Please read this manual first for correct installation and operation. This manual should be retained for

future reference. The information in this manual was current when published. The manufacturer

reserves the right to revise and improve its products. All specifications are therefore subject to change

without notice.

by any means without written permission of the EverFocus Electronics Corporation.

Precautions

1. Do not place any object on top of the cover.

2. Be careful when handling the camera, do not drop it or subject it to strong shock or vibration to

prevent any damages to it. Do not disassemble it or place it on an unstable base.

3. Install the camera away from TV, radio transmitter, magnet, electric motor, transformer, audio

speakers because the magnetic fields generate from above devices will distort the video image.

4. Install the camera away from stoves, or other heat generating devices as the high temperature

could cause deformation, discoloration or other damages of the camera. Install the camera at

where the temperature range will stay between 0°C to 50°C (32°F to 122°F).

5. Never aim the camera at the sun or other extremely bright objects whether it is in use or not.

6. Do not touch the surface of CCD sensor by hand directly. Use a soft cloth to remove the dirt

from the camera body. Use lens tissue or a cotton tipped applicator and ethanol to clean the

CCD sensor and the camera lens. When the camera is not in use, put the cover cap on the lens

mount.

7. All warnings on the products and in the operating instructions should be adhered to.

8. Do not use attachments not recommended by the appliance manufacturer as they may cause

hazards.

9. Do not allow anything to rest on the power cord. Do not locate this appliance where the cord will

be abused by persons walking on it.

10. Do not overload wall outlets and extension cords as this can result in fire or electric shock.

11. Never push objects of any kind into his appliance through cabinet slots as they may touch

dangerous voltage points or short out parts that could result in fire or electric shock.

12. Refer all work related to the installation of this product to qualified service personnel or system

installers.

Federal Communication Commission Interference

Statement

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

Table of Contents

1. Product Overview……………………………………………5

1.1 Features................................................................. 5

1.2 Accessory Parts List................................................ 6

1.3 Specifications......................................................... 7

1.4 Dimensions............................................................. 8

1.5 Back Panel Overview ............................................... 8

1.6 Camera Setting DIP Switch....................................... 9

2. Installation…………………………………………………….10

2.1 Plug the Power...................................................... 10

2.2 Mount the Lens ..................................................... 10

2.3 Connect the Video Output....................................... 10

2.4 Adjust the Lens ..................................................... 10

CHAPTER 2 INSTALLATION

Product Overview

The new redesigned EverFocus color box camera produces excellent images with 1/3” SONY Super

HAD CCD. The EQ series offers cost-effective solutions suitable for all your surveillance

applications. The camera includes an adapter ring and it is compatible with both C-mount and

CS-mount lenses. In addition, EQ300E/EQ200E provides 24 hours monitoring Day/Night function.

Available in high resolution (520TVL) and standard resolution (380TVL).

1.1 Features

zLow light sensitivity 0.4 Lux/F=1.2(AGC ON) is achieved by using the advanced 1/3” SONY super

HAD CCD. (EQ300E)

zLow light sensitivity 0.3 Lux/F=1.2(AGC ON) is achieved by using the advanced 1/3” SONY super

HAD CCD. (EQ200E)

z520 TVL (EQ300E) or 380 TVL (EQ200E) of horizontal resolution

zSupport video drive and DC drive auto IRIS lens

zAdvanced Digital Signal Processor for excellent image quality

zDay/Night function

zBLC, AGC and FL On/Off switchable

zCompatible with both C-mount and CS-mount lens (adapter ring included)

zSystem available for NTSC or PAL

Chapter

CHAPTER 1 PRODUCT OVERVIEW

CHAPTER 2 INSTALLATION

1.2 Accessory Parts List

Please be careful when you unpack the box due to the electronics devices inside. Check and make sure

that you have all the items listed below inside the original box:

zCamera unit x 1

zOperation instructions (this document) x 1

zMounting kit includes:

　 -C adaptor mount ring x 1

-L wrench x 1

Iris Lens Connector (top) x 1

-Iris Lens Connector (bottom) x 1

Please Note: If an item appears to have been damaged in shipment, replace it properly in its carton and

notify the shipper. If any items are missing, notify your EverFocus Electronics Corp. Sales Representative or

Customer Service. The shipping carton is the safest container in which the unit may be transported. Save it

for possible future use.

CHAPTER 1 PRODUCT OVERVIEW

CHAPTER 2 INSTALLATION

1.3 Specifications

Type EQ200E EQ300E

Pickup Device 1/3'' SONY Super HAD CCD

Video Format NTSC or PAL

Scanning System NTSC: 525 TV lines, 60 fields/sec

PAL: 625 TV lines, 50 fields/sec.

