Emmo Max

Owner’s Manual

Version 1.0, J. Lu, M. Wu

2 | P a g e

Table of Contents

E-bike MTO Label……………………………………………………………………………………………………..3

Specifications…………………………………………………………………………………..……………………….4

Charging Your E-bike……………………………………………………………………………….……………5-6

Disc Brake and Tubeless Tire…………………………………………………………….…………….………7

Brakes……………………………………………………………………………………………………………………...8

Kickstand………………………………………….……………………………………………………………………..9

Pedals…………………………………………………………………………………………………………………….10

Seat and Circuit Breaker………………………………………………………………………………………...11

Ignition…………………………………………………………………………………………………………………..12

Remote Controller………………………………………...……………………………………………………….13

Right Side of the Handlebar and Throttle……………………………………………………………….14

Left Side of the Handlebar……………………………………………………………………….……………..15

Dashboard……………………………………….………………………………………………….…………………16

MP3 Player and 12V DC Charging Port…….......………..………….…………………..………….17-18

E-bike Registration…………………………………...……………………………………………………………19

Contact Information……………………………………………………………………………………..………..20

3 | P a g e

E-bike MTO Label

WARNING!

Please make sure this MTO label is on your e-bike. If this label is not present, please ask

your dealer to put one on. All electric bicycles are required to have this sticker on the bike

for it to be a legal vehicle.

4 | P a g e

Specifications

Color:

Black; Red; Orange; White

Dimension (LxWxH):

1880 x 760 x 1245

Wheel Size:

10″/3.5″ Tubeless

Net Weight:

95 kg

Maximum Speed:

32 km/h

Travel Range:

60-70 km*

Charging Time:

3 –8 Hours

Climbing Angle:

25 Degrees

Load Capacity:

250kg

Motor:

Continuous 500W (Super Torque Motor)

Battery:

60V/20Ah GEL SLA

Charger:

AC100-120V, Smart Charger (Battery maintained while charging)

Front Brake:

Disc Brake

Rear Brake:

Disc Brake

Lock System:

Remote Alarm / Remote Starter / Key Ignition Lock / Steer Lock / Motor Lock

Meter & Indicator:

Speedometer, Odometer, Battery Strength Indicator, Light Indicator, Digital Clock

Lighting System:

Headlight w/High Beam, Turning Signals, Brake Light, Tail Light, Indicator Light

Storage:

Lockable Under-Seat Storage, Lockable Rear Box (optional), Lockable Glove Box

* Travel range is based on riding on level ground, no stops, no winds, warm temperatures for a 175lb rider with

no extra cargo.

SPECIAL FEATURES: Super Torque Motor, 3 Speed Control, Cruise Control, Stereo System, 12V

Charging Port, Tubeless Tire, and Disc Brake.

5 | P a g e

Charging the Bike (Lead Acid Battery)

There are two different plugs on your charger: one end that goes into an 110V power outlet, and the other into the charger

port.

1. Take one end of the charger and plug it into the charger port located on the bike (Please make sure that it is fully

plugged in)

2. Plug the other end of the charger into the power outlet.

3. Confirm that the charging indicator turns red.

Note: When the battery is fully charged, the charging indicator will turn green.

4. Unplug the charger from the power outlet.

5. Unplug the charger from the battery/bike.

Note: The charger light must be red when both plugs are plugged in. It will always turn red first if the bike has been used.

It will turn green after it is fully charged.

WARNING!

Charge the bike for no more than 8 hours.

Fully charge the bike once a month during long periods of inactivity. (i.e. during the wintertime)

6 | P a g e

WARNING!

*CHARGING THE E-BIKE

SHOULD TAKE A

MAXIMUM OF 8 HOURS.

*DO NOT CHARGE THE E-

BIKE FOR MORE THAN 12

HOURS. OVERCHARGING

WILL OVERHEAT THE

CHARGER, AND WILL

RESULT IN THE CHARGER

DAMAGING THE

BATTERY.

*MAKE SURE TO FULLY

CHARGE THE E-BIKE

ONCE A MONTH DURING

LONG PERIODS OF

INACTIVITY (i.e.

WINTERTIME).

7 | P a g e

Disc Brakes and Tubeless Tires

The Emmo Max is assembled with disc brakes, as opposed to drum brakes, and tubeless tires. These brakes are virtually

maintenance free; the only maintenance required is the replacement of the fluid every 10,000km. They are also stronger,

more resistant to wear and tear, and last longer than the opposing drum brakes. The tubeless tires are extremely difficult

to puncture, so that chance of getting a flat tire is next to zero. Additionally, air rarely escapes from these tires.

Note: Remember to grease the chains once a month.

The air pressure for the tires should be between 35-40 psi.

8 | P a g e

Front Brake

When this lever is pulled towards the rider, the front

brake activates.

Back Brake

When this lever is pulled towards the rider, the back

brake activates.

Note: When either brake is activated, it will cut off the motor. Always use back brakes first, then front

brakes.

9 | P a g e

Side Stand

The side stand is similar to other bicycles –flick it downwards such that it sticks out, as shown in the picture, then lean

it to the left.

Centre Stand

The centre kick stand is better used for all situations. In order to engage the kickstand, apply pressure with your foot

downwards and gently lift the bike upwards, NOT BACKWARDS.

WARNING!

Please do not engage the side stand when the bike is left unattended. The bike is not completely stabilized with

this kickstand.

10 | P a g e

WARNING!

The law requires all e-bikes to have pedals installed. If the pedals are off, these vehicles will be considered a

motorcycle which does not follow the same regulations as e-bikes.

Foldable Bike Pedals

To fold the bike pedals, push the pedal inwards and lift up.
