Fujitsu SCSI Scanner Installation Procedures

Windows NT 4.0

Rev051906A Page 1 of 9

If you are installing the following models by means of the SCSI interface then use this

document.

SP10C M3093GX\DG Fi-4530C Fi-5120C

SP15C M3096GX Fi-4640S Fi-5220C

SP600C M3097G\G+\DG M4097D Fi-5530C

SP620C M3099G\GX\GH Fi-4750C\L Fi-5650C

SP3091DC FI-4120C\C2 M4099D Fi-5750C

SP3092DC Fi-4220C\C2 Fi-4860C Fi-5900C

SP93GX Fi-4340C Fi-4990C

If you are going to use the USB interface of a dual SCSI/USB model then use the USB scanner

installation guide. For Scansnap models please use the Scansnap installation guide.

Hardware requirements.

You will need a PC system that meets our recommended specifications, an appropriate SCSI

controller, and a SCSI cable (six foot recommended maximum). For recommended PC system

specifications and SCSI controllers please reference the Scanner Hardware Reference page.

You may also need your Operating System Disk.

Step A: Installing the SCSI Host Adapter (Adaptec).

1. Shut down your PC and remove the case cover.

2. Locate a free PCI slot and remove the back plate if necessary.

3. Install the SCSI controller in an open PCI slot.

Make sure that the card is seated completely in the slot and secured in the frame

Warning! Failure to secure the SCSI controller in the PC can result in damage to the

SCSI card, scanner, and/or your system.

4. Boot your PC without the scanner attached.

Step B: Installing the SCSI drivers (Adaptec).

Although Windows NT has driver support for your host adapter it does not support plug and

play. Therefore the SCSI drivers will need to be loaded manually. Follow the instruction below

to install the driver for your host adapter.

Fujitsu SCSI Scanner Installation Procedures

Windows NT 4.0

Rev051906A Page 2 of 9

1. Login with administrator rights.

2. Go to Start, Control Panel, SCSI Adapters.

3. Then click on the Drivers tab and click ‘Add.’

4. Next select ‘Adaptec’ under Manufacturers

5. On the next menu scroll down again and double click on the line that reads –

‘AHA294x\AHA394x or AIC78xx PCI SCSI controller.’

Fujitsu SCSI Scanner Installation Procedures

Windows NT 4.0

Rev051906A Page 3 of 9

6. Insert your WinNT CD system disk and click OK.

7. When prompted to reboot, select no.

8. Then go to www.adaptec.com, and click on the “search” tab. Scroll down to the

“Enter key word or quoted phrase” box and type in “aspi32.exe.”

9. Next scroll down to the drivers section, click on “aspi32.exe” and follow the prompts

to download it to your desktop or a new folder.

10. Afterwards go to that location and double click on the "aspi32.exe" icon.

11. Follow the prompts and then reboot.

If there are no errors then shut down your system and go to the next step.

Special note: If you are using a different SCSI controller than what is shown in these examples

then select the “Have Disk” button, insert your driver CD into the CD Rom, and follow the

prompts.

Check the SCSI drivers

• Once the driver has been added, return to Control Panel

• Double-click on ‘Devices’

• Search for ‘aic78xx’ under Device

Ensure the aic78xx entry under Device displays ‘Started’ under Status and ‘Boot’ under Startup

as seen here. Ensure ‘Aspi32’ entry under Device displays ‘Started’ under Status and

‘Automatic’ under Startup as seen above.

Fujitsu SCSI Scanner Installation Procedures

Windows NT 4.0

Rev051906A Page 4 of 9

Next go to the NT diagnostics window and check for resource conflicts. The SCSI controller

listed as “aic78xx” should not be sharing its IRQ with any other devices in the system.

Step C: Installing the drivers from the Setup CD.

To begin it is recommended that you install the drivers first before connecting the scanner.

Installing the ASPI-Twain driver.

The STI-Twain drivers are not supported by Windows NT, consequently, you must install

the ASPI-Twain driver.

1. Insert the Scanner Setup CD into your CD Rom.

2. Next please complete the pre-registration box when it appears and click the submit

button.

