MKC Series & MKD526 Bracket Instructions

Original Instructions

These instructions are for dening acceptable MKC series or MKD526 bracket installations to a

mounting surface and for installing an MKC, MKC-WP, MKD526 or MKD526-WP loudspeaker to a

designated bracket.

IMPORTANT SAFETY INSTRUCTIONS – READ THIS FIRST

Safety Instructions

Read and heed all warnings and safety instructions in this manual before using this product.

Failure to follow these precautions may result in damage, injury, or death.

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Clean only with a dry cloth.

6) Install loudspeaker in accordance with the manufacturer's instructions.

7) Do not install near any heat sources such as radiators, heat registers, stoves, or other

apparatus that produce heat.

8) Only use attachments/accessories specied by the manufacturer.

9) Refer all servicing to qualied service personnel. Servicing is required when the apparatus

has been damaged in any way, does not operate normally, or has been dropped.

10) Use personal protective equipment not limited to gloves, safety goggles, ear protection,

and lifting supports.

Suspension Warnings

WARNING: Suspending anything, especially overhead of people, should be done with extreme

caution. Always engage the services of a certied professional who is qualied to determine

the requirements for and to implement overhead rigging. Only persons with the knowledge

of proper hardware and safe rigging techniques should attempt to suspend loudspeakers

overhead. Failure to follow these precautions may result in damage, injury, or death.

Tel 800 992 5013 / +1 508 234 6158

www.eaw.com 2

MKC Series & MKD526 Bracket Instructions

Avertissements de suspension

AVERTISSEMENT: Suspendre quoi que ce soit, en particulier les frais généraux de personnes,

doit être fait avec une extrême prudence. Toujours engager les services d'un professionnel

certié qui est qualié pour déterminer les conditions requises et à mettre en œuvre le

gréement en tête. Seules les personnes ayant la connaissance du matériel approprié et les

techniques sécuritaires de gréage devraient tenter de suspendre les haut-parleurs audessus. Le

non-respect de ces précautions peut entraîner des dommages, des blessures ou la mort.

Avvertenze sospensione

AVVERTENZA: Sospendere nulla, soprattutto sovraccarico di persone, deve essere fatto con

estrema cautela. Inserire sempre i servizi di un professionista certicato che si è qualicato

per determinare i requisiti di e ad attuare manovre in testa. Solo le persone con la conoscenza

di tecniche di assemblaggio di sicurezza hardware e dovrebbero tentare di sospendere gli

altoparlanti in testa. La mancata osservanza di queste precauzioni può provocare danni, lesioni

o morte.

Advertencias de suspension

ADVERTENCIA: La suspensión de cualquier cosa, especialmente por encima de las personas, se

debe hacer con mucho cuidado. Siempre contratar los servicios de un profesional certicado

que está calicado para determinar los requisitos para implementar y para las maniobras de

elevación. Sólo las personas con el conocimiento de las técnicas de aparejo de seguridad de

hardware adecuada y deben intentar suspender altavoces por encima. El incumplimiento de

estas precauciones puede resultar en daños, lesiones o muerte.

Suspension Warnungen

WARNUNG: Schwebend alles, vor allem Aufwand von Menschen, sollte mit äußerster Vorsicht

erfolgen. Immer engagieren, die Dienste eines zertizierten Pro, der qualiziert ist, die

Anforderungen zu bestimmen und Überkopfmontage zu implementieren. Nur Personen mit

der Kenntnis der richtigen Hardware und sichere Rigging Techniken sollten Lautsprecher Kopf

auszusetzen versuchen. Die Nichtbeachtung dieser Vorsichtsmaßnahmen kann zu Schäden,

Verletzungen oder zum Tod führen.

Tel 800 992 5013 / +1 508 234 6158

www.eaw.com 3

MKC Series & MKD526 Bracket Instructions

3. Pass unterminated cable ends through the knockout on the input cover and wire loudspeaker (skip if no

connections).

4. Attach input cover to loudspeaker using (9) M5 x 18 screws.

1. Inventory your kit

Item Description Quantity

ABracket 1

BButton Head Screw 2

CFlat Washer 2

DSplit-lock Washer 2

ERubber Washer 2

FSocket Head Screw 1

GFlat Washer 1

HSplit-lock Washer 1

**Refer to Appendix at the end of document for overview of all bracketry across the series**

Tel 800 992 5013 / +1 508 234 6158

www.eaw.com 4

MKC Series & MKD526 Bracket Instructions

2. Bracket limits of use

a. The Brackets are designed to suspend

each corresponding MKC Series &

MKD526 loudspeaker with a design factor

designated on its appropriate bracket

label or exceed most global suspension

regulations. Maximum working load

limits of each bracket can be located on

its appropriately applied label. These

values have been conrmed with Finite

Element Analysis and destructive testing.

b. The weight/mass of each bracket is also listed on its appropriately applied label.

c. Each bracket are designed to suspend only one loudspeaker per bracket.

d. Any geometric or structural modications to the bracket or hardware that is not EAW-

approved will void the warranty and may result in damage, injury, or death.

e. WARNING: Take care when lifting MKC Series or MKD526 products to avoid harm or

damage to product.

f. WARNING: MKC & MKD526 brackets are for suspension of loudspeakers only. Suspension

of persons is prohibited.