Picture Elements 510 x 492 (NTSC) ; 500 x 582 (PAL) 768 x 494 (NTSC) ; 752 x 582 (PAL)

Horizontal Resolution 380 TV Lines 520 TV Lines

Sensitivity 0.3 Lux/F=1.2 0.4 Lux/F=1.2

S/N Ratio Over 48dB (AGC off)

Electronic Shutter 1/50(1/60)~1/100,000

Auto iris Video/Direct Drive switch

Back Light Comp. ON/OFF Switch

Auto Gain Control ON/OFF Switch

Flickerless ON/OFF Switch

Simple Day/Night Auto/OFF Switch

Auto White Balance Yes

Gamma Correction 0.45

Video Output BNC 1.0Vp-p, 75ohm

Sync. Mode Internal sync

Lens Mount C/CS mount

Audio Optional

Power Source 3 types: 12VDC only ; 12VDC/24VAC ; 100VAC~240VAC

Power Consumption 12VDC: 1.6W max.

24VAC: 2.2W max.

100VAC~240VAC:1.6W max.

Dimensions 58mm(W) x 55mm(H ) x 125mm(D) ; 2.3"(W) x 2.2"(H ) x 4.9"(D)

Weight 0.25kg ; 0.55lbs

Operating Temperature 0°C~50°C ; 32°F~122°F (20%~80% Humidity)

Certifications FCC/CE

CHAPTER 1 PRODUCT OVERVIEW

CHAPTER 2 INSTALLATION

1.4 Dimensions

1.5 Back Panel Overview

CHAPTER 1 PRODUCT OVERVIEW

CHAPTER 2 INSTALLATION

1.6 Camera Setting DIP Switch

○

1DD/VD

For video drive auto iris lens, please set switch to VD. For Direct Drive iris lens, set switch to DD.

Wire the cable of lens to Mini Plug according to the following table:

Pin1 Pin Pin3 Pin4

Video Drive +12V GND VD-IRIS GND

DirectDrive Cnt- Cnt+ Drv+ Drv-

For Direct Drive iris lens:

Brightness Level can be adjusted from the IRIS level VR on the back panel.

- Turn counterclockwise to L to get darker picture.

- Turn clockwise to H to get brighter picture.

○

2Electronic Shutter ON/OFF

ES ON: The camera continuously adjusts the shutter speed from 1/60 (NTSC), 1/50 (PAL) second

to 1/100,000 second according to the luminance conditions of the scene.

ES OFF: The shutter speed is fixed at 1/60 (NTSC), 1/50 (PAL) second.

Set ES OFF, when auto iris lens is used. Otherwise, turn ES ON for optimum performance.

The default setting is ON.

○

3BackLight Compensation ON/OFF

When BLC is turned on, the AGC, ES and IRIS operating point are determined by averaging over

the center area instead of entire field-of-view, so that a dimly-lit foreground object at center area

can be clearly distinguished from brightly-lit backgrounds.

BLC should not be used unless it is needed to compensate for backlight.

The default setting is OFF.

Note:

When ES setting is OFF, then BLC function will be inactive.

○

4Automatic Gain Control ON/OFF

AGC ON: The sensitivity increases automatically when light is low.

AGC OFF: A low-noise picture is obtained under a low light condition.

The default setting is ON.

○

5FL (Flickerless) ON/OFF

When picture flicker fiercely, turn FL on, then the camera will stabilize the speed of electronic

shutter at 1/100(NTSC) or 1/120(PAL) automatically, and reduce the flicker immediately.

The default setting is OFF.

○

6D/N Auto/OFF

Day&Night: When light environment is under 5 Lux, the camera will switch to black and white

mode. However, when light environment is over 10 Lux, the camera will switch to color mode.

Please be informed that any D/N switch will result a delay of 4~5 seconds.

The default setting is OFF.

Day&Night OFF: Camera stays in color mode.

Note: when AGC setting is OFF, then D/N function will be inactive.

IRIS

CHAPTER 1 PRODUCT OVERVIEW

CHAPTER 2 INSTALLATION

Installation

This chapter will describe, in general terms, how to install the EQ300E/EQ200E camera.

STEPS:

1. Plug the power

2. Mount the lens

3. Connect the video output

4. Adjust the lens

2.1 Plug the Power

Plug the power cord to the outlet. Power indicator LED should light if the power source is properly

connected.

Warning

•To prevent electrical shock, turn off the electrical power before making electrical

connections.

•Do not expose the appliance to water or moisture, nor try to operate it in wet areas.

•Do not connect high voltage power to the camera. It may damage the camera.

•Do not short circuit the power leads and expose the wire when connecting the power supply

to the camera

2.2 Mount the Lens

i. Remove the cover cap from the top of the lens mount.

ii. If C mount lens is used, please fix the C Mount Ring (the 5 mm thick ring attached in the

accessory bag) to the top of the lens mount before mounting the lens.

iii. Screw the lens firmly onto the lens mount.

2.3 Connect the Video Output

Connect the video output of the camera to a color monitor or other video device through a 75

ohm type coaxial cable with BNC female connector at camera end.