3. Afterwards close your browser and click the Install Products button on the Scanner

Setup Menu.

4. On the next screen click on Twain Driver and you may be presented with the option

to install the Error Recovery Guide.

5. After you have installed the Error Recovery Guide (or not) follow the prompts to

complete the twain driver installation.

6. Do not reboot at this time!

Fujitsu SCSI Scanner Installation Procedures

Windows NT 4.0

Rev051906A Page 5 of 9

Installing the ISIS driver.

7. Next go back to the Scanner Setup Menu and click on ISIS Driver.

8. If you didn’t install the Error Recovery Guide during the Twain driver installation you

will be asked again. Proceed and follow the prompts to complete the ISIS driver

installation.

9. Do not reboot at this time!

Installing ScandAll 21.

10. Back to the Scanner Setup Menu and click on Software Utility - ScandAll 21.

11. The ScandAll 21 installation wizard will appear. Click next and follow the prompts to

complete the installation.

12. Once all of the above is completed then remove the Scanner Setup CD, Reboot

your system, and go to Step E.

Step D: Installing the drivers from our Web Page.

Installing the ASPI-Twain driver.

The STI-Twain drivers are not supported by Windows NT, consequently, you must install

the ASPI-Twain driver.

1. Create a new folder and name it Fujitsu Downloads.

2. Next go to the following link and click on Drivers and Downloads.

3. Fill in the pre-registration box when it pops up and continue to the drivers download

page.

4. Afterwards click on ASPI Twain Software Drivers.

5. Scroll down the list of scanner models in the left column and select the appropriate

ASPI Twain driver to the right of your scanner model.

6. Double click on the driver file name and the File Download box will popup.

7. Click on Save and then use the browse (or other folder navigation) button until you

have the Twain Download folder you created in the Save As box.

8. Click Save.

9. When completed close the Download Complete window and go to the Twain

Download folder.

10. Open the folder and you will see the saved driver file. Double click on the file to

unzip it and the WinZip* self-extractor box will popup. Click on browse and select the

Fujitsu Downloads folder, then click on Extract. The file will begin to unzip and

when finished a message box will report the number of files unzipped. Click on OK

and close WinZip.

11. In the ASPI Twain Download folder locate the setup.exe file and double click.

Afterwards follow the prompts and reboot when finished

Fujitsu SCSI Scanner Installation Procedures

Windows NT 4.0

Rev051906A Page 6 of 9

Installing the ISIS driver.

1. Create a new folder and name it Fujitsu Downloads.

2. Next go to the following link and click on Drivers and Downloads.

3. Fill in the pre-registration box when it pops up and continue to the drivers download

page.

4. Afterwards click on ISIS Software Drivers.

5. Scroll down the list of scanner models in the left column and select the appropriate

ISIS driver to the right of your scanner model.

6. Double click on the driver file name and the File Download box will popup.

7. Click on Save and then use the browse (or other folder navigation) button until you

have the ISIS Download folder you created in the Save As box.

8. Click Save.

9. When completed close the Download Complete window and go to the ISIS

Download folder.

10. Open the folder and you will see the saved ISIS driver file. Double click on the file to

unzip it and the WinZip* self-extractor box will popup. Note and accept the default

folder it is creating then click on Extract. The file will begin to unzip and when

finished a message box will report the number of files unzipped. Click on OK and

close WinZip.

11. In the new ISIS folder that you noted earlier locate the setup.exe file and double

click. Afterwards follow the prompts and reboot when finished.

Installing ScandAll 21.

1. Create a new folder and name it Fujitsu Downloads.

2. Next go to the following link and click on Drivers and Downloads.

3. Fill in the pre-registration box when it pops up and continue to the drivers download

page.

4. Afterwards click on Software Utilities.

5. Double click on the file name and the File Download box will popup.

6. Click on Save and then use the browse (or other folder navigation) button until you

have the Scandall Download folder you created in the Save In Box.

7. Click Save.

8. When completed close the Download Complete window and go to the Scandall

Download folder.