Figure 2 - Vertical Orientation.

May also be ipped 180° from

above image (Not applicable

with MKD526 Bracketry)

Figure 1 - Horizontal Conguration

3. Installation of the brackets to a mounting surface

a. Test t a bracket on an MKC Series or MKD526

loudspeaker to conrm the correct angle, loudspeaker

and bracket orientation before installing the bracket

to the mounting surface.

b. Congurations - Depending on mounting option

used, the MKC Series U-Brackets may be installed

horizontal (back and arms are level/parallel to the

ground - gure 1) or vertical (back and arms are

plumb/perpendicular to the ground - gure 2).

MKD526 U-Brackets may only be used in a horizontal

orientation. If a vertical deployment is needed, the

Yoke bracket may be used.

Tel 800 992 5013 / +1 508 234 6158

www.eaw.com 5

MKC Series & MKD526 Bracket Instructions

NOTE:theoutermostmountingpoint“A”isdesignedasanopenslottoallowforeasylocatingofan

MKCSeriesorMKD526Loudspeakerandlooselypre-installedhardware.Ifusingtheslottedmounting

point,thebracketmustbeinstalledorientedwiththeslotangledupwardasvisuallyshowninFigure1,

opposing the ground.

c. Level - The back ange of the brackets must be level when installed to the mounting

surface for either gure 1 or 2 orientation and before installing an MKC Series or MKD526

loudspeaker to the bracket. Any geometric or structural modications to the brackets or

hardware that are not EAW-approved will void the warranty and may result in damage,

injury, or death.

d. Mounting options

NOTE: It is recommended that you consult a building professional for the proper mounting

hardware before mounting the bracket. Due to various construction methods and materials,

the hardware for securing the bracket to the mounting surface is not supplied. It is required

that the use of hardware locking methods, not limited to lock washers, thread-locker, or

nylon-retention feature, be applied when securing the bracket to the mounting surface or

Figure 3 - Each bracket has multiple mounting hole options as shown above

One Ø5/8in (Ø15.9mm) hole (iii)

1. This hole can be used as a ceiling pole mount or a wall wire pass through.

2. If installing any bracket by this hole, a secondary safety point is suggested to be

secured.

Two inner Ø5/16in (Ø8.5mm) holes (ii)

1. These inner holes are spaced apart from each other on center and aligned.

2. These two inner holes may be used to install the bracket to a mounting surface

using load bearing hardware; both holes must be secured.

4. Installation of an MKC Series or MKD526 loudspeaker to a bracket.

a. Choosing a loudspeaker conguration

• Each bracket has an angle lock option.

• The mounting point is always connected using the M10 screw location on the top

and bottom of the loudspeaker (exception being MKD526 Yoke Bracket)

Tel 800 992 5013 / +1 508 234 6158

www.eaw.com 6

MKC Series & MKD526 Bracket Instructions

• The outermost mounting point "A" is designed as an open slot to allow for easy

locating of the loudspeaker and loosely pre-installed hardware when using the

slotted mounting point, the bracket must be installed oriented with the slot

angled upward, opposing the ground.

• Use of the angle lock point is optional. The angle lock point is used for locking

the loudspeaker at a specic set angle.

b. Installing a loudspeaker onto a mounted bracket.

WARNING: Take care when handling and wear PPE gloves to protect from crushing and

impacts with digits, limbs, and/or product.

Note, for weather protected applications (using WP Series Loudspeakers), apply user-

supplied, waterproof, non-hardening, non-locking thread sealant to the threads of

two button head screws (B) & the single socket head screw (F) per the thread sealant’s

instructions. Failure to do so could result in water ingress and damage to the loudspeaker.

• Onto each of two button head screws (B), place a split-lock washer (C) and a at

washer (D).

• Onto each of the socket head screw (F), place a split-lock washer (H) and a at

washer (G).

Figure 4 - Locking washer is rst on bolt, then at washer, rubber washer to be inside of bracket anges

Tel 800 992 5013 / +1 508 234 6158

www.eaw.com 7

MKC Series & MKD526 Bracket Instructions

WARNING HEAVY LIFTING, MULTIPLE PERSON LIFT – Lift the loudspeaker to align the

center threaded mounting hole with the brackets preferred mounting point.

• Using an Allen wrench, loosely thread the screws and washers (B, C & D) through

the bracket mounting point, through the selected rubber washer (E) and into the

loudspeaker’s center threaded mounting hole. Repeat for the opposite side.

• Do to the bracket’s slotted mounting point “A”, the hardware may be preassembled

to the loudspeaker.

• Note: If using the slotted mounting point, the bracket must be installed oriented with

the slot angled upward, opposing the ground.

