Ecoped ode Bedienungsanleitung
2.
PRINTSPEC: EN_ODE-2010v1
© 2010 MIDLAND INTERNATIONAL INC.
3.
WARNING / AVERTISSEMENT
IMPROPER ELECTRIC BICYCLE USE CAN RESULT IN SEVERE INJURY OR DEATH
L’UTILISATION INAPPROPRIÉE DU VÉLO POURRAIT ENTRAÎNER DES BLESSURES GRAVES VOIRE
MORTELLES.
ALWAYS USE A DOT
APPROVED HELMET
AND PROTECTIVE
GEAR
TOUJOURS PORTER
UN CASQUE ET DES
VÉTEMENTS DE SÉCU-
RITÉ APPROUVÉS
DO NOT CARRY PAS-
SENGERS
NE JAMAIS ACCEPT-
ER DE PASSAGERS
NEVER USE ON HIGH
SPEED ROADS
NE JAMAIS UTILISER
LE VÉLO SUR DES
ROUTES À GRANDE
VITESSE
NEVER USE WITH
DRUGS OR ALCOHOL
NE JAMAIS UTILISER
SOUS L’INFLUENCE
DE DROGUES OU
D’ALCOOL
NEVER OPERATE:
- Without proper training or instruction.
- At speeds too fast for your skills or
conditions.
NE JAMAIS UTILISER:
- Sans avoir été entraîné ou informé sur l’utilisation de
l’équipement.
- À des vitesses trop rapides pour son niveau de connais-
sance ou pour les conditions de la route.
ALWAYS:
- Wear proper riding gear.
- Avoid un-paved surfaces as they may
seriously affect handling and control.
TOUJOURS:
- Porter des vêtements de conduite appropriés ainsi que
des lunettes de sécurité.
- Éviter les surfaces non pavées qui pourraient sérieuse-
ment affecter le contrôle du volant.
READ OWNER’S MANUAL CAREFULLY BEFORE OPERATING.
FOLLOW ALL INSTRUCTIONS AND WARNINGS.
LIRE ATTENTIVEMENT LE MANUEL DE L’USAGER AVANT D’UTILISER LE VÉLO. SUIVRE LES INSTRUC-
TIONS ET AVERTISSEMENTS DE CE MANUEL.
WARNING / AVERTISSEMENT
This manual should be considered a permanent part of your ECOPED and should remain with the ECOPED
when resold or otherwise transferred to a new user or operator. The manual contains important safety
information and instructions should be read carefully before operating the ECOPED.
4. 4.
5.
WELCOME
Thank you for purchasing the ECOPED Ode.
LIMITED WARRANTY
ECOPED gives a 90 DAY LIMITED WARRANTY from the original
date of purchase on all components of the ECOPED Electric Bicycles
against defects in material or workmanship. During the warranty
period ECOPED will repair, provide replacement parts or replace your
ECOPED Ode at no charge at the discretion of ECOPED. This war-
ranty does not cover normal wear items or damage caused by neglect
or misuse of the product.
Electric Motor 90 Days
Battery (see battery section) 90 Days
Frame 90 Days
Warranty void if:
- Frame is bent or broken.
- Wheels are bent or broken.
- Fender is bent or broken due to abuse.
- Any sign of accident, impact, jumping, spinouts or roll over.
- Any ECOPED that has been altered structurally, modified, neglected,
improperly maintained or used for racing.
- Improper or infrequent battery charging (see battery section).
The warranty begins on the original date of purchase. This warranty is
not transferrable to another consumer.
All information contained within this publication is based on the lat-
est product information at the time of publication. Due to constant
improvements in the design and quality of production components,
some minor discrepancies may result between the actual vehicle and
the information presented in this manual. We reserve the right to make
product changes at any time, without notice and without incurring any
obligation to make the same or similar changes to the ECOPED previ-
ously built or sold. Depictions and/or procedures in this publication are
intended for reference use only. ECOPED is not liable for any inciden-
tal, consequential, or contiguous damages arising from the use of this
product.
6. 6.
REGISTRATION
The warranty registration form must be submitted to ECOPED within
30 days of purchase along with the UPC (Universal Product Code)
label on the box. The registration form can be found on the last page
of this Owner’s Manual or online at www.ecoped.ca.
BOTH the registration form and UPC label must be submitted in order
to activate the warranty coverage.
To register your ECOPED by mail, submit both the UPC label and com-
pleted registration form to the address listed on the form. You can also
register your ECOPED online at: www.ecoped.ca (UPC label must still
be mailed to the address listed on the registration form). Upon receipt
of this registration, ECOPED will record and register your warranty. No
verification of registration and warranty will be sent to the purchaser.
