Festool CTC SYS I Bedienungsanleitung

en Original Instructions - Cordless mobile dust extractor 6

Read all instructions before using

CTC SYS I

Festool GmbH

Wertstraße 20

73240 Wendlingen

Germany

www.festoolusa.com

10418891_A / 2021-03-16

1-1

1-2

1-3

1-5

1-4

1-6

1-7

1-8

1-9

1-10

1-11

1-12

1-13

1-14

1-15

1-16

1-17 1-18

1-19

1-20

click

145°

45°

6-2

6-1

Contents

1 Symbols.......................................................6

2 About this manual....................................... 6

3 Safety warnings...........................................7

4 Intended use..............................................11

5 Technical data........................................... 11

6 Functional Description..............................12

7 Preparations..............................................12

8 Battery pack.............................................. 12

9 Commissioning..........................................12

10 Connecting a device.................................. 13

11 Settings......................................................13

12 Working..................................................... 14

13 Remote control..........................................15

14 Warning signals.........................................15

15 Service and maintenance..........................16

16 Transportation...........................................16

17 Environment.............................................. 17

18 General information..................................17

1 Symbols

Warning of general danger

Warning of electric shock

Read the operating manual and safety

warnings.

Read the operating instructions and

safety instructions.

Wear a dust mask.

WARNING! The machine may contain

hazardous dust!

Do not climb on the unit

Do not absorb any water or liquids!

Do not leave in the rain!

Risk of tilting!

Inserting the battery pack

Removing the battery pack

Tip or advice

Handling instruction

Do not dispose of it with domestic

waste.

Tool contains a chip which stores data.

See section 18.2

W watt

h hour

min minutes

s seconds

kg kilograms

Pa pascal

dB decibel

V volts

A amperes

Hz hertz

~ a.c. alternating current

d.c. direct current

n0no load speed

Class II construction

rpm

min-1 revolutions per minute

’’ inch

lbs. pound

diameter

2 About this manual

Save these instructions

It is important for you to read and understand

this manual. The information it contains relates

to protecting your safety and preventing prob

lems. The symbols below are used to help you

recognize this information.

English

DANGER Description of imminent hazard and failure to avoid hazard will result in death.

WARNING Description of hazard and possible resulting injures or death.

CAUTION Description of hazard and possible resulting injuries.

NOTICE Statement including nature of hazard and possible result.

HINT Indicates information, notes, or tips for improving your success using the tool.

3 Safety warnings

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basis precautions should always be

followed, including the following:

READ ALL INSTRUCTIONS

BEFORE USING THIS DUST EXTRACTOR:

WARNING - To reduce the risk of fire, electric shock, or in

jury:

– Disconnect battery pack before cleaning or servicing.

– Use indoors only.

– Do not allow to be used as a toy. Close attention is necessary when used

by or near children.

– Use only as describes in this manual. Use only manufacturer's recom

mended attachments.

– If the dust extractor is not working as it should, has been dropped, dam

aged, left outdoors, or dropped into water, return it to a service center.

– Do not handle dust extractor with wet hands.

– Do not put any object into openings. Do not use with any opening

blocked; keep free of dust, lint, hair, and anything that may reduce air

flow.

– Keep hair, loose clothing, fingers, and all parts of body away from open

ings and moving parts.

– Use extra care when cleaning on stairs.

– Do not use to pick up flammable or combustible liquids, such as gaso

line, or use in areas where they may be present.

– Do not pick up anything that is burning or smoking, such as cigarettes,

matches, or hot ashes, hot chips or particles, sparks.

– Do not use without dust bag and/or filters in place.

English

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

Further safety instructions

– This appliance must not be used by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience

and knowledge. Children need to be supervised to ensure they do not

play with the device.

– This machine must not be used by people who might have a particularly

adverse reaction to an electric shock (e.g. people with cardiac pace

makers), because the possibility of the machine building up a static

charge cannot be excluded.

–Ensure you are on a firm base. The effects of a shock moment, e.g. due

to antistatic discharge, may lead to accidents.

–WARNING! Operators must be appropriately instructed in the

use of this machine.

–WARNING! This machine is only intended for use under dry

conditions.

–WARNING! Device may contain hazardous dust. Only have the

device maintained and emptied, and only have the filter replaced by an

authorised specialist using suitable protective equipment.

– Always operate with the filter system installed!

–Risk of explosion and fire: Do not extract:

– Sparks or hot dust;

– combustible or explosive materials (e.g. magnesium, aluminium, pet

rol, diluting agents);

– aggressive materials (e.g. acid, alkaline solutions, solvents);

– chemically reactive materials, which lead to the generation of heat,

acids/bases, gases, etc. (e.g. reactive two-component materials, alu

minium and water).

– Observe all national safety regulations as well as the material manufac

turer's specifications!

– WARNING!

Do not extract embers or other ignition sources. Do not use in conjunc

tion with machines that generate sparks!

Per NFPA 484, do not collect incompatible materials that may react with

the metal particles and do not use the dust extractor to collect materials it

English

was not designed to collect. Doing so can result in the contents of the dust

extractor catching fire.

– Always use suitable protective equipment!

– If intact following a visual inspection, work in a dry environment accord

ing to instructions!

– Check the battery interface and the filter regularly in order to prevent a

hazard. In the event of damage, the battery interface must be replaced

by an authorised service workshop only.

– Do not lift or transport the device using a crane hook or lifting gear.

– Only carry the machine using the handle, front handle or shoulder strap

provided.

– Risk of tilting, do not place on sloped areas!

–NOTE

This machine is only intended for indoor use.

This machine must only be stored indoors.

Follow the operating manual for the charger and the battery pack.

–Do not use power supply units or third-party battery packs to operate

cordless devices. Do not use third-party chargers to charge the bat

tery pack. The use of accessories not expressly authorised by the man

ufacturer can result in electric shocks and/or serious accidents.

–Keep the unused battery pack away from metal objects (e.g. nails,

screws, keys, paper clips, etc.) that could cause bridging of the con

tacts. A short circuit between the battery contacts can cause burns or

fire.

–Only use the battery pack in combination with your Festool device.

This is the only way to protect the battery pack from dangerous over

load. Use of another device can lead to injury and fire hazard.

–Do not use a battery pack or appliance that is damaged or modified.

Damaged or modified batteries may exhibit unpredictable behavior re

sulting in fire, explosion or risk of injury.

–Disconnect the battery pack from the appliance before making any ad

justments, changing accessories, or storing appliance. Such preven

tive safety measures reduce the risk of starting the appliance acciden

tally.

Health hazard by dust

WARNING!

various dust created by power sanding, sawing, grinding, drilling and other

construction activities contains chemicals known (to the State of California)

to cause cancer, birth defects or other reproductive harm. Some examples

of these chemicals are:

– lead from lead-based paints,

English

– crystalline silica from bricks and cement and other masonry products,

and

– arsenic and chromium from chemically treated lumber.

The risk from these exposures varies, depending on how often you do this

type of work. To reduce your exposure to these chemicals: work in a well

ventilated area, and work with approved safety equipment, such as dust

masks that are specially designed to filter out microscopic particles. Wash

hands after handling.

WARNING

TO REDUCE THE RISK OF INJURY, USER

MUST READ INSTRUCTION MANUAL.

English
