Powerware Series

Eaton 9395 UPS

225–300 kVA

Single-Feed Kit Installation Instructions

®

Eaton 9395 UPS (225–300 kVA) Single Feed Kit S164201722 Rev 2 www.eaton.com/powerquality

1

Eaton 9395 UPS (225–300 kVA) Single-Feed Kit Installation

NOTE Refer to the applicable installation and operation manual supplied with the UPS during installation.

WARNING

Installation should be performed only by qualified personnel.

To install the single-feed kit:

1. If not already accomplished, remove one top screw and two bottom screws

securing the UPS left front panel (refer to the applicable Eaton 9395 UPS manual

for panel location). Lift the panel straight up to remove it from the panel hanger

bracket at the top of the cabinet.

2. If not already accomplished,remove the screws securing the internal safety

shield panel and remove the panel to gain access to the rectifier and bypass input

terminals. Retain the hardware for later use.

3. Using hardware from the single-feed kit (see Table 1), install the single-feed

jumper cables from the kit between the rectifier input terminals and the input

bypass input terminals (see Figure 1). Tighten the bolts to the torque values

listed in Table 2.

4. Return to the applicable Eaton 9395 UPS manual to complete the wiring.

Table 1. Supplied Terminal Hardware

Part Size Quantity Terminals Used On Eaton Part Number

Jumper Cable N/A 6 Rectifier and Bypass Input 152602507

(wire kit with 6 cables)

Bolt, Grade 5 M12 45 mm 6Rectifier and Bypass Input 180190078-113

Flat Washer M12 12 Rectifier and Bypass Input 180500036-120

Conical Washer M12 6 Rectifier and Bypass Input 180500037-120

Nut M12 6 Rectifier and Bypass Input 180200001-07

Table 2. Single-Feed Power Cable Terminations

Terminal Function Terminal Function Bus Landing Tightening Torque

Nm (lb ft) Bolt Size

Rectifier Input

E1 Phase A 1 – 1 bolt mounting 76 (56) M12

E2 Phase B 1 – 1 bolt mounting 76 (56) M12

E3 Phase C 1 – 1 bolt mounting 76 (56) M12

Bypass Input

E6 Phase A 1 – 1 bolt mounting 76 (56) M12

E7 Phase B 1 – 1 bolt mounting 76 (56) M12

E8 Phase C 1 – 1 bolt mounting 76 (56) M12

EATON 9395 UPS (225–300 KVA) SINGLE-FEED KIT INSTALLATION

Eaton 9395 UPS (225–300 kVA) Single Feed Kit S164201722 Rev 2 www.eaton.com/powerquality 2

Single Feed Jumpers

from Kit (2 per phase)

Rectifier Input Terminals

Bypass Input Terminals

1 Bolt, 2 Flat Washers,

1 Conical Washer, and

1 Nut from Kit (6 places)

Figure 1. Eaton 9395 UPS (225–300 kVA) Single Feed Kit

*1642017222*

164201722 2