NO WARRANTY COVERAGE WILL BE ALLOWED UNLESS YOUR
ECOPED IS REGISTERED WITH ECOPED AND THE UPC LABEL
HAS BEEN PROVIDED.
The bicycle’s serial number is located under the seat, adjacent to the
removable battery. DO NOT REMOVE THIS STICKER!
WARRANTY COVERAGE AND EXCLUSIONS
ECOPED limited warranty excludes any failures that are not caused by
a defect in material or workmanship. The warranty does not cover ac-
cidental damage, normal wear and tear, abuse, or improper handling.
This warranty does not cover any ECOPED that has been altered
structurally, modified, neglected, improperly maintained, or used for
purposes other than for which it was manufactured and intended.
ECOPED does not cover any damages which occur during trailer
transit or as a result of unauthorized service or the use of unauthorized
parts including chemicals, fuels, and lubricants.
PLEASE SEE THE SAFETY SECTION BEFORE OPERATING THE
ECOPED!
Initial set-up of your ECOPED is very important in ensuring trouble-free
operation.
7.
HOW TO OBTAIN WARRANTY SERVICE
If your ECOPED requires warranty service, please contact the ECOPED
customer service center at 1-877-528-3772 for instructions on filing for
a warranty claim. You can also find a list of authorized ECOPED ser-
vice centers listed on the website: www.ecoped.ca. When requesting
warranty service you must have your copy of the Warranty Registration
form and the sales receipt for authorization.
YOUR ECOPED ODE
Detachable Storage
Double Stand
Battery
Rear Wheel Lock
Tailights
Headlights
Throttle Grip
Steering Column
Instrument Panel
Ignition
8. 8.
CONTENTS
1.
Important
Registration & Warranty
Your ECOPED
Safety
1.1 Age Restrictions................................................
1.2 Safety Legend...................................................
1.3 Important Safety Notes.....................................
1.4 Safety Decals and Locations.............................
1.5 Safety Gear.......................................................
10
10
11
13
14
2. Display Unit & Controls
2.1 Left Handlebar...................................................
2.2 Right Handlebar................................................
2.3 Ignition..............................................................
2.4 Display Unit......................................................
2.5 Wheels..............................................................
2.6 Tires..................................................................
2.7 Motor.................................................................
2.8 Battery...............................................................
2.9 Lighting.............................................................
15
16
17
17
18
18
18
19
21
3. Inspection
3.1 Inpsection Before Riding...................................
3.2 Inspection After Riding......................................
23
25
4. Riding
4.1 Weather.............................................................
4.2 Weather Conditions..........................................
4.3 Seasons............................................................
4.4 Road Conditions...............................................
25
25
26
26
4.5 Pedaling............................................................
4.6 Turning..............................................................
4.7 Acceleration......................................................
4.8 Braking..............................................................
4.9 Parking..............................................................
27
27
28
28
28
9.
5. Maintenance
5.1 Battery Maintenance.........................................
5.2 Battery Recycling..............................................
5.3 Lubrication........................................................
5.4 Tires..................................................................
5.5 Brakes..............................................................
5.6 Storage.............................................................
5.7 ECOPED Cleaning............................................
29
30
30
30
30
30
31
6. Specifications........................................................... 33
7. Notes....................................................................... 34
10.
10.
1. SAFETY
WARNING!
Failure to follow the safety instructions in this manual may result in serious injury and/
or death.
1.1 AGE RESTRICTIONS
Operation is prohibited for anyone under the age of 16.
KNOW YOUR ECOPED
The operator of the ECOPED is responsible for their own personal
safety, as well as the safety of others.
Never operate the ECOPED without proper understanding of Safety
Training in the Owner’s Manual. ECOPED highly recommends that
beginners take a training course with a licensed instructor. You can
access information on electric bicycle rider training programs on our
website: www.ecoped.ca
Operating your ECOPED without proper instruction could be hazard-
ous to the operator. The risk of injury may increase greatly if you are
not trained to operate the ECOPED properly under different situations
and weather conditions.
For information on e-bike legislation in your area, please visit www.
ecoped.ca. Under the duration of provincial pilot programs, all conven-
tional bicycle legislation and fines apply to the use of e-bikes, such as
your new ECOPED Ode.
1.2 SAFETY LEGEND
You will come upon the following types of safety notes and reminders
when reading this manual.
WARNING!
This safety alert warning indicates a potential hazard that may result in serious
personal injury.
CAUTION!
This safety alert caution indicated a potential hazard that may result in minor personal
injury or damage to the vehicle.
