EverFocus WDII EQ600 Bedienungsanleitung

INSTRUCTION MANUAL

1/3” W-Dynamic High Resolution Color Camera

Version1.0

About this manual

Before installing and using this camera, please read this manual carefully.

Be sure to keep it handy for later reference.

EQ600 WDII

Safety Warning

1. Read manual carefully before installing the unit.

Please read this manual first for correct installation and operation.

2. Never install the camera on a ceiling that cannot hold its weight

The product may fall down to cause damages.

3. Do not install the camera near electric or magnetic fields.

Installed the camera away from TV, radio transmitter, magnet, electric motor, transformer, audio

speakers because the magnetic fields generate from above devices will distort the video image.

4. Always stop using when the product emits smoke or abnormal heat

5. Never disassemble the camera nor put impurities in it

Disassembly or impurities may result in trouble or fire.

6. Never face the camera toward the sun.

Direct sunlight or severe ray may cause fatal damage to sensor and internal circuit.

7. Keep the power cord away from wet and never touch the power cord with wet hands.

Touching the wet power cord with hands or touching the power cord with wet hands may result in

electric shock.

8. Never install the camera in areas exposed to water, oil or gas.

The water, oil or gas may result in failure, electric shock or file.

9. Cleaning

Do not touch the surface of sensor by hand directly. Use a soft cloth to remove the dirt from the

camera body. Use lens tissue or a cotton tipped applicator and ethanol to clean the sensor and the

camera lens.

10. Do not operate the camera beyond the specified temperature, humidity or power source

ratings.

Use the camera at temperatures within 0℃

℃℃

℃~ 40℃

℃℃

℃and humidity below 90%. The input power

source is DC12V/AC24V.

Notice:The information in this manual was current when published. The manufacturer reserves the

right to revise and improve its products. All specifications are therefore subject to change without notice.

Table of Contents

1. Product Overview……….………………..……………..………………………….…….…2

1.1 Main Features.…..…………..………………………………………………..…………2

1.2 Content List………………………………………………………………………………2

1.3 Specifications……………..……….……………………………………………………..3

2. Back Panel Connections………………………….………………………….…………….4

3. Operation………………………………………………………..………………..……..…5~6

3.1 Setup Buttons…...………………………………………………………………..……...5

3.2 Display/Close the user setup menu screen…..………………………………………6

4. Main Menu Flow……..…………..………..…………………………………………………7

5. Preset Mode……………..……………………………..…….………………………………8~9

5.1 User Setup Menu Flow….…………………………………………………………..….8

5.2 User Setup……………………………………………………………………………….9

6. Camera ID………………………………………………………..………………………10~11

6.1 Camera ID……………………………………………………………………………….10

6.2 ID Position……………………………………………………………………………….11

6.3 ID Color ………………………………………………………………………………….11

6.4 ID Background…………………………………………………………………………..11

7. Advanced Setup…………………………..…………..…….…………………………12~13

7.1 Auto IRIS…………………………………………………………………………….…..12

7.2 White Balance……………………………………………………………………..……12

7.3 LineLock…………………………………………………………………………………13

7.4 Viewing………………………………..………..…………………………………..14

8. Save/Restore……………………………………………………………………………..…15

Appendix-A…Camera ID Character patterns……………………………………….……..17

Appendix-B…Factory Settings Chart……………………………………..………….…….18

Product Overview

1. Product Overview

By utilizing Digital Pixel SystemTM (DPS) sensor technology, the new EQ600WDII dramatically

improves the performance of surveillance camera in extreme lighting conditions. Where traditional

CCD cameras have difficulty processing images in strong backlighting, the EQ600WDII processes

each pixel independently, correcting for the variations and providing the best possible image under

the lighting conditions.

1.1Main Features

 1/3” Color DPS sensor

 High resolution: Over 480 TV Lines/1.0lux and low speed shutter up to 32x

 Day/Night function

 OSD function control

 With programmable camera ID up to 12 characters

 Compact stylish design for discrete observation

 Free S/W for remote configuration through RS232 via PC

 Image flip: Horizontal reverse

1.2Content List

 1/3” W-Dynamic High Resolution Color Camera unit

 User’s manual

 Mini Din male connector cable for S-Video / RS-232

Specifications

1.3 Specifications

Pickup Device 1/3” Color DPS sensor

Picture Element 720(H) ×540(V)

Horizontal Resolution >480 TV lines

Sensitivity 1.0 Lux/ F=1.2 (50IRE color)

Low Speed shutter Up to 32x(2,4,8,16,32)

S/N Ratio >48dB

Auto exposure: YES

Auto White Balance Yes, 2500K ~9500K

Back light compensation YES

Auto IRIS YES

Video Outputs 1.0Vp-p composite S-Video(Y/C output)

Auto Gain Control Yes

Day/Night function ON/OFF

Dynamic range 95dB typical, 120dB max

Synchronization Internal or Line Lock (AC input required)

Image Flip Yes, Horizontal reverse

Video Output: 1 Vp-p / 75 ohm composite, S-Video (Y/C output)

Imaging System NTSC/ PAL

On Screen Display Yes

Power Source AC24V / DC12V

Operating Temperature 0℃

℃℃

℃~ 40℃

℃℃

℃

Power Consumption 7W max.

