Fujitsu C150-E146-02EN Handbuch

C150-E146-02EN

M4097D Image Scanner

Operator's Guide

M4097D

Image Scanner

Operator's Guide

February, 2000 First edition

February Second edition

Revised contents

Specification No. C150-E146-02EN

Date publishedEdition

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential instal-

lation. This equipment generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the instruction manual, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC warning: Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate the equip-

ment.

NOTE

• The use of a non-shielded interface cable with the referenced device is prohibited.

The length of the parallel interface cable must be 3 meters (10 feet) or less. The

length of the serial interface cable must be 15 meters (50 feet) or less.

• The length of the power cord must be 3 meters (10 feet) or less.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conformme à la norme NMB-003 du

Canada.

As an ENERGYSTAR ® Partner, Fujitsu Limited has determined that this scanner

meets ENERGYSTAR® guidelines for energy efficiency. ENERGYSTAR® is a

U. S. registered mark.

The contents of this manual may be revised without prior notice.

Printed in Japan.

No part of this manual may be reproduced in any form without permission.

iii

FUJITSU FRANCE S.A.

I, Place des Etats-Unis, SILIC 310, 94588

Rungis cedex, FRANCE

TEL:33-1-4180-3880

FAX:33-1-4180-3866

http://www.fujitsu-europe.com/home/

FUJITSU COMPUTERS (SINGAPORE) PTE,

LTD.

20 Science Park Road #03-01, Tele Teck

Park Singapore Science Park II, Singapore

117674 Republic of Singapore

TEL:65-777-6577

FAX:65-771-5669

http://www.fujitsu-computers.com.sg/

FUJITSU HONG KONG Limited

10/F, Lincoln House, Taikoo Place, 979

King’s Road, Island East, Hong Kong

TEL:852-827-5780

FAX:852-827-4724

TLX:62667

http://www.fujitsu.com.hk/

FUJITSU ITALIA S.p.A.

Via Nazario Sauro, 38 20099 Sestos,

Giovanni (MI), ITALY

TEL:39-2-26294-1

FAX:39-2-26294-201

http://www.fujitsu-europe.com/home/

FUJITSU NORDIC AB

Kung Hans väg,S-192 68 Sollentuna,

SWEDEN

TEL:46-8-626-4500

FAX:46-8-626-4588

http://www.fujitsu-europe.com/home/

FUJITSU LIMITED

International Operations

Marunouchi 1-6-1, Chiyoda-ku,Tokyo 100

JAPAN

TEL:(81-3)3216-3211

FAX:(81-3)3213-7174

TLX:J2283

Cable:”FUJITSU LIMITED TOKYO”

http://www.fujitsu.co.jp/

FUJITSU COMPUTER PRODUCTS OF

AMERICA,INC.

2904 Orchard Parkway,San Jose.

California 95134-2022,U.S.A.

TEL:1-408-432-6333

FAX:1-408-432-3908

http://www.fcpa.com/

FUJITSU AUSTRALIA LIMITED

Fujitsu Hause 2 Julius Avenue North Ryde N.S.W

2113 AUSTRALIA

TEL:61-2-9776-4555

FAX:61-2-9776-4019

http://www.fujitsu.com.au/

FUJITSU CANADA,INC.

2800 Matheson Blvd.East,Mississauga.

Ontario L4W 4X5,CANADA

TEL:1-905-602-5454

FAX:1-905-602-5457

http://www.fujitsu.ca/

FUJITSU DEUTSCHLAND GmbH.

Frankfurter Ring 211,

8000 München 40,F.R,GERMANY

TEL:49-89-32378-0

FAX:49-89-32378-100

http://www.fujitsu.de/

FUJITSU ESPAÑA,S.A

Edificio torre Europa 5a

Paseo de la Castellana 95 Madrid 28046,SPAIN

TEL:34-1-581-8000

FAX:34-1-581-8300

http://www.fujitsu-europe.com/home/

FUJITSU EUROPE LTD.

2,Longwalk Road,Stockey Park,Uxbridge

Middlesex,UB11 1AB,U.K

TEL:44-81-573-4444

FAX:44-81-573-2643

http://www.fujitsu-europe.com/home/

Please send your comments on this manual or on Fujitsu products

to the following addresses:

IMPORTANT NOTE TO USERS

READ ALL OF THIS MANUAL CAREFULLY BEFORE USING THIS PRODUCT.

