time, power,

frequency, or duty cycle while a treatment is in progress. It is not necessary

to stop the treatment.

• Portable. The Dynatron 150plus is small and light-weight making it readily

portable. An optional carry case is available from your Dynatronics dealer.

• Optional Battery Operation. The device may be operated with power

supplied by an optional battery, offering greater flexibility in treatment sites.

• Two-Year Warranty on the device and soundheads.

This manual provides instructions for Ultrasound setup and treatment with the

Dynatron 150plus. Please read this manual, particularly the section on

contraindications, warnings, and precautions, before treating a patient with this

device.

About Ultrasound

Ultrasound therapy is supported by a wealth of scientific literature. Channeling

sound waves through muscle, nerve, bone, and connective tissue has been

documented to aid in reducing pain, muscle spasms, and joint contractures. The

Dynatron®150plus

“Ultrasound Usage “Cautions” in this manual provide some general guidelines for

Ultrasound treatment to help ensure you deliver safe and effective treatments to your

patients. Further information about Ultrasound may be obtained from published

medical literature.

Before using your Dynatron 150plus, be sure to read the operating instructions,

contraindications, warnings, and precautions contained in this manual.

Dynatron®150plus

Installation and Features

Unpacking

When you receive the unit, immediately unpack it and all accessories and check for

possible damage, obvious or concealed. In case of damage, immediately notify the

carrier and take any steps necessary to file a claim for the damage sustained. Do not

destroy or discard the shipping carton. The carton should be reused if the device must

be shipped for any reason. The carton is specially designed to protect the unit from

shipping damage. Improper packaging of the unit during transport can result in damage

and invalidate the warranty.

Complete the warranty registration found at the back of this manual and return it

to Dynatronics within 30 days of purchase. This is essential to insure you are not

billed for services that are covered by the warranty policy.

Connect the AC power cord, which is equipped with a hospital grade UL listed plug, to

a properly grounded 110/120V 60 Hz AC outlet. The device will automatically switch

to 220/240V 50 Hz when connected to a power source with that voltage. Do not place

the cord or the device in a place where the cord could be tripped over or accidentally

pulled out of its socket during a treatment.

Read the operating instructions and the contraindications, warnings and precautions in

this manual before proceeding with a treatment.

Standard Accessories

Qty Description

1 Dynatron 150plus unit

1 Power cord

1 Operator’s manual

1 Application manual

1 Sample bottle Ultrasound gel

1 Applicator soundhead

Optional Accessories

Additional soundheads are available in sizes, 2 cm2, 5 cm2, or 10 cm2.

Rechargeable battery pack

Pin-to-banana adapter for stim input

Ultrasound coupling gel

Dynatron®150plus

Installation & Features 4

Dynatron 150plus Physical Features

Before operating the Dynatron 150plus, acquaint yourself with the control panel by

reviewing the illustration. Each of the features is numbered in the diagram, and a

description for each feature follows.

Dynatronics

FREQ

1 MHz

3 MHz

DUTY

CYCLE

POWERTIME

PAUSE

STOP

START

10%

50%

20%

CONT

1210 11

8 13

2 MHz

Dynatron 150plus Control Panel

1. POWER OFF/ON SWITCH: Located on the back of the unit. This switch is labeled

“1” and “0”. Set the switch to “1” for ON; set the switch to “0” for OFF.

2. ELECTRICAL STIM INPUT

JACK: This jack is used for

combining Ultrasound with

electrical stimulation. The

output end of a lead connected

to a Dynatron electrotherapy

device may be plugged into this

jack. The current from the stim

device is delivered through the

soundhead.

3. BATTERY INPUT: This input

located on the back of the

device provides connection to Dynatron 150 plus Input Jack

Inhaltsverzeichnis

Andere Dynatron Laborausrüstung Handbücher

Dynatron

Dynatron 900+ Bedienungsanleitung

Beliebte Laborausrüstung Handbücher anderer Marken

Qiagen

Qiagen DML 3000 Bedienungsanleitung

Queensgate

Queensgate NANOSCAN OP400 Programmierhandbuch

Conviron

Conviron GEN1000-GE Bedienungsanleitung

Parr Instrument

Parr Instrument 4560 Bedienungsanleitung

IKA

IKA IC control Bedienungsanleitung

Integra

Integra DOSE IT Bedienungsanleitung

Agilent Technologies

Agilent Technologies 5800 ICP-OES Bedienungsanleitung

Endress+Hauser

Endress+Hauser Cleanfit CPA875 Bedienungsanleitung

NI PXI-5422 Handbuch

Collomix

Collomix Aqix Bedienungsanleitung

SPEX SamplePrep

SPEX SamplePrep 6875 Freezer/Mill Series Bedienungsanleitung

Ocean Insight

Ocean Insight FLAME-NIR+ Bedienungsanleitung

Parker

Parker ALIGN-MG-NA Bedienungsanleitung

BD 644787 Bedienungsanleitung

DENTAURUM

DENTAURUM Compact Megaplus Bedienungsanleitung

Biuged Laboratory Instruments

Biuged Laboratory Instruments BGD 626 Bedienungsanleitung

VWR

VWR SAS Super IAQ Bedienungsanleitung

illumina

illumina MiSeqDx Bedienungsanleitung