Dimensions (mm) 56 (W) x 68 (H) x101 (D)

Lens mount C/CS mount, DD Drive

Back Panel Connections

2. Back panel connections

(1)S-Video / RS-232 port:

Connect Mini Din Male Connector to S-Video / RS-232 port for better video output quality or

communication. Please refer to the pin assignment of the S-Video/ RS-232 port as below:

(2)AC24V/DC12V Compatible Input Terminal:

This power terminal is for connecting theAC24V/DC12V power supply cord

(3)Video Output Connector: Connect the video output of the camera to a color monitor or other

video devices through a 75 Ohm type coaxial cable with BNC female connector at backside of

the camera.

(4) Tact switcher for left cursor

(5) Tact switcher for down cursor

(6) Tact switcher for right cursor

(7) Tact switcher for up cursor

(8) Tact switcher for on-screen setting menu

(9) Auto Iris Lens Connector

This connector is used to connect with the auto iris lens by a 4 pin male connector

Pin 1 Pin 2 Pin 3 Pin 4

Video Drive +12V GND VD-IRIS GND

DirectDrive Cnt- Cnt+ Drv+ Drv-

(4)

(1)

(2)

(3)

(5)

(6)

(7)

(8)

Y GND

GND

C GND

(9)

Operation

3.Camera Setup Operations

This camera utilizes an On Screen Display (OSD) user setup menu.

3.1 Setup Buttons: To set items on the user setup menu, use the following buttons on the back

panel.

①

①①

①

Up Button: This button is used to move the cursor upwards. Use this button to select an

item or adjust the parameters.

②

②②

②

Down Button: This button is used to move the cursor downwards. Use this button to select

an item or adjust the parameters.

③

③③

③

Right Button: This button is used to move the cursor to the right. Use this button to select

or adjust the parameters of the select item. The parameter changes each

time as this button is pressed.

④

④④

④

Left Button: This button is used to move the cursor to the left. Use this button to select or

adjust the parameters of the select item. The parameter changes each time

as this button is pressed.

⑤

⑤⑤

⑤

Set Button: This button is used to set the determined parameters. If the item has its own

setting menu, press this button to display the setting menu.

①

①①

①Up Button

③

③③

③Right Button

②

②②

②Down Button

④

④④

④Left Button

⑤

⑤⑤

⑤Set Button

Operation

3.2 Display/Close the user setup menu screen

I. Press the SET button for 2 second

The menu screen will appear on the monitor as the block shown above.

II. Using the cursor button

Use the cursor button or to move the cursor up or down. Use the cursor button or

to adjust the mode or parameter of settings. The select item will be highlighted with a

gray color bar.

III. Switch to sub-menu screens

When the item with sub-menu is selected (highlighted), press the SET button to switch to

the sub-menu for further settings. Please refer to the figure below.

Note: For those select items with “…” sign in the end, they have the sub-menu for further

settings.

IV. Return to previous page

After setting, use the cursor buttons to select PREVIOUS PAGE, then press the SET

button.

V. Close the menu screen

To close the menu screen, use the cursor button to select EXIT MENU and press the

SET button. Or press the SET button for 1 sec.

SET

Butto

The Cursor Buttons & the SET Button

Sub-Menu

Main Menu

EWD600 MAIN MENU

PRESET MODE INDOOR…

CAMERAID OFF

> ADVANCED SETUP…

SAVE/RESTORE…

EXIT MENU

EWD600 MAIN MENU

> PRESETMODE INDOOR…

CAMERAID OFF

ADVANCED SETUP …

SAVE/RESTORE…

EXIT MENU

ADVANCED SETUP

> AUTO IRIS…

WHITE BALANCE…

LINELOCK…

VIEWING…

Highlighted

MENU Flow

4. MAIN MENU FLOW

ADVANCED SETUP

> AUTO IRIS…

WHITE BALANCE…

LINELOCK…

VIEWING…

EWD600 MAIN MENU

>PRESET MODE… <INDOOR…>

<OUTDOOR…>

<FLUOR. ….>

<BACKLIGHT…>

<USER…>

EWD600 MAIN MENU

>CAMERA ID… < OFF>

<ON…>

SAVE/RESTORE

> RESTORE USER SETTINGS..

SAVE USER SETTINGS..

RESTORE FACTORY SETTINGS..

RESET CAMERA..

MENUREV. 0.1

PREVIOUS PAGE…

EWD600 MAIN MENU

>PRESETMODE INDOOR…

CAMERAID OFF

ADVANCED SETUP…

SAVE/RESTORE…

EXIT MENU

5. PRESET MODE

I. Select the suitable settings, such as

INDOOR, OUTDOOR, FLUOR. or

BACKLIGHT based on the installation

environment.