IF NOT USED CORRECTLY, UNEXPECTED INJURY MAY BE CAUSED TO

USERS OR BYSTANDERS.

While all efforts have been made to ensure the accuracy of all information in this

manual, FUJITSU assumes no liability to any party for any damage caused by

errors or omissions or by statements of any kind in this manual, its updates or

supplements, whether such errors are omissions or statements resulting from

negligence, accidents, or any other cause. FUJITSU further assumes no liability

arising from the application or use of any product or system described herein; nor

any liability for incidental or consequential damages arising from the use of this

manual. FUJITSU disclaims all warranties regarding the information contained

herein, whether expressed, implied, or statutory.

FUJITSU reserves the right to make changes to any products herein, to improve

reliability, function, or design, without further notice and without obligation.

Preface

This manual explains how to use the M4097D image scanner.

This manual contains chapters on the following topics:

COMPONENTS

INSTALLATION AND CONNECTIONS

OPERATING INSTRUCTIONS

ADF DOCUMENT SPECIFICATIONS

SCANNER SPECFICATIONS

SETUP MODE

It also contains a Glossary of Terms and an Index.

Refer to Cleaning and Maintenance Guide for information about the routine

operation of the M4097D.

The Reference Guide contains chapters on OPERATING INSTRUCTIONS,

CLEANING, REPLACEMENT OF PARTS, ADJUSTMENT and TROUBLE-

SHOOTING.

The M4097D is a very fast and highly functional image scanner developed

for volume filing, using charge-coupled device (CCD) image sensors. This

scanner features duplex scanning and high quality image processing with an

automatic document feeder (ADF).

Important information that requires special attention is indicated as follows:

WARNING

WARNING indicates that personal injury may result if you do not follow a

procedure correctly.

CAUTION

CAUTION indicates that damage to the scanner may result if you do not follow a

procedure correctly.

Indicates care required to avoid pinching of fingers or hands.

NOTICE/NOTE

A NOTICE provides “how-to” tips or suggestions to help you perform a procedure

correctly.

A NOTE is particulaly useful for first-time users.

Official Fujitsu part names are indicated with an initial capital letter, as in the part

name, “Pick roller.”

Conventions

vii

CONTENTS

vii

❑

CHAPTER 1 COMPONENTS

Checking the Components ........................................................ 1-1

Units and Assemblies ............................................................... 1-2

Operator Panel.......................................................................... 1-5

❑

CHAPTER 2 INSTALLATION AND CONNECTIONS

Precautions ............................................................................... 2-1

Inspection.................................................................................. 2-2

Repositioning the Shipping Lock ............................................... 2-4

Cable Connections .................................................................... 2-5

Mounting the Stacker ................................................................ 2-7

Setting the SCSI ID and the SCSI Terminator .......................... 2-8

❑

CHAPTER 3 OPERATING INSTRUCTION

Turning the Power On ............................................................... 3-1

Waking up the Scanner from the Low Power Mode .................. 3-2

Manual Feed Mode Setting ....................................................... 3-3

Loading Documents on the ADF ............................................... 3-4

Loading Documents on the Flatbed .......................................... 3-9

Loading Documents Larger than the Document Bed .............. 3-10

Reading a Page from a Thick Book ........................................ 3-11

❑

CHAPTER 4 ADF DOCUMENT SPECIFICATION

Document Size.......................................................................... 4-1

Document Quality ..................................................................... 4-2

ADF Document Feeder Capacity .............................................. 4-4

Areas not to be Perforated ........................................................ 4-5

Grounding Color Areas ............................................................. 4-6

Double Feed Detection Condition ............................................. 4-7

Job Separation Sheet ............................................................... 4-8

❑

CHAPTER 5 SCANNER SPECIFICATIONS

Basic Product Specification....................................................... 5-1

Installation Specification............................................................ 5-2

Dimensions ............................................................................... 5-3

viii

❑

CHAPTER 6 CONSUMABLES AND OPTIONS

Consumables ............................................................................ 6-1

Options...................................................................................... 6-2

Video Interface Option .............................................................. 6-3

IPC-4D Option........................................................................... 6-8

❑

CHAPTER 7 SETUP MODE

Activating the Setup Mode ........................................................ 7-1

Contents of the Setup Mode ..................................................... 7-2

❑

GLOSSARY OF TEAMS ............................................................................... GL-1

❑

INDEX.............................................................................................................. IN-1

❑

Declaration of Conformity

viii