9. Open the folder and you will see the saved Scandall file. Double click on the file to

unzip it and the WinZip* self-extractor box will popup. Click on browse and select the

Scandall Download folder, then click on Extract. The file will begin to unzip and

when finished a message box will report the number of files unzipped. Click on OK

and close WinZip.

10. In the Scandall Download folder locate the Scandall.exe file and double click.

Afterwards follow the prompts and when completed go to Step E.

Fujitsu SCSI Scanner Installation Procedures

Windows NT 4.0

Rev051906A Page 7 of 9

Step E: Unlocking the shipping lock.

If your model scanner does not have a flatbed then proceed to Step F.

The flatbed model scanners typically include a lock on the flatbed designed to protect

the scanner during shipment. Before the scanner can be used the shipping lock must be

unlocked. To unlock it do the following:

1. Located the shipping lock slider tab or knob underneath the end of the scanner.

2. Slide or rotate the lock to the unlock position.

If your model has the old style “L” bracket shipping lock.

3. Slide the scanner to its side as shown in figure below.

4. Unscrew the retainer screw and remove the shipping bracket.

5. Place the shipping bracket in the “use position” slot and secure it with the retainer

screw (see figure below).

6. Place scanner back in its normal position.

Fujitsu SCSI Scanner Installation Procedures

Windows NT 4.0

Rev051906A Page 8 of 9

Step F: Connecting the Scanner.

Warning! Before proceeding ensure that the power is off when connecting or disconnecting the

SCSI cable to the scanner or workstation. Failure to follow the procedure above could result in

damage to the SCSI card, scanner, and/or your system.

The default SCSI ID setting for the 5000/4000 series scanners is 5 and for the 3000

series scanners is 6. However, selecting a different SCSI ID may be required when

there are several devices on a SCSI chain. Changing the SCSI ID will vary depending on

the model that you have. On some models you change the SCSI ID by accessing the

scanner’s Setup Menu through the front panel. On other models you physically change

the SCSI ID selector on the back of the unit. Please consult your user manual for which

method to use with your model. Setting the SCSI ID to 0, 1, or 7 is NOT recommended

as these settings are typically reserved for hard drives and the SCSI host adapter.

Next if the scanner is the last device (only device) on the SCSI chain then it must be

terminated. If the scanner is not the last device on the SCSI chain, then the terminator

should be removed or turned off before connecting it to the next SCSI device. Many

models of our scanners have automatic termination built in. Some of our older models

will require a plug in terminator (see figure below). Please consult your user manual for

which method to use with your model.

Typically the SCSI ports are located on the back of the scanner (the one exception being

the Fi-5650C which is on the front). Depending on the model the SCSI port connector(s)

may be any one of the following:

A. DB25 Pin

B. 50-pin Centronics

C. 50-pin High Density (HD-50) or

D. 68-pin Wide SCSI.

Fujitsu SCSI Scanner Installation Procedures

Windows NT 4.0

Rev051906A Page 9 of 9

Use the appropriate cable to connect the scanner to the SCSI controller in your PC and

ensure that all connections are securely fastened. To identify the type of connector for

your model please consult the user manual or refer to the Scanner Hardware Interface

Specifications Web page.

Finally connect the power cord to the scanner and a wall outlet then turn on the scanner.

For those models without a power switch plug in the power supply to the back of the

scanner. To establish communication between the Scanner and your PC system turn on

the scanner prior to turning on your system. The scanner power and LED/LCD display

will light up. Next after the scanner completes its startup initialization the LED/LCD will

display either ready or the number one. This indicates that the scanner is ready.

Step G: Scanning with ScandAll 21.

1. Launch ScandAll 21 by clicking on the shortcut link on your desktop or manually by

clicking on Start, Programs, Scanner Utility for Microsoft Windows, then

ScandAll 21.

2. After the Untitled Screen has open, click on Scan and choose Select Source.

3. Select the Fujitsu Twain source for your scanner by Highlighting it and clicking

OK. You will only need to do this once unless you are scanning with multiple

sources.

4. Once you are back at the Untitled Screen click on Scan and select To View this

time. The Twain User Interface will popup.

