Emos H1133 Bedienungsanleitung

H1133

RS|HR|BA

WiFi DOORBELL

DOMOVNÍ ZVONEK WiFi

DOMOVÝ ZVONČEK WiFi

DZWONEK DOMOWY WiFi

WIFIS AJTÓCSENGŐ

HIŠNI ZVONEC WiFi

KUĆNO ZVONO WiFi

TÜRSPRECHANLAGE WLAN

 Wi-Fi 

SONERIE DE CASĂ WiFi

WiFi DURŲ SKAMBUTIS

WiFi DURVJU ZVA NS

User manual

3010001133_31-H1133_150×190

WiFi Doorbell

1 | App Introduction

Download the app from the iTunes App Store® or the

Google Play Store®. Search“IPBell”and select our free app.

You can scan bar code on the cover to download the APP.

APP contains the following languages, same as moblie

devices: Simplied Chinese, Traditional Chinese, English,

French, German, Japanese, Dutch, Italian, Spanish, Me-

IPBell

iOS Android

The New-generation WiFi doorbell can work via WiFi or connecting with network cable. After visitor(s) press call button,

smartphone or tablet will interact with the doorbell, users will enjoy its functions like real time video & audio, unlock,

photo & video recording, alarm, P2P cloud service push messages of visitor calls, PIR and tamper alarms. TheWiFi doorbell

has capabilities of tamper alarm, PIR detection, night view. Maximum capacity of the system can be 8 doorbells working

with 8 smart phones/tablets.

xico, Korean, Brazil, Portuguese, Danish, Finnish, Norwe-

gian, Swedish, Russian, Polish, Turkish, Ukrainian, Arabic,

Croatian, Czech, Greek, Hebrew, Romanian, Slovak, Thai,

Indonesian, Malay, Hungarian, Vietnamese, Hindi. Display

portrait and landscape screen.

App Name is IPBell, Scan QR code to download APP

2 | Features

Serivce Serivce P2P Serivce

Audio Format ADPCM

Processor 2-way audio

Video

Format H.264

Sensor 1/4 CMOS Ov9712, 1 Mega Pixels

Frame Rate 25 fps

Lens 3.6 mm

Night vision Night vision Yes

Network Network 1 WiFi; 2 Network cable

Alarm Alarm PIR and tamper alarms

Action PIR alarm push messages, Tamper alarm call to mobile device

Other

Waterproof IP55

Power 9–16 V DC 1 A or POE

Temperature -20–55 °C

Humidity 10–95 % RH

Weight G.W.: 600 g

Function Real time video and audio, unlock, alarm

3 | Package Contents

WiFi Doorbell

Power

adapter

Unlock

control

Screw and

rubber plug

Adhesive

tape

User

manual

DC Cable RJ45 cable POE injector Screwdriver

H1133

4 | Interface

39 mm Photoresistor

Reset Arming

Arming LED

Tamper alarm

RJ45 Network Cable

Microphone

Camera

PIR sensor

Working light

“Call”button

Speaker

Infrared led

145 mm

39 mm

93 mm

Doorbell is in disarming state if arming led is on after power on, it will enter arming state and arming led is o after press the

arming button. it will sound an alarm after press arming button under arming state.

5 | Network connections and power supply

Doorbell’s power and network connection selection, please refer to:

1. Power and network cable both available, plug the network cable and power.

2. Power available but no network cable, plug the power and connect to WiFi, try to ensure that the doorbell’s received signal

strength is higher.

a) Power with adapter

9~ 16 V 1 A

WiFi Doorbell

6 | b) Power with PoE

7 | Installation

1 | Use four screws at the corner to x doorbell on the wall.

Hexagon

screw

2 | Use two screws in the middle to x doorbell to the 86 box or 2" × 4" box.

Hexagon

screw

box 86

box 2" × 4"

H1133

Length <= 80 m

Providing power and wired

network

Router or switch

POE injector

3 | Choose the hotspot like“IPB-XXXXXX” (XXXXXX is 6

gures)

4 | Input the default password as“123456789” then click

“Join”

8.1. | Mobile device join to doorbell’s

hotspot

8.1.1 | Add doorbell into mobile device

(Ignore this step if connect to a wired

network or non-administrators)

The rst one to add doorbell into network is administrator. The

wireless router should be placed near the doorbell.The enviro-

ment should be less-metals, less-brick walls between doorbell

and router to get better WiFi signal.

1 | Press“Reset”button to reset doorbell after

power on. And there is voice prompt.

2 | Press“Call”button for more than 3 seconds to generate

hotspot.

WiFi Doorbell

8.1.2 | Input information

5 | Mobile devices connect to 3G/4G cellular data or WiFi,

run app entering into main interface, touch to add a

new doorbell.

6 | Default name is DoorBell. Default administrator’s

username is“admin”, they can be modied after

successfully adding the doorbell. Ensure mobile devices

and doorbells are in the same network if touch“Search”.

7 | Select the ID which prex is IPB and followed by 6

gures that are same as hotspot’s 6 gures. Non-

administrators could manually input it or scan QR code,

or search ID if within the same LAN

8 | Input username (minimum length is 5) and password

(minimum length is 6), then click“Done”

H1133

8.1.3 | Join router

(Ignore this step if connect to a wired network or

non-administrators.)

9 | Current doorbell status should be online. If it‘s oine,

touch then touch

10 | Touch“WiFi Setting”. It supports 802.11 b/g/n/ac

wireless router

11 | Touch“WiFi network”. The available router will be

displayed. Please choose target router

12 | After input password, please touch “Done”. Then

doorbell will restart. After 40 seconds, doorbell will be

in online state.

WiFi Doorbell

8.2 | Doorbell status

Status include online, oine, wrong password, user

doesn’t exist, connecting.“Connecting” normally means

mobile devices don’t activate WiFi or 3G/4G.

Same users connect one doorbell could not log in multiple

mobile devices simultaneously.

8.3 | Delete doorbell

Touch “Edit”, then touch “Done” you could delete or batch

delete.

8.4 | Edit doorbell

Edit doorbell name, username, password, then touch

“Done”

9 | Monitor

Touch to monitor when it’s online, picture recording/video

recording/alarm functions can be activated, but unlocking

function can’t be activated by this step.

10 | Settings

If doorbell is oine, click If still oine, check network

setting. When doorbell is online, touch , to enter

setting.

H1133

10.1 | System Setting

Audio prompts:

There is audio prompt when you press doorbell or add

new doorbells.

Conguration mode:

Only administrator has permission to set. After successful

doorbell(s) adding, o state is recommended.

PIR detection:

When it’s on, it will push messages of visitor to mobile

devices.

10.2 | User management

Administrator edits existed username and password.

Non-administrators edit existed password.

Administrator could add or delete users.

11 | Ring setting

Touch to set ring, view software version or exit.

WiFi Doorbell