II. Press the SET button to enter USER

SETUP menu for adjusting the

parameters.

III. The parameters will be stored as USER

automatically after changed.

5.1 USER SETUP Menu Flow

USERSETUP

>CAMERAVIEW SHADOW

SLOW SHUTTER OFF

WDRMODE AUTO…

METER MODE NORMAL…

USERSETUP

>CAMERA VIEW <SHADOW>

USERSETUP

>SLOW SHUTTER <OFF>

<ON>

AUTO DYNAMIC RANGE

>BIAS +++++++++

–36 6 36

LIMIT +++++++++

0 24 36

PREVIOUS PAGE…

NORMAL METER PRESETS

>PRESETS <FULLSCREEN..>

<USER…>

PREVIOUS PAGE…

EWD600 MAIN MENU

>PRESET MODE <INDOOR…>

<OUTDOOR…>

<FLUOR. ….>

<BACKLIGHT…>

<USER…>

MANUAL DYNAMIC RANGE

>RANGE +++++++++

0 24 36

PREVIOUS PAGE…

USERSETUP

>WDR MODE <AUTO…>

<MANUAL…>

USERSETUP

>METER MODE <NORMAL…>

<BACKLIGHT…>

BACKLIGHT METER PRESETS

>PRESETS <FULLSCREEN..>

<USER…>

<USERBL-ZONE ADJUST>

PREVIOUS PAGE…

SLOW SHUTTER SETUP

>SHUTTERLIMIT 8X

SS PROTERTY COLOR

B/W

SS THRESHOLD +++++++++

0 28 42

Andere Handbücher für WDII EQ600

Inhaltsverzeichnis

Andere EverFocus Sicherheitskamera Handbücher

EverFocus

EverFocus EQ150 Bedienungsanleitung

EverFocus

EverFocus EZ930 eZ.HD Series Bedienungsanleitung

EverFocus

EverFocus EPTZ3150 Bedienungsanleitung

EverFocus

EverFocus EZN Series Bedienungsanleitung

EverFocus

EverFocus ED100 Series Bedienungsanleitung

EverFocus

EverFocus EZ-PLATECAM-002 Bedienungsanleitung

EverFocus

EverFocus EZ610 Montageanleitung

EverFocus

EverFocus EHH5241 Betriebsanleitung

EverFocus

EverFocus EQ200E Bedienungsanleitung

EverFocus

EverFocus POLESTAR EHN7260 Bedienungsanleitung

EverFocus

EverFocus NeVio EAN900 Bedienungsanleitung

EverFocus

EverFocus EDN3340 Bedienungsanleitung

EverFocus

EverFocus EPD200A Bedienungsanleitung

EverFocus

EverFocus 630 TVL Bedienungsanleitung

EverFocus

EverFocus EMN Series Bedienungsanleitung

EverFocus

EverFocus EDH5102 Bedienungsanleitung

EverFocus

EverFocus ED700W Bedienungsanleitung

EverFocus

EverFocus EFD300A Bedienungsanleitung

EverFocus

EverFocus EDH5240 Bedienungsanleitung

EverFocus

EverFocus True Day/Night Bedienungsanleitung

EverFocus

EverFocus Speed Dome EPTZ1000 Bedienungsanleitung

EverFocus

EverFocus EHD930F eZ.HD Series Bedienungsanleitung

EverFocus

EverFocus Speed Dome EPTZ1000 Bedienungsanleitung

EverFocus

EverFocus H.265 VANGUARD II Series Bedienungsanleitung

Beliebte Sicherheitskamera Handbücher anderer Marken

Okina USA

Okina USA SIR36-870VF650LP Bedienungsanleitung

Divio

Divio NDR155PA Bedienungsanleitung

Canon

Canon VB-C500D Bedienungsanleitung

Easy Access

Easy Access EasyGuard Bedienungsanleitung

Vivotek

Vivotek FD9389-EHV-v2 Bedienungsanleitung

TUYA

TUYA COSMO W2 Bedienungsanleitung

Eusso

Eusso UNC7500-IR Einrichtungshandbuch

urmet domus

urmet domus 1096/204 Bedienungsanleitung

VC VC20 series Bedienungsanleitung

Axis

Axis Q1614 Bedienungsanleitung

ieGeek

ieGeek DD201 Bedienungsanleitung

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Bedienungsanleitung

Vicon

Vicon V662-D-1 Betriebsanleitung

Grundig

Grundig GCH-K0274P Bedienungsanleitung

Lorex

Lorex VANTAGE LBC7032 Bedienungsanleitung

4xem

4xem WPT Bedienungsanleitung

Samsung

Samsung SCV-3082 Bedienungsanleitung

Vitek

Vitek VTC-C544 Bedienungsanleitung