5. Select the scanning parameters that you wish to use – Color mode, resolution,

paper size, etc…

6. Next under Scan Type choose either ADF or Flatbed in the dropdown box.

7. Place your document in the ADF or on the Flatbed face down and click on the Scan

button.

8. After the document is scanned close the Twain User Interface and the image will

appear on the Untitled Screen.

Congratulations! You have successfully completed and tested your scanner installation.

Step H: Installing third party software applications.

After you have successfully installed all the Fujitsu software and hardware, then it is time

to install any additional third party scanning software that you wish to use. Please follow

the software manufacturer’s instructions for installation.

*If you do not have any unzipping software installed on your system, you can download a free

evaluation copy at www.winzip.com.

Andere Handbücher für FI-4120C

Dieses Handbuch passt für folgende Modelle

Andere Fujitsu Scanner Handbücher

Fujitsu

Fujitsu fi-600F Handbuch

Fujitsu

Fujitsu ScanSnap N1800 Bedienungsanleitung

Fujitsu

Fujitsu fi-8190 Bedienungsanleitung

Fujitsu

Fujitsu M4099D Bedienungsanleitung

Fujitsu

Fujitsu fi-7140 Bedienungsanleitung

Fujitsu

Fujitsu PA03338-B005 - FI-5750C Image Scanner Bedienungsanleitung

Fujitsu

Fujitsu M3099A Handbuch

Fujitsu

Fujitsu S510 - ScanSnap - Document Scanner Bedienungsanleitung

Fujitsu

Fujitsu FI 6140 - Document Scanner Handbuch

Fujitsu

Fujitsu fi-6800 Konfigurationshandbuch

Fujitsu

Fujitsu S500M - ScanSnap - Document Scanner Handbuch

Fujitsu

Fujitsu ScanPartner 620C Bedienungsanleitung

Fujitsu

Fujitsu ScanSnap Organizer Bedienungsanleitung

Fujitsu

Fujitsu ScanSnap N1800 Bedienungsanleitung

Fujitsu

Fujitsu ScanSnap iX100 Montageanleitung

Fujitsu

Fujitsu fi-4340C Konfigurationshandbuch

Fujitsu

Fujitsu M3092DC Bedienungsanleitung

Fujitsu

Fujitsu ScanPartner Jr. C Betriebsanleitung

Fujitsu

Fujitsu S510 - ScanSnap - Document Scanner Handbuch

Fujitsu

Fujitsu ScanSnap iScanner fi-6010N Konfigurationshandbuch

Fujitsu

Fujitsu fi-6400 Bedienungsanleitung

Fujitsu

Fujitsu ScanSnap N1800 Handbuch

Fujitsu

Fujitsu FI-4120C Bedienungsanleitung

Fujitsu

Fujitsu ScanSnap S1300i Bedienungsanleitung

Beliebte Scanner Handbücher anderer Marken

Plustek

Plustek Scanner Bedienungsanleitung

Z/I Imaging

Z/I Imaging PhotoScan 2001 Bedienungsanleitung

Renkforce

Renkforce DS100-5M Bedienungsanleitung

Image Access

Image Access WideTEK A2 Bedienungsanleitung

Canon

Canon imageFORMULA CR-120N Bedienungsanleitung

GeoSlam

GeoSlam ZEB Horizon Montageanleitung

Kodak

Kodak i5800 Scanner Bedienungsanleitung

Kodak

Kodak i7300 Bedienungsanleitung

Revopoint

Revopoint POP Bedienungsanleitung

Eddyfi Technologies

Eddyfi Technologies Floormap X Bedienungsanleitung

Faselase

Faselase F6 Bedienungsanleitung

Uniden

Uniden BC340CRS Bedienungsanleitung

Infinite Peripherals

Infinite Peripherals INFINEA TAB M Bedienungsanleitung

Mustek

Mustek PageExpress 4800 Pro Bedienungsanleitung

Optex

Optex 750830 Bedienungsanleitung

Innova

Innova 5210 Bedienungsanleitung

Visioneer

Visioneer CardReader 100 Kurzanleitung

Rohde & Schwarz

Rohde & Schwarz TSME6 Bedienungsanleitung