• Onto each of two button head screws (B), place a split-lock washer (C), a at

washer (D) and the selected rubber washer (E). Thread these screws and related

hardware three complete turns into the loudspeaker’s two threaded mounting

holes.

• Leave as large a space as possible between the rubber washer (E) and the at

washer (D).

• WARNING HEAVY LIFTING, MULTIPLE PERSON LIFT – Lift the loudspeaker

into the bracket slots with the large rubber washers (E) inside the bracket

and the at and lock washers (C & D) outside the bracket.

• Position the loudspeaker to the desired angle.

• In securing the angle using the angle locking point, align the loudspeaker to desired

angle.

• Onto a socket head screw (F), place a lock washer (H) and a at washer (G).

• Using an Allen wrench, loosely thread the screw and washers (F, G, & H) through

the bracket angle lock point and into the loudspeaker’s center threaded

mounting hole.

• Using allen wrenches, tighten all screws (B & F).

5. Review the MKC Series or MKD526 Loudspeaker installation

a. Conrm the loudspeaker is level or plumb depending on the conguration.

b. Conrm the aim angle is as expected.

c. Conrm all hardware is tight.

d. For weather protected applications, conrm all sealants were applied properly.

Tel 800 992 5013 / +1 508 234 6158

www.eaw.com 8

MKC Series & MKD526 Bracket Instructions

6. Maintenance of an MKC Series or MKD526 U-Bracket installation

a. WARNING: Not following Maintenance instructions could result in equipment damage,

serious injury or death.

b. Maintenance should only be performed by an experienced technician.

c. As with any professional loudspeaker system, routine maintenance must be conducted in

order to ensure the longevity and safe, consistent performance.

d. Inspect the bracket for corrosion and other damage. Brackets with visible damage

should be replaced and discarded.

e. Inspect hardware securing the bracket to the mounting surface for corrosion or

looseness. Tighten loose hardware and consider installing hardware locking methods.

Replace and discard corroded hardware.

f. Inspect hardware mounting the loudspeaker to the bracket for corrosion or looseness.

Tighten loose hardware. Replace and discard corroded hardware.

g. For weather protected applications (using WP Series Loudspeakers), inspect hardware

sealants for cracking or gaps in sealant. Replace damaged sealant with user-supplied,

waterproof, non-hardening, non-locking sealant per the sealant’s instructions. Failure to do

so could result in water ingress and damage to the loudspeaker.

h. Clean brackets and loudspeakers with a dry cloth.

7. Dismantling the MKC Series or MKD526 bracket installation

a. WARNING HEAVY LIFTING – Fully support the weight of the loudspeaker. Using a

allen wrench, remove the screws at the mounting and angle lock points. Carefully lower

the loudspeaker to the ground.

b. Support the weight of the bracket. Remove the mounting hardware securing the bracket

to the mounting surface. Carefully lower the bracket to the ground.

c. Discard all damaged components.

EU Declaration of Conformity

EAW North America Inc hereby declares that this device is in compliance with Directive

2006/42/EC

A copy of this EU Declaration of Conformity is available at https://eaw.com/downloads/#142-

660-wpfd-certications

Tel 800 992 5013 / +1 508 234 6158

www.eaw.com 9

MKC Series & MKD526 Bracket Instructions

APPENDIX A - MKD526 Bracketry

Under Balcony Bracket (WP not

available)

Yoke Bracket

U-Bracket

Tel 800 992 5013 / +1 508 234 6158

www.eaw.com 10

MKC Series & MKD526 Bracket Instructions

APPENDIX B - MKC Series Bracketry

WP Brackets ONLY

MKC50 MKC60 MKC80 MKC120

Andere Handbücher für MKC Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Beliebte Sprecher Handbücher anderer Marken

argon audio

argon audio IE20 Bedienungsanleitung

Denon

Denon SC-N7 Bedienungsanleitung

Gemline

Gemline Ace 3952 Bedienungsanleitung

Focal

Focal ON WALL 300 Bedienungsanleitung

HEADRUSH

HEADRUSH Maximus HRSP 5024 Bedienungsanleitung

SoundLogic

SoundLogic BCCS-6/6395 Bedienungsanleitung

Peavey

Peavey DTH 218 Bedienungsanleitung

Avantree

Avantree Pluto Air Bedienungsanleitung

Morel

Morel Integra Series INTEGRA OVATION 4 Bedienungsanleitung

Oppo

Oppo SONICA Bedienungsanleitung

Bose

Bose SoundLink Wireless Music System Bedienungsanleitung

Rocksteady

Rocksteady Stadium Bedienungsanleitung

Bowers & Wilkins

Bowers & Wilkins 4 Bedienungsanleitung

Sonance

Sonance SONOS OUTDOOR Series Bedienungsanleitung

Electro-Voice

Electro-Voice EVID FM4.2 Bedienungsanleitung

Pioneer

Pioneer XW-HTD630 Bedienungsanleitung

Onn

Onn BWA16AA002 Bedienungsanleitung

HP GL313AA - USB Speakers PC Multimedia Bedienungsanleitung
