Enable-IT 865Q PRO Bedienungsanleitung

Enable-IT 865Q PRO Gigabit

Professional Grade PoE Extender Kit

Quickstart Guide

Professional Grade Networking

INSTALLING THE 865Q PRO ULTRA POE EXTENDER KIT

The Enable-IT 865Q PRO Ultra PoE Extenders have a distance restriction of 3,000ft (915m)

over 2-pair or more of Category rated 5e or better wiring from device extension to device

extension. Therefore a site survey of the wiring and installation planning are highly

recommended.

The 865Q Ultra PoE Extender is a 56V 150W very high power PoE Extender Solution for the

most demanding applications. This Power Detect solution supports any 802.3af/at or 802.3bt

standard PoE Device.

Perform an Out Of The Box Test (OOTBT)

We recommend that you perform a quick out of the box test to ensure the working order

of your Enable-IT 865Q PRO Ultra PoE Extender units prior to installing. This will also

serve to familiarize you with how easy the process should be.

Step 1) Using the provided Ethernet patch cord, connect the Interlink ports on the 865Q

units together as shown in the diagram below.

Step 2) Next connect your LAN Data Input into the 865Q PRO CO LAN 3 RJ45 port.

The ports are not auto sensing for PoE if you use a PoE Switch and can cause

issues, but the 865Q PRO uses it’s own much higher powered PoE source.

Step 3) Lastly connect the AC power cord to the 56V 150W DC Injector and to an AC

outlet.

The Green Interlink Status LEDs will start flickering slowly and then fast as the units talk

to each other. After a second you should see a solid Green Interlink Status LED on each

unit to confirm a link is established. This confirms basic proper operation of the units.

For a more detailed test and to confirm your PoE Device Equipment works with the 865Q

PRO units, connect your PoE Devices to the Gigabit LAN ports on the 865Q PRO CPE unit.

865Q PRO CPE Unit

865Q PRO CO Power bundle

RJ-45 Interlink Cabling up to 3,000 feet / 915m

4 - PoE output ports

LAN Data IN Port 3

Do not use a PoE Switch

Performing the On-Site Installation

After removing the Enable-IT 865Q PRO Ultra PoE Extender Kit from the box, and performing

the Out Of The Box Testing (OOTBT), all that remains to install the unit on-site is to mount the

unit, build the interconnect wiring and attach the PoE device cabling with the provided Ethernet

Patch cords.

Troubleshooting

First examine the backbone wiring pair and make sure you have solid connections. The Interlink

Sync LED will be lit solid Green with rapid pulsing on each 865Q PRO unit to show proper connection

and pairing. If the Interlink Sync LED Link is flashing slow to fast and never goes solid…. Then follow

the steps below:

1) Make sure your wiring is straight through and not connected to any Telco punch down

blocks; If so remove from the block and use Telco butt clips to bridge wire.

2) Check for a firm connection of the RJ-45 connections in each 865Q PRO unit, and

power is applied to the 865Q PRO CO units.

3) You can easily isolate any issue by performing an Out Of The Box Test (OOTBT). This

test will confirm the correct working order of your Enable-IT 865Q PRO Ultra PoE

Extender Kit. This will point to a possible issue with your long distance Interlink wiring

being affected by possible outside interference.

865Q PRO (4-Port) DIP Switch Settings

•Default is all DIP switches Down = On for 4-port PoE

•Switch 1:

LAN 1 / LAN 2 PoE On – Down / On Position - Default

LAN 1 / LAN 2 PoE Off – Up / Off Position

•Switch 2: 4-Pair output

PoE 4-Pair – Down / On Position - Default

PoE 2-Pair – Up / Off Position (PIN 1,2,3 & 6)

•Switch 3:

LAN 3 PoE On – Down / On Position - Default

LAN 3 PoE Off – Up / Off Position

•Switch 4: Not Used

LAN 4 PoE On – Down / On Position - Default

LAN 4 PoE Off – Up / Off Position

TECHNICAL SUPPORT

Online Technical Services

The Enable-IT Support Portal is available 24/7 to open a ticket or check the status of one. Please use

this support website as your first source for help as it contains an on-line knowledge base of articles,

documentation, FAQ's and other problem-solving resources. This web-based support resource

provides the quickest solution to the most common technical support issues.

Returning Products for Warranty Repair

Enable-IT warrants to the original purchaser of this described Product ("you" or the "End User") that,

for the limited lifetime period commencing on the date the Product was purchased (the “Warranty

Period"), the Product will be substantially free from defects in materials and workmanship under

normal use and conditions. Lifetime Warranty details here: https://warranty.enableit.com

This warranty does not apply to Products, which are resold as used, repaired or reconditioned.

Electrical or water damage is not covered under this warranty, extended warranties or

Advanced Replacement Program (AREP).

In order to obtain an authorized RMA approval, the End User must complete the required information

online located at https://support.enableit.com Ifyouhavequestionsordifficultycompletingthis

information you may contact the Customer Care Team at 888-309-0910 between the hours of 7:00

a.m. and 4:00 p.m. Pacific Time(PST).

Returning Products for Refund

Enable-IT, Inc. offers a generous 45-Day refund on a single Ethernet Extender Kit only, and is

subject to a 20% Restocking Fee. Shipments without a valid or authorized RMA number, or

sent to our corporate Las Vegas address, can be refused and / or billed for additional shipping.

Sales and Customer Care:

Toll Free US and Canada 888 309-0910

Other International +1 702 924-0402

E Mail [email protected]

[email protected]

RMA Support:

https://support.enableit.com
